  • Page 1 Model : ASD126 True Day/Night Vandal Resistant 12x Mini PTZ Dome Instruction Guide...
  • Page 3 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN THE COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage"...
  • Page 4 NOTICE Important Safety Guide 1. Read, heed and follow all the Instructions Read all the safety and operating instructions before using the product. 2. Keep this manual Keep this manual for reference in future. 3. Attachments / Accessories Use only the attachments or accessories specified by the manufacturer. 4.
  • Page 5 NOTICE Caution  Operating  Before using, make sure that the power supply and others are properly installed.  While operating, if any abnormal condition or malfunction is observed, stop using the product immediately and then contact your local dealer. ...

  • Page 6: Table Of Contents

    TABLE OF CONTENTS ① Introduction Features Package Components Main Part Description ② Installation DIP Switch Setup Installation with Ceiling Mount Bracket Installation with Wall Mount Bracket Wiring and Cabling ③ Operation Check Point before Operation Check Points for Preset and Pattern Function before Operation OSD Menu Reserved Preset (Hot Keys) Preset...

  • Page 7: Features

    INTRODUCTION Features  Powerful Zoom Camera & Setup Options  Image Sensor : Sony 1/4" Super-HAD CCD (12 model) Sony 1/4" ExView-HAD PS CCD (12 WDR model) : 12 Optical Zoom, 12 Digital Zoom  Zoom  Day & Night, Privacy Mask and WDR (12 WDR models only) ...
  • Page 8 INTRODUCTION  MAX. 8 sets of Swing are programmable. This function is that the camera moves repetitively between two preset positions at programmed speeds.  MAX. 4 Patterns are programmable. This function is that the camera memorizes the path (mostly curve path) by the joystick of the controller and revives the trajectory operated by the joystick as closely as possible.
  • Page 9 INTRODUCTION  Perfect Outdoor Environment Compatibility and Easy Installation  The fans and heaters are built-in in the camera for cold and hot temperature environment. Also idealistic mechanical design protects the camera from water and dust. (IP66 when installed properly with wall mount bracket only / Only for outdoor models) ...

  • Page 10: Package Components

    INTRODUCTION Package Component  Product & Accessories  Main Body & Surface Mount Bracket  Default Accessories [Main Cable, Wrench]  Accessories for The Models with Alarm In/Out  Accessories for The IP Addressable Models Function [I/O Cable] [Crossover LAN Cable, Audio Cable, CD] ...

  • Page 11: Main Part Description

    INTRODUCTION Main Part Description  Dome Cover Do not detach the protection vinyl from the dome cover before finishing all the installation process to protect the dome cover from scratches or dust.  DIP Switch Used to set up camera IDs and protocols. ...

  • Page 12: Dip Switch Setup

    INSTALLATION DIP Switch Setup Before installing the camera, set up the DIP switch to configure the camera ID and the com munication protocol.  Camera ID Setup  ID numbers of cameras are set up with binary numbers. See the examples shown below. Binary Value ex) ID=5 ex) ID=10...
  • Page 13 INSTALLATION  Communication Protocol Setup  Select an appropriate Protocol with the DIP switch combination. Switch Mode Protocol (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps Others Reserved  Match the camera protocol with the camera protocol in the setting of your DVR or controller to control the camera.
  • Page 14 INSTALLATION  Terminal Resistor Setup The terminal resistor is used for the following cases.  Case 1 : In case that the control cable length between a camera and a controller is relatively very long (1:1 Connection) If the communication cable length is very long, the electrical signal will bound in the terminal point.

  • Page 15: Installation With Ceiling Mount Bracket

    INSTALLATION Installation with Ceiling Mount Bracket ① Remove the ceiling tile from the ceiling ② Pull the wire(s) and cable(s) for the and cut a hole whose diameter is system as below. Wire the cable(s) to the 30~40mm on the ceiling tile to pass the ports.

  • Page 16: Installation With Wall Mount Bracket

    INSTALLATION Installation with Wall Mount Bracket ① Make a hole whose diameter is 30~40mm ② Pull the wire(s) and cable(s) for the on the mounting surface to pass the system as below. Wire the cable(s) to the wire(s) cable(s) through ports.

  • Page 17: Wiring And Cabling

    INSTALLATION Wiring and Cabling  Port Description  Main Cable Port Pin Number (RJ45) Connector / Wire Color Signal Video + BNC Connector Video  RS-485 + RS-485  Yellow Orange Power + Power  White  I/O Cable Port Pin Number (RJ25) Wire Color Signal Blue...
  • Page 18 INSTALLATION  Power Description  Carefully check the voltage and current capacity of the rated power. The rated power is indicated in the back of main unit. Input Voltage Current Model Range Consumption INDOOR 0.8 A Analog Model OUTDOOR 2.5 A DC12V DC 11V ~ 18V Model...
  • Page 19 INSTALLATION  Video  Use BNC coaxial cable only.  Alarm Input Sensor Input is detected by Short or Open between Sensor IN Terminal and COMMON Terminal. If you want to use Alarm Input, the types of sensors must be selected. The sensor types are divided into Normal Open and Normal Close.

  • Page 20: Check Point Before Operation

    OPERATION Check Points before Operation  Before turning on the system, check if the wire(s) and cable(s) are connected properly.  Check if the camera ID on the controller is properly selected. The camera ID must be identical to that of the target camera. The camera ID can be checked by reading the DIP switch of the camera or on OSD.

  • Page 21: Osd Menu

    OPERATION OSD Menu With OSD menu, the system can be properly configured for each  Function application.  Entering into OSD Go Preset [95] Reserved Presets (Hot Keys)  Description Some Preset numbers are reserved to change some parameters without entering into OSD menu.

  • Page 22: Preset

    OPERATION Preset MAX. 127 positions are programmable. The Preset number can be  Function assigned from 1 to 128 except 95. Preset 95 is reserved for entering into OSD menu. Camera parameters such as White Balance, Auto Exposure and others can be set up independently and each preset can have its own parameter values independently from the other persets.

  • Page 23: Pattern

    OPERATION Pattern This function is that the camera memorizes the path (mostly curve  Function path) by the joystick of the controller and revives the trajectory operated by joystick as closely as possible. MAX. Patterns programmable Maximum 1200 communication commands can be programmed in a pattern. ...

  • Page 24: Group

    OPERATION Group This function is that the camera memorizes the combination of  Function Presets, Pattern and/or Swings sequently and runs Presets, Pattern and/or Swings repetitively. MAX. 8 sets of Group are programmable. Each group can have MAX. 20 actions which are the combination of Preset, Pattern and Swing.
  • Page 25 OPERATION  Alarm Input 3 Alarm Inputs are available. When external sensors activate, the camera runs pre-defined actions such as Preset, Pattern, Swing and Group. After the pre-defined time period passed, “Post Alarm” activates, which is pre-defined. Note that only the latest alarm input is effective when multiple sensors are activated at the same time.

  • Page 26: Osd Display

    OPERATION OSD Display Action Title Preset Label LABEL12345 PRESET1 Alarm Information I:-2- O:1 Camera ID CAM 1 15/4/x1/N P/T/Z Information  P/T/Z Information Displays the amount of pan from zero degree vertical, the amount of tilt from zero degree horizontal and current compass direction. Also identifies the amount of the zoom magnification.

  • Page 27: ④ Osd Menu

    OSD MENU Quick Programming Guide  The menu items with < > always have sub-menus.  To go to submenus or make the cursor move to the right, press NEAR key.  To go to the previous-upper level menus, press FAR key. ...

  • Page 28: Display Setup

    OSD MENU Display Setup Display setup allows you to program how labels are DISPLAY SETUP displayed on the monitor. In case of AUTO, the labels are ------------------------ displayed on the monitor when there are any changes in CAMERA ID parameters. PTZ INFORMATION AUTO ACTION TITLE...

  • Page 29: Privacy Zone Mask Setup

    OSD MENU  Compass Direction Setup Move the camera to a target position and press NEAR SET NORTH DIRECTION button to save the direction as North. The direction is the ------------------------ reference direction to assign other compass directions. MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL Privacy Zone Mask Setup...
  • Page 30 OSD MENU  Privacy Zone Mask Area Setup Move your camera to an area to mask. Then a mask and the EDIT MASK 1 menu to adjust the mask size will be displayed. ------------------------ MOVE TO TARGET POSITION [NEAR:SELECT/FAR:CANCEL]  Privacy Zone Mask Size Setup Adjusts the mask size.

  • Page 31: Camera Setup

    OSD MENU Camera Setup Sets the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------  Focus Mode [AUTO/MANUAL/SEMIAUTO] FOCUS MODE SEMIAUTO Sets camera Focus mode. DIGITAL ZOOM IMAGE FLIP  SEMIAUTO Mode SHARPNESS This mode automatically exchanges focus STABILIZATION modes between Manual Focus mode and <WHITE BALANCE SETUP>...
  • Page 32 OSD MENU  Stabilization [ON/OFF] Compensates image vibrations by wind or others. The images with vibrations are compensated by Digital Zoom function and the image resolution with this function should be lower than normal image resolution when this function is turned on.
  • Page 33 OSD MENU  Auto Exposure Setup  Backlight [ON/OFF] or [OFF/BLC/WDR] AE SETUP - GLOBAL Sets Backlight Compensation. 12 WDR ------------------------ model has WDR(Wdie Dynamic Range) BACKLIGHT function. DAY/NIGHT AUTO BRIGHTNESS This function is disabled when Iris is IRIS AUTO Manual mode.
  • Page 34 OSD MENU  SENS-UP [AUTO(2~256)/OFF] Sets SENS-UP. This setting activates Slow Shutter function when luminance of image (signal) is too dark. It is possible to set up the maximum number of frames piled up one on another by Slow Shutter function.

  • Page 35: Motion Setup

    OSD MENU Motion Setup Sets the general functions of Pan/Tilt motions. MOTION SETUP  Motion [ON/OFF] ------------------------ MOTION LOCK Lock If Motion Lock is set to ON, it is impossible to PWR UP ACTION set up and delete Preset, Swing, Pattern and AUTO FLIP Group.
  • Page 36 OSD MENU  Parking Action Setup This feature allows the camera to begin a specified action PARKING ACTION SETUP after a programmed time of inactivity. ------------------------ PARK ENABLE  Park Enable [ON/OFF] WAIT TIME 00:10:00 If Park Enable is set to ON, the camera PARK ACTION HOME runs an assigned function automatically if...
  • Page 37 OSD MENU  Alarm Input Setup Defines Alarm Function. When an alarm is receive, an ALARM INPUT SETUP input signal to the camera triggers the user-defined action ------------------------ programmed for the alarm. ALARM NO.  Alarm No [1~3] TYPE N.OPEN ACTION NOT USED Selects a sensor number to set up.

  • Page 38: Preset Setup

    OSD MENU Preset Setup  Preset [1~128] PRESET SETUP Number Selects a preset number to set up. If a ------------------------ selected preset is already defined, the PRESET NO. camera moves to the pre-defined position CLR PRESET CANCEL and preset parameters such as Label and <EDIT SCENE>...
  • Page 39 OSD MENU  Preset Scene Setup ○ 1 Use the Joystick to move the camera to a desired EDIT SCENE - PRESET 1 position. ------------------------ ○ 2 Save the preset position by pressing NEAR key. ○ 3 Press FAR key to cancel targeting the preset position. MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL]...

  • Page 40: Swing Setup

    OSD MENU Swing Setup  Swing [1~8] SWING SETUP Number Selects a Swing number to edit. If the ------------------------ selected Swing is not defined, "NOT USED" SWING NO. is displayed in the 1st Position and the 2nd 1ST POS. NOT USED 2ND POS.

  • Page 41: Pattern Setup

    OSD MENU Pattern Setup  Pattern Number [1~4 ] PATTERN SETUP Selects a Pattern number to edit. If the ------------------------ selected pattern number is not PATTERN NO. defined, "UNDEFINED" will UNDEFINED CLR PATTERN CANCEL displayed under the selected pattern RUN PATTERN number.

  • Page 42: Group Setup

    OSD MENU Group Setup  Group Number [1~8] GROUP SETUP Selects a Group number to edit. ------------------------ If the selected Group number is not GROUP NO. UNDEFINED defined, "UNDEFINED" will CLEAR GROUP CANCEL displayed under the selected Group RUN GROUP number.
  • Page 43 OSD MENU ③ Define Action, Dwell time and Option. Note that the dark EDIT GROUP 1 rectangular is the cursor. Move the cursor Left/Right to ------------------------ select an item and move cursor Up/Down to change NO ACTION ### DWELL OPT each parameter.
  • Page 44 OSD MENU ⑥ After finishing setting up, press FAR key to exit. Then the EDIT GROUP 1 cursor will move to “SAVE”. Press Near key to save the ------------------------ data. NO ACTION ### DWELL OPT ------------------------ 1 PRESET 1 00:03 360 2 NONE 3 NONE 4 NONE...

  • Page 45: System Initialize

    OSD MENU System Initialization  Clear All Data Deletes all configuration data and the system SYSTEM INITIALIZE is set to the factory default. ------------------------  Clear Display Set Initializes all the configuration data for Display. CLEAR ALL DATA CLR DISPLAY SET ...

  • Page 46: ⑤ Specifications

    SPECIFICATIONS Specifications CAMERA PART (12 WDR Model) Video Signal Format NTSC Image Sensor 1/4'' ExView-HAD PS CCD Total Pixels 811(H)508(V) 410K 795(H)596(V) 470K Effective Pixels 768(H)494(V) 380K 752(H)582(V) 440K Horizontal Resolution 560 TV Lines(Color), 600 TV Lines(B/W) Video Signal-to-Noise 52 dB (AGC Off) 12 Optical Zoom, 12 Digital Zoom Zoom Forcal Length...
  • Page 47 SPECIFICATIONS CAMERA PART (12 Model) Video Signal Format NTSC Image Sensor 1/4'' Super HAD CCD Total Pixels 811(H)508(V) 410K 795(H)596(V) 470K Effective Pixels 768(H)494(V) 380K 752(H)582(V) 440K Horizontal Resolution 560 TV Lines(Color), 600 TV Lines(B/W) Video Signal-to-Noise 52 dB (AGC Off) 12 Optical Zoom, 12 Digital Zoom Zoom Forcal Length...
  • Page 48 SPECIFICATIONS MECHANISM PART 360(Endless) Movement Range Tilt 90 Preset 360/sec. Speed 0.05 ~ 360/sec. (Proportional to Zoom) Swing 1~ 180/sec. Preset 127 Presets (Label, Independent Camera Parameter Setting) Pattern 4 Patterns [1200 Commands(Approx. 5 Minute) / Pattern] Swing 8 Swings 8 Groups (MAX.
  • Page 49 SPECIFICATIONS MECHANICAL Ceiling Mount Wall Mount Dome Polycarbonate Material Internal Polycarbonate, ABS External Aluminium 107. 5mm /  4.2” Dome Size 158.2216 mm Dimension 274.5227.3 mm Weight Approx 2.6 Kg Approx 2.8 Kg [Note] 1) Specification and features are subject to change without prior notice. 2) Specification and features are different by models.

  • Page 50: Dimension

    SPECIFICATIONS Dimension (Indoor/Outdoor model)  Main Body  Ceiling Mount Type  Wall Mount Type [Unit : mm] Speed Dome Camera Instruction Manual 49/49...
