The Allied Hydraulic Snowblower is offered in three main sizes: 60", 72" and 84". The 72" and 84" sizes are also made available in a higher capacity version for use on equipment with high flow hydraulic systems.
Safety - Hydraulic Snowblower Safety Safety Instructions Remember, YOU are the key to safety. Good safety practices not only protect you, but also the people around you. Make these practices a working part of your safety program. Be certain that everyone operating this equipment is familiar with the recommended operating and maintenance procedures and follows all the safety precautions.
• Read and understand the Operator’s Manual and all safety signs before operating, servicing, adjusting, repairing, or unplugging the equipment. • Do not attempt any unauthorized modifications to your Allied by Farm King product as this could affect function or safety, and could affect the life of the equipment.
Safety - Hydraulic Snowblower Transport Safety • Review Transport Safety instructions in tractor manual before moving. • Check with local authorities regarding transport on public roads. Obey all applicable laws and regulations. • Make sure the SMV (Slow Moving Vehicle) emblem and all the lights and reflectors that are required by the local highway and transport authorities are in place, are clean, and can be seen clearly by all overtaking and oncoming traffic.
Safety - Hydraulic Snowblower Safety Signs • The following illustration shows the approximate location and detail of safety signs. • Keep all safety signs clean and legible and replace any that are damaged or missing. • When original parts are replaced, any safety signs affixed to those parts should be replaced as well.
Assembly - Hydraulic Snowblower Assembly Instructions Unpack all components and remove from shipping material. Verify quantities provided with parts listing. NOTE: Depending on your shipping/assembly configuration, steps 2-3 may already be completed. 2. Begin with spout to snowblower assembly: - Place UHMV spout ring (815503) on top of spout base plate of snowblower fan housing.
Page 11
Assembly - Hydraulic Snowblower 4. Universal Wiring Harness Installation (Optional): A three piece universal wiring harness (816225) is provided to allow for quick and easy disconnects and hookups. The snowblower segment is to be left permanently installed to snowblower and has a coupling that can be connected/disconnected conveniently with main hydraulics.
Start-up and Operation - Hydraulic Snowblower Start-up and Operation Instructions The hydraulic system of the snowblower is configured so that the fan motor is prevented from stalling in a snow overload condition. A significant increase in fan loading increases the hydraulic pressure drop across the fan motor, which in turn diverts flow away from the auger motor, thereby reducing/stopping further fan loading and simultaneously providing more power to clear the fan.
Bolt Torque - Hydraulic Snowblower Bolt Torque Checking Bolt Torque The tables shown below give correct torque values for various bolts and hex bolts. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide.
Troubleshooting - Hydraulic Snowblower Troubleshooting Symptom Probable Cause Remedy Nothing works • Hydraulic valve not engaged • Engage to full detent • One or more quick couplers • Fully engage all couplers not completely engaged • Incorrect flow direction • Switch flow direction using controls or swapping hose ends • Defective quick coupler...
Parts - Hydraulic Snowblower When Ordering Parts Always give your dealer the Model, Color and Serial Number of your machine to assist them in ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of interest to exactly identify the required part.
Page 21
Parts - Hydraulic Snowblower Item Part Number Description 815497 19T 1/2" Pitch Spout Rotation Sprocket 815498 Hydraulic Manifold - Shield 815499 Spout Rotation Motor - Shield 815503 UHMW Spout Ring 815505 Flat Head Socket Cap 3/8-16 x 1.25 815506 Snowblower Spout Spacer 815507 Snowblower Spout Clamp 815508...
Parts - Hydraulic Snowblower Hose Assembly - Model 60" SF Part Number Description 816191 Hose 3/8 x 66 9/16 Fjic x 9/16 F90 Hose 3/4 x 23.8 1-16 Fjic Jic 45 816206 816207 Hose 3/4 x 27.3 1-1/16 Fjic x 45 816208 Hose 5/8 x 25 7/8 Fjic x 7/8 Jic 45 816209...
Parts - Hydraulic Snowblower Hose Assembly - Model 72" SF Part Number Description 816191 Hose 3/8 x 66 9/16 Fjic x 9/16 F90 Hose 3/4 x 23.8 1-16 Fjic Jic 45 816206 816207 Hose 3/4 x 27.3 1-1/16 Fjic x 45 816209 Hose 3/8 x 23 9/16 Fjic x Jic 45 816211...
Parts - Hydraulic Snowblower Hose Assembly - Model 72" HF Part Number Description 816059 Hose 3/8 x 43.4 9/16 Fjic 45 Hose 5/8 x 32 7/8 Fjic x 7/8 Jic 45 816060 816061 Hose 3/8 x 27.7 9/16 Fjic x Jic 45 816191 Hose 3/8 x 66 9/16 Fjic x 9/16 F90 816214...
Parts - Hydraulic Snowblower Hose Assembly - Model 84" SF Part Number Description 816191 Hose 3/8 x 66 9/16 Fjic x 9/16 F90 Hose 3/4 x 23.8 1-16 Fjic Jic 45 816206 816207 Hose 3/4 x 27.3 1-1/16 Fjic x 45 816209 Hose 3/8 x 23 9/16 Fjic x Jic 45 816212...
Parts - Hydraulic Snowblower Hose Assembly - Model 84" HF Part Number Description 816059 Hose 3/8 x 43.4 9/16 Fjic 45 Hose 3/8 x 27.7 9/16 Fjic x Jic 45 816061 816191 Hose 3/8 x 66 9/16 Fjic x 9/16 F90 816214 Hyd SB Main Return Hose 816189...
Page 29
Parts - Hydraulic Snowblower Item Part Number Description 816420 Plug - Right X3929 Seal Kit Relief Valve - High Flow 816421 Relief Valve - Standard Flow 816534 X3930 Seal Kit 816422 Plug - Top Right X3930 Seal Kit 816423 Plug - Left Front X3932 Seal Kit 816424...
Hole Locations for Width Extendor Kits - Hydraulic Snowblower Hole Locations for Width Extendor Kits HIGH FLOW WIDTH STANDARD FLOW WIDTH CENTER OF HOLE IS FLUSH WITH SURFACE 3.64 6.25 6.25 0.53 6.25 0.53 6.25 6.25 6.25 6.25 1.75 1.75 Item Part Number Description...
Page 33
Maintenance - Hydraulic Snowblower Part Number Description 816049 Electric Switch Housing - Base 816050 Electric Switch Housing - Top 816220 Hyd SB Harness, Cab 816221 Hyd SB Harness, Battery 816222 Hyd SB Harness, Valve 816223 Eaton Switch - Left & Right 816224 Eaton Switch - Up &...
Pictorial References - Hydraulic Snowblower Pictorial References Harness secured to hydraulic hose Manifold Hookups Top view of snowblower connections Harness routed with existing hydraulic lines on lift arm Harness Coupler Main harness routing Main harness routing Main harness routing...
Page 35
Pictorial References - Hydraulic Snowblower Main harness routing (cab lifted) Negative Positive Extra length coiled Main Harness power connections Coupler located behind operator station Harness follows existing cab harness Extra length coiled Coupler from main harness In-cab harness routing Control Box In-cab harness routing Chute hydraulic hook-ups...
Warranty - Hydraulic Snowblower Allied by Farm King Limited Warranty This document limits your warranty rights. Base Limited Warranty Buhler Industries Inc. provides this warranty only to original retail purchasers of its product. Buhler Industries Inc. warrants to such purchasers that all Buhler Industries Inc. manufactured parts and components used and serviced as provided for in the Operator’s Manual shall be free...
Page 37
Warranty - Hydraulic Snowblower Authorized Dealer and Labor Costs Repairs eligible for labor under this limited warranty must be made by Buhler Industries Inc. or an authorized Farm King dealer. Buhler Industries Inc. retains the exclusive discretion to determine whether it will pay labor costs for warranty repairs or replacements, and the amount of such costs that it will pay and the time in which the repairs will be made.
Page 38
Warranty - Hydraulic Snowblower (Note that some provinces or states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations and exclusion may not apply to you.) This warranty gives you specific legal rights and you may also have other rights, which vary from province to province or state to state.
