Instant Transmission WIRELESS 868 MHz Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

WIRELESS 868 MHz WEATHER STATION
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this Weather Station with wireless 868 MHz transmission of outdoor
temperature and display of indoor temperature, weather forecast icons and weather tendency indicators. It
is further featuring a DCF-77 radio controlled clock and alarm function. With four easy to use function
keys, this innovative product is ideal for use in the home or office.
29

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WIRELESS 868 MHz and is the answer not in the manual?

Questions and answers

Related Manuals for Instant Transmission WIRELESS 868 MHz

Summary of Contents for Instant Transmission WIRELESS 868 MHz

  • Page 1 Instruction Manual INTRODUCTION: Congratulations on purchasing this Weather Station with wireless 868 MHz transmission of outdoor temperature and display of indoor temperature, weather forecast icons and weather tendency indicators. It is further featuring a DCF-77 radio controlled clock and alarm function. With four easy to use function...
  • Page 2 FEATURES: The Weather station Hanging hole Battery compartment LCD Display cover Foldout stand Function keys...
  • Page 3 • DCF-77 Radio controlled time function with manual time setting options • DCF time reception ON/OFF • 24 hour display • Alarm function with snooze • Temperature display in degree Celsius (°C) • Indoor and outdor temperature with MIN/MAX records •...
  • Page 4 SETTING UP: Note: This weather station receives only one outdoor transmitter. First, insert the batteries into the Temperature transmitter. (see “Install and replace batteries in the Temperature transmitter“). Immediately after and within 30 seconds, insert the batteries into Weather station (see “Install and replace batteries in the Weather station”).
  • Page 5 Note: Daily DCF reception is done at 02:00 and 03:00 every day. If the reception at 03:00 is not successful, then at 04:00 and 05:00 and 06:00 there are other tries, until one is successful. If the reception at 06:00 is still not successful, then the next try takes place at 02:00 next day.

  • Page 6: How To Install And Replace Batteries In The Temperature Transmitter

    HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE TRANSMITTER The Temperature Transmitter uses 2 x AA, IEC LR6, 1.5V battery. To install and replace the batteries, please follow the steps below: Remove the battery compartment cover at the back of the transmitter. Insert the batteries, observing the correct polarity (see marking).

  • Page 7: Function Keys

    FUNCTION KEYS: Weather station: The weather station has four easy to use function keys. MIN/MAX RESET key SET key ALARM key + key SET key • Press the key to enter manual setting modes: Time zone, Time reception ON/OFF and Manual time •...

  • Page 8: Alarm Key

    ALARM key • Enter the alarm setting mode • Switch the alarm ON/ OFF • Stop the alarm MIN/MAX RESET key • Press and hold to reset the MIN/MAX temperature records • Activate the snooze • Exit manual setting modes...

  • Page 9: Lcd Screen And Settings

    LCD SCREEN AND SETTINGS: Radio controlled time reception icon Time Alarm icon Low battery indicator (weather station) MIN/MAX indoor Indoor temperature Temperature in °C Weather Weather tendency forecast icon indicator Outdoor Reception Low battery indicator Signal icon* (transmitter) MIN/MAX outdoor Outdoor temperature Temperature in °C...

  • Page 10: Section 1 - Time And Alarm

    * When the outdoor signal is successfully received by the Weather Station, this icon will be switched on. (If not successful, the icon will not be shown in LCD) So user can easily see whether the last reception was successful (icon on) or not (icon off). For a better display clarity, the LCD screen is split into 4 sections.

  • Page 11: Manual Settings

    Section 3 - WEATHER FORECAST AND WEATHER TENDENCY ICONS • Display of the weather to be expected in form of three weather symbols and two weather tendency indicators in form of an arrow, which change their appearance depending on the air pressure development Section 4 - OUTDOOR TEMPERATURE •...

  • Page 12: Time Zone Setting

    TIME ZONE SETTING: Time zone (flashing) The time zone default is "0" hour. To set a different time zone: The current time zone value starts flashing. Use the + key to set the time zone. The range runs from 0, -1, -2…-12, 12, 11, 10… 2, 1, 0, in consecutive 1-hour intervals.

  • Page 13: Manual Time Setting

    In area where reception of the radio-controlled time (DCF time) is not possible, the time reception function can be turned OFF. The clock will then work as a normal Quartz clock. (Default setting is ON). The digit “ON” digit will start flashing on the LCD. Use the + key to turn OFF the time reception function if necessary.

  • Page 14: Alarm Setting

    To set the clock: The hour digits start flashing in the time display section. Use the + key to adjust the hours and then press SET key to go to the minute setting. The minute will be flashing. Press the + key to just the minutes. Confirm with the SET key and exit the setting mode.
  • Page 15 Press ALARM button once and minute digit will be flashing. User shall then press + button to set the minute. Press ALARM button once to confirm the setting. To activate/ deactivate the alarm function, press the ALARM button once. The display of the alarm icon represents that the alarm is "ON".
  • Page 16 Sunny Cloudy with Rainy sunny intervals For every sudden or significant change in the air pressure, the weather icons will update accordingly to represent the change in weather. If the icons do not change, then it means either the air pressure has not changed or the change has been too slow for the Weather station to register.

  • Page 17: The Weather Tendency Indicator

    Note : After setting up, readings for weather forecasts should be disregarded for the next 12-24 hours. This will allow sufficient time for the Weather Station to collect air pressure data at a constant altitude and therefore result in a more accurate forecast. Common to weather forecasting, absolute accuracy cannot be guaranteed.
  • Page 18 increasing and the weather is expected to improve, but when indicator points downwards, the air-pressure is dropping and the weather is expected to become worse. Taking this into account, you will see how the weather has changed and how it is expected to change. For example, if the indicator is pointing downwards together with cloud and sun icons, then the last noticeable change in the weather was when it was sunny (sun icon only).

  • Page 19: Low Battery Indicator

    Note: The MIN/MAX indoor temperature range is -9ºC to + 38ºC with 1°C resolution. OUTDOOR TEMPERATURE AND MIN/MAX RECORDS The outdoor temperature and outdoor MIN/MAX records are displayed on the last section of the LCD. Outdoor icon Outdoor reception signal icon MAX outdoor temperature record Outdoor Temperature...

  • Page 20: 868 Mhz Reception Check

    Low battery indicator is displayed on the LCD when the batteries require changing. 868 MHz RECEPTION CHECK The Weather station should receive the temperature data within 3 minutes after set-up. If the temperature data is not received 3 minutes after setting up (not successfully continuously, the outdoor display shows “- - -”...
  • Page 21 However, this depends on the surrounding environment and interference levels. If no reception is possible despite the observation of these factors, all system units have to be reset (see Setting up). POSITIONING THE TEMPERATURE STATION: The Weather Station may be hung onto wall easily or free standing. To wall mount Choose a sheltered place.
  • Page 22 With the foldout stand, the weather station can be placed onto any flat surface. POSITIONING THE TEMPERATURE TRANSMITTER: The Transmitter is supplied with a holder that may be attached to a wall with the two screws supplied. The Transmitter can also be position on a flat surface by securing the stand to the bottom to the Transmitter.

  • Page 23: Care And Maintenance

    Secure the bracket onto a desired wall using the screws and plastic anchors. Clip the remote temperature sensor onto the bracket. Note: Before permanently fixing the transmitter wall base, place all units in the desired locations to check that the outdoor temperature reading is receivable. In event that the signal is not received, relocate the transmitters or move them slightly as this may help the signal reception.

  • Page 24: Specifications

    • Special care shall be taken when handling a damaged LCD display. The liquid crystals can be harmful to user's health. • Do not make any repair attempts to the unit. Return them to their original point of purchase for repair by a qualified engineer.

  • Page 25: Liability Disclaimer

    Temperature transmitter 2 x AA, IEC, LR6, 1,5V Battery life cycle (Alkaline batteries recommended) Approximately 12 months Dimensions (L x W x H) : Weather station 84 x 22,6 x 149 mm Temperature transmitter 38,2 x 21,2 x 128,3 mm LIABILITY DISCLAIMER: •...
  • Page 26 • This product is designed for use in the home only as indication of the temperature and other weather data. • This product is not to be used for medical purposes or for public information. The specifications of this product may change without prior notice. •...
