NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.

4-4. BEZEL ASSEMBLY AND LCD PANEL

(Check the Sony Electronics Service Information
2-580-640-01 SCREW, +BVTP2 4X16
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
2-580-602-01 SCREW, +PSW M4X12
2-580-629-01 SCREW, +BVST 3X8
152
154
155
156
157
158
REF. NO. PART NO.
151 X-2189-662-1 BEZEL ASSEMBLY (42AM)
152 4-103-642-21 EMBLEM, SONY NO.8
153 1-826-891-11 LOUDSPEAKER (5.8X12.6CM)
154 3-879-107-01 GUIDE, LIGHT
155 A-1543-917-A H4K BOARD, MOUNTED
KDL-42V4100
NOTE: Les composants identifi es per un trame et
une marque ! sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specifi e.
151
153
159
160
161
DESCRIPTION [ASSEMBLY INCLUDES]
NOTE: The components identifi ed by a red outline and a
confi dential information. Specifi c instructions must be adhered to whenever
these components are repaired and/or replaced.
See Appendix A: Encryption Key Components in the back of this manual.
website for any additional service related issues for this model.)
162
REF. NO. PART NO.
[152] * 156 3-293-436-01
157 A-1543-916-A
158 1-826-891-21
159 3-290-805-21
160 1-802-691-11
161 N/A
162 N/A
KDL-42V4100
DESCRIPTION [ASSEMBLY INCLUDES]
PANEL, CLEAR (42)
H3E BOARD, MOUNTED
LOUDSPEAKER (5.8X12.6CM)
BAR, UNDER (ML)
LCD PANEL (42INCH FHD TFT) [161-162]
ETC-INVERTER MT BOARD (L)
ETC-INVERTER MT BOARD (R)
mark contain
73
