Alexor PC9155-433/868 Installation Manual page 87

SIA False Alarm Reduction Installations
For a list of the defaults value programmed when the unit is shipped from the factory and for any other programming information refer to table below.
Caution:
Call Waiting Cancel (section [382], Option 4) feature on a non-Call Waiting line will prevent successful communication to the supervising station.
Fire Alarm Verification feature (Auto Verified Fire Zone type [89]) is supported on the DSC Wireless Smoke Detector, Model WS4916. The fire alarm delay is 40s.
Notes:
Programming at installation may be subordinate to other UL requirements for the intended application
Cross zones have the ability to individually protect the intended area (e.g., motion detectors which overlap)
Cross zoning is not recommended for line security Installations nor is it to be implemented on exit/entry zones.
This pannel has a communication delay of 30 seconds. The delay can be removed or it can be increased up to 45 seconds at the request of the end user in consultation with the
installer.
Do not duplicate any reporting codes. This applies to all communication formats other than SIA or CID sending automatic programmed reporting codes.
The security system shall be installed with the sounding device activated and the communicator enabled for transmission using SIA or CID format.
SIA Feature
Programming Section
Exit Time
[005], 3rd entry
Progress Annunciation/
Disable - for Silent Exit
[014], Option 6 ON
Exit Delay Restart Enabled
[016], Option 2 ON
Auto Stay Arm on
Unvacated Premises
[001]-[002] Zone type 05, 06, 32
Exit Time and Progress
Annunciation/Disable
or Remote Arming
[005] and [014] bit 6
Entry delay(s)
[005], 1st and 2nd entry
Abort Window
for Non-Fire zones
[101]-[134] bit 7 ON
Abort Window - for
Non-Fire zones
[377], 4th entry
Abort Annunciation
[382], Option 3 ON
Cancel Annunciation
[328], 8th entry
Duress Feature
[*][5] Master Code
Option 2 ON
Cross Zoning
[016] Option 1
[101]-[134] bit 8 OFF
Cross Zone Timer
[176]
Swinger Shutdown for Alarms
[377] 1st entry
Swinger Shutdown Enable
[101] - [134] bit 6 ON
24-Hr. Auto-verified Fire
(Wireless) Zone type [89]
Call Waiting Cancel Dial String
[304], [382], Option 4 OFF
System Test:
[*][6] Master Code, Option 4
Walk Test Mode:
[*][6] Opt 8
Comments
Access to entry and exit delays and bell time out for the system
Enables audible exit beeps from the keypad for the duration of exit delay
Enables the exit delay restart feature
Function Key: Stay Arming. All Stay/Away type zones (05, 06) and Instant Stay/Away
zones (32) will be automatically bypassed
System times and audible exit beeps can be disabled when using the wireless key to
Away Arm the system
Access to entry and exit delays and bell time out for the system
Note: Combined entry delay and communications delay (Abort window) shall not
exceed 60s
Access to zone attributes, i.e., swinger shutdown, transmission delay and cross zone.
Individual zones attribute bit 7 (Transmission delay) is by default ON
Access to the programmable delay before communicating alarms
Note: Combined entry delay and communications delay (Abort window) shall not
exceed 60s
Enables the "Communication Cancelled" message display on keypad
Access to the reporting code for alarm cancelled
Do not derive code from an existing Master/User code (e.g., Master code is 1234, the
duress code should not be 1233 or 1235)
This option enables cross zoning for the entire system. Individual zones can be
enabled for cross zoning via zone attribute bit 8 in sections [101] - [134]
Access to the programmable cross zone timer
Access to the swinger shutdown limit for zone alarms
Access to zone attributes, i.e., swinger shutdown, transmission delay and cross zone.
Individual zones attribute bit 6 (Swinger Shutdown enabled) is by default ON
Access to 24-Hr. Auto-verified fire (wireless)
Access to the dialing sequence used to disable call waiting
The system activates all keypad sounders, bells or sirens for 2 seconds and all keypad lights turn on.
Refer to the User Manual (part no. 29007326).
This mode is used to test each zone on the system for proper functionality.
Appendix D: Regulatory Approvals Information
Testing
APP-9
Range/Default Requirement
Range:45- 255 seconds Required
Default: 60 sec. (programma-
ble)
Keypads may be disabled Allowed
Default: Enabled
Default: Enabled Required
If no exit after full arm Required
Default: Enabled
Default: Enabled Allowed
Range: 30 sec. to 4 min. Required
Default: 30 sec. (programma-
ble)
May be disabled Required
by zone or zone type
Default: Enabled
Range: 15 - 45 sec. Required
Default: 30 sec. (programma-
ble)
Annunciate that no Required
alarm was transmitted
Default: Enabled
Annunciate that a Required
Cancel was transmitted
Default: Enabled
No 1+/- derivative of another Allowed
user code. No duplicates with
other user codes
Default: disabled
Programming required Required
Default: Disabled
May program Allowed
Range: 001-255 sec./min.
Default: 60 seconds
For all non-fire zones Required
shut down at 1 or 2 trips (programma-
Default: 1 Trip ble)
For non-police Allowed
response zones
Default: Enabled
Activates If a restoral is Not Required
received within the specified
time
Default: disabled
Dependant on user phone Required
line
Default: disabled
