Redsail CM-Series Manual

Laser engraving & cutting
Hide thumbs
Table of Contents

Advertisement

Quick Links

CM-Series Laser Engraving
&Cutting
Readsail Tech Co.,Ltd

Advertisement

Table of Contents
loading

Related Manuals for Redsail CM-Series

Summary of Contents for Redsail CM-Series

  • Page 1 CM-Series Laser Engraving &Cutting Readsail Tech Co.,Ltd...
  • Page 2 This type of Laser Cutting Machine is GB4 series Laser Product .Please note laser radiation when use it. Avoid your eyes or skin get direct or scattering radiation!

  • Page 3: Table Of Contents

    Catalog Prolog.......................1 Matters need attention：................2 Chapter 1 Safety Directions 1·1 Machinery Safety 1·1·1 General Safety Rules ................3 1·1·2 General Safety Items ................3 1.1.3 Machine hanging and Transport Safety ............3 1.1.4 Electrical Safety ................4 1.1.5 Mechanical Safety ................4 1.2 Safety Signs ..................5 1.3 Warning Signs ..................8 Chapter 2 Summary 2.1 character....................9...

  • Page 4: Prolog

    Prolog Thank you for choosing Redsail Products ! This use manual provides the users with Machine’s Safety, installation ,operation and daily maintenance of the relevant considerations and guidance. For your safety，proper use the product，be sure to read this manual carefully before operation，...

  • Page 5: Matters Need Attention

    Matters need attention All of the products will be full tested before delivery. Considering transportation and other reasons, please confirm the following points:  During transport, device is deformed or damage, please dont use if the device is damaged to avoid the hurt from danger, please inform our company or local agent in time for such condition.

  • Page 6: Chapter 1 Safety Directions

    Chapter 1 Safety Directions 1.1 Machinery Safety 1.1.1 General Safety Rules (1) Know your machine For your personal safety ， read this manual and CNC system manual carefully, Know applications and limitations of the machine,and potential danger related to the machine, make the operation according to the manual direction.

  • Page 7: 1·1·2 General Safety Items

    (10) Must be close the machine power when repair, replace the parts or assembly and reassemble the motor. (11) Dont make the machine running when nobody 1.1.2 General Safety Items Please read this manual and CNC system manual carefully before operation, make the operation according to according to the User Manual directions.

  • Page 8: Electrical Safety

    Attention Items When machine lifting and handling, please note whether there is an barrier or person around the machine, please clean the barrier and let people leave before hanging. To avoid the collision and danger. When machine is lifting and handling, control the speed not too fast, should forbid the urgent brake, in order to avoid the machine shaking to lose balance and fall down.

  • Page 9: Mechanical Safety

    1.1.5 Mechanical Safety After unpacking, firstly you must check the equipment is intact after long transportation. Turn on the machine when the first time or when stopping using for a long time, please check if there is interfere in all axis, then lubricate the machine fully before you run the machine.
  • Page 10 Safety Attention: This section is direction for the important iterms that the user must abey, such as receipt confirmation, storage, handling, installation, wiring, operation, inspection, liquid waste disposal, etc. Danger Please supply the power for the machine according to the mentioned voltage, frequency in this manual.
  • Page 11 the personal injury . Settings, checking, fault diagnosis and troubleshooting should be done by qualified person. Otherwise will cause the fire, electric shock or injury. Please don ’ t damage or pulling electric cable vigorously, don ’ t make too big pulling force to the cable, don’t embed the fixture in the cables.
  • Page 12  Water, oil and medicines and chemical reagents may drip  Vibration or impact can be transmitted to machine. ■Installation Attention Note This machine is the precise product , please avoid the strong impact. Otherwise will cause the malfunction. Please don’t thead on the product or place the heavy objects on it. Otherwise will damage the machine.
  • Page 13 of machine will descend if power is turned on / off frequently. ■ Running Attention Note When running, must turn off the power immediately for any abnormal situation. Otherwise will damage the machine. Operator must be qualified. Otherwise will damage the machine or make the personal injury.

  • Page 14: Warning Signs

    General Attention Items ■ Please note when operating Redsail have no responsibility for any damage and loss made by unauthorized modification for the machine. Corrosive liquid is forbidden for lead rail and working table when cleaning the machine. Prepare two units portable - type dry powder fire extinguisher to avoid the accident.

  • Page 15: Chapter 2 Summary

    Chapter 2 Summary CM series Laser Engraving and Cutting Machine is equipped with high performance three-phase motors and three-phase stepper driver,with high speed cutting and high running accuracy; Also equipped with imported dual rail, make sure the cutting more smooth and running more stable. 2.1 character: ...

  • Page 16: Chapter 3 Machine Installation And Directions

    Chapter 3 Machine Installation and Directions 3.1 Laser Tube Installation 1·Mirror Holder 2·Water outlet 3Cathode- 4·Water in 5·Anode+ 6·Tube holder 7·Laser out Please refer to the above Figure when you install the laser tube. According to Figure, solder the anode wire (pink /thick line), the cathode wire (black/ blue line) in the correct location of laser tube.(While soldering, please don’t keep the electric soldering iron touching the welding point in so long a time in case it burn out the laser tube), poor soldering is not allowed.

  • Page 17: Connection Of Water Pipe, Air Pipe, Air Pump And Water Cooler

    3.2 Connection of water pipe, air pipe, air pump and water cooler Back of device Note: 1：water inlet 2：water outlet 3：air pipe 4：Air plug（signal input） 5：water outlet（water chiller） 6：water inlet(water chiller) 7 air pump outlet 8：Air plug（signal output） 9： power input 220V 10：water inlet（water chiller） 11：water outlet connection：...

  • Page 18: Ventilator And Ventiduct Connection

    Function of Water Chiller: Before machine working, please do make sure there is full of recycled water in the laser tube, otherwise, it will damage the laser tube and can not be repaired. Please do keep the water clean before you put it in the water cooler, dirty water will have bad effect on the laser, and decrease the life of laser tube (Pure water is recommended).

  • Page 19: Power Supply Input/Output Directions

    (2) Following the above figure shows，put the ventiduct 5 respectively connected with 4 air exhaust fan air inlet and 6 machine’s air outlet, and for a reasonable fixed，to improve the machine exhaust efficiency. 3.4 Power Supply Input/Output Directions 1·Ground Wire Terminal 2·AC220V Main power switch 3·AC220V Power output socket, supply the power for air pmup, water chiller.
  • Page 20 1 · USB cable interface:connect the computer and control board of machine for data transmission. 2·U disk interface: Use U disk to transmit the data to the control board. 3·Cover protection switch : control device to open and close the cover , the device processing and pause function.

  • Page 21: Usb Data Wire Connection

    3.6 USB data wire connection Please connect the two ends of the USB Cable (which came along with the machine) with the USB port of control board in the machine and computer. Below Figure: 1·Device USB port 2·USB cable 3·Computer USB port This system supports offline work, here is the way: By downloading the parameters of the file in the software to the USB flash memory, then plug the USB flash memory into the USB port of the equipment.

  • Page 22: Chapter 4 Adjustment Of Optical Path

    1 · Emergency stop switch: Control the power on/off for the main part, such as switch power supply, laser power supply and so on. 2·Main power switch: Control the main power on/off. 3·Control system panel(refer control system instrument for more information). Chapter 4 Adjustment of Optical Path After connecting all accessories of the machine, please switch on the power of water cooler (in front of water cooler), when the water inside the laser tube...
  • Page 23 Steps: The first step: Regulate test power to below 50%, to keep the power not too high. The second step: Optical path adjustment between laser rube and the first reflecting mirror. Put the test paper (paper self-adhesive tape) in front of the first reflecting mirror, then press “Pulse/Run ”button slightly(loose immediately after pressing slightly, only you can see the spot on the test paper), then check whether there is a spot in the center of the first reflecting mirror.
  • Page 24 other. If the two spots coincide with each other and near to the center of the mirror, it shows optical path between the first reflecting mirror and the second reflecting mirror is correct; if not, please adjust the screws at the back of the first reflecting mirror holder to make sure the spots coincide with each other.
  • Page 25 (Y-axis direction) and the height of the laser tube, to make sure the spots are within the hole of laser head (center is better). Below Figure: is better). Figure 1 1·The thrid reflecting Mirror holder 2·The second reflecting mirror holder The fifth Step: Optical path adjustment between the third reflecting mirror and the focus lens.
  • Page 26 1·The third reflecting mirror holder 2·Laser head The sixth Step: laser processing After adjusting optical path and measuring focal length with focusing plate, then you can process objects. Below Figure: Figure 1...

  • Page 27: Chapter 5 Software Installation And Operation

    Chapter 5 Software Installation and Operation 5.1 Software Installation Please insert the software CD into the computer, install the software in CD. Please read the control system user manul for more information for this section. 5.2 Software Operation Before using the device, please read this user manual and the control system user manual carefully, know all functions for the software, please refer to the control system user manual for the detail operation.

  • Page 28: Ground Wire Connection

    7.1 Ground wire connection As the equipment has some sensltive components such as the switching power supply, laser power supply,filter and other components. However, in the usage of these parts will have a certain static interference. In order to minimize static interference and reduce a series of failures caused by static electricity, so should note the following points before installation.
  • Page 29 35℃. If more than 35 ℃, then the recycled water need to be replaced or add the ice into the water to cool down the water (Recommends that users select the water chiller, or use two water tanks). Cleaning tank (Changing the water): Firstly turn off the power, unplug the tube inlet, let the water of the laser tube flow into the tank automatically, unplug the water pipe and signal cable.
  • Page 30 cleaning along with center to the edge of the lens carefully. No.3 mirror and focus lens need to be taken off from the holder, clean them with the same way, Please put it back after cleaning. Attention:： (1)Should wipe the mirrors and lens slightly, dont make any damage for the coating surface.
  • Page 31 Attention:： 1 Cleaning guide: please prepare the dry cotton, lubricating oil. 2 Cleaning of the linear guide: Firstly, move the laser head to the right side (or left side), wipe with a dry cloth until it is shiny cleaned, plus with a little lubricating oil, push the laser head slowly several times, let the lubricating oil scatter uniformly.
  • Page 32 7.3.2 Follow the sequence of the machine’s power on/off: when start the machine, firstly open the water chiller, then open the power switch, open the laser switch at last. When close the machine, firstly close the laser switch, then close the power switch, close the water chiller at last.
  • Page 33 R E D S A I L T E C H C O . , L T D...
