Summary of Contents for RTS DV-4350

  • Page 2 DANKIE VIR U ONDERSTEUNING! Baie geluk met die aankoop van die RTS DV-4350 YZTERVARK handradio. Nie net is die radio maklik om te gebruik nie, dit is ook koste effektief, uitstekende kwaliteit en ‘n handradio waarop u kan staatmaak vir...
  • Page 3 RTS DV-4350 YZTERVARK radio te voorkom, let asseblief na die volgende: 1. Hou die handradio en toebehore weg van kinders af.
  • Page 4 UITPAK VAN RADIO Wanneer u die RTS DV-4350 YZTERVARK radio uit sy verpakking haal, maak seker dat die volgende items in die pakkie is voor u van die verpakkingsmateriaal ontslae raak: STANDAARD BYBEHORE VOORSIEN: Indien enige van die genoemde bybehore nie daar is nie, of selfs beskadig is,...

  • Page 5: Neem Kennis

    ‘n tyd, al word die battery vol en reg herlaai. Die battery moet dan vervang word. VOORGESKREWE BATTERYLAAIER Wees asseblief seker dat u slegs die batterylaaier gebruik wat aan u RTS DV-4350 YZTERVARK handradio voorgeskryf is. Ander modelle se herlaaiers kan skade aan u radio en selfs beserings aan u persoon veroorsaak.

  • Page 6: Installering En Verwydering Van Battery

     As die battery vol gelaai is, moet dit nie weer laai nie, dit kan die battery se lewensduur beïnvloed. INSTALLERING EN VERWYDERING VAN BATTERY Druk die battery se lippies tussen die gleufies in en skuif die battery teen die radio vas.
  • Page 7 ONTHOU: Die antenna is nie ‘n handvatsel nie, dit is nie ‘n sleutelring nie, moet dit nie sien as ‘n enigiets anders as deel van jou radio nie, moet die radio nie aan sy antenna rond dra nie, jy beskadig jou radio en antenna. INSTALLERING EN VERWYDERING VAN BELTKNIP Spasieer die beltknip in die ooreenstemmende groefies op die agterkant van die handradio, skroef dan kloksgewys vas.
  • Page 9 BEKENDSTELLING A. LED Indikasie - Die LED brand aanmekaar ROOI wanneer die radio uitsaai, en GROEN wanneer die radio sein ontvang. B. Kanaal skakelaar - Draai kloksgewys om kanale te verander. Kanaal nommer 16 is die skandeer kanaal. C. Aan/Af skakelaar en Volume kontrole. Draai kloksgewys om aan te skakel, en antikloksgewys om af te skakel.
  • Page 10 Verander die volume. Hou die monitering sleutel vas en luister na die klank terwyl die Krag skakelaar/Volume kontrole gedraai word. Draai kloksgewys om die volume te verhoog en anti-kloksgewys om die volume te verminder. Kies ‘n kanaal - draai die kanaal skakelaar om jou kanaal te kies. Kanaal 16 is die skandeer kanaal.
  • Page 11 EKSTRA FUNKSIES “SQUELCH “ VLAK Die doel van hierdie funksie is om die luidspreker te demp wanneer daar nie ‘n sterk genoeg sein aanwesig is nie (“SQUELCH” af) en om irriterende geraas vlakke uit te skakel. Wanneer die “SQUELCH” VLAK dus korrek gestel is (“SQUELCH” aan) sal u slegs klank hoor wanneer die radio sein sterk is, en onnodige geraas sal dus uitgeskakel wees.
  • Page 12 jy in die mikrofoon praat. Die VOX funksie kan slegs werk met ‘n KOPSTUK (headset) toegerus met ‘n mikrofoon. Wanneer u van die VOX funksie gebruik maak, maak seker dat die volume van die funksie korrek opgestel word, wat die toestel sal help om klankvlakke te herken.
  • Page 13 SPESIFIKASIES Frekwensie 400 - 470 Mhz RF krag uitset ≤ 5W Kanaal kapasiteit 16 kanale Bedryfsspanning 3.7V Grootte 115mm X 60mm X 33mm Gewig 180g ALLE SPESIFIKASIES KAN VERANDER SONDER KENNISGEWING PROBLEEMOPLOSSINGSGIDS Geen krag a) Maak seker die battery is korrek gekoppel b) Batterypak mag uitgeput wees, herlaai of vervang.
  • Page 14 1) 12 MAANDE WAARBORG OP DIE RADIO. BYBEHORE SOOS LAAIER, BATTERY, ANTENNA WORD NIE GEDEK NIE. 2) FOUTIEWE RADIOS WORD DEUR KLIENT NA DIE RTS HANDELAAR GESTUUR WAAR DIE RADIO AANGEKOOP IS. 3) HOU ASSEBLIEF U FAKTUUR VIR U WAARBORG.
  • Page 15 THANK YOU! We are grateful for your choice of our transceiver. We believe that this easy-to-use transceiver will provide dependable and cost-effective communications for you. Our professional two-way radios incorporate the latest in advanced technology and craft. So you will be pleased with the quality and features of our products.
  • Page 16 PRECAUTIONS 1. Refer service to qualified technicians only. 2. Do not disassemble or modify the transceiver for any reason. 3. Do not expose the transceiver under direct sunlight long time or to extremely hot condition. 4. Do not place the transceiver on the unstable surface. 5.

  • Page 17: Unpacking And Checking Equipments

    UNPACKING AND CHECKING EQUIPMENTS Carefully unpack the transceiver. We recommend that you identify the items listed in the following table before discarding the packing material. If any items are missing or have been damaged during shipment, please contact the dealers immediately. SUPPLIED ACCESSORIES Item Name Quantity...
  • Page 18 Belt Clip User’s Manual...
  • Page 19 CHARGING THE LI-ION BATTERY PACK Please charge the new battery pack before using it. The new or stored (more than two months) battery pack, which can not reach its full capacity for the first charging. After 2 or 3 times charging and discharging, it can reach full charge.

  • Page 20: Installing/Removing The Battery Pack

    INSTALLING/REMOVING THE BATTERY PACK The usage time of JL-11 Battery Pack is about 8 hours, which is based upon 5% transmit/5% receive/90% standby (standard duty cycle). See following images: CAUTION: 1.Do not short-circuit the terminals of the battery or throw the battery into the fire.

  • Page 21: Installing The Antenna

    INSTALLING THE ANTENNA Screw the antenna into the connector on the top of the transceiver by holding the antenna at its base and turning it clockwise until secure. NOTE: The antenna is neither a handle, a key ring retainer, nor a speaker, microphone attachment point.
  • Page 22 NOTE: The transceiver is not fully water resistant when using speaker/microphone.
  • Page 23 GETTING ACQUAINTED A. Led Indicator-- The LED indicator lights continuously red when transmitting. And lights green when in reception condition. Channel Switch—Rotate it to select the channel. No.16 channel is scanning channel. C. POWER SWITCH/VOLUME CONTROL Turn clockwise to switch ON the transceiver. Turn counterclockwise fully to switch OFF the transceiver.

  • Page 24: Adjusting The Volume

    OPERATION SWITCHING POWER ON/OFF Turn the power switch/volume control clockwise. You will hear a beep and speech, indicating the transceiver is ON. ADJUSTING THE VOLUME Hold Monitor button down to listen to audio level while rotating the Power switch/Volume control. Rotate clockwise to increase and counterclockwise to decrease volume.

  • Page 26: Time-Out Timer (Tot)

    ADDITIONAL FUNCTIONS: SQUELCH LEVEL The purpose of Squelch is to mute the speaker when no signals are present (Squelch OFF). With the squelch level correctly set, you will hear sound only while actually receiving signals (Squelch ON). The squelch level can be adjusted via program software.

  • Page 27: Battery Low Alert

    When you operate the VOX function, you must use an optional headset with microphone. 1.When operating the VOX function, be sure to set the VOX Gain level which allows the transceiver to recognize the sound levels. 2.If the microphone is too sensitive, the transceiver will begin transmitting when there is noise in the background.

  • Page 28: Ctcss (Continuous Tone Coded Squelch System)

    BUSY CHANNEL LOCK-OUT (BCL) Busy Channel Lock-out function can be turned ON/OFF with program software on every channel. When activated, BCL prevents you from interfering with other parties who may be using the same channel that you selected. Pressing the PTT switch while the channel is in use will cause your transceiver to emit an alert tone and transmission will be inhibited (you cannot transmit).
  • Page 29 SPECIFICATIONS: Frequency Range:400-470MHz RF Rated Power:≦5W Channel Capacity:16S Operated Voltage: 3.7V Dimensions:115mm×60mm×33mm Weight: 180g NOTE All specifications are subject to change without notice. TROUBLESHOOTING GUIDE No Power ·Check battery installation and/or replace batteries. Voltage Capacity Quickly Go Out. The battery life is over, replace new one. Couldn't I communicate with other group members.
  • Page 30 Hear the voice from other groups. Please change your CTCSS for the channel. At the same time, you also need to the CTCSS for all the radios in your group. If you don't like this, you may apply another channel frequency. Why can I hear the voices clearly from other group, sometimes, my voice is intermittent.
  • Page 31 WARRANTY CARD Model: Serial NO.: Dealer: User name: Address: Purchase Date: Tel. NO.: Fax NO.: Zip Code: Warranty Remarks: 1. The consumer keeps the warranty card as the proof for repairing. 2. The card is of validity with the stamp and date. 3.
