Repair Clinic ASD2626HE Parts
Service
This manual is to be used by qualified appliance
technicians only. Maytag does not assume any
responsibility for property damage or personal
injury for improper service procedures done by
an unqualified person.
Side-by-Side
Refrigerators
This Base Manual covers general information
Refer to individual Technical Sheet
for information on specific models
This manual includes, but is
not limited to the following:
Jenn-Air
JCB2280HE*
JCB2282HT*
JCB2282KT*
JCD2292HT*
JCD2292KT*
JCD2295KE*
JSD2695KE*
Amana
ACD2234HR*
ACD2238HT*
ASD2324HR*
ASD2326HR*
ASD2328HR*
ASB2623HR*
ASD2622HR*
ASD2624HE*
ASD2626HE*
ASD262RHR*
Maytag
MSD2351HE*
MSD2355HE*
MSD2357HE*
MSD2359KE*
MSD2655HE*
MSD2657HE*
MSD2659KE*
MZD2665HE*
MZD2669KE*
PSD263LHR*
PSD266LHE*
PSD267LHE*
16025628
Replaces 16022689
February 2005
Advertisement
Chapters
Table of Contents
Troubleshooting
Related Manuals for Maytag ACD2234HR*ACD2238HT Series
Summary of Contents for Maytag ACD2234HR*ACD2238HT Series
- Page 1 Refer to individual Technical Sheet an unqualified person. for information on specific models This manual includes, but is not limited to the following: Amana ACD2234HR* ACD2238HT* ASD2324HR* ASD2326HR* Side-by-Side ASD2328HR*...
-
Page 2: Important Information
Telephone Number WWW.AMANA.COM ..........1-800-843-0304 WWW.JENNAIR.COM ..........1-800-536-6247 WWW.MAYTAG.COM ..........1-800-688-9900 CAIR Center in Canada .......... 1-800-688-2002 Amana Canada Product .......... 1-866-587-2002 Recognize Safety Symbols, Words, and Labels DANGER DANGER—Immediate hazards which WILL result in severe personal injury or death. WARNING WARNING—Hazards or unsafe practices which COULD result in severe personal injury or death. -
Page 3: Table Of Contents
Table of Contents Important Information ............ 2 Freezer Thermistor ..........32 Product Design ............. 4 Evaporator Removal ..........32 Component Testing ............5 Defrost Terminator (Thermostat) ......33 Service Procedures ............11 Defrost Heater ............33 Service Equipment ............ 11 Ice Maker Removal (some models) ...... -
Page 4: Product Design
Product Design WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Refrigeration System Mechanical Defrost System Compressor forces high temperature vapor into fan... -
Page 5: Component Testing
Component Testing WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Component Description Test Procedures... - Page 6 Component Testing WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Component Description Test Procedures...
- Page 7 Component Testing WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Component Description Test Procedures...
- Page 8 NOTE: Drier used in R12 sealed system is not interchangeable with drier used in R134a sealed system. Always replace drier in R134a Desiccant (20) 8 x 12 4AXH - 7 M>S> - system with Amana part number B2150504. Grams Before opening refrigeration system, recover HFC134a refrigerant for safe disposal.
- Page 9 Component Testing WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Description Test Procedures Water valve...
- Page 10 Component Testing WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Electric damper Damper control balances the air delivery Check resistance across terminals.
-
Page 11: Service Procedures
Service Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a 10,000 ohm resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Service Equipment Drier Replacement Listed below is equipment needed for proper servicing... -
Page 12: Refrigerant Precautions
Service Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a 10,000 ohm resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Refrigerant Precautions To AC supply WARNING... -
Page 13: Dehydrating Sealed Refrigeration System
Service Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a 10,000 ohm resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Testing Systems Containing No Refrigerant Charge Dehydrating Sealed Refrigeration System 1. -
Page 14: Restrictions
Service Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a 10,000 ohm resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. 3. -
Page 15: Evacuation And Charging
Service Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a 10,000 ohm resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Evacuation and Charging High Side Gauge Low Side Gauge... -
Page 16: Charging
Service Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a 10,000 ohm resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Charging Refrigerant Charge NOTE: Do not use captured or recycled refrigerant in... -
Page 17: Hfc134A Service Information
Service Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a 10,000 ohm resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. HFC134a Service Information CAUTION HFC134a is alternative refrigerant for CFC12. -
Page 18: Replacement Service Compressor
Service Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a 10,000 ohm resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Replacement Service Compressor Brazing HFC134a service compressors will be charged with... -
Page 19: Refrigerant Flow 22, 23, 26 Cu. Ft
Refrigerant Flow SUCTION LINE CAPILLARY TUBE EVAPORATOR OUTLET FLANGE LOOP EVAPORATOR PROCESS TUBE COMPRESSOR EVAPORATOR PROCESS TUBE INLET HIGH SIDE DRIER CONDENSER COMPRESSOR DISCHARGE LINE 22, 23, 26 cu. ft. Side by Side Refrigerant Flow Diagram 16025628 ©2005 Maytag Services... -
Page 20: Cabinet Air Flow 22, 23, 26 Cu. Ft
Cabinet Air Flow SIDE BY SIDE AIRFLOW DIAGRAM REFRIGERATOR AIR SUPPLY TUNNEL FREEZER BACK TO FRESH FOOD (AIR BAFFLE) COMPARTMENT CONTROLS EVAPORATOR FAN ASSEMBLY AIR SUPPLY (IN FOAM) LARGE BEVERAGE CHILLER AIR SUPPLY (SOME MODELS) EVAPORATOR SMALL BEVERAGE CHILLER REFRIGERATOR AIR AIR SUPPLY RETURN TUNNEL (SOME MODELS) -
Page 21: Ice And Water Flow Diagram
Ice and Water Dispenser Diagram WATER FILTER INLET WATER FILTER OUTLET ICEMAKER ICE &WATER DISPENSER WATER TANK DETAIL 5/16” x 5/16” PUSH CONNECTOR UNION WATER LINE IS ROUTED IN A CONDUIT UNDER THE FLOOR OF UNIT 22, 23, 26 cu. ft. Model Side by Side Ice and Water Flow Diagram 16025628 ©2005 Maytag Services... -
Page 22: Water Valve Diagram
Water Valve Diagram WATER FILTER OUTLET SOLENOID VALVE WATER SUPPLY HOOKUP WATER TANK INLET 5/16” WATER FILTER INLET DETAIL ICE MAKER INLET 1/4” 22, 23, 26 cu. ft. Model Side by Side Ice and Water Flow Diagram 16025628 ©2005 Maytag Services... -
Page 23: Typical External Sweat Pattern
Typical External Sweat Pattern Classification of condensation: 1 = Haze or Fog 2 = Beading 3 = Beads or Small Drops 4 = Drops Running Together 16025628 ©2005 Maytag Services... -
Page 24: Troubleshooting Chart
Troubleshooting Chart WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Troubleshooting chart on following pages contains symptoms that may be seen in malfunctioning units. - Page 25 Troubleshooting Chart WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Symptom Possible Causes Corrective Action...
- Page 26 Troubleshooting Chart WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Symptom Possible Causes Corrective Action...
-
Page 27: System Diagnosis
System Diagnosis SUCTION HEAD T1 INLET T2 OUTLET T3 SUCTION WATTAGE PRESSURE PRESSURE TEMPERATURE TEMPERATURE TEMPERATURE VARIATION CONDITION VARIATION VARIATION VARIATION VARIATION VARIATION FROM FROM FROM FROM NORMAL FROM NORMAL FROM NORMAL NORMAL NORMAL NORMAL Refrigerant Increase Increase Warmer Warmer Colder Increase Overcharge... - Page 28 System Diagnosis the high side (condenser) of the system. To diagnose for a restriction versus a refrigerant shortage, discharge the system, replace the drier-filter, • Only partial frosting of evaporator instead of even evacuate and recharge with the specified refrigerant frosting of entire coil.
- Page 29 System Diagnosis Symptoms of Low or High Ambient Temperature Installation Lower ambient air temperature reduces the condensing temperature and therefore reduces the temperature of the liquid entering the evaporator. The increase in refrigeration effect due to operation in a lower ambient results in a decrease in power consumption and run time.
-
Page 30: Disassembly Procedures
Disassembly Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Refrigerator Compartment Mid Level Electronic Control (some models) 1. -
Page 31: Adaptive Defrost Control (Adc) (Some Models)
Disassembly Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Adaptive Defrost Control (ADC) (some models) Water Filter Assembly (some models) 1. -
Page 32: Auger Motor Assembly (Some Models)
Disassembly Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Auger Motor Assembly (some models) Evaporator Fan Motor and Fan Blade 1. -
Page 33: Defrost Terminator (Thermostat)
Disassembly Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Defrost Terminator (Thermostat) Machine Compartment 1. -
Page 34: Condensate Drain Tube
Disassembly Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Condenser Removal 6. -
Page 35: Cabinet Doors
Disassembly Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test procedures require power to be connected. Discharge capacitor through a resistor before attempting to service. Ensure all ground wires are connected before certifying unit as repaired and/or operational. Cabinet Doors Dispenser D/C Solenoid (some models) 1. -
Page 36: Ice 'N Water Systems
Ice ‘N Water Systems Troubleshooting of 5 button electronic Ice ‘N Water dispenser Dispenser Operation Select mode by pushing the button on the dispenser panel. A green indicator light WATER CRUSHED CUBED above the button indicates the current selection. Selection mode cannot be changed from CRUSHED CUBED from... - Page 37 Ice ‘N Water Systems Table A: Harness 10-pin Connector Configuration Color Signal Ice Door Chute Solenoid Dispenser Light Crushed Cubed Line Out Main Actuator Water Valve Line In Neutral Note: All voltage measurements are referenced to line neutral or pin 10 (WH wire) of 10-pin connector. Symptom Possible Cause Test Procedure...
- Page 38 Ice ‘N Water Systems Symptom Possible Test Procedure Repair Cause Cubed LED is illuminated Failed Main Disconnect power. Remove both leads from the Replace switch. but does not dispense dispenser switch and measure resistance across switch terminals. Resistance should read less than 1 Ω in cubed ice when Main switch (failed dispenser switch is...
- Page 39 10.0 New filter installed Amana specifies a minimum supply pressure of 35 psig for water filter units. Minimum pressure requirement ensures that water valves close and sufficient water volume is available to fill icemaker. Proper fill is 140 cc. of water in 7.5 seconds. Failure of water valves to close because of low pressure will result in fill-tube freeze-up or dripping at cavity.
-
Page 40: Troubleshooting Of 3 Button Electronic Ice 'N Water Dispenser
Ice ‘N Water Systems Troubleshooting of 3 button electronic Ice ‘N Water dispenser Dispenser Operation Select mode by pushing the button on the dispenser panel. A green WATER CRUSHED CUBED indicator light above the button indicates the current selection. Dispenser Light Light activates at full power when dispensing ice or water. - Page 41 Ice ‘N Water Systems Symptom Possible Test Procedure Repair Cause No LED lit Switch failure in With unit powered, open freezer door. Press Replace switch. freezer door. freezer door switch in. If freezer light does not turn off, switch is defective. Incorrect Verify wire color on 9-pin connector.
- Page 42 Ice ‘N Water Systems Symptom Possible Test Procedure Repair Cause Crushed ice Failed Disconnect power. Remove both leads from the Replace switch starts to dispense dispenser switch and measure resistance across switch terminals. Resistance should read less than 1 Ω as soon as switch (failed Crushed mode is...
- Page 53 Appendix A A - 1...
- Page 54 Side-by-Side Use & Care Guide Table of Contents Important Safety Instructions ..1-2 Water Filter......... 20-22 Installation ........3-9 Food Storage Tips ..... 23-25 Temperature Controls....10-12 Care and Cleaning....26-29 Fresh Food Features ....13-15 Operating Sounds ......30 Freezer Features ......
-
