Jensen JHD1510 Quick Reference Manual

JHD1510 Quick Reference Guide JHD1510 Quick Reference Guide
AUDIO MENU: With each press of the button
choose from the following AUDIO ADJUSTMENT
options: BASS, TREBLE, BALANCE (left to right),
and FADER (front to back). Use the rotary encoder
knob to adjust desired mode. Press and hold to
access the SYSTEM MENU.
MUTE: Press to MUTE audio.
MODE: With each press of the button the radio
will change through the following modes:
AM/FM, *SAT, *iPOD, and AUX.
PTY: Press to get program
list type. Use rotary encoder
knob to select. Press and hold
SEEK < or > to tune to selected SEEK < or > to tune to selected
program type station.
MUTE: Press to MUTE audio.
BAND: Press to select preset
group FM1, FM2, FM3, AM1,
or AM2 each with 6 channel
memory locations.
WB: Press and hold to
listen to WEATHERBAND.
PTY: Press and hold to
change channel lock code.
MUTE: Press to MUTE audio.
MODE: Press and hold
to enter CHANNEL
LOCK function.
Volume & Power On/Off: Push to turn
power ON or OFF. Turn to INCREASE
or DECREASE volume.
STATION STORE BUTTONS:
Press & hold to store current channel playing.
Momentarily press to recall stored channel.
NOTE: you can store up to 18 channels
(6 channels per band FM1, FM2, FM3, AM1, AM2).
BAND: Press to select STATION STORE BUTTONS:
preset group SR1, SR2, or Press & hold to store current channel playing.
SR3 each with 6 channel Momentarily press to recall stored channel.
NOTE: you can store up to 18 channels
memory locations.
(6 channels per band SIR1, SIR2, SIR3).
*Some features may not be available depending on installed factory options.
EQ/LOUD: Press to choose one of the
predefined bass and treble curves.
Press and hold to turn loudness ON/OFF.
DISP/SCROLL:
to change display info
between single and
dual line text display.
AUXILIARY INPUT: Insert
stereo connector from any
portable audio player.
TUNE: Press > to tune
UP in frequency. Press <
to tune DOWN in frequency.
Press and hold to fast search.
AS/PS: Press to SCAN
through currently stored
presets. Press & hold to
STORE strongest broad-
cast stations in your area.
TUNE/SEEK: Press >>
to tune UP in frequency.
Press << to tune DOWN in
frequency. Press and hold
to fast search.
S-MOD/ENTER: Press to
access CATEGORY MODE
and confirm selection. Press
TUNE/SEEK to change cat-
egory. Press again to select.
Press and hold to return to
channel tuning mode.
AS/PS: Press to scan
through currently stored
presets. Press and hold to
Press
access preset tuning mode.
