Changing A Bulb - Vehicles With: 3-Door - Ford Fiesta Owner's Manual

2. Remove the screws.
3. Disconnect the electrical connector.
4. Remove the headlamp.
Note: When fitting the headlamp, make
sure that you reconnect the electrical
connector correctly.
Note: When fitting the headlamp, make
sure that you fully engage the headlamp in
the retaining clips.
Fiesta (CCN)
Maintenance
CHANGING A BULB - VEHICLES
WITH: 3-DOOR
Switch the lamps and the ignition off.
Let the bulb cool down before
removing it.
Note: Only fit bulbs of the correct
specification.
Note: The following instructions describe
how to remove the bulbs. Fit replacements
in the reverse order unless otherwise stated.
Headlamp
Note: Remove the covers to gain access to
the bulbs.
A
B
C
Headlamp Low Beam
1. Remove the headlamp. See
Removing a Headlamp (page 163).
164
WARNINGS
Headlamp low beam
Headlamp high beam and side
lamp
Direction indicator
