Summary of Contents for AEG Electrolux LAVAMAT 72640
- Page 1 Ofrecido por www.electromanuales.com LAVAMAT 72640 User manual Washing machine...
- Page 2 Ofrecido por www.electromanuales.com Dear Customer Thank you for choosing one of our high-quality products. With this appliance you will experience the perfect combination of functional design and cutting edge technology. Convince yourself that our appliances are engineered to deliver the best performance and control - indeed we are setting the highest standards of excellence.
-
Page 3: Table Of Contents
Ofrecido por www.electromanuales.com Contents Contents Instruction for the user Safety information Product description Detergent dispenser drawer Control panel First use Personalization Acoustic signals Daily use Laod the laundry Measure out the detergent and the fabric softener Select the required programme Select the spin speed or the Rinse Hold option Programm option button Select the Prewash option... - Page 4 Ofrecido por www.electromanuales.com Contents At the end of the programme Child safety lock Washing programmes 20-21 Programme informations Preparing the wash cycle 23-27 Sorting out the laundry Temperatures Before loading the laundry Maximum loads Laundry weights Removing stains Detergents and additives Quantity of detergent to be used Degrees of water hardness International wash code symbols...
-
Page 5: Contents
Ofrecido por www.electromanuales.com Contents Consumption value Installation 40-44 Unpacking Positioning and levelling Water inlet Water drainage Electrical connection Permanent connection Enviroment concerns Packaging materials Old machine Ecological hints Guarantee Customer service centres... -
Page 6: Instruction For The User
Ofrecido por www.electromanuales.com Safety information Instruction for the user Safety information Prior to using for the first time The safety of AEG/ELECTROLUX appliances complies with the industry ● standards and with legal requirements on the safety of appliances. However, as manufacturers, we feel it is our duty to provide the following safety notes. You MUST read them carefully before installing or using the appliance. - Page 7 Ofrecido por www.electromanuales.com Safety information Do not use your washing machine to wash articles with whalebones, material ● without hems or torn material. Always unplug the appliance and turn off the water supply after use, clean ● and maintenance. Under no circumstances should you attempt to repair the machine yourself. ●...
-
Page 8: Safety Information
Ofrecido por www.electromanuales.com Safety information Before washing, ensure that all pockets are empty and buttons and zips are ● fastened. Avoid washing frayed or torn articles and treat stains such as paint, ink, rust, and grass before washing. Underwired bras must NOT be machine washed. -
Page 9: Product Description
Ofrecido por www.electromanuales.com Product description Product description Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Detergent dispenser drawer Rating plate Control panel Drain pump Door opening handle Adjustable feet Detergent dispenser drawer The prewash detergent is added at the beginning of the wash programme. -
Page 10: Control Panel
Ofrecido por www.electromanuales.com Control panel Control panel ALGODÓN ECO ALGODÓN 20 MIN - 3KG 1200 CENTRIFUGAR DESCARGA ACLARADO SINTÉ- TICOS LANA PLUS PLANCHA DELICADOS FÁCIL PLUS SILENT SYSTEM PLUS 9 10 Programme selector dial «Quick» button Spin reduction button Display «Prewash»... -
Page 11: Personalization
Ofrecido por www.electromanuales.com Personalization 1200 Acoustic signals The machine is provided of an acoustic device, which sounds in the following cases: at the end of the cycle ● in the event of operating problems ● By pressing the «Prewash» and «Stain» buttons simultaneously for about 6 seconds, the acoustic signal is deactivated (except for the events of operating problems). -
Page 12: Select The Required Programme
Ofrecido por www.electromanuales.com 2. If required, pour fabric softener into the compartment marked (the amount used must not exceed the MAX mark in the drawer). Close the drawer gently. Select the required programme You can choose the right programme for any ALGODÓN ECO ALGODÓN type of laundry following the descriptions on... -
Page 13: Select The Spin Speed Or The Rinse Hold Option
Ofrecido por www.electromanuales.com Select the spin speed or the rinse hold option Press the Spin button repeatedly to change the spin speed, if you want your laundry to be spun at a speed different from the one proposed by the washing machine. -
Page 14: Select The Prewash Option
Ofrecido por www.electromanuales.com Select the Prewash option 1200 Select this option if you wish your laundry to be prewashed at 30°C before the main wash. The Prewash ends with a short spin in programmes for cotton and synthetic fabrics, whereas in the programmes for delicate fabrics the water is only drained. -
Page 15: Display
Ofrecido por www.electromanuales.com On the display will be visualized the decreased washing time. The maximum load is 6 kg for cottons and 2 kg for synthetics and delicates. By pressing this button twice, the relative pilot light remains lit, the washing duration will be reduced to wash lightly soiled laundry or items that have been used or worn for a short time. -
Page 16: Select The Start/Pause
Ofrecido por www.electromanuales.com Alarm codes In the event of operating problems, some alarm codes can be displayed, for example (see paragraph «Something not working»). End of programme When the programme has finished a flashing zero is displayed, the «Door» pilot light and the Start/Pause light go out and the door can be opened. -
Page 17: Programme Progress Display
Ofrecido por www.electromanuales.com You must select this option after you have set the programme and before you press the Start/Pause button. The wash programme can be delayed from 30 min - 60 min - 90 min, 2 hours and then by 1 hour up to a maximum of 20 hours by means of this button. If you wish to add laundry in the machine during the delay time you will press Start/Pause button to put the machine in pause. -
Page 18: Select An Additional Rinse
Ofrecido por www.electromanuales.com Select an additional rinse 1200 This appliance is designed for saving water. However, for people with a very delicate skin (allergic to detergents) it may be necessary to rinse the laundry using an extra quantity of water (extra rinse). Press simultaneously the Spin Speed and Prewash buttons for some seconds: the Extra Rinse pilot light comes on in the programme progress display. -
Page 19: At The End Of The Programme
Ofrecido por www.electromanuales.com At the end of the programme The machine stops automatically, the Start/Pause light goes off and a flashing will appear on the display. If the Rinse Hold option have been selected, the «Door» pilot light illuminates, a flashing will appear on the display, the Start/Pause light goes off and the door remains locked to indicate that the water must be emptied out before opening the door. -
Page 20: Washing Programmes
Ofrecido por www.electromanuales.com Washing programmes Washing programmes P P r r o o g g r r a a m m m m e e / / D D e e s s c c r r i i p p t t i i o o n n o o f f T T y y p p e e o o f f l l a a u u n n d d r r y y O O p p t t i i o o n n s s T T e e m m p p e e r r a a t t u u r r e e... -
Page 21: Washing Programmes
Ofrecido por www.electromanuales.com Washing programmes Washing programmes P P r r o o g g r r a a m m m m e e / / D D e e s s c c r r i i p p t t i i o o n n o o f f T T y y p p e e o o f f l l a a u u n n d d r r y y O O p p t t i i o o n n s s T T e e m m p p e e r r a a t t u u r r e e... -
Page 22: Programme Informations
Ofrecido por www.electromanuales.com Programme informations Programme informations Selecting this programme the laundry is gently washed and spun to avoid any creasing. In this way 40° Easy Iron ironing is easier. Furthermore the machine will perform additional rinses. Washing programme for machine washable wool Wool well as for hand washable woollens and delicate fabrics with Handwash... -
Page 23: Preparing The Wash Cycle
Ofrecido por www.electromanuales.com Preparing the wash cycle Preparing the wash cycle Sorting out the laundry Follow the wash code symbols on each garment label and the manufacturer’s washing instructions. Sort the laundry as follows: whites, coloureds, synthetics, delicates, woollens. Temperatures for normally soiled white cottons and linen (e.g. -
Page 24: Maximum Loads
Ofrecido por www.electromanuales.com Preparing the wash cycle Maximum loads Recommended loads are indicated in the washing programme charts. General rules: Cotton, linen: drum full but not too tightly packed; Synthetics: drum no more than half full Delicate fabrics and woollens: drum no more than one third full. Washing a maximum load makes the most efficient use of water and energy. -
Page 25: Removing Stains
Ofrecido por www.electromanuales.com Preparing the wash cycle Removing stains Stubborn stains may not be removed by just water and detergent. It is therefore advisable to treat them prior to washing. Blood: treat fresh stains with cold water. For dried stains, soak overnight in water with a special detergent then rub in the soap and water. -
Page 26: Detergents And Additives
Ofrecido por www.electromanuales.com Preparing the wash cycle Detergents and additives Good washing results also depend on the choice of detergent and use of the correct quantities to avoid waste and protect the environment. Although biodegradable, detergents contain substances which, in large quantities, can upset the delicate balance of nature. -
Page 27: Degrees Of Water Hardness
Ofrecido por www.electromanuales.com Preparing the wash cycle Degrees of water hardness Water hardness is classified in so-called “degrees” of hardness. Information on hardness of the water in your area can be obtained from the relevant water supply company, or from your local authority. Note: A water softener must be added when water has a medium-high degree of hardness (from degree of hardness II). -
Page 28: International Wash Code Symbols
Ofrecido por www.electromanuales.com International wash code symbols International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature... -
Page 29: Care And Cleaning
Ofrecido por www.electromanuales.com Care and cleaning Care and cleaning You must DISCONNECT the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. -
Page 30: Washing Drum
Ofrecido por www.electromanuales.com Care and cleaning 2. Remove the conditioner insert from the middle compartment. 3. Clean all parts with water. 4. Put the conditioner insert in as far as it will go, so that it is firmly in place. 5. -
Page 31: Drain Pump
Ofrecido por www.electromanuales.com Care and cleaning Drain pump The pump should be inspected regularly and particularly if • the machine does not empty and/or spin • the machine makes an unusual noise during draining due to objects such as safety pins, coins etc. blocking the pump. Proceed as follows: 1. -
Page 32: Water Inlet Filter
Ofrecido por www.electromanuales.com Care and cleaning 8. Put the cap back on the emergency emptying hose and place the latter back in its seat. 9. Screw the pump fully in. 10. Close the pump door. Warning! When the appliance is in use and depending on the programme selected there can be hot water in the pump. -
Page 33: Frost Precautions
Ofrecido por www.electromanuales.com Care and cleaning 7. replace the emergency emptying hose in its seat after having plugged it; 8. screw the pump again and close the door. Frost precautions If the machine is installed in a place where the temperature could drop below 0°C, proceed as follows: 1. -
Page 34: Something Not Working
Ofrecido por www.electromanuales.com Something not working Something not working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. During machine operation it is possible that the y y e e l l l l o o w w Start/Pause pilot light flashes, one of the following alarm codes appears on the display and at the same some acoustic signals sound every 20 seconds to indicate that the machine is not working:... - Page 35 Ofrecido por www.electromanuales.com Something not working Problem Possible cause/Solution The end of the drain hose is too low. The machine fills then empties • Refer to relevant paragraph in «water drainage» immediately: section. The drain hose is squashed or kinked. •...
- Page 36 Ofrecido por www.electromanuales.com Something not working Problem Cause possible/Solution The programme is still running. • Wait the end of washing cycle. The door lock has not been released. The door will not open: • Wait some minutes. There is water in the drum. •...
-
Page 37: Something Not Working
Ofrecido por www.electromanuales.com Something not working Problem Cause possible/Solution The drum light doesn’t work: Please contact your local Service Centre. If you are unable to identify or solve the problem, contact our service centre. Before telephoning, make a note of the model, serial number and purchase date of your machine: the Service Centre will require this information. -
Page 38: Techinical Data
Ofrecido por www.electromanuales.com Technical data Techinical Data Width 60 cm Height 85 cm Dimensions Depth 63 cm (door included) Electrical connection Voltage - Information on the electrical connection is given on the rating Overall power - Fuse plate on the inner edge of the appliance door Minimum 0,05 MPa Water supply pressure... -
Page 39: Consumption Value
Ofrecido por www.electromanuales.com Consumption value Consumption value Water consumption Energy consumption Programme duration Programme (in litres) (in kWh) (in minutes) 95° White Cottons 40° Cottons 60° 0.85 Synthetics 40° 0.35 Easy Iron 40° Delicates 30° Wool/Handwash/Silk 0.25 Rinses 0.08 Drain Spin 30°... -
Page 40: Installation
Ofrecido por www.electromanuales.com Installation Installation Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. 1. - Page 41 Ofrecido por www.electromanuales.com Installation 4. Unscrew and remove the two large rear bolts B and the six smaller bolts C. HEC0003 5. Remove the bracket D and tighten up the six smaller bolts C. Slide out the relevant plastic spacer E. HEC0023 6.
-
Page 42: Positioning And Levelling
Ofrecido por www.electromanuales.com Installation Positioning and levelling Install the machine on a flat hard floor. Make sure that air circulation around the machine is not impeded by carpets, rugs etc. Before placing it on small tiles, apply a rubber coating. Never try to correct any unevenness in the floor by putting pieces of wood, cardboard or similar materials under the machine. -
Page 43: Water Drainage
Ofrecido por www.electromanuales.com Installation 3. Set the hose correctly by loosening the ring nut. After positioning the inlet hose, be sure to tighten the ring nut again to prevent leaks. 4. Connect the hose to a tap with a 3/4” thread. Always use the hose supplied with the appliance. -
Page 44: Electrical Connection
Ofrecido por www.electromanuales.com Installation P1118 Important! The drain hose may be extended to a maximum of 4 metres. An additional drain hose and joining piece is available from your local Service Centre. Electrical connection This machine is designed to operate on a 220-230 V, single-phase, 50 Hz supply. -
Page 45: Enviroment Concerns
Ofrecido por www.electromanuales.com Environment concerns Enviroment concerns Packaging materials The materials marked with the symbol are recyclable. >PE<=polyethylene >PS<=polystyrene >PP<=polypropylene This means that they can be recycled by disposing of them properly in appropriate collection containers. Old machine Use authorised disposal sites for your old appliance. Help to keep your country tidy! The symbol on the product or on its packaging indicates that this product may not be treated as household waste. -
Page 46: Guarantee
Ofrecido por www.electromanuales.com European Guarantee European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee orotherwise by law. If you move from one of these countries to another of the countries listed, the appliance guarantee will move with you subject to the following qualifications: The appliance guarantee starts from the date you first purchased the appliance... -
Page 47: Customer Service Centres
Ofrecido por www.electromanuales.com Customer service centres www.electrolux.com Albania +35 5 4 261 450 Rr. Pjeter Bogdani Nr. 7 Tirane Belgique/België/Belgien +32 2 363 04 44 Bergensesteenweg 719, 1502 Lembeek Česká republika +420 2 61 12 61 12 Budějovická 3, Praha 4, 140 21 Danmark +45 70 11 74 00 Sjællandsgade 2, 7000 Fredericia... - Page 48 Ofrecido por www.electromanuales.com www.electrolux.com...
