ThinkStation
Hardware Maintenance Manual
Machine Types: 4262, 4263, 4264, 4265, 4266, 4269, 4271, and 4272

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ThinkStation 4262 and is the answer not in the manual?

Questions and answers

Related Manuals for Lenovo ThinkStation 4262

Summary of Contents for Lenovo ThinkStation 4262

  • Page 1 ThinkStation Hardware Maintenance Manual Machine Types: 4262, 4263, 4264, 4265, 4266, 4269, 4271, and 4272...
  • Page 3 ThinkStation Hardware Maintenance Manual Machine Types: 4262, 4263, 4264, 4265, 4266, 4269, 4271, and 4272...
  • Page 4 © Copyright Lenovo 2010, 2011. LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.

  • Page 5: Table Of Contents

    ..SATA or SAS RAID ... Lenovo Welcome....Configuring the Marvell BIOS Setup to enable Additional information resources .
  • Page 6 Installing a new hard disk drive ..Windows 7 Ultimate 64 Recovery CD ..Replacing a hard disk drive..Chapter 11. Additional service Replacing the optical drive .

  • Page 7: Chapter 1. About This Manual

    This manual contains service and reference information for ThinkStation™ computers listed on the front cover. It is intended only for trained servicers who are familiar with Lenovo® computer products. Before servicing a Lenovo product, be sure to read the Safety Information in Chapter 2 “Safety information” on page 3.
  • Page 8 Lenovo plans to transition to RoHS compliance well before the implementation date and expects its suppliers to be ready to support Lenovo's requirements and schedule in the EU. Products sold in 2005 will contain some RoHS compliant FRUs. The following statement pertains to these products and any product Lenovo produces containing RoHS compliant parts.

  • Page 9: Chapter 2. Safety Information

    Observe the following rules when working on electrical equipment. © Copyright Lenovo 2010, 2011...
  • Page 10 Important: Use only approved tools and test equipment. Some hand tools have handles covered with a soft material that does not insulate you when working with live electrical currents. Many customers have, near their equipment, rubber floor mats that contain small conductive fibers to decrease electrostatic discharges. Do not use this type of mat to protect yourself from an electric shock.

  • Page 11: Voltage-Selection Switch

    Voltage-selection switch Some computers are equipped with a voltage-selection switch located near the power-cord connection point on the computer. If your computer has a voltage-selection switch, ensure that you set the switch to match the voltage available at your electrical outlet. Setting the voltage-selection switch incorrectly can cause permanent damage to the computer.

  • Page 12: Handling Electrostatic Discharge-Sensitive Devices

    5. Check for any obvious alterations. Use good judgment as to the safety of any alterations. 6. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage. 7.
  • Page 13 • French • German • Hebrew • Italian • Korean • Spanish DANGER Electrical current from power, telephone and communication cables is hazardous. To avoid a shock hazard: • Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm.
  • Page 14 CAUTION: When laser products (such as CD-ROMs, DVD-ROM drives, fiber optic devices, or transmitters) are installed, note the following: • Do not remove the covers. Removing the covers of the laser product could result in exposure to hazardous laser radiation. There are no serviceable parts inside the device. •...
  • Page 15 Chapter 2 Safety information...
  • Page 16 ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) PERIGO ThinkStation Hardware Maintenance Manual...
  • Page 17 A corrente elétrica proveniente de cabos de alimentação, de telefone e de comunicações é perigosa. Para evitar risco de choque elétrico: • Não conecte nem desconecte nenhum cabo ou execute instalação, manutenção ou reconfiguração deste produto durante uma tempestade com raios. •...
  • Page 18 • Não remova as tampas. A remoção das tampas de um produto a laser pode resultar em exposição prejudicial à radiação de laser. Não existem peças que podem ser consertadas no interior do dispositivo. • A utilização de controles ou ajustes ou a execução de procedimentos diferentes dos especificados aqui pode resultar em exposição prejudicial à...
  • Page 19 Chapter 2 Safety information...
  • Page 20 ThinkStation Hardware Maintenance Manual...
  • Page 21 Chapter 2 Safety information...
  • Page 22 DANGER Le courant électrique provenant de l'alimentation, du téléphone et des câbles de transmission peut présenter un danger. Pour éviter tout risque de choc électrique : • Ne manipulez aucun câble et n'effectuez aucune opération d'installation, d'entretien ou de reconfiguration de ce produit au cours d'un orage.
  • Page 23 Connexion Déconnexion 1. Mettez les unités HORS TENSION. 1. Mettez les unités HORS TENSION. 2. Commencez par brancher tous les cordons sur les 2. Débranchez les cordons d'alimentation des prises. unités. 3. Débranchez les câbles d'interface des connecteurs. 3. Branchez les câbles d'interface sur des connecteurs. 4.
  • Page 24 ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) ATTENTION: Soulevez la machine avec précaution. ATTENTION: L'interrupteur de contrôle d'alimentation de l'unité et l'interrupteur dubloc d'alimentation ne coupent pas le courant électrique alimentantl'unité. En outre, le système peut être équipé de plusieurs cordonsd'alimentation.
  • Page 25 • Die Verbindung zu den angeschlossenen Netzkabeln, Telekommunikationssystemen, Netzwerken und Modems ist vor dem Öffnen des Gehäuses zu unterbrechen, sofern in den Installations- und Konfigurationsprozeduren keine anders lautenden Anweisungen enthalten sind. • Zum Installieren, Transportieren und Öffnen der Abdeckungen des Computers oder der angeschlossenen Einheiten die Kabel gemäß...
  • Page 26 Laserstrahlung bei geöffneter Verkleidung. Nicht in den Strahl blicken. Keine Lupen oder Spiegel verwenden. Strahlungsbereich meiden. ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) ACHTUNG: Arbeitsschutzrichtlinien beim Anheben der Maschine beachten. ACHTUNG: Mit dem Netzschalter an der Einheit und am Netzteil wird die Stromversorgung für die Einheit nicht unterbrochen.
  • Page 27 Chapter 2 Safety information...
  • Page 28 PERICOLO La corrente elettrica proveniente dai cavi di alimentazione, del telefono e di comunicazione può essere pericolosa. Per evitare il rischio di scosse elettriche: • Non collegare o scollegare qualsiasi cavo oppure effettuare l'installazione, la manutenzione o la riconfigurazione del prodotto durante un temporale. •...
  • Page 29 • Se possibile, utilizzare solo una mano per collegare o scollegare i cavi di segnale. • Non accendere assolutamente apparecchiature in presenza di incendi, perdite d'acqua o danno strutturale. • Scollegare i cavi di alimentazione, i sistemi di telecomunicazione, le reti e il modem prima di aprire i coperchi del dispositivo, salvo istruzioni contrarie relative alle procedure di installazione e configurazione.
  • Page 30 PERICOLO Alcune unità laser contengono un diodo laser di Classe 3A o Classe 3B. Tener presente quanto segue: Aprendo l'unità vengono emesse radiazioni laser. Non fissare il fascio, non guardarlo direttamente con strumenti ottici ed evitare l'esposizione al fascio. ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) ATTENZIONE:...
  • Page 31 Chapter 2 Safety information...
  • Page 32 PELIGRO La corriente eléctrica procedente de cables de alimentación, teléfonos y cables de comunicación puede ser peligrosa. Para evitar el riesgo de descarga eléctrica: • No conecte ni desconecte los cables ni realice ninguna tarea de instalación, mantenimiento o reconfiguración de este producto durante una tormenta eléctrica. •...
  • Page 33 • Desconecte los cables de alimentación, los sistemas de telecomunicaciones, las redes y los módems conectados antes de abrir las cubiertas de los dispositivos, a menos que se indique lo contrario en los procedimientos de instalación y configuración. • Conecte y desconecte los cables, como se describe en la tabla siguiente, cuando instale, mueva o abra las cubiertas de este producto o de los dispositivos conectados.
  • Page 34 Algunos productos láser tienen incorporado un diodo láser de clase 3A o clase 3B. Tenga en cuenta lo siguiente: Cuando se abre, queda expuesto a radiación láser. No mire directamente al rayo láser, ni siquiera con instrumentos ópticos, y evite exponerse directamente al rayo láser. ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs)

  • Page 35: Chapter 3. General Information

    This chapter provides general information that applies to all machine types supported by this publication. Lenovo ThinkVantage Tools Note: The Lenovo ThinkVantage Tools program is only available on computers with the Windows 7 operating system from Lenovo. The Lenovo ThinkVantage Tools program helps you work more easily and securely by providing easy access to various tools, such as: •...
  • Page 36 Dimensions Width: 130 mm (5.12 inches) Height: 427 mm (16.81 inches) Depth: 444 mm (17.48 inches) Weight Maximum configuration: 18.5 kg (40.8 lbs) Environment • Air temperature: Operating: 10° to 35°C (50° to 95°F) Non-operating: -10° to 60°C (14° to 140°F) (with package) •...

  • Page 37: Chapter 4. General Checkout

    Service Support and Engineering functions. • Machine type and model • Processor or hard disk drive upgrades • Failure symptom – Do diagnostics indicate a failure? – What, when, where, single, or multiple systems? – Is the failure repeatable? © Copyright Lenovo 2010, 2011...
  • Page 38 – Has this configuration ever worked? – If it has been working, what changes were made prior to it failing? – Is this the original reported failure? • Diagnostics version – Type and version level • Hardware configuration – Print (print screen) configuration currently in use –...

  • Page 39: Chapter 5. Diagnostics

    2. If you are unable to isolate and repair the problem yourself after running the programs, save and print the log files created by the programs. You will need the log files when you speak to a Lenovo technical support representative.

  • Page 40: Pc-Doctor For Dos

    You can also download the latest version of the PC-Doctor for DOS diagnostic program from http://www.lenovo.com/support. The PC-Doctor for DOS diagnostic program runs independently of the Windows operating system. Use the PC-Doctor for DOS diagnostic program if you are unable to start the Windows operating system.

  • Page 41: Test Results

    Run Normal Test runs a more extensive set of tests than Run Quick Test does and takes longer to complete. • Press F5 to automatically run all selected tests in all categories. • From within a test category, press Ctrl+Enter to automatically run only the selected tests in that category. •...
  • Page 42 Quick Erase Hard Drive provides a DOS utility that performs the following: • Destroys the Master Boot Record (MBR) on the hard disk drive. • Destroys all copies of the FAT Table on all partitions (both the master and backup). •...

  • Page 43: Chapter 6. Using The Setup Utility Program

    • Set Administrator Password • Set User Password You do not have to set a password to use your computer. However, using a password improves computing security. If you decide to set a password, read the following sections. © Copyright Lenovo 2010, 2011...

  • Page 44: Password Considerations

    Password considerations A password can be any combination of up to 12 (1 to 12) alphabetic and numeric characters. For security reasons, it is recommended to use a strong password that cannot be easily compromised. To set a strong password, use the following guidelines: Note: The Setup Utility program passwords are not case sensitive.

  • Page 45: Selecting A Startup Device

    USB Support Use this option to enable or disable USB connectors. ICH SATA When this feature is set to Disabled, any optical drives or eSATA devices are disabled and will not be displayed in the system configuration. Marvell SATA/SAS controller When this feature is set to Disabled, all internal hard disk drives are disabled and will not be displayed in the system configuration.

  • Page 46: Advanced Settings

    3. Select the startup devices for the Primary Startup Sequence, the Automatic Startup Sequence, and the Error Startup Sequence. 4. Press Esc to return to the Setup Utility program main menu. You might have to press Esc several times. 5. Press F10 to save the new settings and exit the Setup Utility program. Notes: a.

  • Page 47: Chapter 7. Configuring Raid

    2. From the Setup Utility program main menu, select Devices ® IDE Drives Setup and press Enter. 3. Select SATA RAID Enable and press Enter. 4. Select Enabled and press Enter. 5. Press F10 to save the new settings and exit the Setup Utility program. © Copyright Lenovo 2010, 2011...

  • Page 48: Creating Raid Volumes

    Creating RAID volumes This section describes how to use the Intel Matrix Storage Manager option ROM configuration utility to create RAID volumes. 1. Press Ctrl+I when prompted to enter the Intel Matrix Storage Manager option ROM configuration utility. 2. Use the up and down arrow keys to select Create RAID Volume and press Enter. 3.

  • Page 49: Installing Sata Or Sas Hard Disk Drives

    Installing SATA or SAS hard disk drives Your computer must have the minimum number of SATA or SAS hard disk drives installed for the supported level of RAID below: • RAID Level 0 – Striped disk array – Two hard disk drives minimum –...

  • Page 50: Configuring The Marvell Bios Setup To Set An Optional Hot Spare Hard Disk Drive

    Configuring the Marvell BIOS Setup to set an optional hot spare hard disk drive To configure the Marvell BIOS Setup to set an optional hot spare hard disk drive, do the following: 1. Turn on your computer and press Ctrl+M when prompted to enter the Marvell BIOS Setup. 2.

  • Page 51: Chapter 8. Symptom-To-Fru Index

    • On/Off switch connector • On/Off switch power supply connector • System board power supply connectors • Microprocessor(s) connection Check the power cord for continuity. Power cord Check the turn on switch for continuity. Turn on switch © Copyright Lenovo 2010, 2011...

  • Page 52: Diagnostic Error Codes

    Diagnostic error codes Refer to the following diagnostic error codes when using the diagnostic tests. See “Running tests” on page 34 for the specific type for information about the diagnostic programs. In the following index, X can represent any number. Diagnostic Error Code FRU/Action No action...
  • Page 53 Diagnostic Error Code FRU/Action 1. Make sure the component that is called out is 000-197-XXX BIOS test warning connected and/or enabled. See Chapter 6 “Using the Setup Utility program” on page 37. 2. Re-run test. 3. Replace the component that is called out in warning statement 4.
  • Page 54 Diagnostic Error Code FRU/Action 1. Adapter card 001-038-XXX System Extension failure 2. System board 001-039-XXX System DMI data structure error 1. Flash the system. See “Updating (flashing) the BIOS” on page 225. 2. System board 001-040-XXX System IRQ failure 1. Turn off/on system and re-test. 2.
  • Page 55 Diagnostic Error Code FRU/Action 001-273-XXX System IRQ6 (diskette drive) failure 1. Diskette Cable 2. Diskette drive 3. System board 001-274-XXX System IRQ7 failure 1. Device on IRQ7 2. System board 001-275-XXX System IRQ8 failure 1. Device on IRQ8 2. System board 001-276-XXX System IRQ9 failure 1.
  • Page 56 Diagnostic Error Code FRU/Action 1. Video Ram 005-016-XXX Video Simple Pattern test failure 2. Video card, if installed 3. System board 005-024-XXX Video Addressing test failure 1. Video card, if installed 2. System board 005-025-XXX Video Checksum Value error 1. Video card, if installed 2.
  • Page 57 Diagnostic Error Code FRU/Action 005-2XX-XXX 005-3XX-XXX Video subsystem error 1. Video card, if installed 2. System board 006-000-XXX Diskette interface Test Passed No action 006-0XX-XXX Diskette interface error 1. Diskette drive Cable 2. Diskette drive 3. System board 006-195-XXX Diskette interface Test aborted by user Information only Restart the test, if necessary 006-196-XXX Diskette interface test halt, error threshold 1.
  • Page 58 Diagnostic Error Code FRU/Action 011-196-XXX Serial port test halt, error threshold exceeded 1. Press F3 to review the log file. 2. Restart the test to reset the log file. 011-197-XXX Serial port test warning 1. Make sure the component that is called out is connected and/or enabled.
  • Page 59 Diagnostic Error Code FRU/Action 014-197-XXX Parallel port test warning 1. Make sure the component that is called out is connected and/or enabled. See Chapter 6 “Using the Setup Utility program” on page 37. 2. Re-run test. 3. Replace the component that is called out in warning statement.
  • Page 60 Diagnostic Error Code FRU/Action 015-196-XXX USB port test halt, error threshold exceeded 1. Press F3 to review the log file. 2. Restart the test to reset the log file. 015-197-XXX USB port test warning 1. Make sure the component that is called out is connected and/or enabled.
  • Page 61 Diagnostic Error Code FRU/Action 018-250-XXX PCI Card Services error 1. PCI card 2. Riser card, if installed. 3. System board 020-000-XXX PCI Interface Test Passed No action 020-0XX-XXX PCI Interface error 1. PCI card 2. Riser card, if installed. 3. System board 020-195-XXX PCI Test aborted by user Information only Restart the test, if necessary 020-196-XXX PCI test halt, error threshold exceeded...
  • Page 62 Diagnostic Error Code FRU/Action 1. IDE signal cable 025-02X-XXX 025-03X-XXX 025-04X-XXX IDE Interface failure 2. Check power supply. 3. Reseat IDE signal cable. 4. IDE device 5. System board 025-195-XXX IDE interface Test aborted by user Information only Restart the test, if necessary. 025-196-XXX IDE interface test halt, error threshold 1.
  • Page 63 Diagnostic Error Code FRU/Action 030-196-XXX SCSI interface test halt, error threshold 1. Press F3 to review the log file. exceeded 2. Restart the test to reset the log file. 030-197-XXX SCSI interface test warning 1. Make sure the component that is called out is connected and/or enabled.
  • Page 64 Diagnostic Error Code FRU/Action 071-00X-XXX 071-01X-XXX 071-02X-XXXAudio port error 1. Run the Setup Utility program. 2. Flash the system. See “Updating (flashing) the BIOS” on page 225. 3. System board 071-03X-XXX Audio port failure 1. Speakers 2. Microphone 3. Audio card, if installed. 4.
  • Page 65 Diagnostic Error Code FRU/Action 1. Make sure the component that is called out is 080-197-XXX Game Port interface test warning connected and/or enabled. See Chapter 6 “Using the Setup Utility program” on page 37. 2. Re-run test. 3. Replace the component that is called out in warning statement.
  • Page 66 Diagnostic Error Code FRU/Action 086-199-XXX Mouse Port interface test failed, cause 1. See “Undetermined problems” on page 67. unknown 2. Flash the system and re-test. See “Updating (flashing) the BIOS” on page 225. 3. Replace component under function test. 089-000-XXX Microprocessor Test Passed No action 089-XXX-XXX Microprocessor failure 1.
  • Page 67 Diagnostic Error Code FRU/Action 170-199-XXX Voltage Sensor(s) test failed, cause unknown 1. See “Undetermined problems” on page 67. 2. Flash the system and re-test. See “Updating (flashing) the BIOS” on page 225. 3. Replace component under function test. 1. Power supply 170-250-XXX 170-251-XXX Voltage Sensor(s) Voltage limit error 2.
  • Page 68 Diagnostic Error Code FRU/Action 1. Replace the memory module called out by the test. 201-XXX-XXX System Memory error 2. System board No action 202-000-XXX System Cache Test Passed 202-XXX-XXX System Cache error 1. Cache, if removable 2. System board 3. Microprocessor 206-000-XXX Diskette Drive Test Passed No action 206-XXX-XXX Diskette Drive error...

  • Page 69: Beep Symptoms

    Diagnostic Error Code FRU/Action No action 305-000-XXX Monitor DDC Test Passed 305-250-XXX Monitor DDC self test failure 1. Run the Setup Utility program to enable DDC. 2. Cable 3. Monitor 4. Video card 5. System board 415-000-XXXModem Test Passed No action 415-XXX-XXX Modem error Remove the Modem and re-test the system.

  • Page 70: Post Error Codes

    Beep Symptom FRU/Action 1-3-3-1 short beeps DRAM memory error Perform the following actions in order. 1. Make sure the memory module(s) are properly seated in the connector(s). 2. Replace the memory module(s). 3. Replace the system board. POST error codes Each time you Turn on the system, it performs a series of tests that check the operation of the system and some options.

  • Page 71: Miscellaneous Error Messages

    POST Error Message Description/Action Memory test fail If POST detects an error during memory testing, additional information appears. This information gives specifics about the type and location of the memory error. Press TAB to show POST screen Pressing the TAB key permits the user to toggle between the default POST display screen and a custom POST display screen.
  • Page 72 Message/Symptom FRU/Action 1. Run the Memory tests. Incorrect memory size during POST 2. Memory Module 3. System Board "Insert a Diskette" icon appears with a known-good 1. System Board diagnostics diskette in the first 3.5-inch diskette drive. 2. Diskette Drive Cable 3.

  • Page 73: Undetermined Problems

    Message/Symptom FRU/Action Serial or parallel port device failure (adapter port) 1. External Device Self-Test OK? 2. External Device 3. Cable 4. Alternate Adapter 5. System Board 1. Keyboard Some or all keys on the keyboard do not work 2. Keyboard Cable 3.
  • Page 74 ThinkStation Hardware Maintenance Manual...

  • Page 75: Chapter 9. Replacing Frus

    Figure 1. Front control and connector locations Hard disk drive activity indicator Headphone connector Power switch and power indicator USB connector USB connector IEEE 1394 connector (available on some models) Microphone connector Optical drive eject button © Copyright Lenovo 2010, 2011...

  • Page 76: Locating Connectors On The Rear Of Your Computer

    Locating connectors on the rear of your computer Figure 2 “Rear connector locations” on page 70 shows the locations of the connectors on the rear of your computer. Some connectors on the rear of your computer are color-coded to help you determine where to connect the cables on your computer.

  • Page 77: Locating Parts And Connectors On The System Board

    Figure 3. Component locations Microprocessor 1 Hard disk drive bay Memory modules Hard disk drives (3) Heat sink and fan assembly 2 System board Microprocessor 2 Power supply assembly Optical drive bracket PCI card Optical drive Heat sink and fan assembly 1 Internal Speaker Rear fan assemblies (2) Front fan assembly bracket...
  • Page 78 Figure 4. System board part and connector locations CPU 1 memory slots (6) Clear CMOS (Complementary Metal Oxide Semiconductor) /Recovery jumper CPU 1 memory fan connector Thermal sensor connector CPU 2 12 V power connector Cover presence switch connector Microprocessor 2 Personal System/2®...
  • Page 79 Figure 5 “System board part and connector locations” on page 73 shows the locations of the parts and connectors on the other type of system board. Figure 5. System board part and connector locations CPU 1 memory slots (3) Clear CMOS (Complementary Metal Oxide Semiconductor) /Recovery jumper CPU 1 memory fan connector Thermal sensor connector...

  • Page 80: Removing The Computer Cover

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to remove the computer cover. CAUTION: Turn off the computer and wait three to five minutes to let the computer cool before removing the computer cover.

  • Page 81: Removing And Reinstalling The Front Bezel

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to remove and reinstall the front bezel.

  • Page 82: Removing And Reinstalling The Pci Card Holder

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to remove and reinstall the PCI card holder.

  • Page 83: Installing Or Replacing A Memory Module

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to install or replace a memory module.
  • Page 84 • Always install DIMMs in the numerical order printed on the system board (DIMM1, DIMM2, DIMM3, and so on). Install memory modules into the blue memory slots first. • If your computer has only one CPU installed, be sure to install memory modules only in the memory slots adjacent to that CPU.
  • Page 85 Figure 11. Removing the memory fan duct 7. Open the retaining clips as shown. Figure 12. Opening the retaining clips If you are replacing an old memory module, open the retaining clips and gently pull the memory module out of the memory slot. Figure 13.
  • Page 86 b. If your computer has six memory slots on the system board, you might have to use more force to remove the memory module installed in memory slot 8. Position the new memory module over the memory slot. Make sure that the notch on the memory module aligns correctly with the key in the memory slot.

  • Page 87: Installing Or Replacing A Pci Card

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to install or replace a PCI card. Your computer has the following six expansion slots for installing or replacing PCI cards: •...
  • Page 88 • Two PCI Express x16 card slots To install or replace a PCI card, do the following: 1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect all power cords from electrical outlets and disconnect all cables that are connected to the computer. 2.

  • Page 89: Installing A New Hard Disk Drive

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to install a new hard disk drive into your computer.
  • Page 90 Figure 18. Installing a new hard disk drive into the bracket 7. Connect one end of the signal cable that comes with the new hard disk drive to the rear of the new hard disk drive. Note: The signal cable will be different depending on whether you are installing a SATA hard disk drive or a SAS hard disk drive.
  • Page 91 Figure 21. Installing a new hard disk drive 9. Locate one of the extra five-wire power cables and connect it to the new hard disk drive. Note: You might need to disconnect power cables for other hard disk drives installed in your computer and then rotate the air flow wall outward for easier access to the rear of the new hard disk drive.

  • Page 92: Replacing A Hard Disk Drive

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace a hard disk drive. To replace a hard disk drive, do the following: 1.

  • Page 93: Replacing The Optical Drive

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the optical drive. To replace the optical drive, do the following: 1.
  • Page 94 4. Disconnect the signal cable and the power cable from the rear of the optical drive, press the blue release button as shown, and then slide the optical drive out of the computer. Figure 24. Removing the optical drive 5. Install the optical drive retainer on the side of the new optical drive.

  • Page 95: Replacing The Heat Sink And Fan Assembly

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support CAUTION: The heat sink and fan assembly might be very hot. Turn off the computer and wait three to five minutes to let the computer cool before removing the computer cover.
  • Page 96 b. Pivot the optical drive bracket as shown in the following illustration and then remove it from the chassis. Go to 6 on page 90. Figure 27. Removing the optical drive bracket 6. Disconnect the heat sink and fan assembly cable from the system board. Note the cable location. 7.
  • Page 97 Figure 28. Removing the heat sink and fan assembly 8. Carefully lift the heat sink and fan assembly off the system board. Notes: a. You might have to gently twist the heat sink and fan assembly to free it from the microprocessor. b.

  • Page 98: Replacing The Microprocessor

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support CAUTION: The heat sink and fan assembly might be very hot. Turn off the computer and wait three to five minutes to let the computer cool before removing the computer cover.
  • Page 99 Notes: a. Note the orientation of the notches on the microprocessor. This is important when reinstalling the microprocessor on the new system board. b. Do not drop anything onto the microprocessor socket while it is exposed. The socket pins must be kept as clean as possible.

  • Page 100: Replacing The System Board

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the system board. CAUTION: The heat sink and microprocessor might be very hot.
  • Page 101 14. Remove the six screws that secure the system board to the chassis. Figure 29. Removing the six screws that secure the system board to the chassis 15. Carefully lift the failing system board out of the chassis. Chapter 9 Replacing FRUs...
  • Page 102 16. Position the new system board into the chassis so that the screw holes in the new system board are aligned with those in the chassis. Install the six screws that secure the system board to the chassis. 17. Reinstall the two memory chiller frames and the black cable clip by tightening the eight screws to secure them to the system board.

  • Page 103: Replacing The Battery

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support. Your computer has a special type of memory that maintains the date, time, and settings for built-in features, such as serial-port assignments (configuration).

  • Page 104: Replacing The Power Supply Assembly

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support. ThinkStation Hardware Maintenance Manual...
  • Page 105 This document provides instructions on how to replace the power supply assembly. CAUTION: Never remove the cover on a power supply or any part that has the following label attached. Hazardous voltage, current, and energy levels are present inside any component that has this label attached.
  • Page 106 8. Position the computer upside down. 9. Remove the three screws that secure the side cover as shown in the following illustration. Figure 31. Removing the side cover screws 10. Remove the other six screws that secure the side cover as shown in the following illustration. Then, lift the side cover and remove it from the computer.
  • Page 107 Figure 32. Removing the side cover 11. Disconnect the power supply assembly cables from the system board and the drives. In some models, you might need to disconnect the power supply assembly cables from the Peripheral Component Interconnect (PCI) cards. 12.
  • Page 108 Figure 33. Removing the power supply assembly 13. Install the new power supply assembly into the chassis, make sure the screw holes in the new power supply assembly align with those in the chassis. 14. Install the four screws at the rear of the chassis to secure the new power supply assembly in place. 15.

  • Page 109: Replacing The Front Fan Assembly

    Figure 34. Routing the three power supply assembly cables P3 cable (connected to the rear of the optical drive) P5A/P5B cable (connected to an installed PCI card which requires power source) P4 cable (connected to an installed PCI card which requires power source) 17.
  • Page 110 ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the front fan assembly. Note: Not all computers have the front fan assembly. To replace the front fan assembly, do the following: 1.

  • Page 111: Replacing The Rear Fan Assembly

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the rear fan assembly. Note: Your computer supports two rear fan assemblies.
  • Page 112 To replace the rear fan assembly, do the following: 1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect all power cords from electrical outlets and disconnect all cables that are connected to the computer. 2.

  • Page 113: Replacing The Internal Speaker

    ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support. This section provides instructions on how to replace the internal speaker. To replace the internal speaker, do the following: 1.
  • Page 114 5. Remove the optical drive and the optical drive bracket. See “Replacing the optical drive” on page 87. 6. Locate the internal speaker connector on the system board. See “Locating parts and connectors on the system board” on page 71. 7.

  • Page 115: Completing The Parts Replacement

    Figure 40. Installing the new internal speaker 10. Connect the new internal speaker cable to the system board. See “Locating parts and connectors on the system board” on page 71. 11. Go to “Completing the parts replacement” on page 109. Completing the parts replacement After completing the installation or replacement for all parts, you need to reinstall the computer cover and reconnect cables.
  • Page 116 Setup Utility program. Refer to Chapter 6 “Using the Setup Utility program” on page 37. Note: In most areas of the world, Lenovo requires the return of the defective Customer Replaceable Unit (CRU). Information about this will come with the CRU or will come a few days after the CRU arrives.

  • Page 117: Chapter 10. Fru Lists

    • MT 4262: all models • MT 4263: all models • MT 4264: all models 41R5729 • MT 4265: all models • MT 4266: all models • MT 4269: all models • MT 4272: all models © Copyright Lenovo 2010, 2011...
  • Page 118 Item # FRUs FRU # Microprocessor, Intel Xeon E5502 - 1.86GHz, Dual Core 4.8 QPI, 4MB L2, DDR3-800, 80W • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 46R6630 • MT 4265: CTO • MT 4266: CTO •...
  • Page 119 Item # FRUs FRU # Microprocessor, Intel Xeon E5507 - Quad Core - 2.26GHz - 4.8 QPI DDR3-800-4MB 80W • MT 4262: CTO • MT 4263: 12G 17G 18G 25G 59G 53C 54C 12U 12F 12S 12L 12D 12Y 12M 12A 12Q 12T 12C 12B 12H 12V 12K 12R 12E 12J 79U 79F 79S CTO 83C A1U A1F A1S A1P A1L A1D A1Y A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J...
  • Page 120 Item # FRUs FRU # Microprocessor, Intel Xeon E5620 - Quad Core - 2.40GHz - 5.86 QPI DDR3-1066-12MB Turbo SMT 80W • MT 4262: 11Q CTO • MT 4263: 61G 48C 49C 51C 52C 28A 36Q 65K 65R 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V 71K 71R 71E 71J 23U 23F 23S 23L 23D 23Y 23M 23A 23Q 23T 23C 23B 23H 23V 23K 23R 23E 23J 81U 81F 81S 61U 61F 61S 61L 61L 61D 61Y 61M 61A 61Q 61T 61C 61B...
  • Page 121 Item # FRUs FRU # Microprocessor, Intel Xeon X5550 - 2.66GHz, Quad Core - 6.4 QPI, 8MB L2, DDR3-1333, Turbo, SMT, 95W • MT 4262: CTO • MT 4263: 16G CTO • MT 4264: CTO 46R6638 • MT 4265: CTO •...
  • Page 122 Item # FRUs FRU # Microprocessor, Intel Xeon X5667 - Quad Core - 3.06GHz - 6.4 QPI DDR3-1333-12MB Turbo SMT 95W • MT 4262: 14F CTO • MT 4263: 32A 33A 33T CTO • MT 4264: 11A CTO 71Y9039 • MT 4265: CTO •...
  • Page 123 Item # FRUs FRU # Microprocessor, Intel Xeon E5606 - Quad Core - 2.13Ghz - 4.8 QPI, 8MB Cache, DDR3 - 1066, No HT, No Turbo, 80W • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 03T8031 •...
  • Page 124 Item # FRUs FRU # Microprocessor, Intel Xeon X5647 - Quad Core - 2.93Ghz - 5.86 QPI, 12MB Cache, DDR3 - 1066, Turbo, HT, 130W • MT 4262: CTO • MT 4263: CTO A4U A4F A6J • MT 4264: CTO 03T8028 •...
  • Page 125 Item # FRUs FRU # Memory module, 1GB DDR3 ECC UDIMM PC3-10600 (1333MHz) • MT 4262: 12Q CTO • MT 4263: 26A 27A 28A 29A 31T 32A 36Q 64K 64R 65K 65R 68J 22U 22F 22S 22L 22D 22Y 22M 22A 22Q 22T 22C 22B 22H 22V 22K 22R 22E 22J 23U 23F 23S 23L 23D 23Y 23M 23A 23Q 23T 23C 23B 23H 23V 23K 23R 23E 23J CTO 92A 93A 46R6026...
  • Page 126 Item # FRUs FRU # Memory module, 4GB DDR3 ECC UDIMM PC3-10600 (1333MHz) • MT 4262: CTO • MT 4263: 39M 41J 44C 74C CTO • MT 4264: CTO 64Y9570 • MT 4265: 41J 42J 58J 59J CTO 84J 85J 86J 88J 89B 89H 1DJ 1FJ •...
  • Page 127 Item # FRUs FRU # Memory module, 1GB DDR3 ECC UDIMM PC3-8500 (1066MHz) • MT 4262: CTO • MT 4263: 11G CTO • MT 4264: CTO 53Y6195 • MT 4265: 11G 12G 13G 14G CTO • MT 4266: CTO • MT 4269: CTO •...
  • Page 128 Item # FRUs FRU # Memory module, 4GB DDR3 2RX4 RDIMM PC3-10600 (1333MHz) • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 89Y1291 • MT 4265: CTO • MT 4266: CTO • MT 4269: 29G 31G 32G 33G 34G 35G CTO •...
  • Page 129 Item # FRUs FRU # Optical drive, DVD-ROM Drive - 16x/48x (SATA) - DOS/Linux/XP/Vista/Windows • MT 4262: CTO • MT 4263: 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V 71K 71R 71E 71J 72U 72F 72S 72L 72D 72Y 72G 72M 72A 72Q 72T 72C 72B 72H 72V 72K 72R 72E 72J 23U 23F 23S 23L 23D 23Y 23M 23A 23Q 23T 23C 23B 23H 23V 23K 23R 23E 23J CTO 71Y5543...
  • Page 130 Item # FRUs FRU # Optical drive, DVD Burner/CD-RW Rambo 8 (SATA) - DOS/Linux/ XP/Vista • MT 4262: 11Q 12Q 14F 13J CTO • MT 4263: 39M 41J 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 57G 58G 59G 61G 62G 63G 46C 47C 48C 49C 52C 53C 54C 55C 56C 26A 27A 28A 29A 31T 32A 34A 35A 36Q 64K 64R 65K 65R 66K 66R 78J 68J 69J 12U 12F 12S 12L 12D 12Y 12M 12A 12Q 12T 12C...
  • Page 131 Item # FRUs FRU # Optical drive, DVD Burner/CD-RW Rambo 8 (SATA) - XP/Vista • MT 4262: CTO • MT 4263: CTO 92A 93A 94A 95A 96C 97U 97F 97S 97P 97L 97D 97Y 97M 97A 97Q 97T 97C 97B 97H 97V 97K 97R 97E 97J 98U 98F 98S 98P 98L 98D 98Y 98M 98A 98Q 98T 98C 98B 98H 98V 98K 98R 98E 98J 99U 99F 99S 99P 99L 99D 99Y 99M 99A 99Q 99T 99C 99B 99H 99V 99K 99R 99E 99J A1U A1F A1S A1P A1L A1D A1Y A1M A1A A1Q A1T A1C A1B A1H...
  • Page 132 Item # FRUs FRU # Hard disk drive, 500GB SATA - 7200 rpm, 3 Gb/s, 16MB cache, 3.5" • MT 4262: 11Q 12Q 13J CTO • MT 4263: 39M 41J 11G 12G 13G 18G 23G 24G 25G 67U 67F 67S 57G 58G 59G 61G 62G 63G 48C 49C 53C 54C 55C 56C 35A 35T 65K 65R 68J 69J 12U 12F 12S 12L 12D 12Y 12M 12A 12Q 12T 12C 12B 12H 12V 12K 12R 12E 12J 79U 79F 79S 81U 81F 81S 82U 82F 82S CTO 86M 87M 88M 84J...
  • Page 133 Item # FRUs FRU # Hard disk drive, 300GB SATA - 10000 rpm, 3 Gb/s, 16MB cache, 2.5" • MT 4262: CTO • MT 4263: 21G 22G 22U 22F 22S 22L 22D 22Y 22M 22A 22Q 22T 22C 22B 22H 22V 22K 22R 22E 22J 74C CTO 89M 91M 85J •...
  • Page 134 Item # FRUs FRU # Hard disk drive, 300GB SAS - 15000 rpm, 6 Gb/s, 32MB cache, 3.5" • MT 4262: CTO • MT 4263: 78J CTO • MT 4264: CTO • MT 4265: CTO 03X3621 • MT 4266: CTO •...
  • Page 135 Item # FRUs FRU # Hard disk drive, 128GB SATA Solid State Drive (SSD) - MLC, 1.8" • MT 4262: 14F CTO • MT 4263: 19G CTO • MT 4264: CTO 45N8203 • MT 4265: CTO • MT 4266: 11U 11F CTO •...
  • Page 136 Item # FRUs FRU # Hard disk drive, 2TB SATA - 7200 rpm, 3 Gb/s, 32MB cache, 3.5" • MT 4262: CTO • MT 4263: • MT 4264: 45K0610 • MT 4265: • MT 4266: CTO • MT 4269: • MT 4272: Hard disk drive, 750GB SATA - 7200 rpm, 3 Gb/s, 16MB cache, 3.5"...
  • Page 137 Item # FRUs FRU # Hard disk drive, 1TB SATA - 7200 rpm, 3 Gb/s, 32MB cache, 3.5" • MT 4262: CTO • MT 4263: A7G A8G A9G B1G B2G • MT 4264: 45K0412 • MT 4265: 1BM 1CM 1EJ 1FJ 1JG 1KG 1LG •...
  • Page 138 Item # FRUs FRU # Hard disk drive, 160GB SATA Solid State Drive (SSD) - MLC-SM160, 2.5" • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 03T7026 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO •...
  • Page 139 Item # FRUs FRU # System board, Ibiza - Lite - 2P Intel LGA 1366, Tylersburg 36D, ICH10, C2 Stepping IOH (v1.7 - TPM enabled) • MT 4262: 11Q 12Q 14F 13J CTO • MT 4263: 39M 41J 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 57G 58G 59G 61G 62G 63G 46C 47C 48C 49C 52C 53C 54C 55C 56C 31T 32A 34A 35A 36Q 64K 64R 65K 65R 66K 66R 78J 68J 69J 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V...
  • Page 140 Item # FRUs FRU # System board, Ibiza - Lite - 2P Intel LGA 1366, Tylersburg 36D, ICH10, C2 Stepping IOH (v1.7 - TPM disabled) • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G CTO A7G A8G A9G B1G B2G •...
  • Page 141 Item # FRUs FRU # System board, Ibiza - Lite - 2P Intel LGA 1366, Tylersburg 36D, ICH10, C2 Stepping IOH (v1.6 - TPM disabled) • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G CTO A7G A8G A9G B1G B2G •...
  • Page 142 Item # FRUs FRU # System board, Ibiza - 2P Intel LGA 1366, Tylersburg 36D, ICH10 (Russia Only Ver1.2 + Rework) • MT 4262: 11Q 12Q 14F 13J CTO • MT 4263: 39M 41J 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 57G 58G 59G 61G 62G 63G 46C 47C 48C 49C 52C 53C 54C 55C 56C 31T 32A 34A 35A 36Q 64K 64R 65K 65R 66K 66R 78J 68J 69J 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V...
  • Page 143 Item # FRUs FRU # System board, Ibiza - 2P Intel LGA 1366, Tylersburg 36D, ICH10 ( Ver1.2 - w/ S3 rework + PCI 2.3 compliance rework) • MT 4262: 11Q 12Q 14F 13J CTO • MT 4263: 39M 41J 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 57G 58G 59G 61G 62G 63G 46C 47C 48C 49C 52C 53C 54C 55C 56C 31T 32A 34A 35A 36Q 64K 64R 65K 65R 66K 66R 78J 68J 69J 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V...
  • Page 144 Item # FRUs FRU # Power supply, 800 Watt power supply • MT 4262: 11Q 12Q 14F 13J CTO • MT 4263: 39M 41J 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 46C 47C 48C 49C 52C 53C 54C 55C 56C 26A 27A 28A 29A 31T 32A 34A 35A 36Q 64K 64R 65K 65R 66K 66R 78J 68J 69J 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V 71K 71R 71E 71J 72U 72F 72S 72L 72D 72Y 72G 72M 72A 72Q 72T 72C 72B 72H...
  • Page 145 Item # FRUs FRU # Power supply, 800 Watt power supply • MT 4262: 11Q 12Q 14F 13J CTO • MT 4263: 39M 41J 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 46C 47C 48C 49C 52C 53C 54C 55C 56C 26A 27A 28A 29A 31T 32A 34A 35A 36Q 64K 64R 65K 65R 66K 66R 78J 68J 69J 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V 71K 71R 71E 71J 72U 72F 72S 72L 72D 72Y 72G 72M 72A 72Q 72T 72C 72B 72H...

  • Page 146: Mechanical Frus

    Item # FRUs FRU # Power supply, 800 Watt power supply • MT 4262: 11Q 12Q 14F 13J CTO • MT 4263: 39M 41J 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 46C 47C 48C 49C 52C 53C 54C 55C 56C 26A 27A 28A 29A 31T 32A 34A 35A 36Q 64K 64R 65K 65R 66K 66R 78J 68J 69J 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V 71K 71R 71E 71J 72U 72F 72S 72L 72D 72Y 72G 72M 72A 72Q 72T 72C 72B 72H...
  • Page 147 FRUs FRU # FRU, heat sink RM bracket • MT 4262: all models • MT 4263: all models • MT 4264: all models 41R5592 • MT 4265: all models • MT 4266: all models • MT 4269: all models • MT 4272: all models FRU, mechanical shell kit •...
  • Page 148 FRUs FRU # FRU, memory chiller assembly • MT 4262: all models • MT 4263: all models • MT 4264: all models 41R5655 • MT 4265: all models • MT 4266: all models • MT 4269: all models • MT 4272: all models FRU, PS/2 card and bracket assembly •...
  • Page 149 FRUs FRU # FRU, thermal sense cable • MT 4262: all models • MT 4263: all models • MT 4264: all models 41R2511 • MT 4265: all models • MT 4266: all models • MT 4269: all models • MT 4272: all models FRU, adapter bracket kit, 2.5 to 3.5 •...
  • Page 150 FRUs FRU # FRU, speaker cable assembly • MT 4262: all models • MT 4263: all models • MT 4264: all models 41R5747 • MT 4265: all models • MT 4266: all models • MT 4269: all models • MT 4272: all models FRU, front panel switch cable assembly with plastic bracket •...
  • Page 151 FRUs FRU # FRU, rail kit (combo) • MT 4262: all models • MT 4263: all models • MT 4264: all models 41R5757 • MT 4265: all models • MT 4266: all models • MT 4269: all models • MT 4272: all models FRU, miscellaneous label kit •...
  • Page 152 FRUs FRU # FRU, cable, SATA • MT 4262: all models • MT 4263: all models • MT 4264: all models 41R5481 • MT 4265: all models • MT 4266: all models • MT 4269: all models • MT 4272: all models FRU, miscellaneous metal parts •...

  • Page 153: Keyboard And Mouse

    Keyboard and Mouse Keyboard - USB Preferred Pro FRU # Lenovo Productivity USB US English • MT 4262: 11Q 12Q CTO • MT 4263: 39M 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 57G 58G 59G 61G 62G 63G 26A 27A 28A 29A 32A 34A 35A 36Q 64R 65R 66R...
  • Page 154 Keyboard - USB Preferred Pro FRU # Lenovo Productivity USB Belgian/French • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 155 Keyboard - USB Preferred Pro FRU # Lenovo Productivity USB Hong Kong/Taiwan • MT 4262: CTO • MT 4263: 71B 71V 72B 72V 12B 12V 22B 22V 23B 23V 61B 61V 63B 63V CTO 97B 97V 98B 98V 99B 99V A1V •...
  • Page 156 34G 35G CTO • MT 4272: 14G 15G 16G 17G 18G 19G CTO 41G Lenovo Productivity USB French Canadian • MT 4262: 14F CTO • MT 4263: 67F 71F 72F 12F 22F 23F 79F 81F 82F 61F 63F CTO 97F 98F 99F A1F A2F A3F A4F B3F B4F •...
  • Page 157 Keyboard - USB Preferred Pro FRU # Lenovo Productivity USB Greek • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 158 Keyboard - USB Preferred Pro FRU # Lenovo Productivity USB Iceland • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 159 Keyboard - USB Preferred Pro FRU # Lenovo Productivity USB LA Spanish • MT 4262: CTO • MT 4263: 67S 71S 71D 71Y 72S 72D 72Y 12S 12D 12Y 22S 22D 22Y 23S 23D 23Y 79S 81S 82S 61S 61D 61Y 63S 63D 63Y CTO 97S 97D 97Y 98S 98D 98Y 99S...
  • Page 160 Keyboard - USB Preferred Pro FRU # Lenovo Productivity USB Romanian • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 161 34G 35G CTO • MT 4272: 14G 15G 16G 17G 18G 19G CTO 41G Lenovo Productivity USB Swiss French/German • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 162 34G 35G CTO • MT 4272: 14G 15G 16G 17G 18G 19G CTO 41G Lenovo Productivity USB UK English • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 163 Keyboard - USB Preferred Pro FRU # Lenovo Productivity USB US European • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 164 Keyboard - USB Preferred Pro Fingerprint Reader Keyboard FRU # Fingerprint Reader Keyboard Arabic/French • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 41R0040 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Fingerprint Reader Keyboard Belgium French •...
  • Page 165 Keyboard - USB Preferred Pro Fingerprint Reader Keyboard FRU # Fingerprint Reader Keyboard Chinese/US • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 41R0045 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Fingerprint Reader Keyboard Czech (ABB) •...
  • Page 166 Keyboard - USB Preferred Pro Fingerprint Reader Keyboard FRU # Fingerprint Reader Keyboard French Canadian • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 41R0050 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO •...
  • Page 167 Keyboard - USB Preferred Pro Fingerprint Reader Keyboard FRU # Fingerprint Reader Keyboard Hebrew • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 41R0055 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Fingerprint Reader Keyboard Hungarian •...
  • Page 168 Keyboard - USB Preferred Pro Fingerprint Reader Keyboard FRU # Fingerprint Reader Keyboard Korean • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 41R0060 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Fingerprint Reader Keyboard LA Spanish •...
  • Page 169 Keyboard - USB Preferred Pro Fingerprint Reader Keyboard FRU # Fingerprint Reader Keyboard Romanian • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 41R0065 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Fingerprint Reader Keyboard Romanian •...
  • Page 170 Keyboard - USB Preferred Pro Fingerprint Reader Keyboard FRU # Fingerprint Reader Keyboard Spanish • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 41R0070 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Fingerprint Reader Keyboard Swedish/Finnish •...
  • Page 171 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Keyboard - Full Size PS/2 FRU # Lenovo Productivity PS/2 US English • MT 4262: • MT 4263: • MT 4264: 41A5039 • MT 4265: •...
  • Page 172 Keyboard - Full Size PS/2 FRU # Lenovo Productivity PS/2 Arabic • MT 4262: • MT 4263: • MT 4264: 41A5040 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity PS/2 Arabic/French • MT 4262: •...
  • Page 173 • MT 4263: • MT 4264: 41A5045 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity PS/2 Hong Kong/Taiwan • MT 4262: • MT 4263: • MT 4264: 41A5046 • MT 4265: • MT 4266: •...
  • Page 174 • MT 4263: • MT 4264: 41A5050 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity PS/2 French Canadian • MT 4262: • MT 4263: • MT 4264: 41A5051 • MT 4265: • MT 4266: •...
  • Page 175 Keyboard - Full Size PS/2 FRU # Lenovo Productivity PS/2 Greek/US • MT 4262: • MT 4263: • MT 4264: 41A5080 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity PS/2 Hebrew • MT 4262: •...
  • Page 176 • MT 4263: • MT 4264: 41A5060 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity PS/2 LA Spanish • MT 4262: • MT 4263: • MT 4264: 41A5061 • MT 4265: • MT 4266: •...
  • Page 177 Keyboard - Full Size PS/2 FRU # Lenovo Productivity PS/2 Portuguese • MT 4262: • MT 4263: • MT 4264: 41A5064 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity PS/2 Romanian • MT 4262: •...
  • Page 178 • MT 4263: • MT 4264: 41A5070 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity PS/2 Swiss French/German • MT 4262: • MT 4263: • MT 4264: 41A5071 • MT 4265: • MT 4266: •...
  • Page 179 • MT 4263: • MT 4264: 41A5074 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity PS/2 UK English • MT 4262: • MT 4263: • MT 4264: 41A5075 • MT 4265: • MT 4266: •...
  • Page 180 Keyboard - Enhanced Performance FRU # Lenovo Productivity Enhanced Arabic • MT 4262: • MT 4263: • MT 4264: 41A4962 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity Enhanced Arabic/French • MT 4262: • MT 4263: •...
  • Page 181 • MT 4263: • MT 4264: 41A4967 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity Enhanced Hong Kong/Taiwan • MT 4262: • MT 4263: • MT 4264: 41A4968 • MT 4265: • MT 4266: •...
  • Page 182 • MT 4263: • MT 4264: 41A4972 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity Enhanced French Canadian • MT 4262: • MT 4263: • MT 4264: 41A4973 • MT 4265: • MT 4266: •...
  • Page 183 Keyboard - Enhanced Performance FRU # Lenovo Productivity Enhanced Greek/US • MT 4262: • MT 4263: • MT 4264: 41A5078 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity Enhanced Hebrew • MT 4262: • MT 4263: •...
  • Page 184 • MT 4263: • MT 4264: 41A4982 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity Enhanced LA Spanish • MT 4262: • MT 4263: • MT 4264: 41A4983 • MT 4265: • MT 4266: •...
  • Page 185 Keyboard - Enhanced Performance FRU # Lenovo Productivity Enhanced Portuguese • MT 4262: • MT 4263: • MT 4264: 41A4986 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity Enhanced Romanian • MT 4262: • MT 4263: •...
  • Page 186 • MT 4263: • MT 4264: 41A4992 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity Enhanced Swiss French/German • MT 4262: • MT 4263: • MT 4264: 41A4993 • MT 4265: • MT 4266: •...
  • Page 187 • MT 4263: • MT 4264: 41A4996 • MT 4265: • MT 4266: • MT 4269: • MT 4272: Lenovo Productivity Enhanced UK English • MT 4262: • MT 4263: • MT 4264: 41A4997 • MT 4265: • MT 4266: •...
  • Page 188 Mice FRU # Optical wheel USB mouse (400 DPI)- red wheel (primary) • MT 4262: 111Q 12Q 14F 13J CTO • MT 4263:39M 41J 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 57G 58G 59G 61G 62G 63G 46C 47C 48C 49C 52C 53C 54C 55C 56C 26A 27A 28A 29A 31T 32A 34A 35A 36Q 64K 64R 65K 65R 66K 66R 78J 68J 69J 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V 71K 71R 71E 71J 72U 72F 72S 72L 72D 72Y 72G 72M 72A 72Q 72T 72C 72B 72H 72V 72K 72R 72E...
  • Page 189 Mice FRU # Optical wheel mouse (400 DPI), USB - red wheel (secondary) • MT 4262: 111Q 12Q 14F 13J CTO • MT 4263:39M 41J 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 57G 58G 59G 61G 62G 63G 46C 47C 48C 49C 52C 53C 54C 55C 56C 26A 27A 28A 29A 31T 32A 34A 35A 36Q 64K 64R 65K 65R 66K 66R 78J 68J 69J 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V 71K 71R 71E 71J 72U 72F 72S 72L 72D 72Y 72G 72M 72A 72Q 72T 72C 72B 72H 72V 72K 72R 72E...

  • Page 190: Adapters And Miscellaneous Frus

    Adapters and miscellaneous FRUs Adapters and miscellaneous FRUs FRU # L1 IEEE 1394 PCI adapter • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 41D2781 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO •...
  • Page 191 Adapters and miscellaneous FRUs FRU # 768MB NVIDIA FX1800 (DVI + DP + DP) • MT 4262: 12Q 13J CTO • MT 4263: 13G 16G 21G 48C 53G 55G 32A 78J 68J 82U 82F 82S CTO • MT 4264: 11A CTO 46R2788 •...
  • Page 192 Adapters and miscellaneous FRUs FRU # 256MB NVIDIA NVS295 (dual DP) • MT 4262: 11Q CTO • MT 4263: 24G 26A 27A 28A 36Q 71U 71F 71S 71L 71D 71Y 71G 71M 71A 71Q 71T 71C 71B 71H 71V 71K 71R 71E 71J 72U 72F 72S 72L 72D 72Y 72G 72M 72A 72Q 72T 72C 72B 72H 72V 72K 72R 72E 72J 23U 23F 23S 23L 23D 23Y 23M 23A 23Q 23T 23C 23B 23H 23V 23K 23R 23E 23J CTO A1U A1F A1S A1P A1L A1D A1Y A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J...
  • Page 193 Adapters and miscellaneous FRUs FRU # 1GB ATI FirePro V7700 (DP+DP+DVI) • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 53Y8573 • MT 4265: CTO 96B 96H • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Soft modem V.90/V.44 •...
  • Page 194 Adapters and miscellaneous FRUs FRU # Modem phone cable • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 39K5120 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO DVI to VGA dongle •...
  • Page 195 Adapters and miscellaneous FRUs FRU # Nvidia Quadro 2000, dual link DVI, DP, DP, 1GB GDDR5 • MT 4262: CTO • MT 4263: CTO 86M 87M 88M 89M 91M 85J 83C 96C 98U 98F 98S 98P 98L 98D 98Y 98M 98A 98Q 98T 98C 98B 98H 98V 98K 98R 98E 98J A3U A3F •...
  • Page 196 Adapters and miscellaneous FRUs FRU # Nvidia Telsa 2050, 3GB GDDR5 • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 89Y8630 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Nvidia Quadro 600, Dual link DVI, DP, 1GB GDDR3 •...
  • Page 197 Adapters and miscellaneous FRUs FRU # Nvidia Quadro 2000D Dual DVI 1 GB GDDR5 • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 03T8418 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO 256MB NVIDIA NVS295, PCIe x1 (Dual DP) •...

  • Page 198: Power Cords

    Power Cords Power Cords FRU # Line Cord - US • MT 4262: 14F CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 67F 67S 57G 58G 59G 61G 62G 63G 26T 27T 28T 29T 31T 32T 33T 34T 35T 26A 27A 28A 29A 32A 34A 35A 71U 71F 71S 71D 71L 71A 71T 72U 72F 72S 72D 72L 72A 72T 12U 12F 12S 12D 12L 12A 12T 22U 22F 22S 22D 22L 22A 22T 23U 23F 23S 23D 23L 23A 23T 79U 79F 79S 81U 81F 81S 82U 82F 82S 61U 61F 61S 61L 61D 61A 61T 63U...
  • Page 199 Power Cords FRU # Line Cord - Brazil (Portuguese) • MT 4262: CTO • MT 4263: 71P 72P CTO 97P 98P 99P A1P • MT 4264: CTO 41R3270 • MT 4265: CTO 94P • MT 4266: CTO • MT 4269: CTO •...
  • Page 200 Power Cords FRU # Line Cord - Hong Kong, UK, Ireland, Singapore, Malaysia, Brunei, Hong Kong • MT 4262: CTO • MT 4263: 26A 27A 28A 29A 31A 32A 33A 34A 35A 71A 72A 12A 22A 23A 61B 61H 62B 62H CTO 92A 93A 94A 95A 97B 97H 97A 98B 98H 98A 99B 99H 99A A1B A1H A1A A7G A8G A9G B1G B2G •...
  • Page 201 Power Cords FRU # Line Cord - Denmark • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 202 Power Cords FRU # Line Cord - South Africa • MT 4262: CTO • MT 4263: 39M 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 26A 27A 28A 29A 31A 32A 33A 34A 35A 71M 72M 71G 72G CTO 86M 87M 88M 89M 91M 92A 93A 94A 95A 97G 97M 97A 98G 98M 98A 99G 99M 99A A1G A1M A1A A7G A8G A9G B1G B2G •...
  • Page 203 Power Cords FRU # Line Cord - Japan and Japanese English • MT 4262: CTO • MT 4263: 41J 78J 68J 69J 71J 72J 12R 12E 22R 22E 23R 23E 61E 61J 63E 63J CTO 84J 85J 97J 98J 99J A1J A5J A6J •...
  • Page 204 Power Cords FRU # Line Cord - China • MT 4262: CTO • MT 4263: 46C 47C 48C 49C 52C 53C 54C 55C 56C 71C 72C 12C 22C 23C 61C 63C 74C CTO 83C 96C 97C 98C 99C A1C • MT 4264: CTO 41R3257 •...
  • Page 205 Power Cords FRU # Line Cord - Australia / New Zealand • MT 4262: CTO • MT 4263: 39M 71M 72M 12M 22M 23M CTO 86M 87M 88M 89M 91M 97M 98M 99M A1M • MT 4264: CTO 41R3197 • MT 4265: 37M 67M 68M 69M 13M CTO 79M 81M 82M 94M 1AM 1BM 1CM •...
  • Page 206 Power Cords FRU # Line Cord - Italy • MT 4262: CTO • MT 4263: 67S 71S 71Y 71L 71G 72S 72Y 72L 72G 12S 12Y 12L 22S 22Y 22L 23S 23Y 23L CTO 97S 97Y 97L 98S 98Y 98L 99S 99Y 99L A1S A1Y A1L A7G A8G A9G B1G B2G 41R3233 •...
  • Page 207 Power Cords FRU # Line Cord - Israel • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...

  • Page 208: Recovery Discs

    Recovery discs Windows XP Professional 64 Mono Recovery CD XP Professional 64 Mono FRU # Japanese • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 03W2826 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO •...
  • Page 209 Windows Vista Business 32 FRU # French • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3673 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO German • MT 4262: CTO •...
  • Page 210 Windows Vista Business 32 FRU # Japanese • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y5662 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Norwegian • MT 4262: CTO •...
  • Page 211 Windows Vista Business 32 FRU # Czech • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3678 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Finnish • MT 4262: CTO •...
  • Page 212 Windows Vista Business 32 FRU # Hungarian • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3682 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Greek • MT 4262: CTO •...
  • Page 213 Windows Vista Business 32 FRU # Korean • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3688 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Slovenian • MT 4262: CTO •...
  • Page 214 Windows Vista Business 32 FRU # Slovakian • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3696 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Arabic Localized • MT 4262: CTO •...

  • Page 215: Windows Vista Business 64 Recovery Cd

    Windows Vista Business 32 FRU # C&L3 Bel Lux (EN FR GR NL) • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3703 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO English for India •...
  • Page 216 Windows Vista Business 64 FRU # French • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3772 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO German • MT 4262: CTO •...
  • Page 217 Windows Vista Business 64 FRU # Japanese • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y5665 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Norwegian • MT 4262: CTO •...
  • Page 218 Windows Vista Business 64 FRU # Czech • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3777 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Finnish • MT 4262: CTO •...
  • Page 219 Windows Vista Business 64 FRU # Hungarian • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3781 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Greek • MT 4262: CTO •...
  • Page 220 Windows Vista Business 64 FRU # Korean • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3787 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Slovenian • MT 4262: CTO •...
  • Page 221 Windows Vista Business 64 FRU # Hebrew • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 64Y3791 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO C&L1 Nordics (EN DK FI NO SV) •...

  • Page 222: Windows 7 Professional 64 Recovery Cd

    Windows 7 Professional 64 Recovery CD Windows 7 Professional 64 FRU # US English • MT 4262: CTO • MT 4263: 39M 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 67U 57G 58G 59G 61G 62G 63G 26A 27A 28A 29A 32A 34A 35A 36Q 64R 65R 66R 71U 71L 71G 71M 71A 71Q 71H 71R 71E 72U 72L 72G 72M 72A 72Q 72H 72R 72E 12U 12L 12M 12A 12Q 12H 12R 12E 22U 22L 22M 22A 22Q 22H 22R 22E 23U 23L 23M 23A 23 23H 23R 23E 79U 81U 82U 61U 63U 61L 63L 61M 61A 61Q 63M 63A...
  • Page 223 Windows 7 Professional 64 FRU # Czech • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 224 Windows 7 Professional 64 FRU # Korean • MT 4262: CTO • MT 4263: 64K 65K 66K 71K 72K 12K 22K 23K 61K 63K CTO 97K 98K 99K A1K • MT 4264: CTO 03W2805 • MT 4265: 33K 53K 13K CTO 94K •...
  • Page 225 Windows 7 Professional 64 FRU # Hebrew • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 226 Windows 7 Professional 64 FRU # Hong Kong • MT 4262: CTO • MT 4263: 71B 72B 12B 22B 23B 61B 63B CTO 97B 98B 99B A1B • MT 4264: CTO 03W2802 • MT 4265: 13B CTO 94B • MT 4266: CTO •...
  • Page 227 Windows 7 Professional 64 FRU # C&L Bel Lux (EN FR GR NL) • MT 4262: CTO • MT 4263: 11G 12G 13G 14G 15G 16G 17G 18G 19G 21G 22G 23G 24G 25G 57G 58G 59G 61G 62G 63G 71G 72G CTO 97G 98G 99G A1G A7G A8G A9G B1G B2G •...
  • Page 228 Windows 7 Professional 64 FRU # Brazilian Portuguese • MT 4262: CTO • MT 4263: 97P 98P 99P A1P • MT 4264: CTO 03W2794 • MT 4265: 94P • MT 4266: • MT 4269: • MT 4272: 41P Hungary • MT 4262: CTO •...

  • Page 229: Windows 7 Ultimate 64 Recovery Cd

    Windows 7 Professional 64 FRU # Japanese • MT 4262: CTO • MT 4263: CTO • MT 4264: CTO 03W2821 • MT 4265: CTO • MT 4266: CTO • MT 4269: CTO • MT 4272: CTO Windows 7 Ultimate 64 Recovery CD Windows 7 Ultimate 64 FRU # US English...
  • Page 230 ThinkStation Hardware Maintenance Manual...

  • Page 231: Chapter 11. Additional Service Information

    • To determine the current Level of BIOS: – Start the Setup Utility program. • Sources for obtaining the latest level BIOS available 1. Lenovo support web site: http://www.lenovo.com/support 2. Lenovo Customer Support Center 3. Levels 1 and 2 Support To update (flash) the BIOS, see “Updating (flashing) the BIOS”...

  • Page 232: Updating (Flashing) The Bios From Your Operating System

    Updating (flashing) the BIOS from your operating system Note: Because Lenovo makes constant improvements to its Web sites, the Web page contents are subject to change without notice, including the contents referenced in the following procedure.

  • Page 233: Power Management

    7. Move the jumper from the standard position (pin 1 and pin 2) to the maintenance position (pin 2 and pin 3). 8. Reinstall any parts and reconnect any cables that have been removed or disconnected. 9. Reinstall the computer cover and reconnect the power cords for the computer and monitor to electrical outlets.
  • Page 234 Table 2. System memory speed DIMM type and speed PC3-10600U PC3-8500U PC3-10600R PC3-8500R 1 GB, 2 1 GB, 2 GB, 4 1 GB, 2 DIMM size (capacity) 1 GB, 2 GB, 4 GB GB, 4 GB, 8 GB GB, 4 8 GB, 16 GB Number of DIMMs installed 1 to 3...
  • Page 235 Table 2. System memory speed (continued) Intel 1333 1333 1066 1333 1333 1066 1066 800 MHz Xeon X5650 Intel 1333 1333 1066 1333 1333 1066 1066 800 MHz Xeon X5660 Intel 1333 1333 1066 1333 1333 1066 1066 800 MHz Xeon X5667 Intel...
  • Page 236 ThinkStation Hardware Maintenance Manual...

  • Page 237: Appendix A. Notices

    Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.

  • Page 238: Television Output Notice

    European conformance CE mark The emission notices information is available in the ThinkStation Safety and Warranty Guide that came with your computer. Trademarks The following terms are trademarks of Lenovo in the United States, other countries, or both: Lenovo The Lenovo logo PS/2...

  • Page 239: Index

    Setup Utility program startup device sequence, changing temporary, selecting Lenovo ThinkVantage Toolbox system board Lenovo ThinkVantage Tools locating parts memory module memory module installing, replacing system board temporary startup device memory speed the BIOS, updating (flashing) 225–226 © Copyright Lenovo 2010, 2011...
  • Page 240 updating (flashing) the BIOS updating (flashing) the BIOS user, password using passwords Setup Utility program viewing and changing settings ThinkStation Hardware Maintenance Manual...
  • Page 242 Part Number: 89Y7336 Printed in USA (1P) P/N: 89Y7336 *89Y7336*...
