This is a supplemental Service Manual for Model R-3V97. This model is quite similar to Base Model R-3V16
(Refer No. is SX433R3V16PX/). Use this supplemental manual together with the Base Model Service Manual for
Completed operation, service information, etc..
MICROWAVE MEASUREMENT ............................................................................................... Inside Front Cover
CAUTION, MICROWAVE RADIATION ................................................................................................................. 1
WARNING .............................................................................................................................................................. 1
WIRING DIAGRAM ............................................................................................................................................... 1
PICTORIAL DIAGRAM ......................................................................................................................................... 2
PARTS LIST ......................................................................................................................................................... 3
SERVICE MANUAL
MODEL
In interests of user-safety the oven should be restored to its original
condition and only parts identical to those specified should be used.

TABLE OF CONTENTS

SHARP CORPORATION
MICROWAVE OVEN
R-3V97
R-3V97
S9632R3V97PX/
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R-3V97 and is the answer not in the manual?

Questions and answers

Related Manuals for Sharp R-3V97

Summary of Contents for Sharp R-3V97

  • Page 1: Table Of Contents

    This is a supplemental Service Manual for Model R-3V97. This model is quite similar to Base Model R-3V16 (Refer No. is SX433R3V16PX/). Use this supplemental manual together with the Base Model Service Manual for Completed operation, service information, etc..

  • Page 2: Microwave Measurement

    R-3V97 MICROWAVE MEASUREMENT After adjustment of door latch switches, monitor switch NARDA 8100 and door are completed individually or collectively, the NARDA 8200 following leakage test must be performed with a survey HOLADAY HI 1500 instrument and it must be confirmed that the result meets...

  • Page 3: Caution Microwave Radiation

    R-3V97 CAUTION MICROWAVE RADIATION DO NOT BECOME EXPOSED TO RADIATION FROM THE MICROWAVE GENERATOR OR OTHER PARTS CONDUCTING MICROWAVE ENERGY. Service engineers should not be exposed to the microwave energy which may radiate from the magnetron or other microwave generating devices if it is improperly used or connected. All input and output microwave connections, waveguides, flanges and gaskets must be secured.

  • Page 5: Parts List

    PARTS LIST ∆ Note: The parts marked " " may cause undue microwave exposure. The parts marked "*" are used in voltage more than 250V. REF. NO. PART NO. DESCRIPTION Q'TY CODE ELECTRIC PARTS 1- 1 QSWTEA109WRE0 Timer motor 90 min. 1- 2 RMOTEA265WRE0 Fan motor...

  • Page 6: Service Information

    R-3V97 Note: The parts marked "*" are used in voltage more than 250V. REF. NO. PART NO. DESCRIPTION Q'TY CODE 5- 3 HPNL-A664WRR0 Door screen ∆ 5- 4 LSTPPA122WRF0 Latch head 5- 5 MSPRTA084WRE0 Latch spring 5- 6 PSHEPA333WRE0 Sealer film...
  • Page 7 R-3V97 4-23 1-20 4-27 7-14 1-10 7-10 4-28 7-12 1-16 4-20 4-19 4-26 1-14 7-14 7-10 4-23 7-12 4-14 1-11 1-13 4-24 7-13 1-15 7-10 4-22 6-12 7-12 1-19 6-13 4-10 6-11 4-16 1-12 4-13 4-25 4-21 4-15 4-17 1-18...

  • Page 8: Packing And Accessories

    R-3V97 CONTROL PANEL PARTS DOOR PARTS MISCELLANEOUS 80±5 Actual wire harness may be different than illustration. PACKING AND ACCESSORIES PACKING PAD KIT (CPADBA165WRK0) TURNTABLE TRAY DOOR PROTECTION SHEET SPADPA204WRE0 OPERATION MANUAL POLYETHYLENE BAG (SSAKHA014WRE0) COOK BOOK ROLLER STAY MICROWAVE OVEN...
