Pig-Tail AC Cord – Cord Dressing in Undercover
STEP1: AC Cord as Packaged From Vendor (installed)
KDL-42V4100
CAUTION
Be Careful to not scratch rear cover
or stand base with AC Plug Metal Tabs.
(Sharp Edge)
KDL-42V4100
LEGEND
SHEET CORE C (2-688-011-01)
QTY=10
LCD TAPE (2-688-062-01)
QTY=4
SLIDE CLAMP (2-650-770-11)
QTY=9
38
