Luggage Compartment Lamp,
Footwell Lamp and Liftgate Lamp
1. Carefully pry out the lamp.
2. Remove the bulb.

CHANGING A BULB

WARNINGS
Switch the lamps and the ignition off.
Failure to follow this warning could
result in serious personal injury.
Make sure the bulbs have cooled
down before removing them. Failure
to follow this warning could result in
serious personal injury.
Note: Only fit bulbs of the correct
specification.
Note: The following instructions describe
how to remove the bulbs. Fit replacements
in the reverse order unless otherwise stated.
Fiesta (CCN)
Maintenance
Headlamp
A
B
C
Note: Remove the covers to gain access to
the bulbs.
Headlamp Low Beam
1. Remove the headlamp. See
Removing a Headlamp (page 163).
2. Remove the cover.
3. Disconnect the electrical connector.
4. Release the clip and remove the bulb.
Note: Do not touch the glass of the bulb.
170
Headlamp low beam
Headlamp high beam and side
lamp
Direction indicator
