Seiwa Techmarine User Manual

5" sunlight readable vertical color display external smart gps receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

CHART PLOTTER NAME
TM5e
TM5i
TM5ce
TM5ci
T-50.05
T-55.05
TM7e
TM7i
TM7ce
TM7ci
TM11
T-59.09
T-59.05
T-59.01
User Manual
DESCRIPTION
5" Sunlight Readable Vertical Color Display
External Smart GPS Receiver
5" Sunlight Readable Vertical Color Display
Internal GPS Receiver
5" Sunlight Readable Vertical Color Display
External Smart GPS Receiver & Internal FF
5" Sunlight Readable Vertical Color Display
Internal GPS Receiver & Internal FF
7" Sunlight Readable Wide Color Display
External Smart GPS Receiver
7" Sunlight Readable Wide Color Display
Internal GPS Receiver
7" Sunlight Readable WVGA Color Display
External Smart GPS Receiver
7" Sunlight Readable WVGA Color Display
Internal GPS Receiver
7" Sunlight Readable WVGA Color Display
External Smart GPS Receiver & Internal FF
7" Sunlight Readable WVGA Color Display
Internal GPS Receiver & Internal FF
11" Sunlight Readable Color Display
External Smart GPS Receiver & Video Input
12" Color Display
External Smart GPS Receiver
15" Color Display
External Smart GPS Receiver
Controller for Color Display
External Smart GPS Receiver
code: (R1609-060710e)
SOFTWARE
S4xgTM5vc_T
S4xgTM5vc_T
S4xgTM5vc_T
S4xgTM5vc_T
S4xgTM7wc
S4xgTM7wc
S4x2TM8wc_qd
S4x2TM8wc_qd
S4x2TM8wc_qd
S4x2TM8wc_qd
S5e2TM11c
S5egTL12c
S5egSW15c
S5egTMctc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Techmarine and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seiwa Techmarine

Summary of Contents for Seiwa Techmarine

  • Page 1 CHART PLOTTER NAME DESCRIPTION SOFTWARE TM5e 5" Sunlight Readable Vertical Color Display S4xgTM5vc_T External Smart GPS Receiver TM5i 5" Sunlight Readable Vertical Color Display S4xgTM5vc_T Internal GPS Receiver TM5ce 5" Sunlight Readable Vertical Color Display S4xgTM5vc_T External Smart GPS Receiver & Internal FF TM5ci 5"...
  • Page 2 Copyright 2010 Seiwa - Hong Kong All rights reserved. No part of this publication may be reproduced or distributed in any form or by any means, or stored in User Manual a database or retrieval system, without prior written permission of the publisher.

  • Page 3: Table Of Contents

    Contents About this User Manual ................13 INTRODUCTION ................13 CONVENTIONS USED ................13 MANUAL LAYOUT ................13 IF YOU NEED ASSISTANCE ................14 Important Information ................15 WARNING ................15 CAUTION ................15 CLEANING PROCEDURE FOR THE PLOTTER SCREEN ..........15 1.
  • Page 4 Creating Mark ................31 Creating Event ................31 Editing User Point ................31 Deleting User Point ................31 Moving User Point ................32 Locating User Point on Map ................32 Sending/Receiving User Point ................ 32 Selecting User Points List page ..............32 2.2 ROUTES ................
  • Page 5 Finding User Points ................45 2.9 ALARMS ................45 Auto Off ................45 Arrival Alarm ................45 XTE Alarm ................45 Anchor Alarm ................45 Depth Alarm ................45 HDOP Alarm ................46 Heading Alarm ................46 Timer Alarm ................46 Timer Direction ................
  • Page 6 Cable Wiring pages ................58 Send/Receive Routes & Marks ............. 59 3.6.2 C-Link menu ................59 3.6.3 Fix & Compass menu ................. 59 3.7 AIS ................60 3.7.1 AIS System Definitions ..............60 3.7.2 To set the chart plotter for receiving AIS ..........61 3.7.3 AIS Menu ................
  • Page 7 5.6.6 Bottom Range ................84 5.6.7 Frequency ................84 5.6.8 Interference Rejection ............... 84 5.6.9 Sensitivity Menu ................85 5.6.10 Display Setup Menu ................85 5.6.11 Transducer Setup Menu ..............85 5.6.12 Alarms Menu ................86 5.6.13 Save & Load Menu ................86 5.7 TRANSDUCERS ................
  • Page 8 TECHNICAL SPECIFICATIONS ................110 MEDIA INSERTING/REMOVING PROCEDURE ............110 Inserting the MEDIA ................110 Removing the MEDIA ................111 CHART PLOTTER DIMENSIONS ................111 INSTALLATION AND REMOVING ................. 111 EXTERNAL WIRING ................112 External Wiring T-50.05 (External GPS Receiver) ........... 112 External Wiring T-55.05 (Internal GPS Receiver) ...........
  • Page 9 Autopilot Connection ................133 External NMEA Connection ................. 133 External Alarm Connection ................. 134 C-COM Connection ................134 T-59.09 ................135 FEATURES & FUNCTIONS ................135 TECHNICAL SPECIFICATIONS ................136 INSERTING/REMOVING PROCEDURE ..............136 Inserting the MEDIA ................137 Removing the MEDIA ................
  • Page 10 User Manual...

  • Page 11: About This User Manual

    About this User Manual INTRODUCTION The chart plotter is a state-of-the-art computerized electronic chart system, de- signed as a sophisticated navigation aid. User friendly operations make the chart plotter easy to operate. All calculations and information necessary for the naviga- tion are performed and displayed on the screen quickly and accurately providing all of the facilities of a conventional GPS but with the added benefit of a powerful electronic chart display.

  • Page 12: If You Need Assistance

    TM5ce/TM5ci ♦ Introduction to the basic information on TM5ce/TM5ci, 5" vertical chart plotter with internal Fish Finder, its features and use. Installation of the chart plotter. T-50.05/T-55.05 ♦ Introduction to the basic information on T-50.05/T-55.05, 7" wide chart plotter, its features and use. Installation of the chart plotter. TM7e/TM7i ♦...

  • Page 13: Important Information

    Important Information WARNING Electronic charts displayed by the chart plotter are believed to be accurate and reliable, but they are not intended to replace official charts which should remain your main reference for all the matters related to the execution of a safe naviga- tion.
