JBL MA6002 Owner's Manual

Jbl marine audio power amplifier owner's manual ma6004, ma6002
Hide thumbs
Table of Contents

Advertisement

Quick Links

MA6004
MA6002
MARINE AUDIO
POWER AMPLIFIER
OWNER'S MANUAL
www.jbl.com
The Official Brand of Live Music.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MA6002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JBL MA6002

Summary of Contents for JBL MA6002

  • Page 1 MA6004 MA6002 MARINE AUDIO POWER AMPLIFIER OWNER’S MANUAL www.jbl.com The Official Brand of Live Music.
  • Page 2 If you do not have the necessary tools or experience, do not attempt the installation yourself. Instead, ask your authorized JBL car audio or marine audio dealer about professional installation. NOTE: This marine product is not intended for automotive applications.
  • Page 3 Figure 1. Terminal connection end plate for MA6004. Figure 2. Terminal connection end plate for MA6002. Remote Connection Speaker Connections Connect the amplifier’s Remote (REM) Refer to the application guides on the terminal to the source unit’s Remote Turn-...
  • Page 4 APPLICATIONS – MA6004 The MA6004 can be set up for stereo 4-channel, 3-channel or bridged 2-channel operation, as shown in Figures 4 through 6. NOTE: For simplicity, Figures 4 through 6 do not show power, remote and input connections. NOTE: Minimum speaker impedance for stereo operation is 2 ohms.
  • Page 5 APPLICATIONS – MA6002 Figure 7. MA6002 used in 2-channel (stereo) Left Right operation to drive a set of full-range speakers. Left Right Figure 8. MA6002 used in bridge mode to drive a subwoofer.

  • Page 6: Troubleshooting

    For subwoofers, choose the highest frequency that removes vocal information from the sound of the subwoofer. If using the MA6004 or MA6002 to drive a subwoofer(s), set the crossover mode to LP (low pass). TROUBLESHOOTING SETTING INPUT...

  • Page 7: Specifications

    • Dimensions (L x W x H): 13-1/4" x 10-1/4" x 2-3/16" (337mm x 261mm x 56mm) • Fuses: 25A x 2 MA6002 • 60W RMS x 2 channels at 4 ohms and ≤1% THD + N • Signal-to-noise ratio: 84dBA (reference 1W into 4 ohms) •...
  • Page 8 250 Crossways Park Drive Woodbury, NY 11797 USA www.jbl.com © 2006 Harman International Industries, Incorporated. All rights reserved. JBL and Harman International are trademarks of Harman International Industries, Incorporated, registered in the United States and/or other countries. Part No. MARINEAMPOM2/06 Declaration of Conformity...

This manual is also suitable for:

Ma6004

Table of Contents
