Equipment Details
A B C
RM4361 and RM4263

MODEL RM4361 AND RM4263

Two rocker switches are used to select the
electric power supply, one for 230V (B) and
one for 12V (A).
Refrigerator temperature is controlled by a
thermostat knob (C) when the refrigerator
runs on 230V.
The gas supply is turned on/off by means of
the knob (D).
Refrigerator temperature is controlled by a
thermostat (E) when the unit runs on LP gas.
Please note that the thermostat has no OFF
position.
The gas flame is electronically lit, monitored
and relit if necessary. For this the toggle
switch (F) should be ON during gas
operation.
An indicator lamp in the switch flashes when
the automatic igniter attempts to light the
burner. Otherwise this lamp is OFF.
36
Gas Operation
D E F
1. Open the shut-off valve of the gas bottle
(check that there is enough gas). Open
any on-board shut-off valve.
2. Check that the switches for mains (B) and
12V (A) operation are OFF.
3. Turn on the gas supply by pressing knob
(D) and turning it to the large flame
position.
4. Set the thermostat knob (E) to the highest
setting.
5. Throw on switch (F). A light in the switch
should now start to flash, indicating that
sparks are being generated at the burner.
6. Press button (D). This opens the flame
failure device and allows gas to flow to
the burner.
7. When the flame lights, the sparking stops
automatically and the switch stops
flashing.
8. Keep the button (D) pressed for a further
10–15 seconds to activate the flame
failure device, then release it.
230V Operation
1. Turn off the gas or 12V operation when
applicable.
2. Turn knob (C) of the thermostat to its
highest (coldest) position.
3. Set switch (B) to position I. The switch
will light up green when the power supply
is connected.
12V Operation
Your refrigerator will only operate on 12V
when the engine of the vehicle is running.
1. If applicable, turn off the gas operation.
2. Set the 12V rocker switch (A) to I. The
switch will light up red when the power
supply is connected.
WARNING:
When in transit, your refrigerator should be
run on 12V and NOT on gas.
Regulating the Temperature
It will take a few hours for the refrigerator to
reach normal operating temperature, so it is
suggested to start the refrigerator well in
advance of a journey and, if possible, to
store it with pre-cooled foodstuffs.
On 230V operation the refrigerator is
controlled by a thermostat knob (C) and this
should be set at 3–5. If a lower (colder)
temperature is desired, set the thermostat to
a higher figure.
On 12V operation the refrigerator works
continuously.
On LP gas operation the refrigerator
temperature is regulated by the gas
thermostat (E) which should be set at 3–5. If
a lower (colder) temperature is desired, set
the thermostat to a higher figure.
Caution: Only use one source of energy
at a time.
