LO-RIDER
UNVENTED
VENT-FREE FIREBOXES
INSTALLATION AND OPERATING
INSTRUCTIONS
MODEL: LCUF36
For use with a listed gas-fired
unvented decorative room heater
not to exceed 40,000 BTU/hr. Do
Not Build a Wood Fire.
Carefully review the instructions
supplied with the decorative type
unvented room heater for the mini-
mum fi replace size requirement.
DO NOT INSTALL AN APPLIANCE
IN THIS FIREBOX UNLESS THIS
FIREBOX MEETS THE MINIMUM
DIMENSIONS REQUIRED FOR
THE INSTALLATION.
If the information in this manual is not followed
exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
– Do not store or use gasoline or other fl ammable
– WHAT TO DO IF YOU SMELL GAS
– Installation and service must be performed by
READ AND SAVE THESE INSTRUCTIONS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
WARNINGS
vapors and liquids in the vicinity of this or any
other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fi re department.
a qualifi ed installer, service agency or the gas
supplier.
