Runco CineWall CW-95DHD User Manual

Full-hd, 2.35:1 in-wall display and digital high definition (dhd) controller/scaler/processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
I
/ I
M
N S T A L L E R
N T E G R A T O R
A N U A L
CineWall™ CW-95DHD
Full-HD, 2.35:1 In-Wall Display
and Digital High Definition (DHD™) Controller/Scaler/Processor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CineWall CW-95DHD and is the answer not in the manual?

Questions and answers

Related Manuals for Runco CineWall CW-95DHD

Summary of Contents for Runco CineWall CW-95DHD

  • Page 1 N S T A L L E R N T E G R A T O R A N U A L CineWall™ CW-95DHD Full-HD, 2.35:1 In-Wall Display and Digital High Definition (DHD™) Controller/Scaler/Processor...
  • Page 2 Runco. The trademarks reproduced in this Runco Owner’s Manual and used on the Runco Products are either owned by Runco or are licensed by Runco. You may not reproduce or use the trademarks without the prior written consent of Runco.

  • Page 3: Important Safety Instructions

    Important Safety Instructions Thank you for your purchase of this quality Runco video product! It has been designed to provide you with the quality of video that is expected in a home theater. For the best performance, please read this manual carefully as it is your guide through the menus and operation.

  • Page 4: Compliance Information

    Compliance Information DECLARATION OF CONFORMITY: Manufacturer’s Name: Runco International, LLC Manufacturer’s Address: 1195 NW Compton Drive, Beaverton, OR 97006-1992 hereby declares that the Products’ Model Numbers: CineWall™ CW-95DHD conform with the provisions of: Council Directive 2004/108/EC on Electromagnetic Compatibility; EN 55022 “Limits and methods of measurements of radio interference characteristics of information technology equipment”...
  • Page 5 Council Directive 2006/95/EC and amended by M1 and C1 on Low Voltage Equipment Safety; EN 60950 “Safety of information technology equipment, including electrical business equipment” The Technical Construction file required by this Directive is maintained at the corporate headquarters of Runco International, LLC, located at 1195 NW Compton Drive, Beaverton, OR 97006-1992.
  • Page 6 PRODUCT DISPOSAL: The Product contains small amounts of tin, lead and/or mercury. Disposal of these materials may be regulated due to environmental considerations. IMPORTANT RECYCLE INSTRUCTIONS Lamp(s) inside this product contain mercury. This product may contain other electronic waste that can be hazardous if not disposed of properly.

  • Page 7: Table Of Contents

    Table of Contents Important Safety Instructions ..................iii Compliance Information ....................iv 1. Introduction .......................1 About This Manual .......................1 Target Audience .....................1 If You Have Comments About This Manual.............1 Textual and Graphic Conventions ................1 Using This Manual ......................2 Description, Features and Benefits ................3 Key Features and Benefits ..................4 Parts List ........................4 Required Personnel, Tools and Materials ..............4...
  • Page 8 Table of Contents 4. Installation .......................25 Overview ........................25 Mounting the CineWall Chassis ..................26 Install Top Flange and Bottom Brackets on Chassis Assembly ......26 Install Chassis Assembly into Wall.................27 Secure Chassis to Wall ..................27 Installing the Screen ....................30 Powering Up the CineWall ..................33 Connecting the CineWall to AC Power ..............33 Aligning the Image ......................34 Connections to the CineWall ..................35...
  • Page 9 Table of Contents Lamp Replacement ....................75 Removing the Old Lamp ..................75 Installing the New Lamp..................76 Resetting Lamp Hours ..................76 How to Maintain Lamp Life ...................76 Filter Replacement .....................76 Determining a Changing Schedule ................76 Removing the Air Filter ..................77 Troubleshooting Tips ....................77 Status LEDs......................77 Isolating Faulty Parts.....................78 7.
  • Page 10 Table of Contents Notes: CineWall™ Installer/Integrator Manual...

  • Page 11: List Of Figures

    List of Figures 2-1. Chassis Installation Brackets ..................7 2-2. DHD Controller Front Panel ..................8 2-3. DHD Controller Rear Panel ..................10 2-4. DHD Controller/CineWall Remote Control..............11 4-1. Installing the Top Flange and Bottom Brackets............26 4-2. CineWall Screen Assembly – Rear View..............30 4-3.
  • Page 12 List of Figures Notes: CineWall™ Installer/Integrator Manual...

  • Page 13: Introduction

    Target Audience and optimize the performance of the CineWall. Runco has made every effort to ensure that this manual is accurate as of the date it was printed. However, because of ongoing product improvements and customer feedback, it may require updating from time to time. You can always find the latest version of this and other Runco product manuals on-line, at www.Runco.com.

  • Page 14: Using This Manual

    Introduction Graphic Conventions: These symbols appear in numerous places throughout the manual, to emphasize points that you must keep in mind to avoid problems with your equipment or injury: TIPS highlight time-saving short cuts and helpful guidelines for using certain features. NOTES emphasize text with unusual importance or special Note significance.

  • Page 15: Description, Features And Benefits

    Introduction Runco, the leading brand in luxury video solutions, proudly announces its new CineWall™ CW-95DHD in-wall video display, which offers custom home theater design and Description, Features installation professionals new levels of installation versatility and convenience while and Benefits achieving full-HD imagery perfection.

  • Page 16: Key Features And Benefits

    Parts List Your CineWall is shipped with the following items. If any items are missing or damaged, please contact your Runco dealer or Runco Customer Service at (800) 23-RUNCO. • CineWall™ Full HD, In-Wall Display and DHD Controller: • Chassis Assembly •...

  • Page 17: System Description

    2. System Description This section briefly describes the various CineWall system components. The Chassis Assembly is a sheet metal assembly that contains all of the active components of the CineWall, as shown below. Chassis Assembly The lower middle section of the chassis assembly contains all of the active components described below.

  • Page 18: Input Connectors And Leds

    System Description ➤ Input Connectors and The CineWall interface board is equipped with the following input connectors and LED LEDs indicators: 1. RS-232 (RJ-45) Connect the Display Control output on the DHD Controller to Option Key RS-232 this input (see Figure 2-3). 2.

  • Page 19: Chassis Installation Brackets

    System Description To reduce the overall depth of the chassis assembly for shipping, the installation brackets that secure the chassis and screen to the wall are packaged separately. These brackets Chassis Installation are installed at the customer site right before installing the chassis assembly into the wall Brackets opening: Top Flange...

  • Page 20: Other System Components

    This filter can be accessed and replaced by a service person by opening the screen and reaching in to replace it. The air filter is Runco part number 379-0012-00. Fold Mirror: The fold mirror reflects light from the display engine and directs it towards the screen.
  • Page 21 System Description 1. RUNCO ICON Lights blue to indicate that the controller is on or powering up. 2. IR SENSOR Receives IR commands from the remote control. 3. VACUUM FLUORESCENT DISPLAY Can be used instead of the On-Screen Display (OSD). Displays currently-selected menu or –...

  • Page 22: Dhd Controller Rear Panel

    System Description Figure 2-3 shows the rear connector panel on the DHD Controller. DHD Controller Rear Panel Figure 2-3. DHD Controller Rear Panel ➤ Outputs 1. HDMI Out Connect this to the HDMI connector on the CineWall (see Input Connectors and LEDs on page 6).

  • Page 23: Cinewall Remote Control Unit

    System Description 9. S-Video 1 / S-Video 2 Two, standard S-Video inputs for connecting a DVD player, satellite receiver or Super VHS (S-VHS) VCR. 10. IR Wired input from a Niles- or Xantech-compatible, infrared (IR) repeater system. It is a 3.5-mm, mini phono jack, wired as follows: Ring = +5V (current limited to 100mA) Tip = IR Input...
  • Page 24 System Description 1. IR OUTPUT INDICATOR Lights when a button is pressed to indicate that an IR signal is being transmitted. 2. ON / OFF Press to turn the display on or off. 3. ENTER Press to select a highlighted menu item or confirm a changed setting. 4.
  • Page 25 System Description 10. Aspect Ratio Selection Buttons Use the red buttons to select an aspect ratio directly or to enter numeric characters, as follows: 16:9 (3) For viewing 16:9 DVDs or HDTV programs in their native aspect ratio. 4:3 (6) Scales the input signal to fit 4:3 display mode in the center of the screen.
  • Page 26 System Description Notes: CineWall™ Installer/Integrator Manual...

  • Page 27: Installation Preparation

    3. Installation Preparation Prior to installing the CineWall, confirm that the installation site meets the requirements described in this section. Site Requirements The CineWall is designed for installation into a dedicated, framed, structurally capable wall Infrastructure with at least 32.50 inches (826 mm) of distance between the user-viewable surface of this wall and anything immediately behind the open framed area.

  • Page 28: Power Requirements

    Installation Preparation ➤ Power Requirements The CineWall requires clean, noise-free AC power. The power cord provided with the CineWall is 6 feet (1.83 meters) long. In order to use it, the power outlet must be no more than 48 inches (1.22 meters) from the cable openings on the right side of the chassis. If the outlet is farther away, substitute a longer power cord for the one provided with the CineWall;...

  • Page 29: Audio/Video Synchronization Issues

    In order to easily Synchronization Issues solve this issue, Runco recommends using the DHD Controller with a high-quality audio receiver that has the ability to effectively synchronize audio and video signals.

  • Page 30: Additional Considerations

    Installation Preparation Table 3-1. Possible Audio Latency for Various Input/Output Timings Input Timing Possible Audio Latency (milliseconds) 1080i/25 1080i/30 1080p/24 1080p/50 1080p/60 ➤ Additional Considerations Here are some other considerations and tips that can help improve your installation, avoid damage, prevent personal injury and prolong operating life: •...

  • Page 31: Unpacking And Inspecting

    CineWall is protected in the shipping containers. Unpack them carefully, inspecting the chassis and screen for scratches, dents or other signs of damage. If the equipment is damaged, save all packing materials and notify both Runco and the carrier immediately. Proceed as follows to unpack your CineWall: 1.
  • Page 32 Installation Preparation 4. With the help of your assistant, grasp the chassis by the handles on either side and lift it straight up and out of the shipping container. Handles 5. Carefully unpack the screen by opening one end of the shipping container and sliding the screen out of the box.

  • Page 33: Site Preparation

    Installation Preparation Because every home theater installation is unique, it is impossible to provide detailed, step-by-step instructions that are applicable to every situation. Instead, this section Site Preparation provides general guidelines for site construction and product installation. Review this information carefully and adapt it as needed to your installation requirements. The instructions in this section describe how to prepare a dedicated home theater for a CineWall installation.
  • Page 34 Installation Preparation Create wall opening: 1. Locate the screen center based on the desired screen height. 2. From this point, measure/mark 44.375 inches to the left and to the right and 19.25 inches above and below. 3. Using a laser level, determine and mark the locations of the opening corners. 4.
  • Page 35 Installation Preparation 6. Frame the wall opening in a manner similar to this example. 88.750" (2254.3 mm) CineWall™ Installer/Integrator Manual...
  • Page 36 Installation Preparation Notes: CineWall™ Installer/Integrator Manual...

  • Page 37: Installation

    4. Installation Table 4-1 gives a quick overview of the CineWall installation process. The sections following this one provide detailed instructions. Overview Table 4-1. Installation Overview For Details, Step Procedure Refer to page... Install Top Flange and Bottom Brackets on Chassis Assembly Place Chassis Assembly with brackets installed into opening in dedicated wall Secure Chassis Assembly to wall...

  • Page 38: Mounting The Cinewall Chassis

    Installation This section provides detailed instructions for installing the CineWall chassis. Mounting the CineWall Chassis ➤ Install Top Flange and Install the Top Flange as shown in Figure 4-1. Then, install the Left and Right Bottom Bottom Brackets on Brackets (the ones with the latches on them) at the bottom corners of the chassis, and Chassis Assembly install the Left Center and Right Center Bottom Brackets in the two intermediate locations.

  • Page 39: Install Chassis Assembly Into Wall

    Installation With the help of your assistant(s), lift the Chassis Assembly by the handles. Install Chassis Assembly into Wall While tilting the Chassis Assembly downward, carefully move the Chassis Assembly into the wall opening. Allow the bottom brackets to come to rest on the bottom of the wall opening.
  • Page 40 Installation The CineWall includes a special spacing tool to make it easier to level the Top Flange and ensure Spacing that it is the correct distance from Tool the Bottom Brackets. 1. Place the Spacing Tool on Top Flange either the Left Center or Right Center Bottom Bracket, as shown.
  • Page 41 Installation 5. Secure the Left and Right Side Light Blocks to the chassis and the opening frame. 6. Secure the Bottom Center Light Block/Strut Catch to the opening frame, between the two Center Bottom Brackets. 7. Install the other Bottom Light Blocks (left, left center, right center, right) as shown below.

  • Page 42: Installing The Screen

    Installation Figure 4-2 shows the CineWall screen assembly. The screen attaches to the hinge on the top flange of the Chassis Assembly via six hooks along the top of the frame. Installing the Screen Two latches at the bottom of the frame secure the screen in the closed position. A strut at the bottom of the frame opens out and holds the screen in the open position during installation or maintenance.
  • Page 43 Installation To install the screen: 1. Remove the Spacing Tool (used to install the chassis; see page 28). 2. With the help of your assistant(s), lift the screen and position it in front of the Chassis Assembly. CineWall™ Installer/Integrator Manual...
  • Page 44 Installation 3. Use the hooks to hang the frame on the hinge at the top of the chassis. 4. Use the strut at the bottom of the frame to prop the screen in the open position. CineWall™ Installer/Integrator Manual...

  • Page 45: Powering Up The Cinewall

    Installation 5. Install the safety catches at the top rear corners of the screen. These prevent the screen from separating from the hinge when the screen is opened or closed. a Remove the nut at one end Safety Remove this nut, of the hinge wing on the Catch install Safety Catch...

  • Page 46: Aligning The Image

    Installation The CineWall optical engine was perfectly adjusted when it left the factory. However, vibration in transit may have moved it. Before connecting the DHD Controller to the display Aligning the Image or performing any other installation tasks, proceed as follows to confirm proper image alignment.

  • Page 47: Connections To The Cinewall

    Installation Proceed as follows to connect the CineWall to your video sources, external controller(s) – if present – and AC power. Connections to the CineWall When connecting your equipment: • Turn off all equipment before making any connections. • Use the correct signal cables for each source. •...

  • Page 48: Connecting The Cinewall To The Dhd Controller

    Installation ➤ Connecting the CineWall Connect the DHD Controller to the CineWall as shown in Figure 4-3 and described in the to the DHD Controller sections that follow. Option Key RS-232 RS-232 RS-232 Communication Cable (provided) DIGITAL DVI Fan - System Fan - DMD DIGITAL HDMI Fan - Lamp...
  • Page 49 Installation Digital Video Connection: Connect the HDMI output from the DHD Controller to the HDMI input on the CineWall, using an HDMI-to-HDMI cable. RS-232 Connection: Connect the Display Control output from the DHD Controller to the RS-232 input on the CineWall. Use a cable with an RJ11 plug at the DHD Controller end and an RJ-45 plug at the CineWall end.

  • Page 50: Connecting Source Components To The Dhd Controller

    Installation ➤ Connecting Source Connect your video sources to the DHD Controller as shown and described in the Components to the DHD sections that follow. Controller HDMI Source Connections: See Figure 4-5. Use the HDMI inputs whenever possible. This ensures the highest video quality because the signal is carried in the digital domain throughout the entire signal path, from source component output into the display.

  • Page 51: Component Video Source Connections

    Installation Component Video Source Connections: Connect your component video sources to the HD1, HD2 and/or Component/SCART inputs as shown in Figure 4-6. RCA-to-BNC adapter COMPONEN T VIDEO OUT DTV-Set-Top Box (DTV-STB) BD/DVD Figure 4-6. Component Video Source Connections CineWall™ Installer/Integrator Manual...

  • Page 52: Rgbhv Source Connections

    Installation RGBHV Source Connections: Connect personal computers and/or other RGB sources to the HD1, HD2 and/or Component/SCART inputs as shown in Figure 4-7. BNC-to-RCA adapter RGB Camcorder Computer Figure 4-7. RGBHV Source Connections CineWall™ Installer/Integrator Manual...

  • Page 53: Scart Rgbs Source Connections

    Installation SCART RGBS Source Connections: Connect the green, blue and red outputs from your SCART source to the Component/SCART input on the DHD Controller. Connect the sync output from your SCART source to the Video input on the DHD Controller. See Figure 4-8.
  • Page 54 Installation Composite and S-Video Source Connections: See Figure 4-9. Composite Camcorder S-Video S-Video Gaming Console Figure 4-9. S-Video and Composite Video Source Connections CineWall™ Installer/Integrator Manual...

  • Page 55: Controller Connection

    Installation Use a straight-through, 9-pin RS-232 cable to connect a PC or control/automation RS-232 Controller system (if present) to the RS-232 port on the DHD Controller; see Figure 4-10. Connection For more information about using this connection, refer to Serial Communications on page 81.

  • Page 56: Connecting 12-Volt Trigger Outputs To External Equipment

    Installation ➤ Connecting 12-volt If your installation includes equipment that responds to 12-volt triggers, connect it to the Trigger Outputs to 12-volt trigger outputs as shown in Figure 4-11. External Equipment Sleeve = Ground To 12-volt trigger-activated Tip = +12V device Figure 4-11.

  • Page 57: Connecting An External Ir Receiver To The Dhd Controller

    Installation If infrared signals from the remote control cannot reach the DHD Controller due to Connecting an External IR excessive distance or obstructions such as walls or cabinet doors, you can connect an Receiver to the DHD external IR receiver to the DHD Controller to extend the range of the remote control. See Controller Figure 4-12.

  • Page 58: Installing Batteries In The Dhd Controller Remote Control

    Installation To install batteries in the DHD Controller remote control: Installing Batteries in 1. Press down the tab on the cover and the DHD Controller pull the cover in the direction of the arrow. Remote Control 2. Insert the included batteries. Ensure that the polarities correctly match the markings inside the battery compartment.

  • Page 59: Powering Up The Cinewall And Dhd Controller

    Installation • Make sure that there is nothing obstructing the infrared beam between the remote control and the IR receiver on the plasma display. The signal from the remote control can be reflected by walls or Note other surfaces. • If the effective range of the remote control decreases, or it stops working, replace the batteries with new ones.
  • Page 60 Installation Notes: CineWall™ Installer/Integrator Manual...

  • Page 61: Operation

    5. Operation To display the Main Menu, press the MENU button on the remote control (Figure 2-4) or DHD Controller front panel (Figure 2-2). On-Screen Display (OSD) Menus To select a menu item, use the buttons on the remote control or DHD Controller front panel to highlight it.

  • Page 62: Main Menu

    Main Menu The Main Menu is the starting point for accessing all CineWall functions. (You must enter a passcode to access the Calibration and Service menus. To obtain this Runco Video passcode, contact Runco Technical Support.) Input Source Aspect Ratio Picture...

  • Page 63: Input Source

    Operation From the Main Menu, select Input Source to choose a video signal source. Input Source ➡ The active source is indicated by an arrow ( ) to its left; in this example, Composite is the Input Source active source. ➡...
  • Page 64 Operation Table 5-1. Aspect Ratio Settings Aspect Remote Ratio of Aspect Ratio Control Description Source Signal Select 16:9 to view 16:9 DVDs and HDTV programs in their native aspect ratio. 16:9 16:9 16:9 4:3 images are stretched horizontally to fit a 16:9 screen.
  • Page 65 Operation Table 5-1. Aspect Ratio Settings (continued) Aspect Remote Ratio of Aspect Ratio Control Description Source Signal Letterbox mode scales (zooms in on) a 4:3 image linearly (by the same amount on all sides) to fill a 16:9 display. Letterbox is best suited for viewing 16:9 LaserDisc movies or non-anamorphic DVDs on a 16:9 screen.
  • Page 66 Operation Table 5-1. Aspect Ratio Settings (continued) Aspect Remote Ratio of Aspect Ratio Control Description Source Signal Select Cinema to view 2.35:1 source material in its native aspect ratio. Cinema masks the upper and lower por- 2.35:1 tions of the screen to create a viewable area with a 2.35:1 aspect ratio.
  • Page 67 Operation Table 5-1. Aspect Ratio Settings (continued) Aspect Remote Ratio of Aspect Ratio Control Description Source Signal 1080i HDTV Image 16:9 720p HDTV Image Select One to One to display the source signal in its native resolution, with no re-sizing or overscan. Native (none) This means, for example, that 720p HDTV...

  • Page 68: Picture

    Color implemented a training program for technicians and installers to use these standards to obtain optimal picture quality from Runco video display devices. Accordingly, Runco Tint recommends that setup and calibration be performed by an ISF certified installation Sharpness technician.
  • Page 69 Operation PLUGE patterns vary but generally consist of some combination of black, white and gray areas against a black background. The example above includes two vertical bars and four shaded boxes. Select Brightness from the Picture menu and press ENTER. Adjust the brightness so that: •...
  • Page 70 Operation Color Saturation: On your external test pattern source, select a color bar pattern like the one shown in Figure 5-4. Figure 5-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint 1. Press the MENU button on the remote control or DHD Controller front panel. 2.
  • Page 71 Operation 11.Adjust the color saturation level until the outermost (gray and blue) color bars appear to be a single shade of blue: Tint: Tint or “hue” is essentially the ratio of red to green in the color portion of the image. When tint is decreased, the image appears redder;...
  • Page 72 Operation Sharpness: “Sharpness” is the amount of high-frequency detail in the image. To adjust sharpness, select Sharpness from the Picture menu and press ENTER. On your external test pattern source, select a pattern like the one shown in Figure 5-5. Adjust as needed, looking for white edges around the transitions from black to gray and differently-sized lines in the “sweep”...

  • Page 73: Input Position

    Operation Use the controls in the Input Position Menu to fine-tune the aspect ratio and image Input Position position for the current source. Input Position Left/Right The input position settings are automatically saved for each input Note Up/Down and resolution. Width Height Left/Right: Select Left/Right from the Input Position menu to shift the projected image...

  • Page 74: Overscan Modes

    Operation No Overscan Crop Zoom 16 :9 = Source Image Area = Mask (Crop) Area = Screen (16:9) Figure 5-6. Overscan Modes Phase (RGB or Component sources): This control adjusts the phase of the pixel sampling clock relative to the incoming signal. Adjust the phase when an RGB or Component image still shows shimmer or “noise”...

  • Page 75: Memory Presets

    Operation For each input, the CineWall lets you save image quality settings as presets that you can Memory Presets recall at a later time. You can create up to four presets per input and display mode (resolution and frame rate). Memory Presets ➡...

  • Page 76: Information

    Information your DHD Controller and display device. Signal System Should you ever need to contact Runco Technical Support, this information will help them Field Service answer your questions or resolve product performance issues. Manufacturing Signal...
  • Page 77 Operation • Gamma: Select Gamma from the Display Color menu to choose a de-gamma curve. Used correctly, the Gamma control can improve contrast while maintaining good details for blacks and whites. If excess ambient light washes out the image and it becomes difficult or impossible to see details in dark areas, lower the gamma setting to compensate.
  • Page 78 (On) or disable (Off) ConstantContrast in the optical engine. ConstantContrast uses a dynamic iris that modulates light to the DMD based on the actual content of the video material. Runco recommends that you disable ConstantContrast before adjusting Brightness, Contrast or other image settings.
  • Page 79 • Splash Timer: When you turn on the CineWall, it projects a welcome screen with the Runco and ISF logos, along with the personalized information you enter as described above. Select Splash Timer from the Splash Configure menu to set the amount of time for which this screen appears.

  • Page 80: Service

    Operation • Splash Enable: When you have finished customizing the splash screen, select Splash Enable from the Splash Configure menu. Then, select On and press ENTER. OSD Position: To adjust the position of the OSD, select OSD Position from the Calibration menu and press ENTER.
  • Page 81 Operation Remote Control: Select Remote Control from the Service menu to change the following settings related to remote control operation. • Remote Code: Select Remote Code from the Remote Control menu to set the infrared (IR) code set to which the CineWall will respond. By default, it is set to 17. You can change this setting if either: •...
  • Page 82 Operation Color Space: Select Color Space from the Service menu to choose the color space of the source signal for HDMI, RGB, and component connections. • The default setting, Auto, functions as follows: • HDMI: If the Auxiliary Video Information (AVI) infoframe contains color space and/or range data, the CineWall uses that information.
  • Page 83 Operation • CUE (Chroma Upsampling Error) Correction: Some DVD players use MPEG decoders that do not correctly “upsample” the 4:2:0 format chroma information on the DVD to the 4:2:2 or 4:4:4 format required by the video encoder of the display device. This so-called “chroma bug”...
  • Page 84 Operation Notes: CineWall™ Installer/Integrator Manual...

  • Page 85: Maintenance And Troubleshooting

    6. Maintenance and Troubleshooting Cleaning Dirt is everywhere, and unless the CineWall is in a super-clean room, from time to time you Cleaning the Screen, will need to clean the screens, mirrors and/or lens. Mirrors and Lens Cleaning products and how to use them: For mirrors and screens, a foam spray cleaner works well.

  • Page 86: Where Is The Dirt

    Maintenance and Troubleshooting Removing dry dust: Often the cleaning problem is just dust, not fingerprints or other oily dirt. If it’s just dust, wiping with a dry cheesecloth or a dry Shop Towel will usually do the job. Or use one of the cleaning products designed specifically for picking up dust. •...

  • Page 87: Lamp Replacement

    Maintenance and Troubleshooting Change the lamp after 6,000 hours of use, or sooner if you notice a significant decrease in brightness. Lamp Replacement 1. Open the screen. Removing the Old Lamp 2. Turn off the AC power switch and remove the power cord. 3.

  • Page 88: Installing The New Lamp

    Maintenance and Troubleshooting ➤ Installing the New Lamp 1. Re-connect the lamp cable you disconnected in Step 5 above. Make sure it is fully seated. If the lamp cable is not fully seated on the lamp plug, the lamp will WARNING not operate properly.

  • Page 89: Removing The Air Filter

    Removing the Air Filter 2. Turn off the AC power switch and remove the power cord. 3. Lift the air filter up and toward you. Then, replace it with a new one (Runco part number 379-0012-00). The CineWall provides several features for identifying and resolving product performance issues.

  • Page 90: Isolating Faulty Parts

    Maintenance and Troubleshooting Table 6-1. CineWall Status LED Indications (continued) When the LED is... LED Name Green Amber Engine Status Optical engine Optical engine fault or commu- nication failure Ballast Status Lamp off Lamp on Ballast fault or communication failure Fan-Lamp Fan failed Fan-DMD...
  • Page 91 Maintenance and Troubleshooting • A fan may have failed. Most fans are sensed. That means the electronics module knows whether they are running or not. If they don’t run when they should, the electronics module turns off the lamp and prevents it from striking (turning on) again. Swapping other parts: You can swap electronics modules or fans in the same way to see if one is bad.
  • Page 92 Maintenance and Troubleshooting Notes: CineWall™ Installer/Integrator Manual...

  • Page 93: Serial Communications

    7. Serial Communications To interface the CineWall with an automation/control system or a PC running terminal emulation software, connect it to the Display Control output of the DHD Controller as RS-232 Connection shown in Figure 4-3 and Figure 4-4. Connect your control system or PC to the RS-232 and Port Configuration input of the DHD Controller as shown in Figure 4-10.
  • Page 94 Serial Communications Table 7-1 lists the RS-232 command set. The “Parameter (min/max)” column shows the valid parameter ranges, or “NA” for commands that take no parameters. When you enter a valid command, the DHD Controller executes it and acknowledges it with a plus sign on the command line (+ >).
  • Page 95 Serial Communications Table 7-1. Serial Commands (continued) Parameter Value Command Description (min/max) Stored? Aspect Ratio Commands 16:9 Selects the 16:9 aspect ratio Selects the 4:3 aspect ratio ASPECT? Returns current aspect ratio CINEMA Selects the Cinema aspect ratio LETTERBOX Selects the Letterbox aspect ratio NATIVE Selects the Native aspect ratio VIRTUALWIDE...
  • Page 96 Serial Communications Table 7-1. Serial Commands (continued) Parameter Value Command Description (min/max) Stored? Image Preset Commands CUSTOM1 Loads “Custom 1” image preset CUSTOM2 Loads “Custom 2” image preset Loads “ISF Day” image preset NIGHT Loads “ISF Night” image preset PRESET? Returns currently-selected preset (ISF Day, ISF Night, Custom 1 or Cus- tom 2)
  • Page 97 Serial Communications Table 7-1. Serial Commands (continued) Parameter Value Command Description (min/max) Stored? Miscellaneous Commands DISPLAY? Returns display device input source value, as follows: 1 = Auto 36 = CW-95DHD INRES? Returns input resolution SERNUM? Returns DHD Controller serial number SWVER? Returns software version number TRIGGER...
  • Page 98 Serial Communications Notes: CineWall™ Installer/Integrator Manual...

  • Page 99: Specifications

    8. Specifications Table 8-1 lists the CineWall specifications. CineWall Table 8-1. CineWall Specifications Specifications Native Resolution: 1920 x 817 (2.35:1) Aspect Ratios: Refer to Table 8-2 Video Standards: NTSC, PAL, ATSC Video Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p Picture Size (16:9 Screen): 95 inches (2413 mm), diagonal Lamp:...

  • Page 100: Dhd Controller Specifications

    Specifications Table 8-2 lists the DHD Controller specifications. DHD Controller Table 8-2. DHD Controller Specifications Specifications Aspect Ratios: 4:3, Letterbox, 16:9, VirtualWide, Cinema, Virtual Cinema, Native Video Standards: NTSC, PAL, SECAM Inputs: (1) Composite (2) S-Video (1) Component/RGBHV/SCART (5 x RCA) (2) Component/RGBHV (5 x BNC) (2) HDMI 1.3 with HDCP (1) Serial Control (RS-232, 9-pin D-sub)

  • Page 101: Dimensions

    Specifications Figure 8-1 shows the CineWall CW-95DHD dimensions (all dimensions are in inches). Dimensions Figure 8-1. CineWall CW-95HD Dimensions CineWall™ Installer/Integrator Manual...

  • Page 102: Supported Timings

    Specifications Table 8-3 lists the signal types supported by each input on the DHD Controller. Supported Timings Table 8-3. Supported Signal Timings by Input Supported? (√ = Yes, – = No) Horizontal Refresh Pixel Frequency Format Resolution Frequency Rate (Hz) (MHz) (kHz) √...
  • Page 103 Specifications Table 8-3. Supported Signal Timings by Input (continued) Supported? (√ = Yes, – = No) Horizontal Refresh Pixel Frequency Format Resolution Frequency Rate (Hz) (MHz) (kHz) √ √ √ 60.00 63.981 108.000 – – – √ √ √ 1280x1024 1280x1024 75.00 79.976...
  • Page 104 Specifications Table 8-3. Supported Signal Timings by Input (continued) Supported? (√ = Yes, – = No) Horizontal Refresh Pixel Frequency Format Resolution Frequency Rate (Hz) (MHz) (kHz) √ √ PAL-M – 59.94/60.00 15.734/15.750 3.580 – – – – √ √ PAL-N –...
  • Page 106 S ER IAL N UM B E R 020-0981-00 Rev. A March 2009 Runco International • (800) 23RUNCO • Fax (503) 748-8161 • www.runco.com...
