TROUBLESHOOTING

1 . UNABLE TO CONNECT/PAIR WITH BLUETOOTH
a . Confirm that your phone, tablet, or device is compatible with Bluetooth
user guide of the device you are trying to connect.
b . Make sure the 3.5mm audio cable is NOT plugged into TRANSIT. (NOTE: when the 3.5mm jack is plugged in,
Bluetooth is automatically turned off.)
®
c . Follow the connection instructions in the 'SETUP' section of this User Guide.
d . Switch TRANSIT 'OFF' and back 'ON', and confirm the power LED light is lit white or purple. If the light is red or
does not come on, plug TRANSIT in to charge the battery.
e . Make sure the volume on the TRANSIT is turned up by pressing the '
quickly.
2 . AUDIO IS DROPPING OUT .
a . Move TRANSIT closer to the connected Bluetooth
b . Make sure TRANSIT is charged, or plugged in and charging. The LED should be white, or if plugged in and charg-
ing, it should be purple.
3 . AUDIO IS DISTORTED .
a . Lower the volume on TRANSIT by pressing the '
b . The best audio clarity will be achieved using the provided 3.5mm audio input cable.
c . Make sure the TRANSIT Momentum Port™ is not blocked or obstructed.
d . Switch the TRANSIT speaker OFF and back ON.
e . Play a variety of tracks to confirm that the content is not corrupted or low (bit-rate) quality.
4 . TRANSIT WILL NOT PLAYBACK USING 3 .5MM AUDIO INPUT .
a . Make sure the volume level is turned up on TRANSIT by pressing the '
quickly.
b . Confirm audio is playing on your source device, and that the volume is turned up on the source device.
c . Make sure the 3.5mm audio jack is plugged in FULLY to both the TRANSIT speaker and the source device.
d . Confirm that there is no damage to the audio cable.
e . Make sure TRANSIT is turned ON and the power light is ON and white or purple.
f . Make sure TRANSIT is charged or plugged in and charging.
STATIC DISCHARGE: TRANSIT is designed to withstand normal static discharges, but in the event of a significant static discharge
®
TRANSIT may lose Bluetooth connection or cause the LED light to momentarily change color or turn off. To correct, simply turn the
power switch 'OFF' and back 'ON'.

TECHNICAL SPECIFICATIONS

ƒ Bluetooth v2.1+EDR compliant. Profiles: A2DP (wireless stereo Bluetooth
®
ƒ Bluetooth wireless range: 33ft (10m)
®
ƒ Size: 3.8in (96.8mm) wide, 6.6in (169mm) long x 1.3in (33.25mm) thin
ƒ Weight: 1.1 lb. (0.5kg)
ƒ Battery: Long-Life Lithium Ion
ƒ Battery playtime: Between 4 to 8hrs (based on volume level and playback content)
ƒ Wall Charger: 5VDC 1A
ƒ Micro USB port for charging.
ƒ Temperature range for use: 130°F (45°C) - 32°F (0°C)
BLUETOOTH INFO
®
ƒ The typical range for Bluetooth
ƒ TRANSIT can pair with up to 8 devices, but can only playback from one device at a time.
DEVICE .
®
device.
®
-
' button.
is up to 33ft (10m).
®
version 2.0 or above by checking the
®
+
' button until you see the LED flash
+
' button until you see the LED flash
), HFP
®
5
