Redsail Laser RS3040A Mini Laser Engraving Machine User Manual Redsail Tech Co., Ltd http://www.hflaser.com... - Page 2 Redsail Laser Thank you very much for buying RS3040A laser engraving machine. In order to make sure that your laser engraving machine can work steadily for a long period of time, please read this manual carefully, be familiar with and master the operation method and technological requirements of the machine in advance.
-
Page 3: Table Of Contents
Redsail Laser Contents 1. Function of RS3040A laser engraving machine 2. Installation of RS3040A laser engraving machine 3. Structure and adjusting method of ray path 4. Basic operation procedure 5. Safety cautions and maintenance 6. Problems and solutions 7. Regulations of repair guarantee Redsail Tech Co., Ltd... -
Page 4: Installation Of Rs3040A Laser Engraving Machine
(cutting) of aviation and navigation models, laser engraving (cutting) of cartoon figures, industrial model laser engraving (cutting), etc. II Installation of RS3040A laser engraving machine Dismount of the packing box After opening the packing box, please check out whether there is any damage on laser tube or not. - Page 5 (There are two pipes at the back of the RS3040A, they connect with laser tube to supply water cooling), 10-20 seconds later, water comes out from right tube. Let the water circulate in the water tank.
-
Page 6: Structure And Adjusting Method Of Ray Path
5) Connect the blower fan with power supply and place it at right position, and then start the machine. 6) Test the laser and adjust the mirror as following steps: III Structure and adjusting method of ray path 1. Structure of the ray path Redsail Tech Co., Ltd http://www.hflaser.com... - Page 7 7. Working platform up and down control screw 2. Structure of the optical components Ray path is ray guide system. RS3040A has adopted flying-optical system. The complete system is made up of laser tube; four reflect mirrors; focus lens and relevant adjusting devices.
- Page 8 Move the laser head to the anywhere, Press “test” button to make a dot. Then move it to another position, make another dot. Make these two dots totally matched together. Redsail Tech Co., Ltd http://www.hflaser.com...
- Page 9 Redsail Laser reflect mirror reflect mirror reflect mirror reflect mirror Adjust the work plate BECAREFUL OF THE LASER BEAN WHEN ADJUSTING. ESPECIALLY NEVER LET THE LASER GOES INTO YOUR EYES!! Redsail Tech Co., Ltd http://www.hflaser.com...
-
Page 10: Basic Operation Procedure
Cleaning of mirrors and lens should be done once a week. It is required that the grounding of all parts of the machine and user's computer should be safe to avoid damage of machine and injuries caused by Redsail Tech Co., Ltd http://www.hflaser.com... - Page 11 It is suggested to use pure water. The minimum amount of cooling water should be 10L. Make sure that the water can submerge the submersible pump. Redsail Tech Co., Ltd http://www.hflaser.com...
- Page 12 10) Guide rails should be cleaned, and lubricant should be added onto the rail every two weeks. 11) The outer equipments (blower fan, air pump, etc.) should be cleaned once every two weeks. Redsail Tech Co., Ltd http://www.hflaser.com...
-
Page 13: Problems And Solutions
Redsail Tech Co., Ltd http://www.hflaser.com... - Page 14 7. This certificate will be valid only after being stamped by distributor. It will be invalid if altered. Redsail Tech Co., Ltd http://www.hflaser.com...
