Summary of Contents for Jabra LINK 850

  • Page 2: Table Of Contents

    ..............9 cONNect aN addItIONaL headset (Guest headset) ........10 cONNect a busy-LIGht INdIcatOr ..................10 mOuNt the Jabra LINK 850 tO the desK ..............10 advanCed settinGs ............... 11 remOvING the remOvabLe cOver ..................11 NOIse at wOrK swItch .......................11 vOIce cLarIty swItch .........................12...

  • Page 3: Product Overview

    Handset port telephone port Usb port Guest headset port mounting bracket microphone volume control Clear dial tone switch voice clarity switch target phone switch noise at work switch Qd port removable cover Jabra link™ 850 User manUal...

  • Page 4: Optional Accessories

    OptIONaL accessOrIes the following Jabra link 850 accessories are available separately: busy-light indicator aC power adapter mute buttton for supervisor cable Jabra link™ 850 User manUal...

  • Page 5: Connecting The Jabra Link 850

    Connection to a PC is necessary to power the Jabra link 850. to connect to power, plug the Usb cable into the Usb port on the Jabra link 850, and connect the other end of the Usb cable into any available Usb port on your PC. the mute indicator will flash red three times to indicate the Jabra link 850 is now connected to power.

  • Page 6: Connect To A Pc (Softphone)

    2. ensure the telephone cable is plugged into the telephone port on the Jabra link 850, and then connect the other end of the telephone cable into the handset port on the desk phone. the Jabra link 850 is now con- nected to the desk phone.

  • Page 7: Connect To A Headset

    Connect a headset to the Qd cable, and plug the Qd cable into the Qd port on the Jabra link 850 if the headset is Qd disconnected during a call, the call will be put on audio-hold. reconnecting the Qd resumes the conversation.

  • Page 8: Configuring The Desk Phone Audio

    Jabra link 850. setting the clear dial tone will enable the Jabra link 850 to function correctly with your specific desk phone.

  • Page 9: Using The Jabra Link 850

    Jabra link 850. mute the headset mIcrOphONe to mute the headset microphone, tap the mute button on the Jabra link 850. the mute indicator will light up red to indicate the microphone has been muted.

  • Page 10: Connect An Additional Headset (Guest Headset)

    (Guest headset) an additional headset can be connected to the guest port on the Jabra link 850 to allow another person to join the conversation. when connected, the additional headset has the same functions as the primary headset.

  • Page 11: Advanced Settings

    Use a screwdriver to remove the removable cover. NOIse at wOrK swItch the noise at work switch on the base of the Jabra link 850 offers two settings for protection against potential risks, such as acoustic shock and noise exposure.

  • Page 12: Voice Clarity Switch

    Jabra link 850 has two settings for adjusting the sound quality of your voice. setting the switch to treble voice may increase the clarity of your voice for the listener.

  • Page 13: Faqs And Troubleshooting

    • ensure the target phone switch on the base of the Jabra link 850 is set to the correct telephone type (desk phone, or softphone). • ensure the clear dial tone switch on the base of the Jabra link 850 is set to the correct position. refer to ‘3 Configuring the desk phone audio’ .
