- Page 1 INSTRUCTION MANUAL ENGLISH GEBRUIKSAANWIJZING NEDERLANDS ’ NOTICE D UTILISATION FRANÇAIS BETRIEBSANLEITUNG DEUTSCH SD12 • DEHUMIDIFIER • LUCHTONTVOCHTIGER • DESHUMIDIFICATEUR • LUFTENTFEUCHTER...
-
Page 2: Table Of Contents
CONTENTS INHOUDSOPGAVE TABLE DE MATIÈRES INHALTSVERZEICHNIS Congratulations Felicitaties Safety considerations Veiligheidsaspecten How it works Werking Placement Plaatsing Wall mounting Muurbevestiging Control panel and operation Bediening Drainage Waterafvoer Cleaning Schoonmaken Long term storage Opbergen Trouble shooting Verhelpen van problemen Technical data Technische gegevens Félicitations Herzlichen Glückwunsch... -
Page 3: Safety Considerations
ENGLISH CONGRATULATIONS Thank you for choosing this innovative Amcor dehumidifier. We suggest that you keep this manual in a safe place for future reference. It describes the many benefits and advanced features this unique product has to offer. Before you use your new dehumidifier you should carefully read these instructions to maximise this product’s performance. -
Page 4: How It Works
HOW IT WORKS ( see picture on page 2 Your Amcor dehumidifier draws air through a washable filter onto a refrigerated cold coil. As the air passes over the cold surface, moisture condenses and collects into a removable water tank. The drier air, slightly warmer through heating by the condenser, is then expelled through the adjustable directional grill at the top of the unit into the room. -
Page 5: Wall Mounting
ENGLISH WALL MOUNTING Your Amcor dehumidifier can stand on its 4 castors or can be hung on a wall. For that purpose the following components are included: - 2 brackets with 4 screws and plugs to fix on the wall;... -
Page 6: Control Panel And Operation
CONTROL PANEL AND OPERATION Controls: 1. Fan speed 2. ON/OFF and humidistat Indicators: 3. On 4. Water container full Starting and humidity control (humidistat) • Firstly, turn the control knob [2] to the position OFF. • Plug the power cord in a working mains socket. •... -
Page 7: Drainage
Precautions: 1. The dehumidifier will not work if the required humidity level is higher than the ambient level. 2. To protect the compressor from possible damage, wait 3 minutes before restarting the dehumidifier after it has been turned off. 3. The operational temperature range is 5 – 35 °C. 4. -
Page 8: Cleaning
ENGLISH CLEANING WARNING! First of all switch off the unit and pull the plug out of the wall socket. Housing Clean the housing with a soft, damp cloth and dry when clean. Never use chemically treated cloths, alcohol or any other product containing solvents as this may cause damage to the housing. -
Page 9: Long Term Storage
Does the hose have a downward slope throughout its length from the dehumidifi er? not working. Is there a kink or sharp bend in the hose? TECHNICAL DATA Model SD12 Power supply 220-240 V/ 50 Hz Power consumption (at 32 °C, RH 90%)
