Toshiba Personal Computer
Satellite E100
Satellite E105
(PSE10x)
Maintenance Manual
TOSHIBA CORPORATION
S/ No
Satellite E100/105
Maintenance Manual

Advertisement

Table of Contents
loading

Related Manuals for Toshiba Satellite E100

Summary of Contents for Toshiba Satellite E100

  • Page 1 Toshiba Personal Computer Satellite E100 Satellite E105 (PSE10x) Maintenance Manual TOSHIBA CORPORATION S/ No Satellite E100/105 Maintenance Manual...
  • Page 2 © 2008 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed with respect to the use of the information contained herein.
  • Page 3 Preface This maintenance manual describes how to perform hardware service maintenance for the Toshiba Personal Computer Satellite E100/105, referred to as Satellite E100/105 in this manual. The procedures described in this manual are intended to help service technicians isolate faulty Field Replaceable Units (FRUs) and replace them in the field.
  • Page 4 The manual is divided into the following parts: Chapter 1 Hardware Overview describes the Satellite E100/105 system unit and each FRU. Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve FRU problems. Chapter 3 Test and Diagnostics describes how to perform test and diagnostic operations for maintenance service.
  • Page 5 Text that you are instructed to type in is shown in the boldface type below: DISKCOPY A: B: The display Text generated by the XXXXX that appears on its display is presented in the type face below: Format complete System transferred Satellite E100/105 Maintenance Manual...

  • Page 6: Table Of Contents

    Table of Contents Chapter 1 Hardware Overview 1.1 Features ..........................1 1.2 System Unit Components ....................9 1.3 2.5-inch HDD........................14 1.4 DVD Super Multi (+-R Double Layer)................15 1.5 Power Supply ........................16 1.6 Batteries ..........................17 1.1.1 Main Battery...................17 1.1.2 Battery Charging Control ...............17 1.1.3 RTC Battery ...................18 Chapter 2...
  • Page 7 Test Program Check ............... 2-24 Procedure 2 Connector Check and Replacement Check......2-24 Chapter 3 Diagnostic Programs General ........................1 Quick Start......................... 3 3.2.1 Quick Test ....................3 3.2.2 Customization Test.................. 3 3.2.3 Keyboard Layout test ................7 Satellite E100/105 Maintenance Manual...
  • Page 8 3.2.4 Hotkey Test ....................8 3.2.5 Audio Play Test..................8 3.2.6 Audio Record Test ...................9 3.2.7 DMI Read ....................9 3.2.8 DMI Write ....................9 3.2.9 System Information ................11 3.2.10 View Logs ....................12 Exit to Free DOS...................12 3.2.11 3.2.12 The Diagnostics Screen Explanation............13 Options ........................16 3.3.1 Overview ....................16 3.3.2...
  • Page 9 Removing the Top Cover................... 4-19 Installing the Top Cover ..................4-20 HDD ........................4-21 Removing the HDD ................... 4-21 Installing the HDD .................... 4-23 ODD Bay Module ....................4-24 Removing the ODD Bay Module ..............4-24 Satellite E100/105 Maintenance Manual...
  • Page 10 Installing the ODD Bay Module ............... 4-25 Display Assembly ....................4-26 Removing the Display Assembly............... 4-26 Installing the Display Assembly ................ 4-27 FAN ........................4-28 Removing the FAN .................... 4-28 Installing the FAN ..................... 4-28 4.10 CPU Cooling Module................... 4-29 Removing the CPU Cooling Module..............
  • Page 11 4.19 Power board, Bluetooth card, Button board and Finger print board......4-50 Removing Power board, Bluetooth card, Button board and Finger print board 4-50 Installing Power board, Bluetooth card, Button board and Finger print board 4-51 Satellite E100/105 Maintenance Manual...
  • Page 12 Appendices Appendix A Handling the LCD Module ................A-1 Appendix B Board Layout ....................B-1 Appendix C Pin Assignments.....................C-1 Appendix D Keyboard Scan/Character Codes ..............D-1 Appendix E Key Layout.....................E-1 E100/105 Satellite Maintenance Manual...

  • Page 13: Chapter 1 Hardware Overview

    Chapter 1 Hardware Overview Satellite E100/E105 Maintenance Manual...
  • Page 14 1 Hardware Overview Satellite E100/E105 Maintenance Manual...
  • Page 15 1.3 2.5-inch HDD........................14 1.4 DVD Super Multi (+-R Double Layer)................15 1.5 Power Supply ........................16 1.6 Batteries ..........................17 1.1.1 Main Battery..................17 1.1.2 Battery Charging Control ..............17 1.1.3 RTC Battery ..................18 Satellite E100/E105 Maintenance Manual...
  • Page 16 Figure 1-5 SATA HDD ......................14 Figure 1-6 DVD Super Multi drive ..................15 Tables Table 1-1 HDD Specifications ....................14 Table 1-2 DVD Super Multi Drive Specifications ..............15 Table 1-3 Battery specifications....................17 Table 1-4 Quick/Normal charging time ..................18 Satellite E100/E105 Maintenance Manual...

  • Page 17: Features

    1.1 Features 1.1 Features The Toshiba Satellite E100/E105 is a full size notebook PC based on the Penryn and Merom and Celeron processor, providing high-speed processing capabilities and advanced features. The computer employs a Lithium Ion battery that allows it to be battery-operated for a longer period of time.
  • Page 18 DVD Super Multi +-R Double Layer Ultra Light DVD Super Multi +-R Double Layer with Label Flash Ultra Light Display The LCD displays available come with one of following types: 14.1” WXGA CSV 200nits color display, resolution 1280×800 Keyboard Satellite E100/E105 Maintenance Manual...
  • Page 19 This slot is for your memory card requirements to provide memory card read on your computer Toshiba Pointing Device Toshiba Pointing Device has one kind of Normal touchpad. Sound System The ALC268 integrated audio controller supports multimedia. The sound system...
  • Page 20 Auto macro) for mainstream ID support. HDMI Out Port (BTO) A HDMI monitor can be connected to the HDMI out port on the computer. The computer has HDMI out port and support BTO. FM Tuner Port (Exclusive with IEEE1394) Satellite E100/E105 Maintenance Manual...
  • Page 21 3D sensor (BTO) Using an acceleration sensor built into the computer, Toshiba HDD Protection detects vibration shocks and similar signs of movement of the computer, and automatically moves the Hard Disk Drive head to safe position to reduce the risk of damage that could be caused by head-to-disk contact.

  • Page 22: Figure 1-1 Id Parts Description Placement

    1 Hardware Overview 1.1 Features Figures 1-1/1-2/1-3 and 1-4 show the computer and its system unit configuration, respectively. Figure 1-1 ID Parts Description Placement Satellite E100/E105 Maintenance Manual...

  • Page 23: Figure 1-2 Computer Block Diagram

    1.1 Features 1 Hardware Overview Figure 1-2 Computer Block Diagram Satellite E100/E105 Maintenance Manual...

  • Page 24: Figure 1-3 System Board Configurations

    1 Hardware Overview 1.1 Features Figure 1-3 System Board Configurations Satellite E100/E105 Maintenance Manual...

  • Page 25: System Unit Components

    1.2 System Unit Components 1 Hardware Overview 1.2 System Unit Components Figure 1-4 is Block Diagram of the System Unit. Figure 1-4 System Unit Block Diagram Satellite E100/E105 Maintenance Manual...
  • Page 26 − 1024 MB (128M x 64) − 2048 MB (256M x 64) − 4096 MB (512M x 64) 1.8 volt operation No parity bit 64-bit data transfer BIOS ROM (Flash EEPROM) 8Mb x 1 chip (1024KB flash parts) Satellite E100/E105 Maintenance Manual...
  • Page 27 − Universal Serial Bus (USB) Controller − LAN Controller − RTC − GPIO − Enhanced Power Management − Intel I/O Virtualization (VT-d) Support − System Management Bus (SMBus 2.0) − Intel High Definition Audio Controller − Enhanced DMA Controller Satellite E100/E105 Maintenance Manual...
  • Page 28 A single KBC WPCE775x chip is used to serve as KBC/ EC and Super IO. − Scan controller function − Interface controller function − Power supply sequence control − Overheat shutdown support − LED control − Beep control − Device ON/OFF − Cooling fan speed control Satellite E100/E105 Maintenance Manual...
  • Page 29 − IEEE 802.11agn Data Rate − IEEE 802.11bg: Standard 54M bps − IEEE 802.11bgn: Standard 54M bps − IEEE 802.11agn: Standard 130M bps Frequency Channel − IEEE802.11bg: 2.4GHz − IEEE802.11bgn: 2.4GHz / 5.4GHz − IEEE802.11agn: 2.4GHz / 5.4GHz Satellite E100/E105 Maintenance Manual...

  • Page 30: Inch Hdd

    Bytes / Sector Specifications Item Capacity (GB) 250 GB 320 GB 500 GB Rotational Speed (RPM) 5400 rpm 5400 rpm 5400 rpm Height 9.5 mm 9.5 mm 9.5 mm User Data Sectors 488,397,168 625,142,488 976,773,168 Bytes / Sector Satellite E100/E105 Maintenance Manual...

  • Page 31: Dvd Super Multi (+-R Double Layer)

    140 ms Data Buffer Size (Mbytes) Formats Supported DVD: DVD-VIDEO, DVD-ROM, DVD-R, DVD-RW, DVD-RAM, DVD+R, DVD+-R (Double Layer), DVD+RW. CD-DA, CD-ROM, CD-R, CD-RW, Mixed-CD, HS CD-RW, US CD- RW, Photo CD (Multi-Session), Video CD, CD-Extra (CD+), CD-Text.. Satellite E100/E105 Maintenance Manual...

  • Page 32: Power Supply

    Monitors the voltage output to the system block (load/logic circuit side). Monitors the voltage, over voltage, input/output current of the battery pack. Monitors the internal temperature of the battery pack. Monitors the supply voltage from the AC adapter. Satellite E100/E105 Maintenance Manual...

  • Page 33: Batteries

    775C controls the charge on/off state and detects a full charge. Battery Charge When the AC adapter is attached, the battery is charged by off-state charge when the system is powered off or by on-state charge when it is powered on. Satellite E100/E105 Maintenance Manual...

  • Page 34: Rtc Battery

    12. 2. The charging time exceeds the fixed limit. 1.1.3 RTC Battery The RTC battery provides power to keep the current date, time and other system information in memory while the computer is turned off. Satellite E100/E105 Maintenance Manual...

  • Page 35: Chapter 2 Troubleshooting

    2 Troubleshooting 概要 Chapter 2 Troubleshooting Satellite E100/E105 Maintenance Manual...
  • Page 36 Procedure 2Test Program Check ..............2-18 Procedure 3Connector Check and Replacement Check......... 2-18 LAN........................2-20 Procedure 1Test Program Check ..............2-20 Procedure 2Connector Check and Replacement Check......... 2-20 2.10 Finger Print(Optional) ..................2-21 Procedure 1Test Program Check ..............2-21 2-ii Satellite E100/E105 Maintenance Manual...
  • Page 37 Procedure 2 Connector Check and Replacement Check........ 2-22 2.12 IEEE 1394 Test ....................2-23 Procedure 1Test Program Check ..............2-23 Procedure 2Connector Check ................ 2-23 2.13 Cooling Module....................2-24 Procedure 1Test Program Check ..............2-24 Procedure 2Connector Check and Replacement Check......... 2-24 Satellite E100/E105 Maintenance Manual 2-iii...
  • Page 38 2 Troubleshooting Figures Figure 2-1 Basic flowchart ....................2-3 Tables Table 2-1 HDD error code and status................2-13 2-iv Satellite E100/E105 Maintenance Manual...

  • Page 39: Outline

    2. Phillips screwdrivers (2 mm, 2.5 mm) 3. Cleaning disk kit (for ODD drive cleaning) 4. Bootable CD 5. Multimeter 6. External monitor 7. Headphone 8. Microphone 9. A-BEX TEST DVD 10. Music CD 11. DVD TSD-1 (TOSHIBA EMI DVD Test Media) Satellite E100/E105 Maintenance Manual...

  • Page 40: Basic Flowchart

    Make sure the Windows® Vista Home Edition has been installed on the HDD. Any other operating system can cause the computer to malfunction. Make sure any piece of optional equipment has been installed. Satellite E100/E105 Maintenance Manual...
  • Page 41 Message "In Touch with Tomorrow Toshiba" displayed procedure in Section 2.7 See the previous page to "Password=" displayed ?? delete the password. Follow the HDD diagnostic OS started ?? procedure in Section 2.5 Figure 2-1 Basic flowchart(1/2) Satellite E100/E105 Maintenance Manual...
  • Page 42 Perform the continuous test to check if the error is intermittent. Identify the test resulting in the Any error detected by the error and perform the appropriate diagnostic program ?? diagnostic procedures The system is normal. Figure 2-1 Basic flowchart (2/2) Satellite E100/E105 Maintenance Manual...
  • Page 43 9. If an error is detected by the IEEE 1394 test, follow the IEEE 1394 troubleshooting procedures in section 2.12. 10. If an error is detected by the Fan On/Off test, follow the cooling module troubleshooting procedures in Section 2.13. Satellite E100/E105 Maintenance Manual...

  • Page 44: Power Supply

    Battery LED Battery LED Power supply status On in Orange Battery being charged On in White Battery fully charged, with AC adapter connected Blinking in Orange Battery low *1 while driving the computer (at equal intervals) Else Satellite E100/E105 Maintenance Manual...
  • Page 45 Make sure the DC IN LED goes on in White. If it does not, go to Procedure 2. Check 2 Make sure the Battery LED goes on in Orange or White. If it does not, go to Procedure 3. Satellite E100/E105 Maintenance Manual...

  • Page 46: System Board

    Check 2. Check 2 Replace the system board with a new one. If the battery pack is still not working properly, perform Check 3. Check 3 Replace the CPU with a new one. Satellite E100/E105 Maintenance Manual...

  • Page 47: Procedure 1 Message Check

    The error message appears when either data stored in RAM to be resumed is lost because the battery has been exhausted or the system board is faulty. *** Resume failure and press any key to continue*** Satellite E100/E105 Maintenance Manual...
  • Page 48 Procedure 3 Replacement Check The system board, memory, or CPU may be defective. Disassemble the computer following the steps described in Chapter 4 and replace the system board, memory module or CPU with a new one. 2-10 Satellite E100/E105 Maintenance Manual...

  • Page 49: Procedure 2 Partition Check

    Type FDISK and press the Enter key. Choose “Display partition Check 2 information” from the FDISK menu. If drive C is listed, perform Check 3. If drive C is not listed, return to the FDISK menu and choose the option to Satellite E100/E105 Maintenance Manual 2-11...
  • Page 50 Enter FORMAT C:/S/U to format the HDD and transfer system files. If the following message appears on the display, the HDD has been formatted. Format complete If you cannot format the HDD using the test program, go to Procedure 4. 2-12 Satellite E100/E105 Maintenance Manual...
  • Page 51 Disk Controller Self Test Failed Disk Controller Test unexpected interrupt Failed Disk Controller action Test Failed Disk dos not support SMART Disk read attribute threshold error Disk read attribute value error Disk SMART attribute value error Satellite E100/E105 Maintenance Manual 2-13...
  • Page 52 The System board may be damaged. Replace it with a new one following the disassembling instructions in Chapter 4. If the problem persists, perform Check 4. Check 4 The CPU may be damaged. Replace it with a new one following the disassembling instructions in Chapter 4. 2-14 Satellite E100/E105 Maintenance Manual...

  • Page 53: Keyboard

    Chapter 4. If the problem persist, perform Check 5. Check 5 The CPU may be faulty. Disassemble the computer following the steps described in Chapter 4 and replace the CPU with a new one. Satellite E100/E105 Maintenance Manual 2-15...

  • Page 54: Display

    Procedure 3. If there is still an error, perform Check 2. Check 2 The LCD/FL cable may be faulty. Replace it with a new one and return to Procedure 3. If there is still an error, perform Check 3. 2-16 Satellite E100/E105 Maintenance Manual...
  • Page 55 The memory may be defective. Replace the memory module with a new one following the steps described in Chapter 4. If the problem persists, perform Check 10. Check 10 The CPU may be faulty. Replace it with a new one following the instructions in Chapter 4. Satellite E100/E105 Maintenance Manual 2-17...

  • Page 56: Odd (Optical Disk Drive)

    CD in the computer's CD, turn on the computer and run the test. Then insert a test ODD (Toshiba-EMI DVD-ROM TEST DISK TSD-1) into the ODD drive. See Chapter 3 for information on how to perform the test.
  • Page 57 Chapter 4. If the ODD drive is still not functioning properly, perform Check 5. Check 5 The memory may be defective. Replace the memory module with a new one following the steps described in Chapter 4. Satellite E100/E105 Maintenance Manual 2-19...

  • Page 58: Lan

    Chapter 4. If the problem persists, perform Check 3. Check 3 The CPU may be faulty. Disassemble the computer following the steps described in Chapter 4 and replace the CPU with a new one. 2-20 Satellite E100/E105 Maintenance Manual...

  • Page 59: Finger Print(Optional)

    If the Finger Print is still not functioning properly, perform Check Check 2 The system board may be defective. Replace the system board with a new one following the steps described in Chapter 4. Then go through procedure 1 again. Satellite E100/E105 Maintenance Manual 2-21...

  • Page 60: Audio Test

    Chapter 4. If the problem persist, perform Check 5. Check 5 The CPU may be faulty. Disassemble the computer following the steps described in Chapter 4 and replace the CPU with a new one. 2-22 Satellite E100/E105 Maintenance Manual...

  • Page 61: Ieee 1394 Test

    Chapter 4. If the problem persists, perform Check 3. Check 3 The CPU may be faulty. Disassemble the computer following the steps described in Chapter 4 and replace the CPU with a new one. Satellite E100/E105 Maintenance Manual 2-23...

  • Page 62: Cooling Module

    Chapter 4. If the problem persists, perform Check 4. Check 4 The CPU may be faulty. Disassemble the computer following the steps described in Chapter 4 and replace the CPU with a new one. 2-24 Satellite E100/E105 Maintenance Manual...
  • Page 63 2.13Cooling Module 2 Troubleshooting Satellite E100/E105 Maintenance Manual 2-25...
  • Page 64 Chapter 3 Diagnostic Programs...
  • Page 65 Save Batch Parameters ................26 3.3.6 LOG Parameters Setting................ 27 3.3.7 Specify LOG Viewer................28 3.3.8 Display LOG File .................. 28 3.3.9 LOG Viewer ..................29 3.3.10 LOG File Sample................... 30 Subtests ........................32 System Test......................... 35 Memory Test....................... 40 Satellite E100 Maintenance Manual...
  • Page 66 3 Diagnostic Programs Storage ........................46 Video........................... 50 Communication (COMM) ..................59 3.10 Peripheral ........................60 3.11 Error Codes and description..................63 3.12 Quick Test Item List ...................... i Satellite E100 Maintenance Manual...

  • Page 68: General

    The DIAGNOSTIC TEST Devices include the following tests: System Test Memory Test Storage Test Video Test Communication Test Peripheral Test Keyboard Layout Test Hot Key Test Audio Play Test Audio Record Test DMI Read DMI Write System Information Satellite E100 Maintenance Manual...
  • Page 69 A Service Diagnostic BOOT CD A Formatted FLOPPY DISK A Test Media CD (A-BEX TEST CD-ROM TCDR-702)(for CD-ROM test) A Test Media DVD (Toshiba-EMI DVD-ROM TEST DISK TSD-1) An External Monitor (for DISPLAY test) A CD-ROM Driver (for CD-ROM test)

  • Page 70: Quick Start

    When this item is selected, the system will run the diagnostic programs according to the procedures you defined. When the test is completed, a file named Custom.log will be saved in the defined location. Please see the following example-- Mouse test. Satellite E100 Maintenance Manual...
  • Page 71 Select ‘Test Mouse’ or press F8 to run the test. The prompt information would be displayed in the screen as below. This test item needs user to verify whether the mouse works normally. The test result will be displayed in the following screen: Satellite E100 Maintenance Manual...
  • Page 72 CPU Speed Test (Step by Step): Select test item: Select System—CPU—CPU Speed, then, press the Enter key. Parameters Setting Choose the OK button after you set the proper parameters in the following window. Satellite E100 Maintenance Manual...
  • Page 73 Configuration) Then press F8 to start the test. User should configure each parameter in advance; otherwise the default parameters would be used. Using this method, user is allowed to select more than one test item at one time. 2) Running the current test item Satellite E100 Maintenance Manual...

  • Page 74: Keyboard Layout Test

    When users choose the item, the names of these countries will be displayed on the screen for user choice. User press any index of token in ASCII, and the program will test the kind of keymap of the country. The test screen would be shown as below: Satellite E100 Maintenance Manual...

  • Page 75: Hotkey Test

    Press E+ +N+D to quit the test. 3.2.5 Audio Play Test Check whether the system could playback audio normally. When the test is completed, a file named Audio_P.log will be saved in the defined location. Satellite E100 Maintenance Manual...

  • Page 76: Audio Record Test

    1 line before user’s editing. User can modify the attribute’s value in the 2 line and press Enter to confirm the current edition and continue editing the next attribute. Satellite E100 Maintenance Manual...

  • Page 77: Sensor Test

    No Item Contents Access An access platform is leveling. platform. Test The Fixture which fixes PC by 90 degree inclination is used. Fixture Vibration/shock doesn't take a PCB at the time of T&D inspection. Satellite E100 Maintenance Manual...
  • Page 78 The display of a test program and the set method of PC are shown below. Display of a Test Program The portion which PC and Test-Fixture contact is green. Set method of PC Upper Judgment If all data is less than ranges, it will be OK. Satellite E100 Maintenance Manual...
  • Page 79 The display of a test program and the set method of PC are shown below. Display of a Test Program Set method of PC Rear Uppe Judgment If all data is less than ranges, it will be OK. Satellite E100 Maintenance Manual...
  • Page 80 The display of a test program and the set method of PC are shown below. Display of a Test Program Set method of PC Right Uppe Judgment If all data is less than ranges, it will be OK. Satellite E100 Maintenance Manual...
  • Page 81 The display of a test program and the set method of PC are shown below. Display of a Test Program Set method of PC Front Uppe Judgment If all data is less than ranges, it will be OK. Satellite E100 Maintenance Manual...
  • Page 82 If it succeeded, the system will prompt a message of PASS, otherwise the message will be FAIL.The test information will be written in log file. Note: Please do not use this program, when you test PC without 3D sensor. Satellite E100 Maintenance Manual...

  • Page 83: System Information

    The name of the program is marked on the top of the screen. At the bottom, the function keys are listed for user operation. During the detection, keyboard operation is invalid. When the detection is finished, the hardware components information will be displayed as follows: Satellite E100 Maintenance Manual...

  • Page 84: View Logs

    On the right column, the configuration information of the highlighted component is listed. Press ESC to exit this program. 3.2.11 View Logs User can enter one choice to view a log file in the screen as follows. Satellite E100 Maintenance Manual...

  • Page 85: Exit To Free Dos

    Test status and result are displayed in the upper right corner of the screen. It displays the test status of the current test item – TEST (in testing), PASS (test finished and its result is passed), FAIL (test finished and its result is failed) and SKIP (test skipped). Satellite E100 Maintenance Manual...
  • Page 86 Status Bar: Located at the bottom of the screen as follows: The status bar is used to indicate the current script setting and test status. It consists of two lines that includes the information as follows: Satellite E100 Maintenance Manual...
  • Page 87 Wait On Error: Display ‘WAIT’ as shown in the above screen when ‘Wait On Error’ is enabled; Pause Enable: Display ‘PAUSE’ when “Pause Enable” is enabled; Manual Interrupt Method: Display ‘Esc: Break’ to tell the user how to manually interrupt the test process. Satellite E100 Maintenance Manual...

  • Page 88: Options

    Test Selected Items Execute all selected test items in this editor. The hot key is F8. If “Interactive” option in batch parameters has not been selected, a warning message would be shown as below: • Edit Batch Parameters Satellite E100 Maintenance Manual...

  • Page 89: Batch Parameters Configuration

    Service Diagnostics Editor by the command of EXIT. • Exit to DOS Exit the Service Diagnostics Editor and back to DOS. 3.3.2 Batch Parameters Configuration The batch parameters configuration screen can be accessed through Service Diagnostics/OPTIONS -> EDIT BATCH PARAMETERS -> BATCH PARAMETERS: Satellite E100 Maintenance Manual...
  • Page 90 Mouse test; If it is disabled, those test items will report FAIL. When the option here is enabled, it would affect all the test items while the same option in “Item Parameters Configuration” only affect that test item. Monitor Battery Life Satellite E100 Maintenance Manual...

  • Page 91: Item's Parameters Configuration

    Specify the repeating times when 'Loop Bound' is chosen under the batch mode. 3.3.3 Item’s Parameters Configuration The test items’ parameters configuration screen can be accessed through Service Diagnostics/Options -> Edit Batch Parameters -> Item’s Parameters-> System- >CPU-> Basic Functionality: • Repeat count Satellite E100 Maintenance Manual...

  • Page 92: Load Batch Parameters

    Some test items (Memory, HDD, e g...) have their individual parameters, which can be configured in their parameters setting window. 3.3.4 Load Batch Parameters Batch parameter is saved in the script file whose extension name is INI (*.INI). Below is the screen shot of “Load Batch Parameters”. Satellite E100 Maintenance Manual...

  • Page 93: Save Batch Parameters

    3.3 Options In this window, you can specify the .INI files that you wanted to be edited or modified. 3.3.5 Save Batch Parameters Here you can save the edited or modified content to the batch parameters files. Satellite E100 Maintenance Manual...

  • Page 94: Log Parameters Setting

    Log Test End Time If selecting this parameter, the end time of the test will be recorded. Log Errors Only If selecting this parameter, errors will be recorded only when the test fails. Log Errors Only with Time Satellite E100 Maintenance Manual...

  • Page 95: Specify Log Viewer

    You can specify the Log file viewer in the Specify Log Viewer screen. The default viewing program of Service Diagnostics is LogView.exe. 3.3.8 Display LOG File You can specify the Log file for viewing in the Display Error Log File screen. Satellite E100 Maintenance Manual...

  • Page 96: Log Viewer

    In this screen, you can specify a Log file and view it with the viewer designated in Specify LOG Viewer. 3.3.9 LOG Viewer Service Diagnostic Log viewer: ↑, ↓ • Scroll a line backward or forward on the screen. • Page Up, Page Down Satellite E100 Maintenance Manual...

  • Page 97: Log File Sample

    The following section is a sample of log file: DIAG REPORT <Module Name>: Service Diagnostic Ver 1.00 ... Memory Tester Build Date 2006.01.10 [Walk High] Begin Time: Wed Jul 05 10:45:36 2006 Satellite E100 Maintenance Manual...
  • Page 98 <Module Name>: Service Diagnostic Ver 1.00 ... Mouse Test Build Date 2006.01.10 [MSTPad] Begin Time: Wed Jul 05 10:48:54 2006 Touch Pad Test : FAIL ITEM TEST FAIL Function ID :502 Error Code :50202 Error Message :Touch Pad Test Fail End Time: Wed Jul 05 10:49:16 2006 Satellite E100 Maintenance Manual...

  • Page 99: Subtests

    01 Write/Read Cycle Test [XWRCycle] 02 Read Cycle Test [XRCycle] 05 Walking 1's Test [WalkHigh] 06 Walking 0's Test [WalkLow] 07 Memory Address [Address] 08 Refresh Test [Refresh] 09 Cache Memory [CacheOne] 10 Random Memory 01 Randomize Test [Random] Satellite E100 Maintenance Manual...

  • Page 100: Subtests

    VESA 640x480x32bit Mode 800X600 Video Modes VESA 800x600x256 Mode VESA 800x600x64K Mode [V800600_15] VESA 800x600x32K Mode [V800600_16] [V800600_24] VESA 800x600x16K Mode [V800600_32] VESA 800x600x32bit Mode 1024X768 Video Modes [V1024768_15] VESA 1024x768x256 Mode [V1024768_16] VESA 1024x768x64K Mode [V1024768_24] Satellite E100 Maintenance Manual...
  • Page 101 [DeviceID] 02 Vendor ID Detection [VendorID] 03 Mac Address Detection [MAC Address] Peripheral 01 Keyboard 01 Keyboard Data Line [KBDataLn] 02 Keyboard Clock Line [KBClokLn] 02 Mouse 01 TouchPad [MSTpad] 03 Led 01 Device Led [KBLED] Satellite E100 Maintenance Manual...

  • Page 102: System Test

    2. CPU Speed This test item is to detect the work frequency of the current CPU. User should change the parameters setting in the following window before the test: Satellite E100 Maintenance Manual...
  • Page 103 This test item is to check whether NPU transfers the abnormal Interrupt program correctly by forcing an abnormal float. 4. CPU Information This test item is used for getting & showing CPU Information. It will be displayed as follows: Satellite E100 Maintenance Manual...
  • Page 104 This test item is to check whether the system clock/calendar works normally. 4. PCI System This test item is to check whether the bus number, device number and function number in PCI bus are valid. 5. Plug and Play Satellite E100 Maintenance Manual...
  • Page 105 Below is the parameter setting dialog window. Set the range of Speed that is to be tested, then choose the OK button to test it. It will be displayed as follows: Satellite E100 Maintenance Manual...
  • Page 106 3.5 System Test 3 Diagnostic Programs Satellite E100 Maintenance Manual...

  • Page 107: Memory Test

    Extended Memory Start Address (MB) & Extended Memory End Address (MB): Set the range of extended memory that is to be tested, the test coverage would be based on the setting and the value in ‘Percent (%) mentioned at below. Satellite E100 Maintenance Manual...
  • Page 108 Special Size, the test of Extended Memory will be taken according to the coverage range that user chooses or time. Extended Memory Start Address (MB) & Extended Memory End Address (MB): Set the range of extended memory that is to be tested, the Satellite E100 Maintenance Manual...
  • Page 109 1 each time; 7. Incremental / Decrement Test Data Pattern is a series of data whose low byte is increasing data from 0x00 and high byte is decreasing data from 0xFF. Subtest 04 Extended Pattern Satellite E100 Maintenance Manual...
  • Page 110 Time Limit(h): Choose or Input the time (hour) of the defined range of the memory to be tested; Time Limit(m): Choose or Input the time (minute) of the defined range of the memory to be tested. 1. Write/Read Cycle Test Test by using both read and write instructions. Satellite E100 Maintenance Manual...
  • Page 111 Random Incremental Read/Write Test. The parameter dialog window is the same as that in ‘Subtest 03 Extended Pattern’. 1. Randomize Test This test item is to check whether the memory could be correctly accessed with randomized data and randomized memory address. Satellite E100 Maintenance Manual...
  • Page 112 Subtest 11 Data Bus Test This test item is to check whether the data bus works normally. Subtest 12 Memory Speed Test This test item is to check the data-transferring rate for the cache memory and the system memory. Satellite E100 Maintenance Manual...

  • Page 113: Storage

    If user chooses Special Size, the test of IDE HDD will be taken according to the coverage range that user chooses or time. Satellite E100 Maintenance Manual...
  • Page 114 This test item involves the following parameters: IDE HDD Test Range—is same as the description of the upper item. LBA Start, LBA End-- specify start and finish byte in LBA(Large Block Address); Option-- Select sequential test or random test; Satellite E100 Maintenance Manual...
  • Page 115 6. SMART Test SMART stands for Self-Monitoring, Analysis and Reporting Technology. SMART test will compare the attribute values with the threshold value in the HDD’s controller to confirm whether there is any failure in the HDD Satellite E100 Maintenance Manual...
  • Page 116 RW under LBA mode with the location address increasing in sequence. 6. Tray Eject Test Check the eject function of the ODD. It will eject the ODD and ask the user to confirm if the operation succeeds. Satellite E100 Maintenance Manual...

  • Page 117: Video

    It will be displayed as follows:. 2. Text Attribute This test item is to check whether the text attribute of normal, hi-intensity, inverse, and blinking in VGA text mode could be correctly displayed on the screen. Satellite E100 Maintenance Manual...
  • Page 118 This test item is to check whether the video memory could be correctly written and read in VGA text mode. According to the comparison of written data with read data, the program would report PASS or FAIL. Satellite E100 Maintenance Manual...
  • Page 119 (dark gray, light blue, light green, light cyan, light red, light magenta, yellow, and white besides the above 8 colors). In the test, user is required to respond according to the instruction in the screen. 5. 80 * 25 Text Mode Satellite E100 Maintenance Manual...
  • Page 120 In the test, user is required to respond according to the instruction in the screen. Subtest 02 640 * 480 VGA Mode This test item is to check whether 680*480 VGA Text mode works normally. In the test, user is required to respond according to the instruction in the screen. Satellite E100 Maintenance Manual...
  • Page 121 4. 1280X800 Video Modes Test Subtest 04 VESA Video Memory This test item is to check whether VESA video memory could be correctly accessed (write data & read data). Below is the test item’s parameter dialog window: Satellite E100 Maintenance Manual...
  • Page 122 This test item is to report the system’s Accelerated Graphics Port status and check whether AGP registers works normally. Subtest 06 LCD Panel Test This test item is to check whether there is any fault in its resolution by displaying the RGB gradient color screens. Satellite E100 Maintenance Manual...
  • Page 123 Direct Color Test This test item is to check the video adapter’s composing ability of direct color in high and true color mode. In the test, user is required to respond according to the instruction in the screen. Satellite E100 Maintenance Manual...
  • Page 124 3 Diagnostic Programs Subtest 10 DAC/Palette Address This test item is to check the function of DAC registers and Palette registers. In the test, user is required to respond according to the instruction in the screen. Satellite E100 Maintenance Manual...
  • Page 125 3 Diagnostic Programs 3.8 Video Satellite E100 Maintenance Manual...

  • Page 126: Communication (Comm)

    1. Device ID Detection Detect the device ID of the network card. 2. Vendor ID Detection Detect the vendor ID of the network card. 3. MAC Address Detection Detect the MAC address of the network card. Satellite E100 Maintenance Manual...

  • Page 127: Peripheral

    At the below screen of Touch Pad test, user can press the left button, right button, and move the mouse to verify its functions for times, and the test will end either by user break or test time is out. Satellite E100 Maintenance Manual...
  • Page 128 3.10 Peripheral 3 Diagnostic Programs Subtest 03 Led Test 1. Led Test Check whether the green and white led works normally. Satellite E100 Maintenance Manual...
  • Page 129 3 Diagnostic Programs 3.10 Peripheral Check whether the orange led works normally. Check whether the HDD led works normally. Satellite E100 Maintenance Manual...

  • Page 130: Error Codes And Description

    Write-Protect Error As above. problems. The test pattern read out from the Base Memory Error base memory is different from Test this memory chip on Address the one that has been written in multiple machines. this address. Satellite E100 Maintenance Manual...
  • Page 131 Check the board. PCI Bus Scan Error PCI test fails. As above. PCI Device Access Error PCI access fails. As above. PCI Config Verification Check PCI configuration on main Wrong PCI configuration. Error board or PCI Device Satellite E100 Maintenance Manual...
  • Page 132 Check for the PCX graphics map. Error map. Physical problems with the video Check and see whether the video Bitblt Engine Test Error card. card has any physical problem. VESA Video Memory As above. As above. Test Error Satellite E100 Maintenance Manual...
  • Page 133 Please insert Net cad test Intel PCI Ethernet card Don’t found Net Card, This Card Please update net card or use not present during MAC can’t be Read MAC by this other method test method 09xx Keyboard Satellite E100 Maintenance Manual...
  • Page 134 Either the disk or the CD-ROM Replace the disk or send the CD- is damaged. ROM for repair. CD Seek Error Either the disk or the CD-ROM Replace the disk or send the CD- is damaged. ROM for repair. Satellite E100 Maintenance Manual...
  • Page 135 3 Diagnostic Programs 3.11Error Codes and Description Eject Error Wrong CD-ROM drive. Exit from the wrong drive. Satellite E100 Maintenance Manual...

  • Page 136: Quick Test Item List

    VESA 1024x768x32bit Mode VESA Video Memory 10% or 3 minutes Color Purity Test Direct Color Test LCD Panel Sequential/Random Read 25% or 3 minutes SMART Check LAN Card Device ID Detection Vendor ID Detection Mac Address Detection Satellite E100 Maintenance Manual...

  • Page 137: Replacement Procedures

    Chapter 4 Replacement Procedures...
  • Page 138 4 Replacement Procedures 4-ii Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...
  • Page 139 Installing the Optional Memory................. 4-16 UWB Module......................4-17 Removing the UWB Module ................4-17 Installing the UWB Module................4-18 Top Cover ........................ 4-19 Removing the Top Cover................... 4-19 Installing the Top Cover ..................4-20 Maintenance Manual 4-iii Satellite E100/E105/ Satellite ProE100/E105...
  • Page 140 Installing the USB board, DC-IN, FM card and RGB cable ......4-40 4.15 Display Mask ......................4-41 Removing theDisplay Mask................4-41 Installing the Display Mask ................4-42 4.16 FL Inverter Board ....................4-43 Removing the FL Inverter Board............... 4-43 4-iv Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...
  • Page 141 Power board, Bluetooth card, Button board and Finger print board......4-50 Removing Power board, Bluetooth card, Button board and Finger print board4-50 Installing Power board, Bluetooth card, Button board and Finger print board 4-51 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...
  • Page 142 Figure 4-28 Removing the display mask ................4-41 Figure 4-29 Removing the FL inverter board ..............4-43 Figure 4-30 Removing the 15.1-inch LCD module and screws ......... 4-46 Figure 4-31 Removing the 15.1-inch LCD module ............4-46 4-vi Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...
  • Page 143 4 Replacement Procedures Figure 4-32 Removing the 15.1-inch LCD cable..............4-47 Figure 4-33 Removing the CCD board and MIC..............4-48 Figure 4-34 Removing Power board, Bluetooth card, Button board and Finger print board .. 4- Maintenance Manual 4-vii Satellite E100/E105/ Satellite ProE100/E105...

  • Page 144: General

    CCD board and USB board DC IN Power Board Bluetooth card FL inverter board, both of which are LCD module FM card and and Finger Print Board shown above the LCD module. CRT cable Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 145: Safety Precautions

    DANGER: Always use the genuine batteries or replacement batteries authorized by Toshiba. Batteries other than those differ in specifications and are incompatible with the computer. They may burst or explode. To avoid leakage of alkaline solutions, never heat or disassemble the battery packs.
  • Page 146 For AC input, be sure to use the AC adapter and AC power cable that come with your computer or Toshiba-recommended equivalents. To avoid the risk of electrical shock, make sure that all the replacement components meet the specifications of the computer and that all the cables and connectors are fastened securely.

  • Page 147: Before You Begin

    See the appropriate explanations and figures for screw sizes. To avoid personal injury, use care to handle components that have sharp edges or corners. After you have replaced a FRU, check that the FRU works correctly to ensure normal computer operation. Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 148: Disassembly Procedures

    Check that all the required screws are used to secure the FRUs. Using wrong screws can damage the threads or heads of the screws or does not ensure that the FRUs are secure. After installing a FRU, make sure that the FRU and computer work normally. Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 149: Tools And Equipment

    0.22 N･m (2.2 kgf･cm) M2.5 (2.5 mm) 0.36 N･m (3.5 kgf･cm) M3 (3 mm) 0.51 N･m (5.0 kgf･cm) M2.5x4 PSP TITE screws 0.204 N･m (2.0 kgf･cm) M2.5x6 GIZA TITE screws 0.36 N･m (3.5 kgf･cm)) Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 150: Colors Of Screw Shanks

    U (stands for unique-pan head screws, studs, etc.) Symbol examples 6 mm bind screw 12 mm bind screw 5 mm stud (The numeral represents the rounded length of the threaded portion regardless of the entire stud length.) Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 151: Removing The Battery Pack

    Battery pack Battery lock Battery release latch Figure 4-1 Removing the battery pack Battry pack Figure 4-2Removing the battery pack NOTE: Dispose of the used battery packs as required by local ordinances or regulations. Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 152: Installing The Battery Pack

    NOTE: Visually check the battery's terminals. If they are dirty, clean them with a dry cloth. 1. Gently insert a new or recharged battery pack into place. Check that the battery release latch slides in and stops with a click. 2. Slide in the battery lock. Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 153: Removing The Optional Pc Card

    2. When the eject button pops out slightly, push it again. 3. When the PC card pops out, grasp it and pull it out. PC card Figure 4-3 Removing the PC card 4-10 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 154: Installing The Optional Pc Card

    2. After checking that the PC card is seated securely, push the PC card release lever slightly. After the PC card is installed, check the hardware configuration in the Hardware Setup or TSETUP program to make sure that the PC card is compatible with the current hardware configuration. Maintenance Manual 4-11 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 155: Removing The Memory Card

    2. Checking that the memory card is seated securely. After the PC card is installed, check the hardware configuration in the Hardware Setup or TSETUP program to make sure that the PC card is compatible with the current hardware configuration. 4-12 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 156: Keyboard Cover And Keyboard

    4. Disconnect the keyboard cable from CN5 and CN8 on the system board. Keyboard cover Figure 4-5 Removing the Keyboard cover and keyboard M2x4 0 black flat head screw Keyboard Figure 4-6 Removing the Keyboard cover and keyboard Maintenance Manual 4-13 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 157: Installing The Keyboard Cover And Keyboard

    3. Place the keyboard cover in the correct position and secure the following 13 latches, in that order: - Five bottom latches. - Six front latches. One latch on right and left side. 4-14 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 158: Optional Memory

    2. Pull the memory module up and out at an angle, using care to avoid touching the connectors CAUTION: The slot A is reserved for main memory. Use the slot B for expanded memory. If only one card is installed, use the slot A Maintenance Manual 4-15 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 159: Installing The Optional Memory

    After the computer is turned on, check the hardware configuration in the Hardware Setup or TSETUP program to make sure that the installed memory module has been recognized by the system. If it has not been recognized yet, check the connections 4-16 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 160: Uwb Module

    1. Remove the two M2x4 black flat-head screws securing the UWB module. 2. Remove the UWB module. M2x4 0 black flat head screw Figure 4-8 Removing the UWB module Maintenance Manual 4-17 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 161: Installing The Uwb Module

    Install the UWB module according to the following procedures and Figures 4-8, after checking that the computer is turned off in boot mode. 1. Insert the UWB module in to the connector. 2. Secure the UWB module with two M2x4 black flat head screws. 4-18 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 162: Top Cover

    Figure 4-9 Removing the Top Cover M2x3 0 black flat head screw Power board cable MMB board cable CN25 Touch pad board cable CN18 Finger print cable Bluetooth cable Figure 4-10 Removing the Top Cover Maintenance Manual 4-19 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 163: Installing The Top Cover

    Turn the computer upside down and secure it with the fifteen screws in the order shown on figure4-9. - Six M2.5x7 black flat head screws. - One M2.5x4 black flat head screws. - Eight M2x2.5 black flat head screws. 4-20 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 164: Hdd

    3. Place the HDD pack on a flat surface (such as a desk), and remove the four M3x3.5 black flat head screws. 4. Place the HDD pack on a flat surface (such as a desk), and remove the chassis. Maintenance Manual 4-21 Satellite E100/E105/ Satellite ProE100/E105...
  • Page 165 M3x3 5 black flat head screw HDD chassis HDD connector M3x3 5 black flat head screw HDD pack Figure 4-12 Removing the HDD chassis CAUTION: Do not apply pressure to the top or bottom of the drive. 4-22 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 166: Installing The Hdd

    HDD pack by its sides. 4. Secure the HDD with three M2x4 black flat head screws. NOTE: When Securing HDD screws, need to screw it with FM cable grounding wire on system board. Maintenance Manual 4-23 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 167: Odd Bay Module

    1. Place the ODD bay module in the correct position and slide it in. 2. Push it in until it clicks into place. 3. Secure the ODD bay module with one M2x4 black flat head screw. 4-24 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...
  • Page 168 Assemble the ODD drive according to the following procedures and Figure 4-14. 1. Seat the ODD bezel on the ODD drive. 2. Seat the bracket and secure it with two M2x4 black flat head screws. Maintenance Manual 4-25 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 169: Display Assembly

    4. Remove six M2.5x4 black flat head screws securing the LCD module to the button cover 5. Remove the display module. CAUTION: LCM module hinge cannot be disassembled. M2 5x6 black flat head screw Figure 4-15 Removing the display assembly 4-26 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 170: Installing The Display Assembly

    5. Secure the display assembly with two M2.5x6 black flat head screws in the order shown on the figure4-15. NOTE: Route wireless LAN antenna in cable fillister and avoid be compressed by ODD drive. Maintenance Manual 4-27 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 171: Fan

    Install the FAN according to the following procedures and Figures 4-17. Seat the FAN in to correct position. Connect the FAN cable to CN2. Secure the FAN with three M2x5 white flat head screws on the FAN. 4-28 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 172: Cpu Cooling Module

    3. Remove CPU cooling module screws in that order mark on cooling module. 4. Remove the CPU cooling module. M2x4 black flat head screw CPU cooling module bracket CPU cooling module CPU cooling module CPU cooling module Figure 4-18 Removing the CPU cooling module Maintenance Manual 4-31 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 173: Installing The Cpu Cooling Module

    V000934150. Figure 4-20 Replace new thermal pad into correct position. 2. Tear down the tap on the thermal pad. Figure 4-21 Tear down the tape Installing the CPU Cooling Module 4-30 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...
  • Page 174 3. Seat the CPU bracket in the correct position. 4. Secure CPU bracket with two black flat head screws. Seat the CPU cooling module and bracket in the correct position and secure them with two M2x4 black flat head screws. Maintenance Manual 4-31 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 175: Cpu

    1. Unlock the CPU by rotating the cam on the CPU socket 120 degrees to the left with a flat-blade screwdriver (in the order shown in the figure below). 2. Remove the CPU. Figure4-22 Removing the CPU 4-34 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 176: Installing T The Cpu

    3. Secure the CPU by rotating the cam 120 degrees to the right with a flat-blade screwdriver. 4. NOTE: FOXCONN CPU socket will be 180 degrees to the left. Figure 4-23 Installing the CPU CAUTION: Seat the CPU by aligning the triangle with the shaded area. Maintenance Manual 4-33 Satellite E100/E105/ Satellite ProE100/E105...
  • Page 177 4 Replacement Procedures Error! Style not defined. Error! Style not defined. Figure 4-24 Securing the CPU 4-34 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 178: Speakers And Wireless Lan

    5. Remove two M2x4 black flat head screw securing the Wireless LAN. 6. Remove the Wireless LAN. Right speaker Left speaker CN29 CN26 M2x4 black flat head screw Figure 4-25 Removing the speakers and Wireless LAN Maintenance Manual 4-35 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 179: Installing The Speakers And Wireless Lan

    3. Connect the left speaker cable in to CN26 and right speaker in to CN29. 4. Seat the Wireless LAN in to correct position. 5. Secure the Wireless LAN with two M2x4 black flat head screws. 4-36 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 180: System Board

    6. Remove the system board. 5x4 white hexagonal bolt M2x4 black flat haed screw 5x4 white hexagonal bolt FM card flat cable M2x4 black flat head screw CN17 CN2003 Figure 4-26 Removing the system board Maintenance Manual 4-37 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 181: Installing The System Board

    3. Secure three M2.5x4 white hexagonal screws on the system board. 4. Secure two M2x4 black flat head screws securing the Mini card. 5. Connect FM card cable in to CN17. 6. Connect DC IN cable in to CN6. 4-38 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 182: Usb Board, Dc-In Fm Card And Rgb Cable

    M2 8x4 5 black flat head screw M2x4 black flat head screw CRT cable DC IN cable USB cable FM card antenna cable CN2002 FM module bracket Figure 4-27 Removing the USB board, DC-IN, FM card and CRT cable Maintenance Manual 4-39 Satellite E100/E105/ Satellite ProE100/E105...
  • Page 183 3. Seat the CRT cable in the correct position and securing with one M2x4 black flat head screw. 4. Seat the RGB cable in the correct position and securing with two M2.8x4.5 black flat head screws. 4-40 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 184: Display Mask

    - Four latches on the right side. - Seven latches on the bottom side M2 5x4 black flat head screw M2 5x4 black flat head screw Seal Seal Dispaly mask Figure 4-28 Removing the display mask Maintenance Manual 4-41 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 185: Installing The Display Mask

    - Two M2.5x4 black flat head screws on bottom 3. Secure the following 4 seals to cover the screws, in that order: - Two gray seals on the bottom - Two gray seals on the top 4-42 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 186: Fl Inverter Board

    2. Disconnect the HV cable from the HV connector and remove the FL inverter board M2 5x5 black flat head screw FL inverter board LCD FL cable HV cable Figure 4-29 Removing the FL inverter board Maintenance Manual 4-43 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 187: Installing The Fl Inverter Board

    1. Connect the LCD/FL cable to LCD/FL connector, and connect the HV cable to the HV connector. 2. Seat the LCD module, FL inverter board in the correct position. 3. Securing the inverter board with one M2.5x5 black flat head screw. 4-44 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 188: Lcd Modules

    3. Turn the LCD upside down. Be sure to place it on a cushioned surface such as a foam pad. 4. Remove the tape and LCD/FL cable connector. Then disconnect the LCD/FL cable. Maintenance Manual 4-45 Satellite E100/E105/ Satellite ProE100/E105...
  • Page 189 Figure 4-30 Removing the 15.1-inch LCD module and screws Right LCD bracket LCD module Left LCD bracket M2x3 black flat head screw M2 5x5 black flat head screw M2x3 black flat head screw Figure 4-31 Removing the 15.1-inch LCD module 4-46 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...
  • Page 190 2. Connect the LCD/FL cable to the LCD module connector. 3. Turn the LCD right side up. 4. Please the LCD module in the correct position and secure it with two M2.5x5 black flat head screws. Maintenance Manual 4-47 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 192: Ccd Board And Mic

    1. Disconnect the CCD cable from the CCD module connector and remove the CCD board. 2. Lift the MIC from the display rear cover. CCD board cable CCD board Figure 4-33 Removing the CCD board and MIC 4-48 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...

  • Page 193: Installing The Ccd Board And Mic

    Install the FL inverter board according to the following procedures and Figure 4-33. 1. Connect the CCD module cable to CCD module connector. 2. Seat the CCD module, MIC in the correct position. Maintenance Manual 4-49 Satellite E100/E105/ Satellite ProE100/E105...

  • Page 194: Power Board, Bluetooth Card, Button Board And Finger Print Board

    9. Remove the touch pad bracket. 10. Release two M2x3 black flat head screws securing the button board. 11. Disconnect the button board flat cable from CN2005. 12. Remove the finger print board. 4-50 Maintenance Manual Satellite E100/E105/ Satellite ProE100/E105...
  • Page 195 M2.5x4 black flat head screws. 5. Connect the MMB board flat cable to MMB board. 6. Seat the power board to the correct position and secure it with one M2x3 black flat head screw. Maintenance Manual 4-51 Satellite E100/E105/ Satellite ProE100/E105...
  • Page 196 次 6000 1 Appendices...
  • Page 197 5 In 1 Card Connector (40-Pin) ............C-9 C.19 CN20 eSATA Connector (11-Pin) ..............C-9 C.20 CN21 SATA HDD Connector (22-Pin) ............C-10 C.21 CN22 Wireless LAN Card Connector (52-Pin) ..........C-10 C.22 CN23 Express Card Connector (26-Pin).............C-11 C.23 CN24 USB Port1 Connector (4-Pin)............C-11 App-ii Satellite E100/E105 Maintenance Manual...
  • Page 198 FM Tuner Board Connector (8-Pin) ..........C-21 C.39 CN2004 Touch Pad Module Connector (12-Pin)........... C-21 C.40 CN2005 Touch Pad Board Connector (8-Pin) ..........C-22 Appendix D Keyboard Scan/Character Codes..............D-1 Appendix E Key Layout ....................E-1 Satellite E100/E105 Maintenance Manual App-iii...

  • Page 199: Appendix A Handling The Lcd Module

    LCD cover before securing the module with four screws. Do not force the module into place, because stress can affect its performance. Also, the panel’s polarized surface is easily scarred, so be carefully when handling it. Satellite E100/E105 Maintenance Manual...
  • Page 200 Also, never scratch the surface. 4. If water or other liquid is left on the panel’s surface for a long period, it can change the screen’s tint or stain it. Be sure to quickly wipe off any liquid. Satellite E100/E105 Maintenance Manual...
  • Page 201 5. Glass is used in the panel, so be careful not to drop it or let it strike a hard object, which could cause breakage or cracks. 6. CMOS-LSI circuits are used in the module, so guard against damage from electrostatic discharge. Be sure to wear a wrist or ankle ground when handling the module. Satellite E100/E105 Maintenance Manual...
  • Page 202 7. Do not expose the module to direct sunlight or strong ultraviolet rays for long periods. 8. Do not store the module at temperatures below specifications. Cold can cause the liquid crystals to freeze, lose their elasticity or otherwise suffer damage. Satellite E100/E105 Maintenance Manual...
  • Page 203 9. Do not disassemble the LCD module. Disassembly can cause malfunctions. 10. If you transport the module, do not use packing material that contains epoxy resin (amine) or silicon glue (alcohol or oxide). These materials can release gas that can damage the panel’s polarization. Satellite E100/E105 Maintenance Manual...

  • Page 204: Appendix B Board Layout

    Apx. B Board Layout Appendices Appendix B Appendix B Board Layout System Board Front View Figure B-1 Board Layout (Front) Satellite E100/E105 Maintenance Manual...

  • Page 205: System Board Back View

    Appendices Apx. B Board Layout System Board Back View Figure B-2 Board Layout (Back) Satellite E100/E105 Maintenance Manual...
  • Page 206 Fingerprint Module Connector (4-Pin)..........C-12 C.28 CN29 Internal Speaker Right Connector (2-Pin) ........C-13 C.29 CN47 DDR2 DIMM0 Connector (200-Pin)..........C-13 C.30 CN51 DDR2 DIMM1 Connector (200-Pin)..........C-16 C.31 CN500 SIM Card Connector (6-Pin) ............C-19 Satellite E100/E105 Maintenance Manual...
  • Page 207 C.36 CN2001 CRT Port Connector (15-Pin)............C-20 C.37 CN2002 FM Antenna Connector (2-Pin) ............C-21 C.38 CN2003 FM Tuner Board Connector (8-Pin) ..........C-21 C.39 CN2004 Touch Pad Module Connector (12-Pin)..........C-21 C.40 CN2005 Touch Pad Board Connector (8-Pin) ..........C-22 Satellite E100/E105 Maintenance Manual...

  • Page 208: Appendix C Pin Assignments

    MB to CRT Board Connector (14-Pin) Table C-3 MB to CRT Board Connector Pin Assignments (14-Pin) Pin No. Signal Name Pin No. Signal Name N$1155259 CRTR_R DGND CRT_G DGND CRT_B DGND VSYNC DGND HSYNC DGND CRT_DDCDATA CRT_DDCCLK DGND Satellite E100/E105 Maintenance Manual...

  • Page 209: Cn4 Robson Card Module Connector (52-Pin

    DGND DGND USB_P10N DGND USB_P10P +V3S DGND +V3S WIMAX_3G_LED# DGND +V1.5S DGND PCI_3S_SERIRQ +V3S Keyboard LED Cable Connector (4-Pin) Table C-5 Keyboard LED Cable Connector Pin Assignments (4-Pin) Pin No. Signal Name Pin No. Signal Name Satellite E100/E105 Maintenance Manual...
  • Page 210 Pin No. Signal Name Pin No. Signal Name NUM_LED#_3 SCROLL_LED#_3 CAPS_LED#_3 +V3S SCAN_IN(1) SCAN_IN(6) SCAN_IN(5) SCAN_IN(0) SCAN_IN(4) SCAN_IN(3) SCAN_IN(2) SCAN_IN(7) SCAN_OUT(3) SCAN_OUT(7) SCAN_OUT(12) SCAN_OUT(8) SCAN_OUT(14) SCAN_OUT(10) SCAN_OUT(6) SCAN_OUT(5) SCAN_OUT(9) SCAN_OUT(11) SCAN_OUT(0) SCAN_OUT(1) SCAN_OUT(15) SCAN_OUT(13) SCAN_OUT(2) SCAN_OUT(4) Satellite E100/E105 Maintenance Manual...

  • Page 211: Cn9 Power Board Connector (4-Pin

    USB_VCC2 USB_L_P2N USB_L_P2P DGND C.12 CN12 LCD/FL Inverter Cable Connector (40-Pin) Table C-12 LCD/FL Inverter Cable Connector Pin Assignments (40-Pin) Pin No. Signal Name Pin No. Signal Name DGND N$811968 DGND N$811968 DGND +V3S LVDS_TXDL0N LVDS_TXDL1N Satellite E100/E105 Maintenance Manual...
  • Page 212 Pin No. Signal Name HDMI_L_TX2P DGND HDMI_L_TX2N HDMI_L_TX1P DGND HDMI_L_TX1N HDMI_L_TX0P DGND HDMI_L_TX0N HDMI_L_TXCP DGND HDMI_L_TXCN HDMI_CEC HDMI_DDCCLK HDMI_DDCDATA DGND N$1138481 TMDS_HPD C.14 CN15 SATA ODD Connector (13-Pin) Table C-14 SATA ODD Connector Pin Assignments (13-Pin) Satellite E100/E105 Maintenance Manual...

  • Page 213: Cn16 1394 Connector (4-Pin

    FM_CLK DGND FM_INT# FM_FREQ_IN FM_R FM_L C.17 CN18 Hot Key Board Connector (6-Pin) Table C-17 Hot Key Board Connector Pin Assignments (6-Pin) Pin No. Signal Name Pin No. Signal Name +V3LA +V5A HOTKEY_INT# DGND HOTKEY_DATA HOTKEY_CLK Satellite E100/E105 Maintenance Manual...

  • Page 214: Cn20 Esata Connector (11-Pin

    MDIO18 MDIO02 MDIO09 MDIO03 MDIO00 C.19 CN20 eSATA Connector (11-Pin) Table C-19 eSATA Connector Pin Assignments (11-Pin) Pin No. Signal Name Pin No. Signal Name USBVCC1 USB_L_P0N USB_L_P0P DGND DGND SATA_IC_C_TXP4 SATA_IC_C_TXN4 DGND SATA_RXN4 SATA_RXP4 DGND Satellite E100/E105 Maintenance Manual...

  • Page 215: Cn21 Sata Hdd Connector (22-Pin

    Pin No. Signal Name Pin No. Signal Name PCIE_WAKE# +V3S CH_DATA DGND CH_CLK +V1.5S CLKREQ_R_WLAN# LPC_3S_FRAME# DGND LPC_3S_AD(3) CLK_PCIE_WLAN# LPC_3S_AD(2) CLK_PCIE_WLAN LPC_3S_AD(1) DGND LPC_3S_AD(0) BUF_PLT_RST# DGND CLK_R_MINICARD1 WXMIT_OFF# DGND BUF_PLT_RST# PCIE_C_RXN_WLAN +V3S PCIE_C_RXP_WLAN DGND DGND +V1.5S C-10 Satellite E100/E105 Maintenance Manual...
  • Page 216 DGND PCIE_C_RXP_NCARD PCIE_C_RXN_NCARD DGND CLK_PCIE_NCARD CLK_PCIE_NCARD# CPPE# EXPRESS_CLKREQ# +V3_EXP +V3_EXP PERST# +V3AUX_EXP PCIE_WAKE# +V1.5_EXP +V1.5_EXP ICH_3A_ALERT_DAT ICH_3A_ALERT_CLK CPUSB# USB_P4P USB_P4N DGND C.23 CN24 USB Port1 Connector (4-Pin) Table C-23 USB Port1 Connector Pin Assignments (4-Pin) Satellite E100/E105 Maintenance Manual C-11...
  • Page 217 Signal Name USB_P6P DGND USB_P6N CH_CLK BTMDL# BT_RESET# +V3_BT CH_DATA KILL_SWCH# DGND C.27 CN28 Fingerprint Module Connector (4-Pin) Table C-27 Fingerprint Module Connector Pin Assignments (4-Pin) Pin No. Signal Name Pin No. Signal Name DGND USB_P8P C-12 Satellite E100/E105 Maintenance Manual...
  • Page 218 MA_DM(0) MA_DQS#(0) DGND MA_DQS(0) MA_DATA(6) DGND MA_DATA(7) MA_DATA(2) DGND MA_DATA(3) MA_DATA(12) DGND MA_DATA(13) MA_DATA(8) DGND MA_DATA(9) MA_DM(1) DGND DGND MA_DQS#(1) MA_CLK_DDR4 MA_DQS(1) MA_CLK_DDR4# DGND DGND MA_DATA(10) MA_DATA(14) MA_DATA(11) MA_DATA(15) DGND DGND DGND DGND MA_DATA(16) MA_DATA(20) Satellite E100/E105 Maintenance Manual C-13...
  • Page 219 MA_CKE1 +V1.8 +V1.8 MA_CS2# MA_A(15) MA_BA2 MA_A(14) +V1.8 +V1.8 MA_A(12) MA_A(11) MA_A(9) MA_A(7) MA_A(8) MA_A(6) +V1.8 +V1.8 MA_A(5) MA_A(4) MA_A(3) MA_A(2) MA_A(1) MA_A(0) +V1.8 +V1.8 MA_A(10) MA_A(16) MA_A(15) MA_RAS# MA_WE# MA_CS0# +V1.8 +V1.8 MA_CAS# MA_ODT0 C-14 Satellite E100/E105 Maintenance Manual...
  • Page 220 DGND DGND MA_DATA(42) MA_DATA(46) MA_DATA(43) MA_DATA(47) DGND DGND MA_DATA(48) MA_DATA(52) MA_DATA(49) MA_DATA(53) DGND DGND MA_CLK_DDR2 DGND MA_CLK_DDR2# MA_DQS#(6) DGND MA_DQS(6) MA_DM(6) DGND DGND MA_DATA(50) MA_DATA(54) MA_DATA(51) MA_DATA(55) DGND DGND MA_DATA(56) MA_DATA(60) MA_DATA(57) MA_DATA(61) DGND DGND Satellite E100/E105 Maintenance Manual C-15...

  • Page 221: Cn51 Ddr2 Dimm1 Connector (200-Pin

    MB_DM(0) MB_DQS#(0) DGND MB_DQS(0) MB_DATA(6) DGND MB_DATA(7) MB_DATA(2) DGND MB_DATA(3) MB_DATA(12) DGND MB_DATA(13) MB_DATA(8) DGND MB_DATA(9) MB_DM(1) DGND DGND MB_DQS#(1) MB_CLK_DDR4 MB_DQS(1) MB_CLK_DDR4# DGND DGND MB_DATA(10) MB_DATA(14) MB_DATA(11) MB_DATA(15) DGND DGND DGND DGND MB_DATA(16) MB_DATA(20) C-16 Satellite E100/E105 Maintenance Manual...
  • Page 222 MB_CKE1 +V1.8 +V1.8 MB_CS2# MB_A(15) MB_BA2 MB_A(14) +V1.8 +V1.8 MB_A(12) MB_A(11) MB_A(9) MB_A(7) MB_A(8) MB_A(6) +V1.8 +V1.8 MB_A(5) MB_A(4) MB_A(3) MB_A(2) MB_A(1) MB_A(0) +V1.8 +V1.8 MB_A(10) MB_A(16) MB_A(15) MB_RAS# MB_WE# MB_CS0# +V1.8 +V1.8 MB_CAS# MB_ODT0 Satellite E100/E105 Maintenance Manual C-17...
  • Page 223 DGND DGND MB_DATA(42) MB_DATA(46) MB_DATA(43) MB_DATA(47) DGND DGND MB_DATA(48) MB_DATA(52) MB_DATA(49) MB_DATA(53) DGND DGND MB_CLK_DDR2 DGND MB_CLK_DDR2# MB_DQS#(6) DGND MB_DQS(6) MB_DM(6) DGND DGND MB_DATA(50) MB_DATA(54) MB_DATA(51) MB_DATA(55) DGND DGND MB_DATA(56) MB_DATA(60) MB_DATA(57) MB_DATA(61) DGND DGND C-18 Satellite E100/E105 Maintenance Manual...

  • Page 224: Jack1 Rj45 Lan Connector (12-Pin

    LAN_CP LAN_CN LAN_RDN LAN_DP LAN_DN +V3_LAN LED_R3S_LANTXACT# +V3_LAN LED_R3S_LANLINK# C.33 JACK2 External MIC Connector (6-Pin) Table C-33 External MIC Connector Pin Assignments (6-Pin) Pin No. Signal Name Pin No. Signal Name DGND MIC_L MIC_R MICS Satellite E100/E105 Maintenance Manual C-19...

  • Page 225: Jack3 Head Phone Connector (6-Pin

    CRT_DATA H_SYNC V_SYNC CRT_CLK C.36 CN2001 CRT Port Connector (15-Pin) Table C-36 CRT Port Connector Pin Assignments (15-Pin) Pin No. Signal Name Pin No. Signal Name DGND CRT_CLK CRT_DATA DGND H_SYNC DGND V_SYNC DGND DGND C-20 Satellite E100/E105 Maintenance Manual...

  • Page 226: Cn2002 Fm Antenna Connector (2-Pin

    Touch Pad Board C.39 CN2004 Touch Pad Module Connector (12-Pin) Table C-39 Touch Pad Module Connector Pin Assignments (12-Pin) Pin No. Signal Name Pin No. Signal Name LEFT_TP DB_TP_LED_ON RIGHT_TP DGND_TP DGND_TP TP_IM_CLK_5 TP_IM_DAT_5 +TP_5S +TP_5S Satellite E100/E105 Maintenance Manual C-21...

  • Page 227: Cn2005 Touch Pad Board Connector (8-Pin

    Apx. C Pin Assignments C.40 CN2005 Touch Pad Board Connector (8-Pin) Table C-40 Touch Pad Board Connector Pin Assignments (8-Pin) Pin No. Signal Name Pin No. Signal Name GND_TP DB_TP_LED_ON TP_IM_CLK_5 TP_IM_DAT_5 +TP_5S +V3LA_TP LID_SW#_3_TP C-22 Satellite E100/E105 Maintenance Manual...
  • Page 228 Apx. D Keyboard Scan/Character Codes Appendix D Keyboard Scan/Character Codes Table D-1 Scan Codes (set 1 and set 2) (1/4) Code set 1 Code set 2 Note Keytop Make Break Make Break ‘ ~ 7 & BkSp Satellite E100/E105 Maintenance Manual...
  • Page 229 Table D-1 Scan Codes (set 1 and set 2) (2/4) Code set 1 Code set 2 Note Keytop Make Break Make Break Caps Lock ‘ “ Enter Shift (L) No.102 , < . > Shift (R) Satellite E100/E105 Maintenance Manual...
  • Page 230 Appendices Table D-1 Scan Codes (set 1 and set 2) (3/4) Code set 1 Code set 2 Note Keytop Make Break Make Break Ctrl Alt (L) Space ALT (R) ← Home ↑ ↓ PgUp PgDn → Satellite E100/E105 Maintenance Manual...
  • Page 231 5. * This key corresponds to key No. 42 in a 102-key model. 6. * Refer to Table D-6, No. 124 key scan code. 7. * Refer to Table D-7, No. 126 key scan code. 8. * 205~207 are for JAPAN keyboard only Satellite E100/E105 Maintenance Manual...
  • Page 232 Shift key, scan codes are changed as listed below: With left Shift With right Shift Set 1 E0 AA __________ E0 B6 E0 2A ___________ E0 36 Set 2 E0 F0 12 ________ E0 F0 59 E0 12 ___________ E0 59 Satellite E100/E105 Maintenance Manual...
  • Page 233 Code set 2 Make Break Make Break ← Home ↑ ↓ PgUp PgDn → Table D-4 Scan Codes with Fn key Code set 1 Code set 2 Keytop Make Break Make Break CTRL LALT ARROW NUMERIC Scrl Satellite E100/E105 Maintenance Manual...
  • Page 234 Code set 1 Code set 2 Make Break Make Break (–) Table D-6 No.124 key scan code Shift Code set 1 Code set 2 Make Break Make Break Prt Sc Common Ctrl + Shift + Alt + Satellite E100/E105 Maintenance Manual...
  • Page 235 Apx. D Keyboard Scan/Character Codes Table D-7 No.126 key scan code Shift Code set 1 Code set 2 Make Make Pause Common* E1 1D E1 F0 Ctrl* E0 46 7E E0 F0 *: This key generates only make codes. Satellite E100/E105 Maintenance Manual...

  • Page 236: Appendix E Key Layout

    Apx. E Key Layout Appendices Apx. E Appendix E Key Layout United States (US) Keyboard Figure E-1 United Status Keyboard French Canadian (Bilingual) Keyboard Figure E-2 French Canadian Keyboard Satellite E100/E105 Maintenance Manual...

This manual is also suitable for:

Satellite e105

Table of Contents
