Goodman GCH95 Installation Instructions Manual

Goodman GCH95 Installation Instructions Manual

Gas-fired warm air furnace
Hide thumbs Also See for GCH95:
Table of Contents

Advertisement

Quick Links

G
(Type FSP CATEGORY IV Direct or Non Direct Vent Air Furnace)
ATTENTION INSTALLING PERSONNEL
As a professional installer you have an obligation to know the product better than the customer. This includes all safety
Prior to actual installation, thoroughly familiarize yourself with this Instruction Manual. Pay special attention to all safety
warnings. Often during installation or repair it is possible to place yourself in a position which is more hazardous than
Remember, it is your responsibility to install the product safely and to know it well enough to be able to instruct a customer
Safety is a matter of common sense...a matter of thinking before acting. Most dealers have a list of specific good safety
The precautions listed in this Installation Manual are intended as supplemental to existing practices. However, if there is
a direct conflict between existing practices and the content of this manual, the precautions listed here take precedence.
IO-299G
11/09
GMH95/GCH95/GCH9
-F
W
AS
IRED
I
NSTALLATION
Installer: Affix all manuals adjacent to the unit.
These furnaces comply with requirements
embodied in the American National Stan-
dard / National Standard of Canada ANSI
Z21.47·CSA-2.3 Gas Fired Central Fur-
naces.
RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION.
precautions and related items.
when the unit is in operation.
practices...follow them.
NOTE: Please contact your distributor or our website
for the applicable Specification Sheet referred to in this manual.
Goodman Manufacturing Company, L.P.
5151 San Felipe, Suite 500, Houston, TX 77056
www.goodmanmfg.com
2006-2009 Goodman Manufacturing Company, L.P.
©
A
F
ARM
IR
I
NSTRUCTIONS
in its safe use.
URNACE
®
C
US

Advertisement

Table of Contents
loading

Related Manuals for Goodman GCH95

Summary of Contents for Goodman GCH95

  • Page 1 GMH95/GCH95/GCH9 IRED URNACE NSTALLATION NSTRUCTIONS Installer: Affix all manuals adjacent to the unit. (Type FSP CATEGORY IV Direct or Non Direct Vent Air Furnace) These furnaces comply with requirements embodied in the American National Stan- ® dard / National Standard of Canada ANSI Z21.47·CSA-2.3 Gas Fired Central Fur-...
