INSTALLATION AND OPERATING INSTRUCTIONS
HEAT RECIRCULATING GAS FIREPLACE
MODEL : STi – NG Natural Gas
STi – LP Propane
These gas appliances have been tested in accordance
with National Safety Standards, and have been certified
by Warnock Hersey for installation & operation as
described
in
these
Instructions in the United States.
Check with your local building code agency before you
begin your installation to ensure compliance with local
codes, including the need for "permits" and follow-up
inspections. If any problems are encountered regarding
code approvals, or if you need clarification of any of the
instructions contained here, contact:
ALPINE GAS FIREPLACES
#801-768-8411 / www.alpinefireplaces. com
WARNING:
instructions are not followed exactly, a fire or
explosion
may
damage , personal injury or loss of life.
Improper installation, adjustment, alteration,
service or maintenance can cause property
damage, personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
INSTALLER:
HOMEOWNER:
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
Alpine Gas Fireplaces
782 West State Street
Lehi, Utah 84043
7/00
STi Series
Installation
and
Operating
If the information in these
result
causing
PLEASE LEAVE THIS MANUAL WITH THE CUSTOMER
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
•
Do not touch any electrical switch; do
•
property
not use any phone in your building.
Immediately call your gas supplier from
•
a neighbor's phone. Follow the gas
supplier's instructions
If you cannot reach your gas supplier,
•
call the fire department.
INSTALLATION AND SERVICE MUST
BE PERFORMED BY A QUALIFIED
INSTALLER, SERVICE AGENCY OR THE
GAS SUPPLIER.
Tested by:
I T S
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Alpine STi – NG
Summary of Contents for Alpine STi – NG
- Page 1 “permits” and follow-up inspections. If any problems are encountered regarding code approvals, or if you need clarification of any of the instructions contained here, contact: ALPINE GAS FIREPLACES #801-768-8411 / www.alpinefireplaces. com WHAT TO DO IF YOU SMELL GAS: WARNING: If the information in these Do not try to light any appliance.
-
Page 2: Table Of Contents
The installation of this appliance should Fastening Face Pieces.....11 not be attempted by anyone not familiar with these Control Panel Access basic principles. Door Installation ......11 Remote Control (Optional)......11 Alpine STi Series Gas Fireplaces... -
Page 3: Safety Information
SAFETY INFORMATION Alpine STi Series Gas Fireplaces... -
Page 4: Before Start
MATERIAL SHOULD NOT BE PLACED ON OR 14) Never obstruct the flow of ventilation and combustion air to the fireplace. Always be sure NEAR THE APPLIANCE. the vent termination and air inlets remain clear and open. Alpine STi Series Gas Fireplaces... -
Page 5: System Specifications
16 of this manual before proceeding. than 1/2 psig. 1) When preparing an existing fireplace for an Alpine insert, ensure that the clearances in this manual are strictly adhered to. SYSTEM SPECIFICATIONS 2) Measure... -
Page 6: Preparing The Insert
If you are not familiar with gas piping or your local codes, do not attempt to install the gas piping. Note: Take special care not to damage the gasket on the appliance adapter. Alpine STi Series Gas Fireplaces... -
Page 7: Chimney Liners
CHIMNEY LINERS FLASHING DAMPER COMBUSTION AIR VENT LINER COMBUSTION AIR Alpine STi Series Gas Fireplaces... -
Page 8: Venting Requirements
30’. The minimum vertical length of the venting Intake Vent system is 8’. Horizontal termination of the vent is not approved. Two 3” chimney liners (#09400) are used with Alpine Band Clamp Appliance Adaptor STi series inserts. One liner will supply the combustion air to the fireplace, the other will vent the flue gases. -
Page 9: Positioning The Insert
The bottom trim panel will need to be installed to adjust the height. See “Trim Panel Installation”. Exhaust Vent Intake Vent Band Clamp Attach Fastening Screw Slide Adapter in Gently Figure 7 - Inserting the Fan Figure 5- Connecting the Appliance Adapter Alpine STi Series Gas Fireplaces... -
Page 10: Complete The Gas Connection
If the pilot is erratic, noisy, or yellow, call your positions to avoid combustion related problems. Alpine Fireplaces Dealer or another qualified service technician to make the adjustment. Note: A flame hitting directly on the bottom of a (Refer to figure 9A) log will burn dirty and cause excessive soot build up on the log and inside the firebox. -
Page 11: Derating The Burner
REMOTE CONTROL (OPTIONAL) TRIM AND DOOR INSTALLATION An Alpine Remote Control Kit (08501) may be Attach all trim panels before snugly tightening all of installed on this fireplace. The remote control kit the screws. -
Page 12: Operation & Maintenance
Note: If the pilot will not stay lit after several tries, turn the gas control knob to the “off” posi- Thermocouple IGNITOR WALL in located tion and call your Alpine dealer, your gas sup- BUTTON SWITCH on back of (PIEZO) inlet... -
Page 13: Fireplace Maintenance
SERVICE INFORMATION 13) In the event of a power outage, your Alpine 5) The appliance and the venting system must be fireplace my still be used as a source of radiant inspected before use, and at least annually, by a heat. -
Page 14: Replacing The Glass
In the event that you break your glass by impact, 4) Obtain the proper replacement for the broken log. purchase your replacement from an authorized Alpine 5) Replace the log set and close the door panel. dealer. See the replacement parts list for ordering information. -
Page 15: Normal Operating Sounds Of
Blower: Alpine uses a State of the Art blower to push the heated air throughout your home. It is not unusual for the fan to make a rushing air sound when it is on. This sound will increase and decrease in volume depending on the speed of setting of your blower controller. -
Page 16: Clearance Information
See Figure 15 & 16 Hearth Height 0” top of Hearth Depth 16” fireplace Minimum Hearth Width 48” side view of fireplace Fig. 15 - Mantel Clearance Fig. 14 - Insert Clearances Fig. 16 - Hearth Clearances Alpine STi Series Gas Fireplaces... -
Page 17: Instruction Plate
2) Turn off all electric power to the appliance 1) Push in the gas control knob slightly and if service is to be performed. turn clockwise to “OFF”. Do not force. DVI-700-1 DO NOT REMOVE THIS INSTRUCTION PLATE Alpine STi Series Gas Fireplaces... -
Page 18: Troubleshooting Guide
• Follow same steps for thermocouple Caution: Any safety screen or guard removed for servicing an appliance must be replaced prior to operating the appliance Alpine STi Series Gas Fireplaces... -
Page 19: Replacement Parts List
32135 33135 34135 782 West State Street Right 32140 33140 34140 Lehi, Utah 84043 B.F. 32145 33145 34145 (801) 768-8411 Doors STi 270 STi 310 STi 360 Valve 32065 33065 34065 Vent 32820 33820 34820 Alpine STi Series Gas Fireplaces... -
Page 20: Exploded View
EXPLODED VIEW Termination Cap (#09317) Venting Adapter (#09318) Band Clamp (#08530) 3" Aluminum Venting (#09400) Band Clamp (#08530) Appliance Adapter (#29700) Adapter Gasket (#29701) Alpine STi Series Gas Fireplaces... -
Page 21: Warranty Information
This lifetime war- ranty does not cover warping or rusting of the firebox. The damaged part or parts of the firebox will be repaired or replaced at Alpine's option. Parts which are returned to Alpine and are found damaged by burnout on inspection will be repaired, or replaced with a new part, without charge to the purchaser as long as the unit is still under warranty.
