Web and MAC Authentication
Setup Procedure for Web/MAC Authentication
<html>
<head>
<title>EWA User Login</title>
<meta http-equiv="Content-Type" content="text/html; charset=iso-8859-1">
<meta http-equiv="refresh" content="5;URL=https://<!- ESI(WAUTHSSLSRVGET,1) ->/EWA/
index.html">
</head>
<body bgcolor="#FFFFFF" text="#000000">
<h1><font face="Verdana, Arial, Helvetica, sans-serif">EWA User Login </font></h1>
<p><font face="Verdana, Arial, Helvetica, sans-serif">In order to access this
network, you must first log in.</font></p>
<p><font face="Verdana, Arial, Helvetica, sans-serif">Redirecting in 5 seconds
to secure page for you to enter credentials or <a href="https://<!- ESI(WAUTHSSLSRVGET,1) ->
/EWA/index.html">click
here</a>.</font></p>
<p> </p>
</body>
</html>
3-26
Filename: sslredirect.html
The sslredirect file is the web page displayed when a client is redirected to an
SSL server to enter credentials for web authentication. If you have enabled
SSL on the switch, you can enable secure SSL-based web authentication by
entering the ssl-login parameter when you enable web authentication.
The WAUTHSSLSRVGET ESI inserts the URL that redirects a client to an SSL-
enabled port on an EWA server to verify the client's username and password.
Filename: reject_novlan.html
The reject_novlan file is the web page displayed after a client login fails and
no VLAN is configured for unauthorized clients.
The WAUTHQUIETTIMEGET ESI inserts the time period used to block an
unauthorized client from attempting another login. To specify the time period
before a new authentication request can be received by the switch, configure
a value for the quiet-period parameter (see page
).
3-37
