Satellite E105 Detailed Product Specification
Model Name: E105-S1602
C1
2
Operating System
• Genuine Windows Vista
®
Home Premium (SP1, 64-bit version)
Processor and Chipset
®
®
Intel
Centrino
2 Processor Technology featuring:
• Intel
®
Core™ 2 Duo Processor P7350
o 2.0GHz, 3MB L2 Cache, 1066MHz FSB
• Mobile Intel
®
GM45 Express Chipset
• Intel
®
Wi-Fi Link 5100AGN (802.11a/g/n)
5
Memory
• Configured with 4GB DDR2 800MHz (max 4GB)
6
Storage Drive
• 500GB (5400 RPM); Serial ATA hard disk drive
Fixed Optical Disk Drive
• DVD SuperMulti with Labelflash
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
o Supports Labelflash
the disk.
8
Display
• 14.1" diagonal widescreen TruBrite
native resolution (WXGA)
o Native support for 720p content
9
Graphics
• Mobile Intel
®
Graphics Media Accelerator 4500MHD with 128MB-
1342MB dynamically allocated shared graphics memory
Sound
• Built-in stereo speakers
Input Devices
• 85 key backlit US keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Media Control Buttons:
o Mute
o CD/DVD control buttons
Communications
• Webcam and microphone built into LCD bezel
• FM Tuner with antenna
• 10/100/1000 Ethernet
• Intel
®
Wi-Fi Link 5100AGN (802.11a/g/n)
• Bluetooth
®
version 2.1 plus Enhanced Data Rate (EDR)
Expandability
• 2 main memory slots. Both slots may be occupied.
• Memory Card Reader
o Secure Digital, Memory Stick™, Memory Stick PRO™,
MultiMedia Card, xD Picture Card [shared slot]
Ports
• Video
HDMI
o
• Audio
o S/P DIF output port (shared with headphone port)
o Microphone input port
o Headphone output port
• Data
o USB v2.0 – 3 ports with USB Sleep and Charge
o 2 x USB v2.0
Part Number: PSE10U-00D007
3
4
7
®
drive supporting 11 formats
®
media to burn high quality labels directly on
®
TFT LCD display at 1280x800
10
11
© Copyright 2009 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
1
o RJ-45 LAN port
• Security
o Fingerprint reader
Physical Description
• Fusion™ Finish – Copper Brown color
• Dimensions (W x D x H Front/H Rear): 13.4" x 9.69" x 1.20" /1.24"
without feet
• Weight: Starting at 4.99 lbs., depending upon configuration
Power
• 75W (19V 3.95A) 100-240V/50-60Hz AC Adapter.
o Dimensions (W x D x H): 5.00" x 2.01" x 1.20"
o Weight: starting at 0.77 lbs.
13
Battery
• 5000mAh (8 cell) Lithium Ion battery pack
C1
Software
• Toshiba Software and Utilities
o Electronic User's Guide
o TOSHIBA Resources
o TOSHIBA Value Added Package
o TOSHIBA ConfigFree
o TOSHIBA Assist
o TOSHIBA DVD Player
o TOSHIBA Disc Creator
o TOSHIBA Extended Tiles for Windows Mobility Center
o TOSHIBA Face Recognition
o TOSHIBA HDD Protection (3D Sensor)
o Hard Disc Drive (HDD) Recovery
• Third-party Software
®
o Sun
Java™ 2 Runtime Environment
o Adobe
o Microsoft
o Google™ Toolbar
o Norton Antivirus™, 15-month subscription
®
o Ulead
o PowerCinema for TOSHIBA
• Trial Software
o Microsoft
Environmental Specifications
• This product is RoHS
• Energy Star 5.0 Compliant
• EPEAT™ Gold
16
Temperature
Thermal Gradient
Relative Humidity
(non-condensing)
Altitude
(relative to sea level)
Shock
Vibration
2 YEAR STANDARD LIMITED WARRANTY
• Includes International Limited Warranty for obtaining service when
traveling outside the United States.
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Satellite E105-S1602
UPC: 883974248339
o 1 x eSATA/USB combo port
14
®
®
®
Acrobat
Reader
®
Works 9
®
DVD MovieFactory
5 for TOSHIBA
®
Office Home and Student 2007 Edition, 60-day trial
15
compatible
Operating
5° to 35° C
(41° to 95° F)
15° C per hour (max)
20% to 80%
0 to 3,000 meters
10G
0.5G
12
Non-operating
-20° to 60° C
(-4° to 140° F)
20° C per hour (max)
10% to 95%
0 to 10,000 meters
60G
1.0G
17
®
,
