Monitor Specification - AOC 917Sw Service Manual

19" LCD Color Monitor
1. Monitor Specifications
Model number
Driving system
Viewable Image Size
Pixel pitch
LCD Panel
Video
Separate Sync.
Display Color
Dot Clock
Horizontal scan range
Horizontal scan Size(Maximum)
Vertical scan range
Vertical scan Size(Maximum)
Optimal preset resolution
Highest preset resolution
Resolution
Plug & Play
Input Connector
Input Video Signal
Power Source
Power Consumption
Connector Type
Signal Cable Type
Dimensions & Weight:
Physical
Height (with base)
Characteristics
Width
Depth
Weight (monitor only)
Weight (with packaging)
Temperature:
Operating
Non-Operating
Humidity:
Environmental
Operating
Non-Operating
Altitude:
Operating
Non-Operating
917Sw
TFT Color LCD
481mm diagoanl
0.2835mm(H) x 0.2835mm(V)
R, G, B Analog lnterface
H/V TTL
16.7M Colors
128 MHz
30 kHz - 83 kHz
408.24mm
56 Hz - 75 Hz
255.15mm
1440 x 900 (60 Hz)
1440 x 900 (60 Hz)
VESA DDC2B/CI
D-Sub 15pin
Analog: 0.7Vp-p(standard), 75 OHM, Positive
100~240VAC, 47~63Hz
Active < 37W
Standby < 1W
15-pin Mini D-Sub
Detachable
439 mm
358 mm
204 mm
3.8 kg
4.7 kg
0° to 50°
-20°to 60°
10% to 85% (non-condensing)
5% to 80% (non-condensing)
0~ 3000m (0~ 10000 ft )
0~ 5000m (0~ 15000 ft )
4
AOC 917Sw
