INSTALLATION AND SERVICE MANUAL
ESCORT III, JUICE DISPENSER
SPECIFICATIONS
DIMENSIONS:
•
Width
•
Depth
•
Height (with legs)
WEIGHT:
•
Shipping
•
Empty
•
Operating
ELECTRICAL REQUIREMENTS (Running):
•
115V/60Hz
WATER REQUIREMENTS:
•
Minimum flowing pressure of 25 PSI (1.76 kg/cm
flow rate of three (3) ounces (88.7 mI) per second.
•
Connection 5/8 inch - 18 male flare (3/8 inch flare).
COMPRESSOR:
1/3 HP
CONCENTRATE CONTAINER CAPACITY:
•
Left container
•
Middle container
•
Right container
•
Concentrate container
constant temperature
•
Ice bath water capacity
•
Ice bank
DRINK CAPACITY:
Four (4) five (5) ounce (148 cc) drinks per minute under 45
This manual supersedes Installation and Service Manual 28-0003/03, dated 01/30/03
• NORTH AMERICA – 210-310-7245 • INTERNATIONAL SALES – 210-310-7242 • CUSTOMER SERVICE – 210-310-7242 •
• LATIN AMERICA – 210-310-7245 • EUROPE – 32-2-755-2399 • PACIFIC – 61-8-8268-1978 •
"Lancer" is the registered trademark of Lancer • Copyright — 2006 by Lancer, all rights reserved
"Minute Maid" and "Minute Pak" are registered trademarks of The Coca-Cola Company.
dinecompany.com
FOR THE
14 1/16 inches
(357 mm)
23 1/8 inches
(587 mm)
26 1/2 inches
(673 mm)
152 pounds (68.95 kg)
135 pounds (61.24 kg)
180 pounds (81.65 kg)
7 Amps
128 ounces (3.79 Liters)
106 ounces (3.14 Liters)
128 ounces (3.79 Liters)
o
o
35
F (1.7
C)
320 ounces; 2.5 U.S. gallons
(9.07 kg; 9.46 L)
8.0 pounds (3.63 kg)
6655 LANCER BLVD. • SAN ANTONIO, TEXAS 78219 USA • (210) 310-7000
FAX SALES
FAX Engineering: • 210-310-7096
Please refer to the Lancer web site (www.lancercorp.com) for
information relating to Lancer Installation and Service Manuals,
Instruction Sheets, Technical Bulletins, Service Bulletins, etc.
2
) at a
o
o
o
F (7.2
C) at 75
F (23.9
o
C) ambient inlet water.
REV:
03/31/06
P.N. 28–0003/04
