20" LCD TV
Color Monitor
Service
Service
Service
Description
Table Of Contents......................................................1
Revision List........................................................2
Important Safety Notice.....................................3
1.Specification For LCD-TV...........................................4
1.1 General Specification........................................4
1.2 LCD-TV Description............................................5
1.3 Interface Connector..........................................5
2. Precautions And Notices..................................5
2.1 Assembly Precaution..........................................5
2.2 Operating Precaution........................................5
2.3 Storage Precaution............................................5
2.4 High Voltage Warning.......................................5
3. Input/Output Specification..................................6
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

TABLE OF CONTENTS

Page
Description
4. Adjustments...........................................................7
5. Trouble Shooting...............................................14
7.Block Diagram.........................................................22
7.1 Main Board........................................................22
7.2 Power Board....................................................23
8.Schematic............................................................24
8.1 Main Board............................................................24
8.2 Power Board..........................................................37
9. Explode View....................................................41
10. BOM List..........................................................42
11.PCB Layout........................................................67
11.1 Main Board.......................................... ...........67
11.2 Power Board.....................................................69
SAFETY NOTICE
1
LV20E351
Horizontal Frequency
31.5-49kHz
Page

Advertisement

Table of Contents
loading

Related Manuals for AOC LV20E351

Summary of Contents for AOC LV20E351

  • Page 1: Table Of Contents

    20" LCD TV Color Monitor LV20E351 Service Service Service Horizontal Frequency 31.5-49kHz TABLE OF CONTENTS Description Page Description Page 4. Adjustments………….……......……….7 Table Of Contents..……......…..1 5. Trouble Shooting………………………………………..14 Revision List.…........……..2 6.White-Balance, Luminance Adjustment……………….20 Important Safety Notice.……....……..3 7.Block Diagram………..…..………......22 1.Specification For LCD-TV……....………..4 7.1 Main Board……….…...……………..………....22...

  • Page 2: Revision List

    Revision List Revision Release Date Revision History TPV Model Jun-06-06 Initial Release EAB5ASNBC3VDTM...

  • Page 3: Important Safety Notice

    Important Safety Notice Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service procedures recommended by AOC and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. The special tools should be used when and as recommended.

  • Page 4: Specification For Lcd-Tv

    1. Specifications For LCD TV 1-1 General Specifications 20.1” screen SVGA ( 800 x 600 ) Resolution Feature High Brightness ( 500 cd/m High Contrast Ration ( 500:1 ) Wide Viewing Angle ( 160 H / 160 V ) Built-in Full channel Tuner with Nicam, Teltext. Graphic (VGA) PIP(Video on Graphic) Specification...

  • Page 5: Lcd-Tv Description

    1-2 LCD TV Description The LCD TV will contain a main board (include audio), a switching power board (include an inverter board), an IR board, a function keyboard, and an Earphone board. The main board and power board will house the flat panel to control logic I2C bus, DDC, brightness control logic for LCD panel, DC-DC conversion to supply the appropriate power to the whole board and transmitting TTL level signals into LCD Module to drive the LCD display circuit.

  • Page 6: Input/Output Specification

    3. Input/Output Specification This procedure gives you instructions for installing and using the LCD TV display. 1. Position the display on the desired operation and plug the power cord into a convenient AC outlet. Three-wire power cord must be shielded and is provided as a safety precaution as it connects the chassis and cabinet to the electrical conduct ground.

  • Page 7: Adjustments

    4. Adjustment 4-1 Adjustment Control Function Adjustments items as below: External Controls: (7-key knob) Menu, CH Down, CH Up, Power On/Off, VOL Down, VOL Up, Source OSD Control function: To Use The Menus TO USE THE MENUS 1. Press the MENU button repeatedly to display each menu. 2.
  • Page 8 Note: TINT only work in NTSC video signal input. When adjust any item sub-OSD will show up like this. AUDIO Adjust 1. VOLUME is adjusted from 0 to 100. 2. BASS and TREBLE are adjusted from 0 to 100. You can adjust picture Volume, Bass and Treble to the levels you prefer. When adjust any item sub-OSD will show up like this.
  • Page 9 4. Use INSERT to insert current program into selected position. SETUP 1. BLUE SCREEN for when no video input screen will be blue or blank. If it’s ON, the screen will be in blue. If it’s OFF, the screen will be blank. Preset is ON. 1.
  • Page 10 PC Adjust 1. AUTO TUNE is the function auto-sizing for VGA input. 2. CONTRAST, BRIGHTNESS, FOCUS, CLOCK, H-POSITION, V-POSITION and COLOUR are the functions for PC adjustment. Colour for you can adjust the colour temperature you prefer. COLOUR 1. PIP for turn on / off small picture function. 2.
  • Page 11 Use of the remote control USE OF THE REMOT CONTROL DISPLAY POWER: (1) Display Channel number Press to turn on/off the TV. when use RF input. The TV is never completely (2) Display input source when powered off unless it is use other input except TV physically unplugged.
  • Page 12 TELETEXT Teletext is an information service organized like a magazine, which is provided by some TV stations in addition to regular television broadcasting. TELETEXT Press TELETEXT. The Teletext screen appears. To turn off the Teletext mode, press TELETEXT again. Press MIX to superimpose the teletext over a normal broadcast picture.

  • Page 13: Adjustment Method

    4-2 Adjustment Method Press MENU key to show OSD window or exit, Up / Down key to done the function selection, And + / - key to done the adjustment. 4-3 Front Panel Control Knobs Power Key： Press to turn on or off the TV. MENU Key：Press to show the OSD menu and exit OSD menu at the TV.

  • Page 14: Trouble Shooting

    5. Trouble Shooting 5-1 Panel Control Circuit No Display Check CN101 pin 42-45 Replace panel or FFC is 5V and signal on pin cable to panel 35,37,39,40,25-28,30-33,15- 18,20-23,5-8,10-13 Check U300 Output to CN101 relative circuit and Replace L118, C137 CN101 VCC at Q300, Q301, L309 (5V) Check U300 crystal Replace X300...
  • Page 15 5-2. Main Board Power Circuit 5-3. Remote Control Block...
  • Page 16 5-4. Key Board Control Block 5-5. Pc Control Block...
  • Page 18 5-6. Audio Control Block...
  • Page 19 5-7 Video Control Block Note: 1、If Replace “MAIN-BOARD” , Please re-do “DDC-content” programmed & “WHITE-Balance”. 2、If Replace “ POWER-BOARD INVERTER” only, Please re-do “ WHITE-Balance” 3、Please re-install program before you do change any component.

  • Page 20: White-Balance, Luminance Adjustment

    6. White-Balance, Luminance Adjustment Approximately 30 minutes should be allowed for warm up before proceeding white balance adjustment. Before started adjust white balance, please setting the Chroma-7120 MEM. Channel 1 to 9300 colors, MEM. Channel 2 to 6500 color, and MEM. Channel 3 to 9300 colors, (9300 parameter is x = 283 ± 15, y = 297 ± 15, Y = SPC.
  • Page 21 1. Set the Contrast of OSD function to 45 and Adjust Brightness to chroma-7120 Y>230 cd/m 2. Switch the chroma-7120 to RGB-mode (with press “MODE” button) 3. Switch the MEM.channel to Channel 02 (with up or down arrow on chroma-7120) 4.

  • Page 22: Block Diagram

    7. Block Diagram 7-1 Main Board 20” LCD TV Block Diagram DRAM Tuner SAA5361HL/M1/1 FQ1216ME/I 651 FQFP-100 H-5(SV22) E-Frame Input option Panel SPV302A PBGA-388 SUNPLUS Scaler NJM-2244 VIDEO 1 M-TE1/JR SCART CVBS Key PAD VPC 3230 Decoder S-VIDEO CVBS Inverter AD 9883 D-SUB Head phone...

  • Page 23: Power Board

    7-2 Power Board...

  • Page 24: Schematic

    SCART 100pF 100pF INTERLACE_SY NC 4 R100 COMP_SEL 11/21 1.8K 　 1/16W 56L 634 2 RN106 U104 PI5V330 RN105 AOC (Top Victory) Electronics Co., Ltd. O_PRO_Y 3230_Y SCART_H O_PRO_PB 3230_PB R135 AGND O_PRO_PR 3230_PR Title SCART_CVBS INTERLACE_SY NC SCART_V Size...
  • Page 25 10uF/16V DVD_AR VIDEO_SEL 100k 　 1/16W R370 R369 RN318 DVD_R_1 AGND C168 DVD_L_1 10uF/16V DVD_AL AOC(TOP VICTORY) Electronics CO., Ltd Title R146 R145 VIDEO & AUDIO SELECT 　 1/16W 　 1/16W R368 NC Size Document Number AGND TV2054-2Ea Date: Wednesday , April 07, 2004...
  • Page 26 0.1uF C109 C108 10uF/16V 0.1uF/16V 100uF/16V Q101 PMBS3904 R105 R106 AGND TUNER_OUT 1/16W 　 R107 C110 　 1/16W 47pF AGND AGND AOC (Top Victory) Electronics Co., Ltd. Title TUNER Size Document Number TV2054-2Ea Date: Wednesday , April 07, 2004 Sheet...
  • Page 27 330pF C227 C228 C229 0.0015uF 390pF 0.22uF AGND L207 600 OHM 3.3VS L208 VDDA VDDI 600 OHM 5V_A AOC (Top Victory) Electronics Co., Ltd. L209 Title C230 C231 C232 C233 C234 C235 C236 C237 C238 C239 C240 Micronas 3230D 10uF/16V...
  • Page 28 　 DQMH0 MDQMH0 CASNN MCASNN R353 R351 22 　 1/16W R352 22 　 1/16W 3.3VM 　 1/16W AOC (Top Victory) Electronics Co., Ltd. DQML1 MDQML1 RASNN MRASNN 3,4,6,8,9,11 R355 22 1/16W R356 22 1/16W 　 　 3,4,6,8,9,11 DQMH1 MDQMH1 WENN...
  • Page 29 R319 1/16W 　 　 SRS_CTL CH_SEL3 I/O3 I/O5 R320 　 1/16W VIDEO_SEL I/O4 AOC (Top Victory) Electronics Co., Ltd. VIDEO_SEL for ADC input selection Title SEL1 SEL2 SEL3 audio video (source :HD & VGA) SPV301(Video In/Panel Out) SCART SCART Size...
  • Page 30 3.3VM 3.3VM C301 0.1uF U2.AA23 C302 0.1uF U2.D14 U2.AC9 U2.M4 C303 0.1uF C304 0.1uF C305 0.1uF C306 0.1uF C307 0.1uF C308 0.1uF U2.AC10 C309 0.1uF U2.M23 C310 0.1uF C311 0.1uF C312 0.1uF U2.AC18 C313 0.1uF U2.N4 C314 0.1uF C315 0.1uF U300F C316 0.1uF...
  • Page 31 　 High active RESET_OUT R451 Q406 C434 5264_RST 1N4148W 100K 　 1/16W PMBS3906 10uF/16V R453 R452 2.2K 　 1/16W 　 1/16W AOC (Top Victory) Electronics Co., Ltd. Title TELETEXT Size Document Number TV2054-2Ea Date: Wednesday , April 07, 2004 Sheet...
  • Page 32 C531 C532 C533 C534 C535 10uF/16V 0.1uF 0.1uF 0.1uF 0.1uF 100uF/16V 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 24LC02 AGND AGND AGND AOC (Top Victory) Electronics Co., Ltd. Title AD9883 Size Document Number TV2054-2Ea Date: Wednesday , April 07, 2004 Sheet...
  • Page 33 3.9K 　 1/16W R459 C652 R637 100uF/16V 1/16W 　 R656 　 1/10W R657 R658 1/10W 　 R638 AOC (Top Victory) Electronics Co., Ltd. 　 1/10W 1/16W 　 R645 　 1/10W C653 Title 10uF/16V AUDIO AGND AUDIO_GND Size Document Number TV2054-2Ea...
  • Page 34 0.01uF C631 0.01uF LINE_O_L R805 R608 C663 　 1/16W 　 1/16W LINE_O_R R806 　 1/16W 1uF/16V AOC (Top Victory) Electronics Co., Ltd. C661 C660 0.01uF 0.01uF Title Audio decoder TV2054-2Ea Size Document Number Date: Wednesday , April 07, 2004 Sheet...
  • Page 35 R705 C720 R700 C721 Q703 C722 C723 C724 1/16W 　 10uF/16V 10uF/16V PMBS3904 0.1uF 0.1uF 0.1uF AOC (Top Victory) Electronics Co., Ltd. 　 1/16W L709 Title 600 OHM POWER AGND R706 　 1/8W 12V_A Size Document Number L700 AGND AGND...
  • Page 36 1/10W 1/10W 　 　 1/16W 　 1/10W 0　 0.1uF 　 1/8W 　 1/10W AGND AGND AGND AOC (Top Victory) Electronics Co., Ltd. AGND AGND For EMI Title LVDS AGND Size Document Number TV2054-2Ea Date: Wednesday , April 07, 2004 Sheet...

  • Page 37: Power Board

    8.2 Power Board R919 47_1/2W_M R920 C913 47_1/2W_M 102P_500V 5Vout D910 F902 12Vout MOSPEC20100 5A/24V/1206 L903 T901 73L-253-91L TO INVERTER PQ26/22.5 FB902 R906 R904 C906 R903 TO AUDIO BD901 1M(1206) 1M(1206) 152P/1KV 100K_2W C916 GBU405 D911 C914 C915 470UF/16V C905 MOSPEC20100 2200UF/16V 2200UF/16V...
  • Page 38 5Vout L101 Q101 FB101 22UH BEAD C101 D101 D102 C106 C107 0.1UF 1000uF/16V SI4431DY-T1 SR24 SR24 1000uF/16V R101 C103 10NF C105 100PF(NPO) LM3485 C104 PGATE IC102 R102 R103 60KF PWR GND C102 20KF 0.1UF Isense MINI SO8 Title <Title> Size Document Number <Doc>...
  • Page 39 CN201 C201 27P/3KV Q201 SI4431 OR AO4411 R201 4.7K Q202 12Vout SST3904 L201 D201 Q203 C202 0.01UF 150UH(60-52) CN203 1000UF/25V 1000UF/25V C205 DTA144WKA C203 C204 C245 C246 0.1UF 0.1UF Q204 PT201 R207 R208 RLZ8.2B D202 27P/3KV ON/OFF DTC144WKA +12VCC R210 C206 Q205 6.8K...
  • Page 40 +12VCC V_REF R298 V_SENSOR_4 D221 1N4148 V_SENSOR_1 R256 D222 1N4148 300K R299 R254 R255 V_SENSOR_5 R293 300K V_SENSOR_2 R257 D224 1N4148 D225 1N4148 Q217 300K D223 R291 R294 300K V_SENSOR_3 V_SENSOR_6 1N4148 680K D226 1N4148 D227 1N4148 R296 R295 300K 680K RK7002 R2100...

  • Page 41: Explode View

    9. Explode View...

  • Page 42: Bom List

    PAPER PLATE 044T9003 6 CORNER PAPER 044TZ001200 4B PIZZA BOX 045T 88606 3 PE BAG FOR BASE 045T 88609 20 EPE COVER-AOC 045T 88626 4 PE BAG FOR MONITOR 050T 500 1 CABLE TIE 052T 1185 MIDDLE TAPE FOR CARTON...
  • Page 43 033T4832 RG L CLIP CABLE 033T4837 RG L STAND TOP 033T6302 14 C PC PLATE ON TOP 034T1527 RG 2L AOC BEZEL 034T1528 GM L REAR COVER 034T1531 RG L STAND 036T 426 KN 4C SPEAKER GRILL 037T 525 2...
  • Page 44 R719 061T 208629 64 6.2OHM +-5% 1W R103 061T152M259 64 2.5 OHM 5% W2 R102 061T152M259 64 2.5 OHM 5% W2 R654 061T153M399 59 3.9 OHM+-5% 3W R655 061T153M399 59 3.9 OHM+-5% 3W R643 061T153M399 59 3.9 OHM+-5% 3W R644 061T153M399 59 3.9 OHM+-5% 3W C644...
  • Page 45 C222 065T 3J2706ET 27PF +-5% 3KV TDK C901 065T305M1022BP 1000PF C902 065T305M1022BP 1000PF C924 065T305M2222B3 C-C220P/250V C922 065T305M2222B3 C-C220P/250V C921 065T306M4722BP 4700PF +-20% 400VAC C915 067T215B102 4R 1000UF 25V 10*23 C914 067T215B102 4R 1000UF 25V 10*23 C905 067T215S15115K EC105C 150UF 450V C920 067T215V102 3N GP KY16VB1000M-CC3 10*16...
  • Page 46 U704 056T 133 30AAC AZ1117H-1.8-E1 U602 056T 535 3 TDA7266D U300 056T 562 87 SPV302A PBGA-388 SUNPLUS U501 056T 567 6 AD9883AKSTZ-140 U703 056T 585 5 RT9164-25PG U101 056T 585 9 IC AP1117E50LA ANACHIP U700 056T 585 4A AP1117E33LA U701 056T 585 4A AP1117E33LA U702...
  • Page 47 RP200 061V 125101 8 CHIP ARRAY 100OHM 1/15W 8P4R RN101 061V 125104 8 CHIP ARRAY 100K OHM 1/16 8P4R RN304 061V 125220 8 CHIP ARRAY 22 OHM 1/16W8P4R RN305 061V 125220 8 CHIP ARRAY 22 OHM 1/16W8P4R RN306 061V 125220 8 CHIP ARRAY 22 OHM 1/16W8P4R RN307 061V 125220 8...
  • Page 48 R330 061V0603101 CHIPR 100 OHM+-5% 1/10W R329 061V0603101 CHIPR 100 OHM+-5% 1/10W R328 061V0603101 CHIPR 100 OHM+-5% 1/10W R327 061V0603101 CHIPR 100 OHM+-5% 1/10W R323 061V0603101 CHIPR 100 OHM+-5% 1/10W R320 061V0603101 CHIPR 100 OHM+-5% 1/10W R319 061V0603101 CHIPR 100 OHM+-5% 1/10W R318 061V0603101 CHIPR 100 OHM+-5% 1/10W...
  • Page 49 R639 061V0603103 CHIPR 10K OHM+-5% 1/10W R640 061V0603103 CHIPR 10K OHM+-5% 1/10W R338 061V0603103 CHIPR 10K OHM+-5% 1/10W R337 061V0603103 CHIPR 10K OHM+-5% 1/10W R336 061V0603103 CHIPR 10K OHM+-5% 1/10W R317 061V0603103 CHIPR 10K OHM+-5% 1/10W R358 061V0603104 CHIPR 100K OHM+-5% 1/10W R359 061V0603104 CHIPR 100K OHM+-5% 1/10W...
  • Page 50 R631 061V0603392 CHIP 3.9K OHM 1/16W R627 061V0603392 CHIP 3.9K OHM 1/16W R620 061V0603392 CHIP 3.9K OHM 1/16W R606 061V0603471 CHIPR 470 OHM+-5% 1/16W R605 061V0603471 CHIPR 470 OHM+-5% 1/16W R603 061V0603471 CHIPR 470 OHM+-5% 1/16W R601 061V0603471 CHIPR 470 OHM+-5% 1/16W R350 061V0603472 RST CHIPR 4.7KOHM +-5% 1/10W...
  • Page 51 R208 061V0603750 9F 75 OHM 1% 1/10W R210 061V0603750 9F 75 OHM 1% 1/10W R118 061V0603822 CHIP 8.2K OHM 1/16W R308 061V0603912 CHIP 9.1K OHM 1/16W R307 061V0603913 CHIP 91K OHM 1/16W R305 061V0603913 CHIP 91K OHM 1/16W R710 061V0805000 CHIP 0OHM 1/10W R658 061V0805000...
  • Page 52 C411 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C412 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C413 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C415 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C421 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C426 065T0603104 12 MLCC 0603 0.1UF K 16V X7R...
  • Page 53 C716 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C523 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C526 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C527 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C528 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C529 065T0603104 12 MLCC 0603 0.1UF K 16V X7R...
  • Page 54 C332 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C333 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C334 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C335 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C336 065T0603104 12 MLCC 0603 0.1UF K 16V X7R C337 065T0603104 12 MLCC 0603 0.1UF K 16V X7R...
  • Page 55 C427 065T0603220 31 CHIP 22PF 50V NPO C210 065T0603220 31 CHIP 22PF 50V NPO C209 065T0603220 31 CHIP 22PF 50V NPO C616 065T0603221 31 CHIP 220PF 50V NPO C229 065T0603224 17 CHIP 0.22UF 16V Y5V C218 065T0603224 17 CHIP 0.22UF 16V Y5V C217 065T0603224 17 CHIP 0.22UF 16V Y5V...
  • Page 56 C159 065T0603680 31 CHIP 68PF 50V NPO C157 065T0603680 31 CHIP 68PF 50V NPO C158 065T0603680 31 CHIP 68PF 50V NPO C223 065T0603683 32 CHIP 0.068UF 50V X7R C500 065T0603822 32 CHIP 8200PF 50V X7R C503 065T0603823 32 CHIP 0.047UF 50V X7R C650 065T0805225 12 CHIP 2.2UF 16V X7R 0805...
  • Page 57 C120 067T 312100 3 SMD EC 10UF 16V 85C B C353 067T 312100 3 SMD EC 10UF 16V 85C B C348 067T 312100 3 SMD EC 10UF 16V 85C B C347 067T 312100 3 SMD EC 10UF 16V 85C B C331 067T 312100 3 SMD EC 10UF 16V 85C B...
  • Page 58 L203 071T 56G151 A CHIOP BEAD 150 OHM L500 071T 56G151 A CHIOP BEAD 150 OHM L605 071T 56G151 A CHIOP BEAD 150 OHM L606 071T 56G151 A CHIOP BEAD 150 OHM L607 071T 56G151 A CHIOP BEAD 150 OHM L608 071T 56G151 A CHIOP BEAD 150 OHM...
  • Page 59 L207 071T 56U601 BEAD 600 OHM L148 071T 57G601 BEAD 1206 600 OHM L309 071T 57G601 BEAD 1206 600 OHM L315 071T 57G601 BEAD 1206 600 OHM L702 071T 57G601 BEAD 1206 600 OHM L703 071T 57G601 BEAD 1206 600 OHM L704 071T 57G601 BEAD 1206 600 OHM...
  • Page 60 IC901 056T 379 33 SG6841SZ IC101 056T 379 37 FP5001DR-LR Q218 057T 417 4 CHIP PMBS3904 BY PHILIPS Q215 057T 417 4 CHIP PMBS3904 BY PHILIPS Q212 057T 417 4 CHIP PMBS3904 BY PHILIPS Q210 057T 417 4 CHIP PMBS3904 BY PHILIPS Q209 057T 417 4 CHIP PMBS3904 BY PHILIPS...
  • Page 61 R102 061V0603102 CHIPR 1K OHM+-5% 1/10W R294 061V0603104 CHIPR 100K OHM+-5% 1/10W R293 061V0603104 CHIPR 100K OHM+-5% 1/10W R292 061V0603104 CHIPR 100K OHM+-5% 1/10W R286 061V0603104 CHIPR 100K OHM+-5% 1/10W R280 061V0603104 CHIPR 100K OHM+-5% 1/10W R267 061V0603104 CHIPR 100K OHM+-5% 1/10W R257 061V0603104 CHIPR 100K OHM+-5% 1/10W...
  • Page 62 R256 061V0603515 CHIPR 5.1MOHM +-5% 1/10W R237 061V0603680 1F CHIP 6.8KOHM 1% 1/10W R207 061V0603680 1F CHIP 6.8KOHM 1% 1/10W R296 061V0603684 CHIP 680K OHM 1/10W R291 061V0603684 CHIP 680K OHM 1/10W R241 061V0603750 1F RES 7K5 1/10W 1% SMT 0603 R212 061V0603750 1F RES 7K5 1/10W 1% SMT 0603...
  • Page 63 C229 065T0805104 22 0.1UF +-10% 25V X7R 080 C224 065T0805104 22 0.1UF +-10% 25V X7R 080 C221 065T0805104 22 0.1UF +-10% 25V X7R 080 C217 065T0805104 22 0.1UF +-10% 25V X7R 080 C213 065T0805104 22 0.1UF +-10% 25V X7R 080 C210 065T0805104 22 0.1UF +-10% 25V X7R 080...
  • Page 64 065T0603104 32 CHIP 0.1UF 50V X7R 065T0603104 32 CHIP 0.1UF 50V X7R 065T0805475 A5 CHIP 4.7UF 10V X5R 071T 59B601 EA CHIP BEAD 600OHM 0603 TB1608 071T 59B601 EA CHIP BEAD 600OHM 0603 TB1608 715T1453 1 I IR BOARD PCB 057T 417 6 PMBS3906/PHILIPS-SMT 061V0603000...
  • Page 65 R223 061T 60230352T 30KOHM 5% 1/6W R220 061T 60230352T 30KOHM 5% 1/6W R249 061T 60243252T 4.3K OHM 5% 1/6W C230 064T701J2240AT 0.22UF +-5% 63V C216 064T701J2240AT 0.22UF +-5% 63V C906 065T 1K152 1T 1.5NF/1KV Z5F+-10% C110 067T 2154713RT KY16VB470M-TP58*15 C907 067T 305220 7T 22uf 50v FB902...
  • Page 66 J204 095T 90 23 TIN COATED J205 095T 90 23 TIN COATED J206 095T 90 23 TIN COATED J207 095T 90 23 TIN COATED J208 095T 90 23 TIN COATED J209 095T 90 23 TIN COATED J210 095T 90 23 TIN COATED J211 095T 90 23...

  • Page 67: Pcb Layout

    11. PCB Layout 11.1 Main Board...

  • Page 69: Power Board

    11.2 Power Board...
