HI-FI FM TRANSMITTER
MS-100 series
INSTRUCTION MANUAL
CANADA
'' Operation of this device is subject to the following two conditions:
(1) This device may not cause interference and (2) this device must accept
any interference, including interference that may cause undesired operation
of the device.''
USA
"This device complies with Part 15 of the FCC rules. Operation of this device
is subject to the following two conditions:(1) this device may not cause
harmful interference; and (2) this device must accept any interference
received, including interference that may cause undesired operation.''
200903-100
DECADE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-100 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Decade MS-100 series

Summary of Contents for Decade MS-100 series

  • Page 1 HI-FI FM TRANSMITTER MS-100 series INSTRUCTION MANUAL CANADA ‘’ Operation of this device is subject to the following two conditions: (1) This device may not cause interference and (2) this device must accept any interference, including interference that may cause undesired operation of the device.’’...

  • Page 2: Table Of Contents

    TABLE OF CONTENT PAGE SECTION 1: GENERAL INFORMATION ..........A) Introduction ..............B) Description ..............C) Warranty ................. D) Warning................E) Technical specifications ..........SECTION 2: INSTALLATION ..............A) Introduction ..............B) Receiving inspection ............C) Connections ..............D) Location of the transmitter..........SECTION 3: OPERATION ...............

  • Page 3: Section 1: General Information

    All claims must be authorized by DECADE prior to shipment of a faulty unit for repairs, and a copy of the invoice must be included in the shipment. Shipping fees are assumed by the client and DECADE will pay for the return of the repaired unit.

  • Page 4: E) Technical Specifications

    (See length chart in the annex section). Location of the transmitter DECADE transmitters are designed for indoor or outdoor use in a dry environment, in temperatures ranging from 0 to 122°F (50°C). In order to obtain optimum performances, it is recommended to place them far from any electromagnetic noise sources (transformers, motors, etc.).

  • Page 5: Section 3: Operation

    SECTION 3 OPERATION Controls and indicators Input level is controlled by a potentiometer located on the front panel. A power indicator and over-modulation LEDs are also located on the front panel. Input and output connectors The MS-100 is equipped with an 1/4'' stereo female chassis phone jack that suits most audio setup combinations.

  • Page 6: C) Bits Switch Codes Table

    Bits switch codes table Freq MHz 88.1 88.3 88.5 88.7 88.9 89.1 89.3 89.5 89.7 89.9 90.1 90.3 90.5 90.7 90.9 91.1 91.3 91.5 91.7 91.9 92.1 92.3 92.5 92.7 92.9 93.1 93.3 93.5 93.7 93.9 94.1 94.3 94.5 94.7 94.9 95.1 95.3...
  • Page 7 Bits switch codes table Freq MHz 98.1 98.3 98.5 98.7 98.9 99.1 99.3 99.5 99.7 99.9 100.1 100.3 100.5 100.7 100.9 101.1 101.3 101.5 101.7 101.9 102.1 102.3 102.5 102.7 102.9 103.1 103.3 103.5 103.7 103.9 104.1 104.3 104.5 104.7 104.9 105.1 105.3...

  • Page 8: Section 5: Applications

    SECTION 5 APPLICATIONS Applications for DECADE transmitters are almost unlimited, but here are a few very popular ones. With DECADE transmitters, a whole new world opens up for hearing impaired people, and most of all for people demanding the best sound reproduction possible, regardless of the environment.
  • Page 9 TECHNICAL SPECIFICATIONS MS-100 RF SECTION MODULATION: FM, 75 kHz deviation FREQUENCY SELECTION: 88.1 to 107.5 MHz FREQUENCY PRECISION: .005% SPURIOUS REJECTION: 45 dB min. SPURIOUS REJECTION: 45 dB min. MAXIMUM POWER: 250µV/m @ 3 m (FCC Part 15 compliance for USA)(RSS-210 for Canada) : 1.0miliwatt (DOC RSS-123) (Canada only).
  • Page 10 6. ST: When activated, the stereo switch enables a digital circuitry that will produce stereo broadcasting. 7. FREQUENCY SELECT : Frequency programming switch 8. AUDIO INPUTS: The audio inputs signals. 9. The transmitting telescopic antenna. Decade Transmitters Inc, Sherbrooke, Quebec, Canada. All rights reserved 2009.

  • Page 11: Telescopic Antenna Length Adjustment

    Telescopic antenna length adjustment. In a manner to achieve good performances (more coverage distance) with your Decade FM transmitter, it is mandatory to adjust the length of the telescopic antenna to it’s associated frequency. Procedures: 1) Choose a free frequency (see Frequency selection page 5).
