Summary of Contents for RTS DV-3135
- Page 1 INSTRUCTION MANUAL...
- Page 3 THANK YOU! Thank you very much for choosing this transceiver. transceiver will provide you with reliable, clear and efficient communication service. This transceiver is robust，durable，excellent sound quality，large volume，long distance communication and easy operation. we are confident that you will be satisfied with its perfect quality and functions.
- Page 4 QUICK OPERATION MANUAL Side key 1 and Side key 2 can be programmed as one of following auxiliary functions. For example: When the [side key 1] or [side key 2] programmed as“Keypad lock”auxiliary function,press side key 1 or side key 2 to enable this function. Operation Refer to page Function...
- Page 5 Voice Prompt Unlock, programmed frequency is out of the “Du”“Du ”sounds at intervals frequency range of transceiver. “Du” sounds continuously Empty frequency During transmitting, RED light flashed and emit Low battery, need to be recharged “DU” and stop transmitting The loudspeaker sounds “du” continuously after TOT function is on, please release [PTT] transmitting for a while, and then stop.
- Page 6 CAUTIONS transceiver is excellent designed with advanced technology. The following tips will be helpful for you in performing your obligation under warranty and understanding the safety of transceiver usage. 1.Keep the transceiver and accessories away from children. 2.Please do not try to open or modify the transceiver without permission, non-professionals operation may also cause damage.
-
Page 7: Table Of Contents
TABLE OF CONTENTS UNPACKING ..................................01 Standard Accessories/Optional Accessories ......................... 02 BATTERY INFORMATION ..............................03 INSTALLATION AND CONNECTION ........................... 07 Installing/Removing the Battery ............................07 Installing/Removing the Antenna ............................07 Installing/Removing the Belt Clip ............................08 Installing Speaker/Microphone Jacks ..........................08 Installing Speaker/Microphone ( Headset) ........................ - Page 8 CONTENTS Squelch ....................................22 Battery Saving ................................... 22 Wide/Narrow Band ................................23 High/Low Power ................................23 CTCSS/DCS ..................................23 Programming Software Starting ............................24 TECHNICAL SPECIFICATIONS ............................25 TROUBLESHOOTING GUIDE .............................. 27 ATTACHED CHART ................................29 CTCSS Frequency Chart ..............................29 DCS Chart ..................................
-
Page 9: Unpacking
UNPACKING Carefully unpack the transceiver. We recommend that you identify the items listed in the following table before discarding the packing material. If any items are missing or have been damaged during shipment, please contact dealer immediately. Supplied Accessories Item Number Quantity QA03V(66-88MHz) -
Page 10: Standard Accessories/Optional Accessories
Standard Accessories/Optional Accessories Standard Accessories Antenna * Battery AC Adaptor Belt Clip Screws Battery Charger QA03V (136-174MHz) (QB-28L1600mAh) (12V/500mA QPS-01) (BC03) (QBC-28L) QA03U (400-480MHz) etc Leather Case Speaker/Microphone Instruction Manual Car Charger Line 12V Jack Note: For frequency band of antenna, please refer to label indicated in the bottom of the antenna. Optional Accessories Battery Pack for Programming... -
Page 11: Battery Information
BATTERY INFORMATION NOTES The battery is not charged at the factory， please charge it before using. After purchasing or long term storage (more than 2 months),the first time charging of the battery may not bring the battery to its normal operation capacity. After repeatly and fully charged/discharged for two or three cycle times, the operating capacity will reach the best performance. - Page 12 BATTERY INFORMATION WARNING： When keys or ornamental chains and other electrical metals contact with the battery terminals, the battery may cause damage or hurt bodies. If the battery terminals short circuit, it will generate a lot of heat, please be careful when you bring or using the battery, please put battery or radio into insulated container instead of metal container.
-
Page 13: How To Store The Battery
BATTERY INFORMATION 3.Plug the Li-ion battery pack or transceiver with a Li-ion battery into the charger. Make sure the battery is connected well with charging terminals. LED light turns into Red --- charging. 4.When it is 90% charged (about 3.5hours charging), LED light turns into light-green (needs 1 hour more charging). -
Page 14: Installation And Connection
INSTALLATION AND CONNECTION Installing/Removing the Battery 1. Align the battery with the back of the transceiver, then press the battery and transceiver firmly together until the release latch locked on the base of the transceiver. 2. To remove the battery , lift the safety catch on the base of the transceiver, then press the release latch underneath the safety catch. -
Page 15: Installing/Removing The Belt Clip
INSTALLATION AND CONNECTION Installing/Removing the Belt Clip Installing the Belt Clip： If necessary, fix the belt clip to the back of transceiver with two supplied 3×8mm screws. NOTE: If the belt clip is not installed, its mounting location may get hot during continuous transmission or when it is left in a hot surrounding. -
Page 16: Installing Speaker/Microphone ( Headset)
ACCESSORIES INSTALLATION Installing Speaker/Microphone ( Headset) Insert speaker/microphone ( headset) plug into the speaker/microphone jack. NOTE: The transceiver is not completely waterproof while using the speaker/ microphone. Installing the Optional Hand Strap 1. Slide the loop of the hand strap through the eyelet on the upper rear of the transceiver. -
Page 17: Getting Acquainted
GETTING ACQUAINTED Antenna Channel Selector Rotate to select channels(from 1 to 16). Power/Volume Switch LED indicator Turn clockwise to switch on the Lights red while transmitting,Lights transceiver.Turn anticlockwise kelly while receiving a signal. until a click sounds to switch off Flashes red when transmitting with transceiver.Rotate from left to right low battery power. - Page 18 GETTING ACQUAINTED PTT (Push to talk) Press it and speak to the microphone to make a call. Release it to receive. Speaker/ Side key 1 Microphone jacks Press to activate its programmable function (refer to page 12) Default setting: None (no function) Side key 2 Press to activate its programmable function(refer to page 12)Default...
-
Page 19: Programmable Auxiliary Functions
PROGRAMMABLE AUXILIARY FUNCTIONS Dealer can program Side key 1 and Side key 2 as one of following auxiliary functions: Please refer to description from page 16. ◆Keypad Lock ◆Keypad Lock (with Backup) ◆Monitor ◆Monitor Momentary ◆None (Default setting : Side key 1) ◆Scan ◆Scan + Temporary Deletion ◆Squelch Off... -
Page 20: Basic Operations
BASIC OPERATIONS 1.Switch On/Off Turn the [Power/Volume Switch] clockwise to switch on the transceiver. Turn the [Power/Volume Switch] anticlockwise to switch off the transceiver. Transceiver will be switched on with a sound of beep if dealers has set up voice prompt function. - Page 21 BASIC OPERATIONS 4.Transmitting To make a call, press and hold the [PTT] key, then speak to the microphone. Hold the microphone about (3-4cm) from your lips, so as to make the receiver obtain the best tone quality. Press [PTT], the LED red indicating lamp lightens. Release [PTT] switch to receive.
-
Page 22: Advanced Operations
ADVANCED OPERATIONS Voice Operated Transmission(VOX) VOX operation allows you to do the hand-free transmission. This function must be activated firstly by dealer. It can only be available with supported headset. When operating VOX, you must set a VOX Gain level. If microphone’s Gain is higher than VOX Gain, the transceiver switch to transmitting mode automatically;... - Page 23 ADVANCED OPERATIONS 3.Press the [Side key 1] to increase the VOX Gain level. Press the [Side key 2] to decrease the VOX Gain level. The VOX Gain can be adjusted in level 1, level 10 and OFF. ★The transceiver announces the VOX Gain level while you adjusting it. If OFF is selected, a beep sounds.
-
Page 24: Keypad Lock
ADVANCED OPERATIONS The following programmable auxiliary functions are programmed by dealer (referring to page 12). Keypad Lock Press and hold the key programmed as [Keypad Lock] for 1 second to lock/unlock the transceiver keys. The following keys/functions are still be workable when Keypad Lock is activated: Keypad Lock, Monitor, Monitor Momentary, PTT, Squelch Off, Squelch Off Momentary and Volume. -
Page 25: Squelch Off/Squelch Off Momentary
ADVANCED OPERATIONS Monitor Momentary: Press and hold to enter into Monitor Momentary function, the transceiver will ignore CTCSS,DCS signals under this function； It can monitor the other sides signal as long as receiving the matched carrier wave. Release the key to return to normal operation. Squelch Off/Squelch Off Momentary You can use the key programmed as Squelch Off or Squelch Off Momentary to receive the weak signals that you cannot hear during normal operation, or to adjust the volume when no signals on your selected... -
Page 26: Priority Scan
ADVANCED OPERATIONS locked out of scan range. To start scanning, press the key programmed as Scan or Scan +Temporary Deletion. Scanning starts from the current channel to the up one through the channel numbers. The Kelly LED indicator light flashes. When a matching signal is received on a channel, the LED indicator light turns into Kelly. -
Page 27: Temporary Deletion
ADVANCED OPERATIONS currently stop. Priority: If dealer has programmed a prioriry channel, it is main channel. Temporary Deletion If a key is programmed as[Temporary Deletion] or [Scan+Temporary Deletion] function, you can temporarily remove assigned channels from the scanning list during scaning. When scan stops at a channel, press and hold the key programmed as [Temporary Deletion] or [Scan+Temporary Deletion] for 1 second to remove this channel from the scanning list, then scan re-start again. -
Page 28: Background Operations
BACKGROUND OPERATIONS Program through QPS3308 software and PC-03 cable. Time-out-Timer (TOT) The purpose of Time-out-timer is to restrict transceiver for continuous long term transmission. When the transceiver of continuous transmission time beyond the due time (Default:3m), transceiver is force to stop transmitting and make a sound of beeping. -
Page 29: Channel Announcement
BACKGROUND OPERATIONS Channel Announcement When using the [Channel Selector] to change the channel, after selecting a channel, there will be a voice reports the channel number you choose in Chinese/English/Russian. (Language in Chinese, English, Russian or off this function which is set up by dealer). Voice Prompt Level Dealers will set on/off Voice Prompt functions. -
Page 30: Wide/Narrow Band
BACKGROUND OPERATIONS Wide/Narrow Band On the basis of different national conditions, users can set 25KHz(wide band) or 12.5KHz (narrow band) to communicate. NOTE:High volume but big distortion when the transceiver with wide band talk to the transceiver with narrow band, and squelch will be easily switch off as the increasing of volume. Low volume but large noise when the transceiver with narrow band talk to the transceiver with wide band. -
Page 31: Programming Software Starting
BACKGROUND OPERATIONS Programming Software Starting 1. Double click“QPS3308”setup.exe”to install as indication. 2. Click start menu in computer, under “ALL PROGRAMS” menu, choose and click “USB to Comport” in QPS3308 program, install “USB to Comport” drivers as indication. 3. Connect the PC-03 programming cable to USB port in PC with transceiver. -
Page 32: Technical Specifications
TECHNICAL SPECIFICATIONS General 66-88MHz 136-174MHz 350-390MHz Frequency Range 400-480MHz 470-512MHz etc. Number of Channel 16 channels 25KHz (Wide Band) Channel Spacing 12.5KHz (Narrow Band) Phase-locked Step 5KHz, 6.25KHz Operating Voltage 7.4V DC ±20% Frequency Stability ±2.5ppm Operating Temperature -20~ +55℃ Size 142×57×41mm Weight... - Page 33 TECHNICAL SPECIFICATIONS Spurious Rejection ≥70dB ≥70dB Hum & Noise ≥40dB ≥36dB Audio Response +1~ -3dB(0.3~3KHz) +1~ -3dB(0.3~2.55KHz) Audio Power Output 1000mW (10%) Audio Distortion ≤5% Transmitting Part (ETSI EN 300 086 standard test) Wide band Narrow band Power Output 5W/1W Modulation 16KΦF3E 11KΦF3E...
-
Page 34: Troubleshooting Guide
TROUBLESHOOTING GUIDE Problem Corrective Action A.The battery may be exhausting, recharge or replace the battery . B.The battery may not be installed correctly, remove the battery and install it again. No Power C.The power switch is broken, send it to local dealers to repair it. D.Battery touch is broken, send it to local dealers to repair it. - Page 35 TROUBLESHOOTING GUIDE A.Different frequency or channel, please adjust it. Cannot talk to or hear other members in B.Different CTCSS/DCS, please reset again. your group C.Out of communication range. Cannot power on or frequent automatically Check whether the battery touch is distorted or broken. power off The other communicating party gets low or Check weather the MIC is stoppage.
-
Page 36: Attached Chart
ATTACHED CHART CTCSS Frequency Chart 67.0 94.8 131.8 171.3 203.5 69.3 97.4 136.5 173.8 206.5 71.9 100.0 141.3 177.3 210.7 74.4 103.5 146.2 179.9 218.1 77.0 107.2 151.4 183.5 225.7 79.7 110.9 156.7 186.2 229.1 82.5 114.8 159.8 189.9 233.6 85.4 118.8 162.2... -
Page 37: Dcs Chart
ATTACHED CHART DCS Chart Professional FM Transceiver...
