  • Page 2 Honda WX10 OWNER’S MANUAL Original instructions MANUEL DE L’UTILISATEUR Notice originale BEDIENUNGSANLEITUNG Originalbetriebsanleitung MANUAL DE EXPLICACIONES Manual original...
  • Page 3 All information in this publication is based on the latest product information available at the time of approval for printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 4 Disposal To protect the environment, do not dispose of this product, battery, engine oil, etc. carelessly by leaving them in the waste. Observe the local laws and regulations or consult your authorized Honda dealer for disposal.

  • Page 5: Table Of Contents

    6. OPERATION ..................7. STOPPING THE ENGINE ..............8. MAINTENANCE ................. 9. TRANSPORTING/STORAGE ............. 10. TROUBLESHOOTING ................ 11. SPECIFICATIONS ................MAJOR Honda DISTRIBUTOR ADDRESSES ....Inside back cover ‘‘ EC Declaration of Conformity ’’ CONTENT OUTLINE ..Inside back cover...

  • Page 6: Safety Instruction

    SAFETY INSTRUCTION To ensure safe operation Honda water pump is designed to give safe and dependable service if operated according to in- structions. Read and understand the Owner’s Manual be- fore operating the water pump. Failure to do so could result in personal injury or equipment dam- age.
  • Page 7 The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Be careful not to touch the muffler while it is hot. Let the engine cool before storing the water pump indoors. The engine exhaust system will be heated during operation and remain hot immediately after stopping the engine.

  • Page 8: Safety Label Locations

    These labels warn you of potential hazards that can cause serious inju- ry. Read the labels and safety notes and precautions described in this manual carefully. If a label comes off or becomes hard to read, contact your Honda deal- er for a replacement. [For European types]...
  • Page 9 [For Canadian and Australian types] [Canadian and Australian types] [Canadian type only] French labels come with the water pump.

  • Page 10: Ce Mark And Noise Label Locations

    CE mark and noise label locations [For European types] NOISE LABEL CE MARK Manufacturer and address Name and address of authorized representative Year of manufacture Dry mass Model...

  • Page 11: Component Identification

    COMPONENT IDENTIFICATION CARRYING HANDLE THROTTLE LEVER DISCHARGE PORT AIR CLEANER SUCTION PORT ENGINE SWITCH PUMP DRAIN PLUG TOP COVER PRIMING WATER FILLER CAP SPARK PLUG (inside the top cover) MUFFLER ENGINE OIL FILLER CAP/DIPSTICK CHOKE LEVER RECOIL STARTER PRIMING BULB STARTER GRIP FUEL FILLER CAP ENGINE SERIAL NUMBER...
  • Page 12 FRAME SERIAL NUMBER Record the frame serial number and the engine serial number (see page ) in the space below. You will need these serial numbers when ordering parts. Engine serial number: Frame serial number:...

  • Page 13: Pre-Operation For Starting

    PRE-OPERATION FOR STARTING Install the hose connector. Be sure to check that the packing is seated in its place and install the hose connector to the port on the pump. HOSE CONNECTOR PACKING HOSE COUPLING HOSE CLAMP RING Connect the suction hose. Use commercially available hose, hose connector, and hose bands.
  • Page 14 Connect the discharge hose. Use a commercially available hose, hose connector, and hose band. A short, large-diameter hose is most efficient. Long or small-diameter hose increases fluid friction and reduces pump output. Tighten the hose band securely to prevent the hose from disconnecting under high pressure.
  • Page 15 Install the garden hose adapter (Canadian type only) GARDEN HOSE ADAPTER An adapter is supplied with the pump for optional connection of a garden hose to the pump discharge port. Garden hose is a convenient and economical option for carrying the discharged water, though its smaller diameter will reduce the maximum discharge capacity of the pump.
  • Page 16 Recommended Oil Use 4-stroke motor oil that meets or exceeds the requirements for API service classification SE or later (or equivalent). Always check the API service label on the oil container to be sure it includes the letters SE or later (or equivalent).
  • Page 17 OIL FILLER HOLE ENGINE OIL FILLER CAP/DIPSTICK UPPER OIL LEVEL UPPER OIL LEVEL...
  • Page 18 Check the fuel level. Check the fuel level by looking through the translucent fuel tank. If the fuel level is low, refuel in a well-ventilated area with the engine stopped. If the engine has been running, allow it to cool. Use automotive unleaded gasoline with a Research Octane Number of 91 or higher (a Pump Octane Number of 86 or higher).
  • Page 19 Gasolines containing alcohol If you decide to use a gasoline containing alcohol (gasohol), be sure its octane rating is at least as high as that recommended by Honda. There are two types of ‘‘gasohol’’: one containing ethanol, and the other containing methanol.
  • Page 20 Check the air cleaner element. Move the choke lever to the CLOSED (upwards) position. Remove the air cleaner cover by unhooking the latch tab on the top of the air cleaner cover and its two lower tabs. Check the element to be sure it is clean and in good condition. If the element is dirty, clean it (see page ).
  • Page 21 Operating environment Always position the pump in an upright position on a firm level surface at least 1 meter (3 feet) away from any walls or other equipment. At least 1 meter (3 feet) Do not allow the pump to tip over or fall in its side during use. If the pump is not positioned upright or if there is not enough space around the pump, cooling air can become restricted or the engine exhaust may be obstructed, causing engine damage.
  • Page 22 Check that all nuts, bolts, and screws are tightened. Check for loose bolts, nuts and screws. Tighten the bolts, nuts and screws properly and securely, if necessary. Check the priming water. The pump chamber should be primed with full of water before operating.

  • Page 23: Starting The Engine

    STARTING THE ENGINE Turn the engine switch to the ON position. ENGINE SWITCH Move the throttle lever away from the LOW position, about 1/2 of the way toward the HIGH position. HIGH THROTTLE LEVER...
  • Page 24 To start a cold engine, move the choke lever to the CLOSED position. Do not use the choke if the engine is warm or the air temperature is high. CHOKE LEVER CLOSED CLOSED Press the priming bulb several times until a fuel flow in the fuel return tube (clear plastic tube) is visually noticed.
  • Page 25 Hold the carrying handle securely and pull the starter grip lightly until you feel resistance, then pull briskly in the direction of the arrow as shown below. Return the starter grip gently. Do not allow the starter grip to snap back against the engine. Return it gently to prevent damage to the starter.

  • Page 26: Carburetor Modification For High Altitude Operation

    High altitude performance can be improved by specific modifications to the carburetor. If you always operate your water pump at altitudes above 1,500 meters (5,000 feet), have your authorized Honda servicing dealer perform this carburetor modification. This engine, when operated at high altitude with the carburetor modifications for high altitude use, will meet each emission standard throughout its useful life.

  • Page 27: Operation

    OPERATION Never use the pump for muddy water, rejected oil, wine, etc. If the choke lever was moved to the CLOSED position to start the engine, gradually move it to the OPEN position as the engine warms CHOKE LEVER OPEN Position the throttle lever for the desired engine speed.

  • Page 28: Stopping The Engine

    STOPPING THE ENGINE To stop the engine in an emergency, simply turn the engine switch to the OFF position. Under normal conditions, use the following procedure. Move the throttle lever fully to the LOW position. THROTTLE LEVER Turn the engine switch to the OFF position. ENGINE SWITCH After use, remove the pump drain plug (see page ), and drain the...

  • Page 29: Maintenance

    If the pump has been used with sea water, etc., clean it with fresh water immediately afterward to reduce corrosion or remove sediment. Use genuine Honda parts or their equivalent for maintenance or repair. Replacement parts which are not of equivalent quality may damage the pump.

  • Page 30: Maintenance Schedule

    Maintenance schedule REGULAR SERVICE PERIOD (3) First Every 3 Every 6 Every Every Perform at every indicated month Each month months months year two years or operating hour interval, whichever comes first. 10 hrs. 25 hrs. 50 hrs. 100 hrs. 300 hrs.
  • Page 31 Changing oil Drain the oil while the engine is still warm to assure rapid and complete draining. Check the fuel filler cap is tightened securely. Remove the oil filler cap and drain the oil into the oil container by the pump toward the oil filler neck. FUEL FILLER CAP OIL FILLER NECK ENGINE OIL FILLER CAP/DIPSTICK...
  • Page 32 Refill with the recommended oil (see page ) and check the oil level (see page ENGINE OIL CAPACITY (Disassembly): 0.08 L (0.08 US qt, 0.07 lmp qt) The oil capacity with replaced is less than the oil capacity with disassembled. UPPER OIL LEVEL Install the oil filler cap.
  • Page 33 Air cleaner service A dirty air cleaner will restrict air flow to the carburetor. To prevent carburetor malfunction, service the air cleaner regularly. Service more frequently when operating the pump in extremely dusty areas. Never use gasoline or low flash point solvents for cleaning. They are flammable and explosive under certain conditions.
  • Page 34 CHOKE LEVER LATCH TAB AIR CLEANER BODY AIR CLEANER ELEMENT AIR CLEANER COVER LOWER TABS...
  • Page 35 Spark plug service CMR5H (NGK) Recommended spark plug: Never use a spark plug of incorrect heat range. To ensure proper engine operation, the spark plug must be properly gapped and free of deposits. Loosen the 5 mm hex socket bolt with a hexagon wrench, then remove the top cover.
  • Page 36 SPARK PLUG CAP SPARK PLUG WRENCH Remove any dirt from around the spark plug area. Remove the spark plug cap and use the proper size spark plug wrench to remove the spark plug. If the engine has been running, the muffler will be very hot. Be careful not to touch the muffler.
  • Page 37 Visually inspect the spark plug. Discard the spark plug if there is apparent wear, or if the insulator is cracked or chipped. Clean the spark plug with a wire brush if it is to be reused. Measure the plug gap with a feeler gauge. Correct as necessary by bending the side electrode.
  • Page 38 Fuel filter service and fuel tank cleaning Gasoline is extremely flammable and is explosive under certain conditions. Do not smoke or allow flames or sparks in the area. Check that the engine oil filler cap is tightened securely. Remove the fuel filler cap and drain the fuel into an approved gasoline container by tipping the pump toward the fuel filler neck.
  • Page 39 Cooling fins service Loosen the 5 mm hex socket bolt with a hexagon wrench, then remove the top cover (see page Inspect the engine cooling fins, and clean out debris if they are clogged. COOLING FINS Install the top cover, and tighten the 5 mm hex socket bolt with a hexagon wrench securely.
  • Page 40 SPARK ARRESTER SERVICE (Equipped type only) The spark arrester must be serviced every 100 hours to keep it functioning as designed. If the engine has been running, the muffler will be very hot. Allow the muffler to cool before servicing the spark arrester. Loosen the 5 mm hex bolt with a hexagon wrench, then remove the top cover (see page Remove the 4 mm screws from the spark arrester, and remove the...

  • Page 41: Transporting/Storage

    TRANSPORTING/STORAGE To avoid severe burns or fire hazards, let the engine cool before transporting the pump or storing it indoors. When transporting the pump, keep the pump level and make sure the fuel filler cap is installed securely. Spilled fuel or fuel vapor may ignite.
  • Page 42 Drain the fuel..Check that the engine oil filler cap is tightened securely. Remove the fuel filler cap and drain the fuel into an approved gasoline container by tipping the pump toward the fuel filler neck. Press the priming bulb several times until there is no more fuel in the fuel return tube.
  • Page 43 Change the engine oil (see page Clean the air cleaner (see page Loosen the 5 mm hex socket bolt, then remove the top cover (see page Remove the spark plug (see page Apply a couple of drops of clean engine oil into the cylinder. Install the top cover temporarily.

  • Page 44: Troubleshooting

    Is the spark plug in good condition? (see page 34 ) Remove and inspect the spark plug. Clean, readjust gap and dry the spark plug. Replace it if necessary. If the engine still does not start, take the pump to an authorized Honda dealer.
  • Page 45 Is the strainer clogged? Are the hose bands installed securely? Are the hoses damaged? Is the suction head too high? If the pump still does not operate, take the pump to an authorized Honda dealer. HOSE CONNECTOR STRAINER SUCTION HOSE HOSE BAND...

  • Page 46: Specifications

    SPECIFICATIONS WX10 Model WATJ Power equipment description code Dimensions and Weight Length 325 mm (12.8 in) Width 220 mm (8.7 in) Height 300 mm (11.8 in) Dry mass (weight) 6.1 kg (13.4 lbs) Engine Model GX25T Engine type 4-stroke, overhead camshaft, 1 cylinder Displacement 25.0 cm (1.53 cu-in)
  • Page 47 Spark plug gap 0.7 m m Refer to page: 34 (0.024 0.028 in) Valve clearance IN:0.08 0.02 mm See your authorized (cold) EX:0.11 0.02 mm Honda dealer Other specifications No other adjustments needed. Specifications are subject to change without notice.

  • Page 48: Major Honda Distributor Addresses

    W e i t e r e I n f o r m a t i o n e n e r h a l t e n S i e g e r n e v o m H o n d a - Kundeninformationszentrum unter der folgenden Adresse oder Telefonnummer: DIRECCIONES DE LOS PRINCIPALES CONCESIONARIOS Honda Para obtener más información, póngase en contacto con el Centro de información para clientes Honda en la dirección o número de teléfono siguientes:...
  • Page 49 AUSTRIA CROATIA FINLAND Honda Motor Europe (North) Hongoldonia d.o.o. OY Brandt AB. Jelkovecka Cesta 5 Hondastraße 1 Tuupakantie 7B 2351 Wiener Neudorf 10360 Sesvete Zagreb 01740 Vantaa Tel. : 43 (0)2236 690 0 Tel. : 385 1 2002053 Tel. :...
  • Page 50 356 21 480 150 http://www.honda.pt info hondakisgepek.hu honda.produtos honda-eu. ICELAND NETHERLANDS REPUBLIC OF BELARUS Bernhard ehf. Honda Motor Europe (North) Vatnagardar 24-26 Afd. Power Equipment- Scanlink Ltd. 104 Reykdjavik Capronilaan 1 Kozlova Drive, 9 Tel. : 354 520 1100 1119 NN Schiphol-Rijk...
  • Page 51 CR honda.ua ventas aucasa.com taller aucasa.com SLOVAKIA REPUBLIC SWEDEN UNITED KINGDOM Honda Slovakia, spol. s r.o. Honda Nordic AB Honda (UK) Power Equipment Prievozská 6 821 09 Bratislava Box 50583 - Västkustvägen 17 470 London Road Tel. : 421 2 32131112 20215 Malmö...
  • Page 52 (& 'HFODUDWLRQ RI &RQIRUPLW\ &217(17 287/,1( &('pFODUDWLRQ GH FRQIRUPLWp '(6&5,37,21 '( 7$%/( '(6 0$7,(5(6 (8.RQIRUPLWlWVHUNOlUXQJ ,1+$/76h%(56,&+7 '(6&5,3&,Ï1 *(1(5$/ '(/ &217(1,'2 '( /$ 'HFODUDFLyQ GH &RQIRUPLGDG &( '(6&5,=,21( '(/ &217(1872 '(//$ 'LFKLDUD]LRQH &( GL &RQIRUPLWj (& 'HFODUDWLRQ RI &RQIRUPLW\ • • •...
  • Page 53 )UDQoDLV )UHQFK ,WDOLDQR ,WDOLDQ 'HXWVFK *HUPDQ 1HGHUODQGV 'XWFK 'DQVN 'DQLVK *UHHN 6YHQVND 6ZHGLVK (VSDxRO 6SDQLVK 5RPkQ 5RPDQLDQ ...
  • Page 54 3RUWXJXrV 3RUWXJXHVH 3ROVNL 3ROLVK 6XRPL  6XRPHQ NLHOL )LQQLVK 0DJ\DU +XQJDULDQ &HVWLQD &]HFK /DWYLHãX /DWYLDQ 6ORYHQþLQD 6ORYDN (HVWL (VWRQLDQ 6ORYHQVþLQD 6ORYHQLDQ F 5R]PHU...
  • Page 55 /LHWXYL NDOED /LWKXDQLDQ %XOJDULDQ 1RUVN 1RUZHJLDQ ...
