Operating Instructions
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
2730B
Model 245347, Series A with Briggs & Stratton 6.5 HP
Motor
2700 psi (186 bar, 18.6 MPa) Operating Pressure
3000 psi (210 bar, 21.0 MPa) Maximum Working
Pressure
2730H
Model 245348, Series A with Honda 6.5 HP Motor
2700 psi (186 bar, 18.6 MPa) Operating Pressure
3000 psi (210 bar, 21.0 MPa) Maximum Working
Pressure
3030
Model 2445349, Series A
3000 psi (210 bar, 21.0 MPa) Operating Pressure
3300 psi (227.5 bar, 22.75 MPa) Maximum
Working Pressure
Related manuals
. . . . . . .
309425
Warnings
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Component Identification
Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure Relief Procedure
Operation
ASM Warranty
ASM Phone Number
3030 Zip Clean
Model 245349 Shown
309424
Table of Contents
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
ti1025
Rev. A
2
3
4
5
6
14
14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ASM Zip-Clean 2730B
Summary of Contents for ASM Zip-Clean 2730B
- Page 1 3000 psi (210 bar, 21.0 MPa) Maximum Working Pressure ASM Phone Number ......3030 Model 2445349, Series A 3000 psi (210 bar, 21.0 MPa) Operating Pressure...
- Page 2 D Handle and route hoses and tubes carefully. Keep hoses and tubes away from moving parts and hot surfaces. Do not use the hoses to pull equipment. Do not expose ASM hoses to temperatures above 150_F (65_C) or below –40_F (–40_C).
-
Page 3: Component Identification
Component Identification High Pressure Hose Con- Pressure Unloader On/Off Engine Switch (side) nection and Garden Hose Adjustment Knob Connection high pressure hose connection garden hose connection Hose Tip Storage Engine Oil Fill Hydraulic Fluid Fill Oil Level Site Gage Gun and wand 309424... - Page 4 Setup Shipping Damage Check the Zip Clean for shipping damage. Notify the carrier immediately if there is any damage. Connect High–Pressure Hose and Gun Connect the high–pressure hose between the pump outlet and gun inlet. Both of these connections are made with quick couplers. CAUTION Up to 100 ft (30 m) of 3/8”...
- Page 5 Pressure Relief Follow these instructions whenever you are instructed to relieve pressure, stop spraying for more than 10 minutes, check or service the equipment, or install or clean the spray nozzle. 1. Engage trigger safety latch. 2. Turn Zip Clean off and remove ignition cable from spark plug.
- Page 6 Operation Startup Always use this startup procedure to ensure the Zip Clean is started safely and properly. Always engage gun trigger safety latch when you stop spraying. This reduces the risk of fluid injection or splashing in eyes or on the skin if the gun is bumped or triggered accidentally. Observe all CAUTIONS in this section to avoid costly damage to Zip Clean.
- Page 7 Turn on water supply. CAUTION Be sure water supply is completely turned on before running Zip Clean. Running Zip Clean without water will damage the pump. Trigger the gun until a constant stream of water sprays from the tip indicating the air is purged from the system. Open fuel shutoff valve.
- Page 8 Pull starter rope quickly to start engine. Pull and return rope until engine starts. HINT: Placing one foot on Zip Clean as a brace provides better leverage. NOTE: For easier starting, have one person start Zip Clean while another triggers gun. If engine is cold, start engine with choke completely closed.
- Page 9 Chemical Injector Operation Follow Pressure Relief Procedure, page 5. Insert chemical filter (attached with clear tubing to chemical injector) into container of chemical. Insert brass coupler into chemical injector. Install the black, large–orifice, chemical tip. (Installing and Changing Spray Tips, page 10). NOTE: The large orifice of chemical tip causes a drop in pressure that actuates chemical injector.
- Page 10 Installing and Changing Spray Tips Spray tips have 4– or 5–digit numbers on them. Spray Pattern Fan Angle Spray Tip The first two digits are the spray angle. Tip Number holding holes are provided on the chassis 00XXX 0_ blaster (red) including one extra hole for future tip placement.
- Page 11 Shutdown, Flushing, and Storage D If Zip Clean will be exposed to freezing temperatures, drain all water out of pump. If it must be stored in freezing temperatures, flush Zip Clean with a 50% antifreeze solution, and relieve pressure. Flush Zip Clean before you use it again to remove antifreeze.
- Page 12 Sound Data Zip Clean Models So nd Data Sound Data 2730 2730 3030 Briggs & Stratton Honda Motor Motor Sound Pressure 92.5 dB(A) 89.0 dB(A) 93.3 dB(A) Sound Level 106.8 dB(A) 103.3 dB(A) 107.6 dB(A) Unit Weight (dry) 95 lbs (43 kg) 99 lbs (45 kg) 135 lbs (61 kg) 309424...
- Page 13 Notes 309424...
- Page 14 ASM distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by ASM, ASM will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by ASM to be defective.
