Digital music player
SAFETY INSTRUCTION
To avoid personal injury or damage to equipment, please ensure that you read this
manual in its entirety before attempting to operate the equipment. Please retain this
manual for future reference.
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT UNDER ANY CIRCUMSTANCES
REMOVE ANY PARTS OF THE EQUIPMENT COVER. THERE ARE NO USER
SERVICEABLE PARTS INSIDE. ALL SERVICING MUST BE CARRIED OUT BY QUALIFIED
SERVICE PERSONNEL.
This icon marks a presence of un-insulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
This icon marks important operating, maintenance and service information that should
be read to prevent possible personal injury
WARNINGS
Do Not Disassemble
Do not attempt to service the equipment beyond that described in this manual. Touching
the equipment's internal parts could result in severe personal injury. All other servicing or
problems as listed below should be referred to qualified Consonance service technicians:
•
The power supply cord or plug has been damaged
•
Objects have fallen or liquid has been spilled into the equipment
•
The equipment does not appear to function normally or exhibits a marked change in
performance
•
The equipment has been dropped or the enclosure damaged
Do not under any circumstances allow anyone to modify your Consonance equipment
without first checking with Opera Audio, your dealer, or your distributor. Unauthorized
modifications will invalidate your guarantee.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the D-Linear7MK2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Consonance D-Linear7MK2

Summary of Contents for Consonance D-Linear7MK2

  • Page 1 Digital music player SAFETY INSTRUCTION To avoid personal injury or damage to equipment, please ensure that you read this manual in its entirety before attempting to operate the equipment. Please retain this manual for future reference. TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT UNDER ANY CIRCUMSTANCES REMOVE ANY PARTS OF THE EQUIPMENT COVER.
  • Page 2 Power Source The equipment should be connected to a power supply only of the type described in this manual or as marked on the equipment. Grounding or Polarization Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience receptacles, and the point where they exit from the amplifier.

  • Page 3: Table Of Contents

    Table of Contents Introduction 4--- 6 Fast operating guide 7---17 Appendix 1 Appendix 2 19---22 Appendix 3 23---24 Reference7 Specification D-Linear7MK2 Specification Warranty...
  • Page 4 Please check the following Appendix ments are complete： Remote control Reference7 D-Linear7MK2 Power Cable Instructions for use Card reader（For SD card transform） extended wire. （For the USB wireless adaptor and USB storage device both in USB port.） 802.11N 150M high speed wireless adaptor.
  • Page 5 Refenrence7 OPERATING TIPS 1. Power switch indicator 2. LED 3. Display touch screen 4. Remote sensor 5. RJ-45 LAN interface 6. USB HOST ports 7. Coaxial Digital output 8. OPTICAL Digital input 9. Balanced Analog outputs 10. RCA Analog outputs 11.
  • Page 6 D-Linear7MK2 GENERAL TIPS 1. Display touch screen 2. USB HOST Port 3. USB HOST jack 4. RJ-45 LAN interface 5. AES digital output 6. Coaxial Digital output 7. RCA analog outputs 8. AC Power connection 9. Fuse 10. Power switch...

  • Page 7: Fast Operating Guide

    Fast operating guide After turning the player on wait about 30 seconds. The icon interface will show up as per the above picture, with 6 icons in total. Only three icons can be seen each time, they can be switched (moved) simply by touch or remote control The icons of this interface indicate the following functions: System settings list or view system properties...
  • Page 8 Play USB storage device Descriptions for each USB port The machine also has USB HOST and the USB DEVICE Interface ports on the rear panel. WARNING NOTE: Do not run both two USB ports at the same time, this can cause a USB failure. Position the on the interface in the middle, then touch it or press the...
  • Page 9 Click the current selected file name on the screen or button on the remote control to play music. The screensaver will be active when music played for 10 seconds. In playing mode, press the RCLL LIST button to recall the file list to select other file to play.
  • Page 10 1. Playing timeline. Recording button: Click this button or press button on the remote control to record the current playing file to the USB storage device (24 bit/96kHz WAV). NOTE: The USB storage device should be FAT32 file system. The FAT32 format operation detail in Appendix 1.
  • Page 11 Single file repeat Folder files repeat; No repeat； Random play； Sequence. NOTE: The DL7 has an internal volume control with screen display, however the Ref 7 does not have a internal volume control but does display the volume bar, please disregard this display if you own the Ref 7.
  • Page 12 Internet Broadcast To play the internet broadcast you need to setup the network correctly. The Appendix 2 is the network setup guide. This icon means Reference 7 network is connected. Click or press the @ button on the remote control to enter the broadcast list: Region, Type.
  • Page 13 Click the or the button on the remote control to record the current playing internet broadcast to USB storage device. Please check the Appendix 1 recording detail. ： NOTE The USB storage device should be FAT32 format. Net Source To play the network the source needs to be setup correctly. The Appendix 2 is the network setup guide.
  • Page 14 Click the roll bar or press the OK button on the remote control to into the samba share, the shared folder computer IP address will be displayed. The Input IP support input the IP address by press the number button on the remote control to visit the shared folder computer.
  • Page 15 USB storage device. Please check the Appendix 1 recording detail. ： NOTE The USB storage device should be FAT32 format. The DAC button for D-Linear7MK2 was switch the R0~R5 digital filter mode.
  • Page 16 SETUP Select the in the center of main menu click it or press button on the remote control to SETUP menu. SETUP menu support 7 option, click the option name or press to select setup option. SETUP OPTION: Network, Brightness, Language, Screen Time, Update, Calibrate, About.
  • Page 17 Screen Time: Screen time is the lighting time of the background light,4 options：5 sec, 10 sec, 30 sec and always. Update: The system support firmware upgrade. Please visit http://www.opera-consoncance.com to download the upgrade firmware. How to update: Copy the update_firmware.bin to USB stick root folder. Plug the USB stick to USB HOST port, into the UPDATE menu, the system will upgrade the firmware automatic.

  • Page 18: Appendix 1

    Appendix 1 Recording In playing internet broadcast or DAC mode, touch this icon for 2 seconds or long press button on the remote control to record music. The recorded file will be auto named and save into USB storage device. The USB storage device must in FAT32 format, select storage location to record the music.
  • Page 19 Appendix 2 Network setting in detail: DHCP opened / closed and input by hand specifications: Find the icon in the main interface，and “ network selection ” menu after entering. Find “ DHCP ” through touching screen or pressing the buttons of remote control.
  • Page 20 2. Access to “IP Addr” after entering IP setting menu.(as left picture).Set up IP address through the of remote control. 3. Return to the previous menu after setting this up and select “Route Addr ”. 4. Set up operation method the same as above after entering “Route Addr”(see right ).
  • Page 21 WI-FI and LAN connection: Plug the wifi module into the USB interface, insert the networking cable into the “LAN” port directly and set up relevant network configuration , then you can use the network functions. To select the “Lan” mode after networking cable of computor insert the “LAN”...
  • Page 22 Selected the right device. ， ， Set up the connected code using the remote control button of ， Note: To select the number 0~9 and English words with the button ， of remote control and letters with the button by moving last code or insert next code.
  • Page 23 Appendix 3: The remote control must be pointed towards to the receiver window and operated within the range of 30 degrees and 7 meters. Please do not place any visual obstruction between them. Please avoid allowing direct sunlight or florescent lighting to fall directly in the receiver sensor of the unit.
  • Page 24 11. Next While music is playing, press the key once and it will jump to the next file for broadcasting. Under searching files, to many files displayed, please use the key to page down. Move down the cursor under the network settings and input the password of the wireless network.

  • Page 25: Reference7 Specification

    Reference7 Specification 1．24Bit/192kHz digital stream music player. 2．Built-in 24Bit/96kHz recording for digital input and internet broadcast. (needs FAT32 storage device) 3．Built-in over 10,000 global Internet Broadcast stations. 4．Upgradeable firmware through USB memory device. 5．Support play WAV/FLAC/ALAC/ACC etc, digital music format. 6．RJ-45 10/100Mbps LAN, support TCP/IP, UpnP, UDP, RTSP, HDCP, PPPoE, HTTP etc, network protocol, support NAS and PC sharing, support MMS, RTSP, HTTP etc, stream media protocol.

  • Page 26: D-Linear7Mk2 Specification

    D-Linear7MK2 Specification 1．24Bit/192kHz digital stream music player 2．Built-in 24Bit/96kHz recording for internet broadcast. (needs FAT32 storage device) 3．Built-in over 10,000 globe Internet Broadcast 4．Upgradeable firmware 5．Support play WAV/FLAC/ALAC/ACC etc, digital music format. 6．RJ-45 10/100Mbps LAN, support TCP/IP, UpnP, UDP, RTSP, HDCP, PPPoE, HTTP etc, network protocol, support NAS and PC sharing, support MMS, RTSP, HTTP etc, stream media protocol.

  • Page 27: Warranty

    Warranty Opera audio guarantees each product manufactured by us to be free from defects in materials and workmanship under normal use. Our obligation under this warranty is limited to making good at our factory any part or parts thereof which shall, within 1 year after delivery to the original purchaser, be returned to us with transportation charges prepaid, and which an examination shall disclose to have been thus defective;...

This manual is also suitable for:

Reference7
