HEADREST DVD REAR SEAT ENTERTAINMENT SYSTEM
SCION xB
OWNER'S
OWNER'S
OWNER'S
OWNER'S
OWNER'S
MANU
MANU
AL
AL
MANUAL
MANU
MANU
AL
AL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the xB and is the answer not in the manual?

Questions and answers

Related Manuals for Scion xB

Summary of Contents for Scion xB

  • Page 1 OWNER’S OWNER’S OWNER’S OWNER’S OWNER’S MANU MANU MANU MANUAL MANU SCION xB HEADREST DVD REAR SEAT ENTERTAINMENT SYSTEM...
  • Page 2 INTRODUCTION Your vehicle is equipped with a Headrest DVD Rear Seat Entertainment System (RSE). The system is designed to give you and your passengers many years of video and audio entertainment in a mobile environment. The system allows you to listen to audio CD’s and watch DVD’s.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This manual contains certain CAUTION and NOTICE Warnings that are used to prevent or reduce the chance of injury or damage to passengers and vehicle equipment, respectively. If you are driving a TOYOTA with a RSE system, please adhere to the following guidelines: CAUTION NOTICE...
  • Page 4 CAUTION CAUTION 1. Keep the monitor clean and dry. Conversational speech on some DVDs is recorded at a low 2. Always seek qualified personnel to perform repairs. Never volume to emphasize the impact of sound effects. If you attempt your own repairs. adjust the volume assuming that the conversations represent 3.
  • Page 5 NOTICE NOTICE Exercise care to prevent dirt and foreign objects from entering Do not operate video games or video equipment if the power the DVD player compartment. Be especially careful not to cords and/or cables are broken, split or damaged. Carefully spill liquids of any kind onto the media controls or into the place cords and/or cables where they will not be stepped on system.
  • Page 6 NOTICE NOTICE Do not insert foreign objects into the DVD openings. Do not play the Rear Seat Entertainment System for extended periods of time with the engine shut off as this will drain the battery. NOTICE NOTICE Do not expose the liquid crystal display (LCD) screen to direct Do not attempt to service, repair or modify the Rear Seat sunlight or intensive ultraviolet rays for extensive periods of time.

  • Page 7: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..............I Settings and Adjustments ........... 13 Federal Communication Commission (FCC) Compliance I Using the Setup Menu ..........13 Exiting the Setup Menu ..........13 SAFETY PRECAUTIONS ..........II-V Language Setup ............13 QUICK START GUIDE ............1 Language for On-Screen Display .......

  • Page 8: Quick Start Guide

    QUICK START GUIDE Operating The DVD System: 1. Turn on the M1 Monitor (passenger side) using the 9. Tilt the screen to a comfortable viewing position (the Power button on the front of the screen or the *Remote headrest itself can be tilted forward to help achieve a Control.

  • Page 9: Controls And Indicator Diagram

    CONTROLS AND INDICATOR DIAGRAM Control Function Descriptions for M1 and M2 Monitor M1 / M2 Panel Control DVD disc insertion slot (disc label towards driver) EJECT EJECT Button Power Indicator LED IR Sensor POWER Button SOURCE Button SCREEN MODE Button (Normal, Wide, Off) PLAY Button STOP Button 10.

  • Page 10: Dvd Headrest System Overview

    DVD HEADREST SYSTEM OVERVIEW 7. The M1 and M2 Monitor will accept an audio / video input through the AUX (use with supplied AV adaptor) input 1. The DVD Headrest system is a versatile audio / video located on the front of the unit. The audio / video device system which includes two monitors, each with a built- could be a video game system, video camera, or other in DVD player.

  • Page 11: Remote Control Operation

    REMOTE CONTROL OPERATION Lift for battery installation Battery Cover Battery Installation: Before attempting to operate your remote control, install the batteries as described below. 1. Turn the remote control face down. Using a fingernail, lift the battery cover off. 2. Install two “AAA” batteries. Make sure that proper polarity (+/-) is observed.

  • Page 12: Remote Control Functional Description

    REMOTE CONTROL FUNCTIONAL DESCRIPTION * Function control is available on the unit and remote control. 1. POWER Button* – Press this button to turn M1 or M2 Monitor ON. Press the button again to turn M1 or M2 Monitor OFF. 2.
  • Page 13 6a.Up ( )/Down ( ) Buttons – Use these buttons to scroll upward and downward, respectively, in menu options. 6b. LEFT ( )/Right ( ) Buttons – Use these buttons to shift left and right, respectively, in the menu options. 6c.
  • Page 14 12. SOURCE Button* – Press this button to select the available sources. On the M1 monitor, the sources are DVD, AV1, & AUX. On the M2 Monitor, the sources are DVD, AV1, & AUX. 13. SUBTITLE Button – Press to display and select the subtitle language in DVD mode.
  • Page 15 16. AUDIO Button – Press to display and select the AUDIO language in DVD mode. Each time you press the button, the language changes. NOTE: The languages for audio vary from disc to disc. – 17. DISPLAY Button – Press to display the current disc information while the disc is playing.
  • Page 16 19. PLAY ( ) Button* – Press to activate the play mode while a disc is loaded in the disc compartment. 20. SCAN FORWARD ( ) Button – Press to search in a forward direction. Press repeatedly to change the search speed from 2, 4, 8, 16 times the normal speed.

  • Page 17: Wireless Headphones Operation

    WIRELESS HEADPHONES OPERATION NOTE: The IR transmitter must be in the “ON” mode. See IR Transmitter “Remote Control Functional Description, The system includes built-in infrared transmitters for use with Item 18. Wireless Headphones. The master monitor (M1) IR transmitter uses CH A of the wireless headphones. An A-B switch allows NOTE: When storing the Wireless Headphones in the the user to select the audio from either the M1 Master (CH A) or seat back pocket or door pocket, pivot the ear pieces to...

  • Page 18: Operation Instructions

    OPERATION INSTRUCTIONS Control Button Functions (M1/M2 Unit) There are six (6) buttons on the M1 unit and M2 unit: 1. POWER Button – Press this button to turn the unit ON/OFF. 2. SOURCE Button – Press this button to select between DVD, AV1, and AUX.

  • Page 19: Dvd Basics

    DVD Basics Loading and Playing Discs To get the optimum use out of your DVD Headrest System, please read this section completely. To Load and Play a Disc Region Coding Press the Power button to turn the unit ON. Pivot the screen forward, select DVD mode and insert the disc (label towards Both the DVD player and DVDs are coded by region.

  • Page 20: Settings And Adjustments

    SETTINGS AND ADJUSTMENTS Exiting the Setup Menu Press the SETUP button to exit. The Setup Menu contains features and options that let you customize your DVD player. For example, you can set a language for the on- LANGUAGE SETUP screen display and limit playback of disc content for children. Using the Setup Menu Language for On-Screen Display 1.

  • Page 21: Subtitle Setup

    SUBTITLE SETUP AUDIO SETUP The SUBTITLE Menu allows the user to select the language of the The AUDIO Menu allows the user to select the language of the subtitles appearing on the DVD screen. audio contained on the DVD screen. NOTE: The type and number of languages for subtitles vary from NOTE: The type and number of languages for audio vary from disc to disc.

  • Page 22: Video Setup

    VIDEO SETUP TV Display TV Type The TV DISPLAY setup allows you to adjust screen setting (aspect he TV TYPE setup allows you to select the color system. ratio). Default setting is NTSC and should not be changed. 4:3 LB NTSC - Select this type for NTSC TV This displays the wide picture with black bands on the upper and lower portions of the screen.

  • Page 23: Rating Setup

    RATING SETUP 1. While in the Rating Setup, use the cursor button Rating 2. Press ENTER for the password prompt. This setting allows you to limit playback of certain discs depending 3. Using the numeric keys enter the password. on the disc rating. If the unit is set to a “G” rating, it will not play 4.

  • Page 24: Screen Saver

    2. Press ENTER to move the highlight to the different 4. Press the cursor button to return to the function options for the selected item. Press to select setup page. the desired options and then press ENTER to confirm the selection. Playing Audio CDs 1.

  • Page 25: Playing Mp3 Discs

    MP3 Format Playing MP3 Discs Use the Next ( l) button on the remote control to move to the MP3 is a format for storing digital audio. An audio CD song next song. Use the Previous (l ) button to move to the can be compressed into the MP3 format with very little loss of quality while taking up much less space.

  • Page 26: Program Play

    Program Play To use the program play option, you must create a play list of songs in the order you want them to play. NOTE: Once you begin adding songs from a folder to create your play list, you cannot add songs from a different folder. 1.

  • Page 27: Troubleshooting

    Troubleshooting SOLUTION PROBLEM IR Sensor Inoperative • Verify that the batteries in the remote are fresh. • Verify that the remote sensor eye is not obstructed. (DVD Player Won’t • Verify that monitor select M1 or monitor select M2 has been selected correctly on the Remote Control. Accept Commands (When monitor Select M1 is pressed on the Remote Control, the remote will only operate the M1 monitor.) From Remote...

  • Page 28: Fuse Replacement

    FUSE REPLACEMENT There is one (1) in-line fuse located inside the side front console kick panel (passenger’s side). If this fuse is blown, the DVD system cannot be turned on. The fuse can be easily replaced by prying the kick panel outward, disengaging the clips and removing the kick panel.

  • Page 29: Specifications

    SPECIFICATIONS Display Type TFT Active Matrix LCD Resolution 1440(W) x 234 (H) 480 (RGB) (W) x 234 (H) Pixels 336,960 Aspect Ratio 16:9 Back Light Edge Light Tube Backlight life 10,000 hours Power Source +12 VDC Power Consumption 35W For 2 Monitors + 2 DVD Operating Temperature -4°F ~ 149°F (-20°C ~ +65°C) Storage Temperature...

  • Page 30: Owner's Notes

    OWNER’S NOTES -23-...
  • Page 31 OWNER’S NOTES -24-...
  • Page 32 For Customer Service Call the Toll-Free Scion Customer Experience Center 1-866-707-2466 or Visit Our Website At www.scion.com PT900-52080-OM 128-7907A...
