- Page 1 HI-FI MONO/ STEREO FM TRANSMITTERS FM-800 / FM-850 INSTRUCTION MANUAL In conformity with FCC part 73 regulations (Verification only)
-
Page 2: Table Of Contents
B) Input and output connectors........C) Optimal input level ............ SECTION 5: MAINTENANCE AND PROGRAMMATION ....A) Maintenance.............. B) Frequency programmation ........C) RF power level programmation ........SECTION 6: APPLICATIONS............! FM-800 technical specifications......ANNEXES ! FM-850 technical specification...... -
Page 3: Section 1: General Informations
All claims must be authorized by DECADE prior to shipment of a faulty unit for repairs and a copy of the invoice must be included in the shipment. Shiping fees are assumed by... -
Page 4: D) Warning
FM receiver. Thus, some care should be taken in the use made out of these transmitters. DECADE transmitters inc. is not responsible for any loss of profit or laws violation during the utilisation of their transmitters. The FCC legislate the use of FM transmitters.A license or special permit from FCC is required for the operation of these units. -
Page 6: Section 2: Front & Back Panel Diagrams
DOC/MDC: CAN 1857 231 175 MODEL : FM-800 CAN 1857 231 113 S/N : 0000 MFG : DECADE TRANSMITTERS INC. SHERBROOKE (QUEBEC) CANADA http://www decade ca 50 ohms DECADE TRANSMITTERS INC. SHERBROOKE (QUEBEC) CANADA BALANCED UNBALANCED BALANCED UNBALANCED... -
Page 7: B) Front & Back Panel Description
6dB gain from 20Hz to 150Hz . balanced (600 Ohms),line level audio signal. Note: The left & right inputs are electronicaly mixed to produce a mono signal (FM-800). Bass boost LED: Indicates that the bass boost is activated. 18 20 Unbalanced inputs: Accept a high impedance unbalanced (10K Ohms),line level audio signal. -
Page 8: Section 3: Installation
Location of the transmitter and antenna DECADE transmitters are designed for indoor or outdoor use in a dry environment, in temperatures ranging from -50 to 50 °C. In order to obtain optimum performances, it is recommended to place them far from any electromagnetic noise source (transformers, motors, etc.). -
Page 9: Section 4: Operation
Input and output connectors FM-800 and FM-850 transmitters come with two sets of inputs: RIGHT and LEFT XLR3 balanced inputs and RIGHT and LEFT 1/4" unbalanced inputs, wich are the two most popular types of input connectors. -
Page 10: C) Optimal Input Level
The transmitting frequency is user programmable via a set of 4 decimal rotary switches (below the FREQUENCY digital readout) on the front panel (FM-800 & FM-850). While the transmitter is off (Power switch is off),determine the frequency of your choice and compose in a squential fashion(from far left switch to right), the number of your choosen FM frequency. -
Page 11: C) Rf Power Level Programmation
50 miliWatts, via a set of 3 decimal rotary switches (below the POWER digital readout) on the front panel (FM-800 & FM-850). determine the RF power of your choice and compose in a squential fashion(from far left switch to right), the number of your choosen RF power. -
Page 12: Section 6: Applications
SECTION 6 APPLICATIONS Applications for DECADE transmitters are subject to FCC regulations , where a license is required. These units comply for the new FCC LP10 class concerning non profit community FM broadcasting applications.Please consult your nearest FCC bureau for further details concerning license... - Page 13 DIMENSIONS: 19" x 11" x 1.75" (48 cm x 28 cm x 4.5 cm), 1 rackmount space WEIGHT: 12 lb (5.45kg) DECADE Transmitters reserves the right to make changes or improvements in manufacturing or design of its products, wich may affect specifications.
- Page 14 DIMENSIONS: 19" x 11" x 1.75" (48 cm x 28 cm x 4.5 cm), 1 rackmount space WEIGHT: 12 lb (5.45kg) DECADE Transmitters reserves the right to make changes or improvements in manufacturing or design of its products, wich may affect specifications.
