3.1.4 Removing the Amplifier board assembly

(See Fig.8, 9)

(1) Disconnect the card wire from LCD board assembly con-
nected to connector CN701
bly. (See Fig.8)
(2) Disconnect the connector wire from Amplifier board as-
sembly connected to connector

board assembly. (See Fig.8)

(3) Disconnect the connector wire from CD door switch con-
nected to connector CN906
bly. (See Fig.8)
(4) Disconnect the connector wire from Amplifier board as-
sembly connected to connector
assembly. (See Fig.9)
(5) Disconnect the connector wire from Amplifier board as-
sembly connected to connector
jack board assembly. (See Fig.9)
(6) Remove the three screws E attaching the Amplifier board
assembly. (See Fig.8)
1-8 (No.MB593)
of the Amplifier board assem-
CN901 of the CD servo
of the Amplifier board assem-
CN101 of the Tuner board
CN801 of the Headphone
CN701
CD servo board CN901
assembly
Fig.8
CN801
Fig.9
CN906 Amplifier board
assembly
E
E
