  • Page 2: Table Of Contents

    Contents Features ..............4 Programme Selection (Previous or Next Programme) ..... 19 Dear SHARP customer ........... 4 Introduction ............. 4 Programme Selection (Direct Access) ..19 Viewing Electronic Programme Guide (EPG) ..19 Preparation ............. 4 Recording via EPG Screen ....... 20 Important safety precautions ........
  • Page 3 Using a Conditional Access Module ..... 35 Viewing Conditional Access Menu (*) ....35 Confi guring Language Preferences ...... 36 Parental Control............ 36 Parental Settings Menu Operation (*) ....37 Timers ..............37 Setting Sleep Timer .......... 37 Setting Programme Timers ....... 37 Adding a Timer ..........
  • Page 4 SPECIAL NOTE FOR USERS IN THE U.K. The mains lead of this product is fi tted with a non-rewireable (moulded) plug incorporating a 5A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked and of the same rating as above, which is also indicated on the pin face of the plug, must be used.

  • Page 5: Features

    Dear SHARP customer Features • Remote controlled colour LCD TV. Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years • Fully integrated Terrestrial digital-cable TV (DVB-T of trouble-free operation of your product, please read...

  • Page 6: Important Safety Precautions

    Important safety precautions • Cleaning—Unplug the AC cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners. • Use a soft damp cloth to gently wipe the panel when it is dirty. To protect the panel, do not use a chemical cloth to clean it.

  • Page 7: Safety Precautions

    Safety Precautions Lightning In case of storm and lightning or when Please read the following recommended safety going on holiday, disconnect the power precautions carefully for your safety. cord from the wall outlet. Power Source Replacement Parts The TV set should be operated only from a 220-240 When replacement parts are required, make sure that V AC, 50 Hz outlet.

  • Page 8: Installation

    Installation Electrical device not in the hands of children Never let children use electrical device unsupervised. To prevent injury, this device must be securely Children can´t always recognize properly the attached to the wall in accordance with the installation possible dangers. Batteries / accumulators can be instructions when mounted to the wall (if the option life threatening when swallowed.

  • Page 9: Package Contents

    Package Contents Optional Accessory The listed optional accessories are available for this LCD colour TV. Please purchase them at your neerest shop. • Additional optional accessories may be available in the near future. When purchasing, please read the newest catalogue for compatibility and check availability.

  • Page 10: Environmental Information

    Environmental Information • This television is designed to consume less energy to save environment. You not only help to save the environment but also you can save money by reducing electricity bills thanks to the energy effi ciency feauture of this TV. To reduce energy consumption, you should take the following steps: •...

  • Page 11: Remote Control Buttons

    Remote Control Buttons Acti vate Portal mode (*) Play (in Media Browser mode) Programme recording Fast rewind (in Media Browser mode) No function Mono/Stereo - Dual I-II / Current Language / Play preview (in Media Browser mode) Image size Teletext / Mix Electronic Programme Guide Numeric buttons AV / Source...

  • Page 12: Lcd Tv And Operating Buttons

    LCD TV and Operating Buttons FRONT and REAR VIEW Control buttons VIEW Control Buttons 1. Standby/On button 2. TV/AV button 3. Programme Up/Down buttons 4. Volume Up/Down buttons N o t e : P r e s s “ ” a n d “...

  • Page 13: Viewing The Connections - Side Connectors

    RF Input connects to an aerial or cable antenna system. Note that if you use a decoder or a media recorder, you should connect the aerial cable through the device to the television with an appropriate antenna cable, as shown in the illustration in the following pages.

  • Page 14: Antenna Connection

    Note that ALL the data stored on the USB disk will Antenna Connection be lost and then the disk format will be converted to Aerial/Cable Connection FAT32 in such a case. USB Disk Connection • Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV.

  • Page 15: Side Hdmi Connection

    • For more information on recording programmes, Side HDMI Connection see sections “Instant Recording”, “Timeshifting”, You can use side HDMI input to connect a device that “Electronic Programme Guide”, “Recordings Library” has an HDMI connector to your TV. Use an appropriate or “Recording Timers”...

  • Page 16: Connecting To A Dvd Player

    Connecting to a DVD Player Using Side AV Connectors If you want to connect a DVD player to your LCD You can connect a range of optional equipment to your TV, you can use connectors of the TV set. DVD LCD TV using side connectors of the TV.

  • Page 17: Connecting To A Wired Network

    Connecting to a Wired Network For connecting to a wired LAN network, you should perform the following steps: • Connect broadband ISP connection ethernet cable to the ETHERNET INPUT of your modem. • Ensure that Nero Media Home software is installed to your PC.(for DLNA function). See Appendix H for more information on the installation process.

  • Page 18: Connecting To A Wireless Network (Optional)

    Connecting to a Wireless Network (Optional) IMPORTANT: “Veezy 100” USB dongle(sold separately) is required to use wireless network feature. To use your TV with your wireless network, you need a “Veezy 100” Wireless USB dongle. To make your modem’ s SSID visible, you should change your SSID settings via modem’s software. The TV cannot connect to the networks with hidden SSID.

  • Page 19: Remote Control Handset

    Note: When the TV is switched to standby mode, Remote Control Handset standby LED can blink to indicate that features such Inserting Batteries as Standby Search, Over Air Download or Timer is active. The LED can also blink when you switch on •...

  • Page 20: Analogue Teletext

    • With digital broadcasting (DVB), in addition to digital Viewing Main Menu teletext broadcasting together with the normal • Press the “ ”/“ ” button at the same time broadcasting, there are also channels with just digital to view main menu. In the Main menu select the sub- teletext broadcasting.

  • Page 21: Recording Via Epg Screen

    (RECORD): the TV will start to record the selected progamme. You can press again to stop the recording. —Timeline schedule— OK (Options): Views/records or sets timer for future programs. INFO (Event Details): Displays the programmes in detail. Green button: Programme schedule will be listed Red button (Prev Day): Displays the programmes Yellow button: Display EPG data in accordance with of previous day.

  • Page 22: Programme Options

    Programme Options In EPG menu, press the OK button to enter the “Event Options” menu. • Use “ ” or “ ” buttons to select your language and press OK button to set selected language and Select Channel continue. In EPG menu, using this option, you can switch to the •...

  • Page 23: Auto Tuning

    If you select CABLE option and press OK button on the remote control to continue, the following message will be displayed on the screen: To continue please select YES and press OK. To • After all the available stations are stored, Channel cancel operation, select NO and press OK.

  • Page 24: Auto Channel Scan Menu Operation

    Auto Channel Scan Menu Operation K_Band = VHF 5-12, UHF 21-69 Digital Cable Manual Search Digital Aerial: Searches and stores aerial DVB stations. In cable manual scan, you can enter frequency, modulation, symbol rate and network channel scan Digital Cable: Searches and stores cable DVB options.

  • Page 25: Analog Fine Tune

    If you start Digital Cable scan process, the following screen will be displayed. Select YES and press OK to continue or select NO and press OK button to cancel. Managing Stations: Channel List The TV sorts all stored stations in the Channel List. You can edit this channel list, set favourites or set active stations to be listed by using the Channel List You can select frequency ranges from this screen.

  • Page 26: Operating The Channel List

    Operating the Channel List ‘0...9’ replaces the highlighted character with the characters printed above the button one by one as the button is pressed. • When fi nished, press OK button to save. Press “MENU” to cancel. Locking a Channel You can press GREEN button to tag/untag all channels;...

  • Page 27: Button Functions

    Button Functions The information banner gives information on the channel selected and the programmes on it. The name • : Add/remove a station. of the channel is displayed, along with its channel • YELLOW : Tag/untag a channel. list number. •...

  • Page 28: Viewing Videos Via Usb

    Viewing Photos via USB When you select Photos from the main options, available image fi les will be fi ltered and listed on this screen. Select a device by using “ ” or “ ” button and press Viewing Videos via USB Jump (Numeric buttons): Jump to selected fi...

  • Page 29: Playing Music Via Usb

    Playing Music via USB Recordings Library When you select Music from the main options, In the main menu, use “ ” or “ ” buttons to select available audio fi les will be fi ltered and listed on this Media Browser. Highlight Recordings Library item by screen.

  • Page 30: Media Browser Settings

    (*) Similtaneous timeshifting recording’s duration Media Browser Settings depends on your connected USB disk’s file size and defined Max. Timeshift in the Recordings Confi guration menu. See the section, “Recordings” for more information on setting Max. Timeshift. Note: Switching to a different broadcast or source; and viewing main menu are not available during the timeshifting.

  • Page 31: Watching Recorded Programmes

    Slow Forward If you press (PAUSE) button while watching recorded programmes, slow forward feature will be available. You can use button to slow forward. Pressing button consecutively will change slow forwarding speed. Select Yes by using “ ” or “ ” / OK buttons to cancel instant recording.

  • Page 32: Step 3: Playing Shared Files Via Media Browser

    • If available networks are found, they will be listed • Wait until the IP address is shown on the screen. This on this screen. means that the connection is now established. • Select media server or network that you want to See the chapter Network Settings for detailed connect by using “...

  • Page 33: Connecting To Your Cell Phone Via Wifi (Optional)

    Connecting to your Cell Phone via WiFi • For 16:9 aspect ratio pictures that have been squeezed into a normal picture (4:3 aspect ratio), (Optional) use the 16:9 mode to restore the picture to its • If your cell phone has WiFi feature, you can connect original shape.

  • Page 34: Confi Guring Picture Settings

    Panoramic Picture Settings Menu Items This stretches the left and right sides of a normal Mode: For your viewing requirements, you can set picture (4:3 aspect ratio) to fi ll the screen, without the related mode option. Picture mode can be set to making the picture appear unnatural.

  • Page 35: Pc Picture Settings

    Note: HDMI True Black On/Off feature functions only Confi guring Sound Settings when the HDMI device output is set to RGB. Sound settings can be confi gured according to your Film mode: Films are recorded at a different number of personal preferences.

  • Page 36: Confi Guring Your Tv's Settings

    AVL: Automatic Volume Limiting (AVL) function sets the Using a Conditional Access sound to obtain fi xed output level between programmes Module (For instance, volume level of advertisements tend to be louder than programmes). IMPORTANT: Insert or remove the CI module only Headphone/Lineout: When you connect an external when the TV is SWITCHED OFF.

  • Page 37: Confi Guring Language Preferences

    Language Settings Confi guring Language Preferences You can operate the TV’s language settings using this menu. Press “MENU” button and select the Settings icon by using “ ” or “ ” button. Press OK button to view Settings menu. Use “ ” or “ ” button to highlight Language and press OK to continue: In the Settings menu, highlight the Language Settings item by pressing “...

  • Page 38: Parental Settings Menu Operation (*)

    Timers To view Timers menu, press MENU button and select Settings icon by using “ ” or “ ” button. Press OK button to view Settings menu. Use “ ” or “ ” button to highlight Timers and press OK to continue: Setting Sleep Timer This setting is used for setting the TV to turn off after a certain time.

  • Page 39: Recording Confi Guration

    Hard Disk Info Recording Confi guration To view the details about the USB disk, highlight Hard Select Recording Confi guration item in the Settings Disk Info by using “ ” or “ ” key and press OK. USB menu to confi gure recording settings. The following disk information will be displayed menu is displayed for recording confi...

  • Page 40: Confi Guring Network Settings

    • Select Sources in the Settings menu and press Confi guring Wired Network Settings in OK button. Advanced Mode • Press“ ” or “ ” buttons to select a source. After pressing GREEN button, Advanced mode will be available. While in Advanced Mode, press RED •...

  • Page 41: Information

    This means that the connection is now established. Confi guring Other Settings To disconnect from a wireless network, you should To view general confi guration preferences, select highlight Confi guration Status and press OK. Other Settings in the Settings menu and press OK button.

  • Page 42: Other Features

    You can manually search for new software by Other Features selecting Scan for upgrade. Displaying TV Information: Programme Number, Application version: Displays the current application Programme Name, Sound Indicator, time, teletext, version. channel type and resolution information is displayed Hard of Hearing: If the broadcaster enables any on the screen when a new programme is entered or special signal concerning the audio, you can set this “INFO”...

  • Page 43: Teletext

    Teletext Tips Teletext system transmits information such as news, Screen Care: Clean the screen with a dry, soft cloth. sports and weather on your TV. Note that is the signal Do not use abrasive solvents as they may damage the degrades, for example in poor/adverse weather coating layer of the TV screen.
  • Page 44 USB Is too Slow: If “USB is too slow” message is Invalid Domain: Ensure that you have already logged displayed on the screen while starting a recording, on to your PC with an authorized username/password try restarting the recording. If you still get the same and also ensure that your domain is active, prior to error, it is possible that your USB disk does not meet sharing any fi...

  • Page 45: Appendix A: Internet Portal

    Appendix A: INTERNET PORTAL You can access PORTAL mode using your TV. To do this, an active internet connection is required. Follow the steps on Connecting to a Wired/Wireless(optional) Network section to connect your TV to internet. After the connection is established, you can select or view portal options. Note: Broadband internet connection is required for high quality viewing.

  • Page 46: Appendix B: Pc Input Typical Display Modes

    Appendix B: PC Input Typical Appendix C: AV and HDMI Signal Compatibility (Input Signal Types) Display Modes The display has a maximum resolution of 1920 x 1080. The following table is an illustration of some of the Source Supported Signals Available typical video display modes.

  • Page 47: Appendix D: Supported Dvi Resolutions

    Appendix D: Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cables (not supplied), you can refer to the following resolution information. 24Hz 25Hz 30Hz 50Hz 60Hz 480i 480p 576i 576p 720p 1080i 1080p Appendix E: Supported File Formats for USB Mode File Format Remarks...

  • Page 48: Appendix F: Software Upgrade

    Appendix F: Software Upgrade • Your TV is capable of fi nding and updating new software upgrades over broadcast channels. • For broadcast channels search, TV looks the available channels stored in your settings. So before software upgrade search, it is advised to auto search and update all available channels. 1) Software upgrade search via user interface •...

  • Page 49: Appendix G: Hbbtv System

    Appendix G: HBBTV System HbbTV (Hybrid Broadcast Broadband TV) is a new industry standard that seamlessly combines TV services delivered via broadcast with services delivered via broadband and also enables access to Internet only services for consumers using connected TVs and set-top boxes. Services delivered through HbbTV include traditional broadcast TV channels, catch-up services, video-on-demand, EPG, interactive advertising, personalisation, voting, games, social networking and other multimedia applications.
  • Page 50 Figure a: ARD start bar application Figure b: ARD EPG application, broadcast video is shown on the left bottom, can be terminated by pressing 0. HbbTv applications use keys on the remote control to interact with the user. When an HbbTv applications is launched, the control of some keys are owned by the application.

  • Page 51: Appendix H: Nero Mediahome Installation

    Click the Next button. Appendix H: Nero MediaHome • The integrated serial is displayed. Installation • Please do not change displayed serial. This software is compatible with Windows XP and Windows 7. To install Nero MediaHome, please proceed as follows: Note: To use DLNA function, this software should be installed to your PC.
  • Page 52 Click the Next button. Click the Install button. • The Select Installation Type screen is displayed. • As soon as all prerequisites are installed, the Install button will change to a Next button. It is possible to choose between Typical, meaning standard installation, or Custom installation.
  • Page 53 Installation fi nishes. Run Nero MediaHome by pressing shortcut icon. The Help us to Enhance Nero Software screen is • Click ADD icon from LOCAL FOLDERS to add the displayed. In order to offer a better service, Nero folder you want to share with the network. Select is collecting anonymous data to determine which the folder that you want to share and click START features are used and what problems, if any, occur.

  • Page 54: Specifi Cations

    • -CVBS analogue output.(In HD channels, this will Specifi cations not be available TV BROADCASTING iii. AUDIO PAL/SECAM B/G D/K K’ I/I’ L/L’ • -MPEG-1 layer I/II, MPEG-2 layer II, AAC, HEAAC, RECEIVING CHANNELS AC3, E-AC3 VHF (BAND I/III) • -Sampling frequencies supported are 32, 44.1 &...

  • Page 55: Dimensional Drawings

    Dimensional Drawings English - 54 - A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 54 A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 54 28.02.2012 17:34:32 28.02.2012 17:34:32...

  • Page 56: End Of Life Disposal

    End of life disposal English - 55 - A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 55 A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 55 28.02.2012 17:35:18 28.02.2012 17:35:18...

  • Page 57: Installing The Stand

    Installing the Stand English - 56 - A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 56 A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 56 28.02.2012 17:35:19 28.02.2012 17:35:19...

  • Page 58: Uninstalling The Stand

    Uninstalling the Stand English - 57 - A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 57 A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 57 28.02.2012 17:35:19 28.02.2012 17:35:19...

  • Page 59: Screw Dimensions

    Screw Dimensions Model Item Number VESA Installation of the Screw Ø4 To the wall LC-40LE340E 400 x 400 (W x H) To the product English - 58 - A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 58 A02_[GB]_MB70_5112UK_DVBT_C_DLNA_HBBTV_MMH_WIFI_40942LED_GOLD11_10075763_50200948.indd 58 28.02.2012 17:36:49 28.02.2012 17:36:49...
