® ® Vision Assembly Guide Vision ™ Guide to: Assembly Battery & Charger Owner Registration First-Time Out White’s Electronics, Inc. - Manufacturers of the World’s Finest Metal Detectors...
Page 2
Hold Trigger & hold ENTER, pump search coil (loop) up and down on the ground until background hum steadies, release ENTER… and then release Trigger and begin searching. (Note releasing Trigger before releasing ENTER) locks Vision in pinpoint mode, squeeze and release trigger twice to unlock pinpoint.
Page 3
Vision Assembly Guide ASSEMBLY - Washers between each loop ear & clevis Search Coil Cable Retainer Clevis Camlock Lower Rod Display S-rod Touch Pads Select Programs Trigger Adjust Controls Elbow Cup Strap Elbow Cup Foam Pads - Inside Elbow Cup...
Page 4
Vision Assembly Guide ASSEMBLY INSTRUCTIONS - . Remove all parts from shipping carton. Check the assembly page to make sure all parts are present. . Use the provided rubber washers between clevis/lower rod and loop ears. Use only nonmetallic washers, fiber bolt, and thumbnut to secure loop/search coil to clevis/lower rod.
Page 5
0. It should be noted at this point that the Vision may not work as expected indoors due to the high degree of metals used in modern construction. It is best to tune and practice (outdoors) to ensure stable, predictable results.
Page 6
6 Vision Assembly Guide To begin using the Vision immediately, use the back-up “AA” battery pack (Blue Decal). Blue Decal • The standard battery holder (Blue Decal) holds eight “AA” cell batteries. Alkaline batteries are recommended for use with this battery holder.
Page 7
“+” and “-“ for each position marked inside the cell tray. Install new “AA” cells noting carefully the correct (+) and (-) positions. If any of the cells are installed incorrectly, battery life will be significantly reduced and/or the Vision may require service by an Authorized Service Center.
Page 8
It is recommended that the battery be removed from the Vision during periods of storage. It is not advisable to store rechargeable batteries for long periods of time without use (six + months).
Page 9
8 volts. It is recommended to either recharge or switch to “AA” pack when occasional unhappy battery starts to appear (flash) on display. With a consistent unhappy battery, Vision will not be operating properly and will soon entirely cease to operate.
Arrow down to Owner Registration and press ENTER. To Exit squeeze and release trigger on hand grip twice Owner Registration – Allows the Vision owner to embed their name and contact information, protected from tampering, but updateable with original factory code.
Page 11
Vision Assembly Guide Contact - Press MENU / TAB to exit Name and select Contact. Type out your contact information using ARROWs, or pressing Menu to bring up the keyboard then ARROWs and ENTER. SAVE – Use MENU / TAB to select SAVE, press ENTER to SAVE your...
Page 12
Vision Assembly Guide USA / Australian Service Centers . White’s Electronics . Electronic 1011 Pleasant Valley Rd. Exploration Sweet Home, OR 97386 575 West Harrison (541) 367 6121 Lombard, IL 60148 Fax (541) 367 6629 (800) 392-3223 Tmarshall@whiteselectronics.com (630) 620-0618 (630) 620-1005 FAX .
Page 13
Vision Assembly Guide White’s reputation has been built on quality products backed by quality service. Our Factory Authorized Service Centers are factory trained and equipped. They offer the same quality service as the factory. Service before and after the sale is the cornerstone of our customer relations.
Page 14
White’s. USA Warranty Transfer If for any reason you should sell your Vision prior to the date the warrant expires, the remaining warranty is transferable. Call 1-800-547-6911, and get an Authorization Number to authorize this transfer.
“Help Balloon” that offers more information about the menu item. Help Balloon Trigger Forward • COMPLETE OWNER’S GUIDE - All of Vision’s systems and controls are explained in complete detail. • DVD - A short DVD designed to visually familiarize and instruct.
Page 16
Hold Trigger & hold ENTER, pump search coil (loop) up and down on the ground until background hum steadies, release ENTER… and then release Trigger and begin searching. (Note releasing Trigger before releasing ENTER) locks Vision in pinpoint mode, squeeze and release trigger twice to unlock pinpoint.
