Receiver Models 7223, 7225 and 7227
USER'S MANUAL
WORLD HEADQUARTERS
Tel: (631) 273-0404
Email:
Communications Specialties Pte Ltd
Tel: +65 6391 8790
Email:
RGBHV Video with
Stereo Audio
55 Cabot Court
Hauppauge, N.Y. 11788 USA
Fax: (631) 273-1638
www.commspecial.com
info@commspecial.com
100 Beach Road
#22-09 Shaw Tower
Singapore 189702
Fax: +65 6396 0138
csiasia@commspecial.com
P/N: 123202 Rev. A
Advertisement
Table of Contents
Related Manuals for Fiberlink 7223
Summary of Contents for Fiberlink 7223
- Page 1 RGBHV Video with Stereo Audio Receiver Models 7223, 7225 and 7227 USER’S MANUAL WORLD HEADQUARTERS 55 Cabot Court Hauppauge, N.Y. 11788 USA Tel: (631) 273-0404 Fax: (631) 273-1638 www.commspecial.com Email: info@commspecial.com Communications Specialties Pte Ltd 100 Beach Road #22-09 Shaw Tower...
-
Page 2: Table Of Contents
CONTENTS General Information ........... 3 Introduction ............3 Technical Specifications ......... 3 Installation Instructions ..........6 Installation Procedure ..........6 System Connections ..........7 Indicator LEDs ............8 Operating Pointers and Troubleshooting ....9 Maintenance and Repairs ......... 10 Limited Warranty ............. 11... -
Page 3: General Information
Following are general descriptions of each unit: 7223 Receiver: 4 baseband outputs of high-res RGB with stereo audio 7225 Receiver: 1 baseband output of high-res RGB with stereo audio, plus one optical loop-through output... - Page 4 Number of Video Channels Supported ....1 RGBHV Number of Baseband RGBHV Video Outputs ... Model 7225: 1; Models 7223 & 7227: 4 RGB Format Supported .... RGB with separate H and V Signal Connectors ....HD-15F RGB Processing ....... 24 bits, no compression or scaling...
- Page 5 *Distance specifications are only approximate and are not guaranteed. Operating loss budget must not be exceeded. DANGER! The transmitting element in the Pure Digital Fiberlink 7225 and 7227 receiver units contain solid state Laser Diodes located within the optical connectors. These lasers emit invisible infrared electromagnetic radiation which can be harmful to human eyes.
-
Page 6: Installation Instructions
2. Connect the AUDIO output(s) to speakers or other destination(s). 3. Connect fiber optic cable from optical output of the 7220 Series trans- mitter to the optical input of the 7223, 7225 or 7227 receiver unit. 4. If using the drop-and-repeat function available on the 7225 and 7227 units, then connect fiber optic cable from the optical output on these units to the optical input on any 7220 Series receiver. -
Page 7: System Connections
System Connections: The input and output connections for the Pure Digital Fiberlink ® 7223, 7225 and 7227 models are as follows: Audio Connector OUTPUT(S): 3.5mm stereo jack Video Connector OUTPUT(S): HD-15F connector Video Pin Out: RGBHV; RGBHV 1-4 Red Out... -
Page 8: Indicator Leds
Indicator LEDs: The Pure Digital Fiberlink 7223, 7225 and 7227 receivers each have ® three integral indicator LEDs that are used to monitor the state of the unit. The status of the LEDs are as follows: Power: ON: (GREEN) Indicates that correct power has been applied. -
Page 9: Operating Pointers And Troubleshooting
OPERATING POINTERS AND TROUBLESHOOTING Optical Fiber: The 7223, 7225 and 7227 receivers operate with most multimode (MM) and single mode (SM) optical fibers. All models within the 7220 Series use the same 1310 nm wavelength and optics for trans- mitting over multimode or single mode fiber, but be aware that the type of fiber you use will affect the system’s loss budget and the maximum... -
Page 10: Maintenance And Repairs
MAINTENANCE AND REPAIRS The Pure Digital Fiberlink 7223, 7225 and 7227 receivers have been ® manufactured using the latest semiconductor devices and techniques that electronic technology has to offer. They have been designed for long, reliable and trouble-free service and are not normally field repair- able. -
Page 11: Limited Warranty
Buyer, the Pure Digital Fiberlink ® 7223, 7225 and 7227 receivers will be free from defects in material and workmanship under normal use and service. A Return Material Autho- rization (RMA) number must be obtained from CSI before any equip- ment is returned by the Buyer.
