Stealthbox SB-VW-GTI/10W6v2 Installation Manual

I N S T A L L A T I O N G U I D E
for the
SB-VW-GTI/10W6v2 SB-VW-GTI/10W6v2
2006-Up GTI MkV, Rabbit & R32 2006-Up GTI MkV, Rabbit & R32
Thank you for choosing a JL Audio Stealthbox
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. If you prefer to perform your own installation,
please read this installation guide completely
before beginning the process.
® for your automotive sound system. With proper
® installed by your authorized JL Audio
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
13 1/2-inches
6-inches
SB-VW-GTI/10W6v2_INSTR_SKU#011250 SB-VW-GTI/10W6v2_INSTR_SKU#011250
INSTALLATION
D I F F I C U L T Y :
2
ESTIMATED TIME:
1 HOUR 1 HOUR
S T E P 1
Remove any contents from the cargo area.
S T E P 2
Place the supplied wax square onto the driver's side rear
cargo panel.
S T E P 3
Thread the supplied socket cup screw into the rear of the
Stealthbox®.
Continued on Next Page
OUT
OF 5
