  • Page 1 7743693 11-2004 (Tab 6) USER & INSTALLATION INSTRUCTIONS User & installation User & installation Instructions Instructions QL Boat trim system QL Boat trim system User & installation User & installation Instructions Instructions QL Boat trim system QL Boat trim system User &...
  • Page 2 Óçìáíôéêü! Questo kit e le relative istruzioni di montaggio sono stati realizzati per le officine di servizio Volvo Penta, i cantieri, i fabbricanti di Ç ðáñôßäá áõôÞ ìáæß ìå ôéò ïäçãßåò ðïõ ôç óõíïäåýïõí, macchine e tutte le altre officine autorizzate il cui personale ha ðáñÜãåôáé...
  • Page 3: Table Of Contents

    CONTENT Presentation of the QL Boat Trim System ..............2 Sizing guidelines ......................3 Component guide......................4 Installation of the QL Boat Trim System ............... 5 System start up ......................8 Operating the system ....................9 Error codes ........................10...
  • Page 4: Presentation Of The Ql Boat Trim System

    Presentation of the QL Boat Trim System Fig. 2 41 mm (1.6”) The system comprises: A. Control Unit B. Control Panel C. Interceptor Units 35 mm (1.4”) D. Cable between Control Unit and Interceptor Unit 180 mm (7.1”) E. Cable between Control Unit and Control Panel...
  • Page 5: Sizing Guidelines

    Two lengts of the cable are available, i.e: * 2.5 m/8.2ft * 4 m/13.1ft Fig. 6 For installation of the components, see chapter Installation of the QL Boat Trim System.
  • Page 7: Installation Of The Ql Boat Trim System

    Installation of the QL Boat Trim System The template , see fig 10, is equipped with pilot holes for marking on the transom. Place the template on the Note! Before starting the installation of your QL Boat transom considering the guidelines as specified above.
  • Page 8 Locate the lower edge of the template flush to the boat If the transom thickness makes it impossible to reach th- bottom, however no part of the template must overlap the rough with the hole cutter, a hole connection from inside transom profile.
  • Page 9 The interceptor unit is equipped with an integrated gas- Note! Different boats may have different transom cons- ket, part of the front cover, which seals towards the tran- tructions, and in case the transom material being used, som surface, thus avoiding water spray between the in- is specially sensitive to water and moisture intrusion, it’s terceptor unit and the transom.
  • Page 10: System Start Up

    The control unit shall be firmly fixed on a dry and easily Note! For Volvo Penta EVC EC engines, the red cable accessible location, e.g. inside of transom. Screws are must not be connected directly to the start key, but ins- not included.
  • Page 11: Operating The System

    This is the confirmation that the calibration is correctly done. If the calibration was not successful, an error code will pop up. If starboard interceptor was not successfully calibrated, the right LEDs, No 6 and 7 will flash. If port interceptor was not successfully calibrated, the left LEDs, No 6 and 7 will flash (see also under the headline Error codes).
  • Page 12: Error Codes

    Error codes - EC 5; Flashing: LED number 6 and 7 on starboard side are flashing. Error: Indicates that the interceptor To help troubleshooting a system that is malfunctioning, blade(s) on starboard side are stuck and can not reach there are some Error Codes (EC) implemented. If an EC the correct position.
  • Page 13 Volvo Penta EVC MC and other mechanical engines 6-8 A 3-8 A Fig. 23...
  • Page 14 Volvo Penta EVC EC (electronical engines) 6-8 A 3-8 A Fig. 24...
  • Page 15 Hole template for control panel Scale 1:1 CE APPROVAL The QL Boat Trim System complies with the requirements in the following CE standards: Electromagnetic compatibility directive 89/336/EEC with addition 91/263/EEC Directive 92/31/EEC Directive 93/68/EEC AB Volvo Penta SE-405 08 Göteborg, Sweden...
