Satellite/Cable TV Set-Top Box Connections / Watching Cable TV DVD Connections / Playing the DVD PC Connections / How to use as PC Exteral Audio Amplifier / Digital Amplifier Connenction JENSEN DVD Connections for IR Basic Use Powering the LCD TV / Selecting input source Application... -
Page 6: Names Of Each Part(Front View) / Accessories
Names of each part Accessories SOUDRCE MENU VOL+ VOL- POWER POWER RETURN MUTE MENU INFO ENTER SOURCE EXIT • • • • EJECT ANGLE PROG • AS PS • MTS SAP • SCALE SLEEP ZOOM SUB T DISP • C LIST •... - Page 7 AC input AUDIO(R/L) OUT POWER ON/OFF switch PC and AUDIO jack IR jack Y,Pb,Pr 2 and AUDIO(R/L) jack HDMI2 jack Y,Pb,Pr 1 and AUDIO(R/L) jack HDMI1 jack AV2 IN ( VIDEO and AUDIO) Names of each part ATSC NTSC AV1 IN (VIDEO and AUDIO) SPDIF S-VIDEO (ATSC/NTSC)
-
Page 8: Mounting On A Desktop / Installation Precautions
Mounting on a Desktop Installation Precautions Wall Mounting Using the Stand... -
Page 9: Installing An Antenna
Installing an Antenna ATSC NTSC... -
Page 10: Remote Control
Remote Control POWER On / off for TV and DVD RETURN Return to previously viewed channel CH+/CH- Increase or Decrease channel MENU Displays the OSD menu on the screen NAVIGATION Move up,down,left or right SOURCE Displays AV Inputs Displays the program guide ANGLE(DVD) Change view angle FAST REVERSE(DVD) -
Page 11: Remote Control
RIGHT RIGHT ENTER ENTER SOURCE SOURCE SOURCE EXIT E IT NOTE DVD functions are intended for JENSEN DVD players only See your JENSEN DVD manual for more information Remote Control TV-FUNCTION DVD-FUNCTION TV-FUNCTION DVD-FUNCTION BUTTON ANGLE PROG MTS SAP MTS-SAP... -
Page 12: Precautions / How To Use Remote Control
Precautions are good . has AC Power. • • • • • •... -
Page 13: Vcr Connections / Watching Video Tape
Terminals vary by manufacturer Connect the LCD TV S Composite In terminal to VCR s Composite OUT terminal using the included Composite cable SOURCE 3 Press to confirm the source selection ENTER 4 Turn on the VCR insert the tape and press play button VCR Connections ATSC NTSC (Included) -
Page 14: Satellite/Cable Tv Set-Top Box Connections / Watching Cable Tv
Satellite/Cable TV Set-TOP Box Connections Terminals vary by manufacturer Watching Cable TV 3 Press to confirm ENTER SOURCE the source selection ATSC NTSC Composite Cable (Included) ATSC NTSC (Not Included) ATSC NTSC • (Not Included) -
Page 15: Dvd Connections / Playing The Dvd
Terminals vary by manufacturer 1.Connect LCD TV’s YPbPr1 or YPbPr2 terminal to DVD’s Video Out terminal . 2.Connect LCD TV’s Audio terminals in YPbPr1 or YPbPr2 to DVD’s Audio Out terminal. SOURCE 1 or YPbPr2”. 3. Press to confirm the source selection. ENTER DVD Connections ATSC NTSC... -
Page 16: Pc Connections / How To Use As Pc
PC Connections Terminals vary by manufacturer ATSC NTSC (Not Included) (Not Included) a VGA a 3 5mm (Headphone) audio cable How to use as PC monitor SOURCE 3 Press to confirm the source selection ENTER... -
Page 17: Exteral Audio Amplifier / Digital Amplifier Connenction
ATSC NTSC ATSC NTSC ... -
Page 18: Jensen Dvd Connections For Ir
All JENSEN Remote Control DVD Functions can be controlled Via the TV IR receiver. You do not need to point the remote conrol at the JENSEN DVD player when this option is used. NOTE: DVD IR control is intended for JENSEN DVD players only. -
Page 19: Powering The Lcd Tv / Selecting Input Source
INPUT SOURCE INPUT SOURCE S Vid p n nt1 p n nt2 HDMI1 HDMI2... -
Page 20: Menu Operation
Menu Operation Use the LEFT and RIGHT buttons to select your main menu option S tup Pictur S und L ck Chann Pictur Standard C ntrast ri htn ss Tint Sharpn ss r M d N r a E it MENU TIMER MENU Allows you to set up a variety of time options... -
Page 21: Customizing The Picture Settings
Picture Sound Picture Mode • Contrast Brightness Color • Tint Sharpness Color Mode • Select Picture Mode Cycles through picture display modes: Standard, Dynamic, Soft, Personal. Contrast Controls the difference between the brightest and darkest regions of the picture. Brightness Controls the overall brightness of the picture Color Controls the color. -
Page 22: Customizing The Sound Settings
Pictur S und M d Tr b a anc SPDIF T p Audi Sound Mode Cycles through sound modes Standard Music Movie Sports and Personal Bass Controls the relative intensity of lower pitched sounds Treble Controls the relative intensity of higher pitched sounds Balance To ad ust the balance of the left and right sound track or turn off the volume of the left and right sound track... -
Page 23: Customizing The Timer Settings
Select TV source for example. (Press SOURCE button to select TV mode) Press the POWER button to turn the LCD TV on. Press the MENU button on the remote control to display the Main menu, and use the UP and DOWN buttons to select the TIMER. -
Page 24: Customizing The Setup Settings
Customizing the SETUP Settings Select TV source for example (Press SOURCE button to select TV mode) Press the POWER button to turn the LCD TV on Press the MENU button on the remote control to display the Main menu and use the LEFT or RIGHT button to select the SETUP Use the UP and DOWN buttons to highlight an individual SETUP option use the LEFT and RIGHT buttons to change the setting and press the MENU or E IT button to exit... - Page 25 Close Caption Use Down button to highlight “Close Caption” , then press RIGHT button or ENTER to enter into the following menu. Picture Sound Timer CC Mode • Basic Selection • Advanced Selection • Option Select CC Mode Basic Selection Advanced Selection Allows you to select the advanced services: Option Audio Only...
-
Page 26: Customizing The Lock Settings
Customizing the LOCK Settings Select TV source for example (Press SOURCE button to select TV mode) Press the POWER button to turn the LCD TV on Press the MENU button on the remote control to display the Main menu and use the LEFT and RIGHT buttons to select the LOCK Use the DOWN button to highlight Enter Password After that the screen will display the next menu After setting press menu or exit button to exit... - Page 27 Application Customizing the LOCK Settings Use Down button to highlight “US” , then press RIGHT or ENTER button to enter into the following menu. Picture Sound Timer MPAA Move Use Down button to highlight “TV” , then press RIGHT or ENTER button to enter into the following menu. Use UP and DOWN buttons to select the ENTER button to block or unblock rating.
- Page 28 Customizing the LOCK Settings Canada button to enter into the following menu. (French) RRT Setting Reset RRT Application Use Down button to highlight “Canada” , then press RIGHTor ENTER S tup Pictur S und L ck Chann Canada En • Canada Fr •...
-
Page 29: Customizing The Channel Settings
Select TV source for example (Press SOURCE button to select TV mode) Press the POWER button to turn the LCD TV on Press the MENU button on the remote control to display the Main menu and use the LEFT and RIGHT buttons to select the CHANNEL Use the UP and DOWN buttons to highlight an individual CHANNEL option use the LEFT and RIGHT buttons to change the setting and press the MENU or E IT button to exit... -
Page 30: Customizing The Channel Settings
Customizing the CHANNEL Settings Favorite Show / Hide Channel No. Channel Label DTV Signal Application If you select “Cable” as input signal in Antenna then you can select Cable Systems: Auto, STD, IRC and HRC. Use DOWN button to highlight “Start to Scan”, then press RIGHT or ENTER buttonto search the channels automatically. -
Page 31: Maintenance And Service
Maintenance and Service In case a problem occurs with your LCD TV please take the following steps first If you still have the problem turn the power off and contact your dealer or an authorized service center Problem The screen does not appear The screen appears too slowly after the power is turned on Screen is too bright or too dark... -
Page 32: Specifications
Maintenance and Service Specifications LCD Panel Panel Size Brightness Contrast Ratio Viewing Angle Max. Resolution INPUT VIDEO S-VIDEO YPbPr(Component) AUDIO (L/R) PC/AUDIO(L/R) HDMI OUTPUT AUDIO (L/R) SPDIF Power Source Power Consumption Dimension Weight (G.W.) The cabinet design and electronics specifications will be modified without prior notice for performance improvement. - Page 33 LCD Wall Mount Bracket Assembly Instructions 1. Lay the TV down with the rear facing up on a non-abrasive surface. Remove the four screws (M5 x 20) shown in Figure A. 3.Attach wall bracket (not supplied) with the four(M5 x 20)screws,using either the 100 x100 or 200 x 400 mount pattern shown in picture B.
- Page 34 LCD STAND Assembly Instructions 1. Remove the six screws (M4 x 10) shown in picture C with a Phillips screwdriver. Remove the stand cover from the TV shown in picture D. 3. Insert the stand into the TV cabinet as shown in picture E. 4.
- Page 35 www asaelectronics com...
