JE2611
26"LCD TV User's Guide
Please observe all safety precautions when using this product.
Please read this manual careful
Guide de l'utilisateur du téléviseur LCD de 26''
Veuillez observer toutes les mesures de sécurité en utilisant ce produit.
Veuillez lire soigneusement ce manuel avant d'utiliser ce produit.
Advertisement
Table of Contents
Related Manuals for Jensen JE2611
Summary of Contents for Jensen JE2611
- Page 1 JE2611 26”LCD TV User’s Guide Please observe all safety precautions when using this product. Please read this manual careful Guide de l’utilisateur du téléviseur LCD de 26’’ Veuillez observer toutes les mesures de sécurité en utilisant ce produit. Veuillez lire soigneusement ce manuel avant d’utiliser ce produit.
-
Page 2: Table Of Contents
VCR Connections / Watching Video Tape ............Satellite/Cable TV Set-Top Box Connections / Watching Cable TV ........External Audio Amplifier / SERVICE USB Connections ..........JENSEN DVD Connections for IR ............... Basic Use Powering the LCD TV / Selecting input source ............Application Menu Operating ................ -
Page 6: Names Of Each Part(Front View) / Accessories
Names of each part MENU Button-OSD Menu Display Button VOL- / VOL+ Button CH- / CH+ Button SOURCE Button POWER Button Accessories POWER RETURN MUTE MENU INFO ENTER SOURCE EXIT • • • • EJECT ANGLE PROG • AS PS •... -
Page 7: Names Of Each Part(Back View)
Names of each part Back View POWER ON/OFF switch HDMI1 jack AV2 IN ( VIDEO and AUDIO) AC input HDMI2 jack AUDIO(L/R) OUT SERVICE jack AV1 IN (VIDEO and AUDIO) IR jack (ATSC/NTSC) -
Page 8: Mounting On A Desktop / Installation Precautions
Mounting on a Desktop Installation Precautions Wall Mounting ensure Using the Stand... -
Page 9: Installing An Antenna
Installing an Antenna... -
Page 10: Remote Control
Remote Control MODE LED The LED will fiash RED for TV mode, and BLUE for DVD mode. Activate TV Mode POWER POWER On / off for TV and DVD Activate DVD Mode RETURN Return to previously viewed channel MUTE Press once mutes audio,press again to CH+/CH- restore audio RETURN... - Page 11 C LIST C-LIST SETUP SETUP ENTER F-LIST AUDIO F LIST ENTER AUDIO SOURCE SOURCE SOURCE SOUND SOUND EXIT EXIT PICTURE PICTURE TITLE NOTE: DVD functions are intended for JENSEN DVD players only. See your JENSEN DVD manual for more information.
-
Page 12: Precautions / How To Use Remote Control
Precautions are good . has AC Power. How to use remote control... -
Page 13: Vcr Connections / Watching Video Tape
VCR Connections Terminals vary by manufacturer (Included) Connect the LCD TV’S Composite In terminal to VCR’s Composite OUT terminal using the included Composite cable. Watching Video Tape SOURCE 3.Press to confirm the source selection or stop operation a few seconds, ENTER will automatically enter the selection mode. -
Page 14: Satellite/Cable Tv Set-Top Box Connections / Watching Cable Tv
Satellite/Cable TV Set-TOP Box Connections Terminals vary by manufacturer Composite Cable (Included) (Not Included) Watching Cable TV SOURCE 3. Press to confirm the source selection or stop operation a few seconds, ENTER will automatically enter the selection mode. -
Page 15: External Audio Amplifier / Service Usb Connections
Connection External Audio Amplifier Connecting to an amplifer or home theater system. Terminals vary by manufacturer. (Not Included) audio output level. SERVICE USB Connections Connection to SERVICE USB. NOTE: This USB connection is for software upgrades only. Does not support any other USB function. -
Page 16: Jensen Dvd Connections For Ir
All JENSEN Remote Control DVD Functions can be controlled Via the TV IR receiver. You do not need to point the remote conrol at the JENSEN DVD player when this option is used. NOTE: DVD IR control is intended for JENSEN DVD players only. -
Page 17: Powering The Lcd Tv / Selecting Input Source
Powering the LCD TV Selecting Input Source INPUT SOURCE INPUT SOURCE HDMI1 HDMI2 Note: stop operation a few seconds, After you selected the desired input sorce, if then will automatically enter the selection mode. -
Page 18: Menu Operating
Menu Operation Use the LEFT and RIGHT buttons to select your main menu option. Audio Allows you to customize the sound options and effects. Audio Audio Setup Setup Picture Timer Lock Channel Picture Timer Lock Channel Standard Standard Picture Mode Sound Mode Contrast Bass... -
Page 19: Customizing The Picture Settings
Customizing the PICTURE Settings or EXIT button to exit. Audio Setup Picture Timer Lock Channel Standard Picture Mode Contrast Brightness Color Tint Sharpness Color Mode Normal HDMI CEC Select Move Exit MENU Picture Mode Cycles through picture display modes: Standard, Dynamic, Soft, Personal. Contrast Controls the difference between the brightest and darkest regions of the picture. -
Page 20: Customizing The Audio Settings
Customizing the Audio Settings Audio Audio or EXIT button to exit Audio Setup Picture Timer Lock Channel Standard Sound Mode Bass Treble Balance TV Speaker Audio Language English Select Move Exit MENU Sound Mode Cycles through sound modes: Standard, Music, Movie and Personal. Bass Controls the relative intensity of lower pitched sounds. -
Page 21: Customizing The Timer Settings
Application Customizing the TIMER Settings Select TV source for example. (Press SOURCE button to select TV mode) Press the POWER button to turn the LCD TV on. Press the MENU button on the remote control to display the Main menu, and use the LEFT and RIGHT buttons to select the TIMER. -
Page 22: Customizing The Setup Settings
Application Customizing the SETUP Settings Select TV source for example. (Press SOURCE button to select TV mode) Press the POWER button to turn the LCD TV on. Press the MENU button on the remote control to display the Main menu, and use the LEFT or RIGHT button to select the SETUP. -
Page 23: Customizing The Setup Settings
Application Customizing the SETUP Settings Close Caption Use Down button to highlight “Close Caption” , then press RIGHT button or ENTER to enter into the following menu. Audio Setup Picture Timer Lock Channel CC Mode Basic Selection Advanced Selection Service1 Option Move Select... -
Page 24: Customizing The Lock Settings
Application Customizing the LOCK Settings Select TV source for example. (Press SOURCE button to select TV mode) Press the POWER button to turn the LCD TV on Press the MENU button on the remote control to display the Main menu, and use the LEFT and RIGHT buttons to select the LOCK Use the DOWN button to highlight “Enter Password”... - Page 25 Application Customizing the LOCK Settings Use Down button to highlight “US” , then press RIGHT or ENTER button to enter into the following menu. Audio Setup Picture Timer Lock Channel MPAA NEXT Move MENU Exit Use Down button to highlight “TV” , then press RIGHT or ENTER button to enter into the following menu.
- Page 26 Application Customizing the LOCK Settings Canada Use Down button to highlight “Canada” , then press RIGHTor ENTER button to enter into the following menu. Audio Setup Picture Timer Lock Channel Canada English Canada French Move Select Exit MENU Canada English Use LEFT and RIGHT buttons to select among: E, C, C8+, G, PG, 14+ and 18+ Canada French...
-
Page 27: Customizing The Channel Settings
Application Customizing the CHANNEL Settings Select TV source for example. (Press SOURCE button to select TV mode) Press the POWER button to turn the LCD TV on. Press the MENU button on the remote control to display the Main menu, and use the LEFT and RIGHT buttons to select the CHANNEL. -
Page 28: Customizing The Channel Settings
Application Customizing the CHANNEL Settings If you select “Cable” as input signal in Antenna then you can select Cable Systems: Auto, STD, IRC and HRC. Use DOWN button to highlight “Start to Scan”, then press RIGHT or ENTER buttonto search the channels automatically. The receivable channels will be stored automatically. -
Page 29: Maintenance And Service
Maintenance and Service Trouble shooting In case a problem occurs with your LCD TV, please take the following steps first. If you still have the problem, turn the power off and contact your dealer or an authorized service center. Problem Action Is the power plug connected? Insert the power plug. -
Page 30: Specifications
Maintenance and Service Specifications 26” TFT LCD LCD Panel Panel Size Brightness 3000:1 Contrast Ratio 178º/178º Viewing Angle Max. Resolution 1366 x 768 VIDEO INPUT AUDIO (L/R) HDMI OUTPUT AUDIO (L/R) Power Source AC 100-240V, 50/60HZ Power Consumption Dimension 662 W x 451 H x 105D mm Weight (G.W.) 10Kg The cabinet design and electronics specifications will be modified without prior notice for...
