Summary of Contents for BenQ Joybook S32 Series

  • Page 1 Joybook S32 Series User Manual Welcome...
  • Page 2 Copyright Joybook models covered by this manual Copyright 2007 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, This manual contains the information about the following transcribed, stored in a retrieval system or translated into any...

  • Page 3: Table Of Contents

    Capturing desktop images ..........38 Turning off your Joybook properly .........18 Changing the location of the media folder ....... 38 Using Windows Mobility Center ..........19 Using BenQ Surround.............. 38 Using your Joybook..............20 Using BIOS setup ................. 39 Using the touchpad..............20 When and how to use BIOS setup...........
  • Page 4 Battery and power ..............54 Connection ................56 System ..................57 Display ..................61 Cleaning and battery maintenance ..........63 Battery maintenance ..............63 Cleaning your Joybook .............63 Service and support..............64 BenQ Joybook Global Online Service ........64 Joybook Overseas Regional Warranty (ORW) online registration.................64 Table of Contents...

  • Page 5: Overview

    Overview About this book Connecting to Information about how to external display connect your Joybook to This book provides you the main information about various devices external display devices. components in your Joybook and demonstrates how to use them. The following are the major chapters of this book. Installing additional Information about how to add memory...

  • Page 6: Typographics

    Typographics The usage of notes, tips and warnings in this manual is specifically for different purposes, which are described as follows: Icon/ Item Meaning Symbol Warning Information mainly to prevent the damage to components, data, or personal injury caused by misuse and improper operation or behavior.

  • Page 7: Getting Started

    Getting started Getting your Joybook ready Depending on the model of your Joybook, the appearance may be different from the illustrations shown in this manual. for use Package contents 1. Installing the battery pack Before using your Joybook for the first time, please check if you Battery retainer A have all the items with you.

  • Page 8: Connecting The Power

    2. Connecting the power • Power systems and plug types may vary depending on your country/region. • When the battery is charging, the battery indicator appears in amber. When the battery is fully charged, the light goes off. Connect the power cord to the power adapter. •...
  • Page 9 Press the Power button to start up your Joybook, and then follow the on-screen instructions to complete the initial Windows Vista setup. • Your Joybook S32 Series works best with Windows Vista™ Home Basic, Windows Vista™ Home Premium, Windows Vista™ Business, or Windows Vista™ Ultimate. Installing...

  • Page 10: Expanding The Capabilities Of Your Joybook

    Expanding the capabilities of your Joybook Access local area network (LAN) by connecting a network cable Connect an external display device (such as a monitor or to the LAN port of your Joybook. projector) to the 15-pin D-sub video socket of your Joybook. Insert an ExpressCard/34 module or ExpressCard/54 module to Connect a telephone line to the modem port of your Joybook further expand the capabilities of your Joybook.
  • Page 11 Connect a microphone to the microphone input socket to Use the optical drive to access data on various kinds of discs and record sounds. enjoy movies or music. Insert a Memory Stick, Memory Stick Pro, SD, MMC, or xD Connect an earphone to the audio output socket to output memory card following the direction indicated on the card to sounds.
  • Page 12 Connect digital camcorders and high-speed storage equipment Output video images on your Joybook to a TV or A/V device to this IEEE 1394 (FireWire) Port. that has an S-Video Input socket by connecting it to the S-Video Out socket on your Joybook. Unless you intend to use the sound reproduction output of the built-in Joybook speakers, you will also need to separately connect the Joybook audio output socket to an appropriate...

  • Page 13: Touring Your Joybook

    QEye, (12) with one touch. For details, refer to "Using QShot" on page BenQ Surround Allows you to turn on or turn off SRS TruSurround XT in your Sound Manager with one touch. Keyboard Touchpad Refer to "Using the touchpad"...
  • Page 14 Indicators (10) Five-in-One memory card slot Refer to "Indicators" on page 16 for details. For a Memory Stick, Memory Stick Pro, SD, MMC, or xD memory card. Wireless button (11) LCD (Liquid Crystal Display) panel Press this button to activate/deactivate wireless devices like Bluetooth and WLAN.

  • Page 15: Left Side View

    Left side view Left-side components S-Video Out socket Allows the Joybook to output video signals to S- Power socket Video capable devices, such as a television set or For connecting AC power supply to power the VCR. Joybook and charge the battery. For details, refer to "S-Video output"...
  • Page 16 ExpressCard slot LAN (Local Area Network) port (RJ-45 This ExpressCard slot accepts two formats of the connector) standard ExpressCard modules: ExpressCard/34 Allows the Joybook to connect to a 10/100/ and ExpressCard/54. The ExpressCard/34 1000Mbps fast Ethernet 1000BASE-T network. module is characterized by its 34 mm width, and Please be careful to avoid plugging a RJ-11 phone the ExpressCard/54 module is characterized by its cable connector in the RJ-45 port.

  • Page 17: Right Side View

    Right side view (3) (4) Right-side components DVD/CD-RW Combo/DVD Super-Multi drive (available on selected models) The type of the optical drive varies by model, and the Modem port (RJ-11 connector) support of disc types depends on the optical drive that Accepts an analog telephone line for use with the comes with your Joybook.

  • Page 18: Rear View

    Rear view Optical drive ejection button Discs can be inserted/ejected by pressing this ejection button. Manual tray opening If you wish to open the disc tray when your Joybook power is off, or it can't be opened using the ejection button, insert a pointed object (like an opened paper clip) into the tray ejection hole next to the ejection button to release the disc tray.

  • Page 19: Bottom View

    Battery retainer B • For more information about adding additional Secures the battery in place. memory, the limit of maximum memory, or the types of BenQ certified memory modules for your Joybook, refer to "Installing additional memory" on page Touring your Joybook...

  • Page 20: Indicators

    Indicators (2) (3) Indicators Scroll Lock indicator Lights up in blue when the Scroll Lock is activated. Power button indicator • When the system is on, it lights up in blue. • When the system is in Standby, it lights up in Num Lock indicator amber.
  • Page 21 (6) (7) Indicators Wireless button indicator • When the wireless LAN is turned on, it lights up Battery indicator in blue. • When the system is on and the battery is in use, • When Bluetooth is turned on, it lights up in it lights up in blue.

  • Page 22: Getting Started With Windows Vista

    Getting started with Windows Vista Depending on your purchased model, your Joybook may come • How to locate, download, and install latest system device pre-installed with the latest Microsoft operating system: drivers. Windows Vista™ Home Basic, Windows Vista™ Home • How to setup scheduled events for system maintenance. Premium, Windows Vista™...

  • Page 23: Using Windows Mobility Center

    Using Windows Mobility 4. On the Advanced settings tab, double-click Power buttons and lid to expand this category. Center 5. Then, double-click Start menu power button to expand this item. Windows Mobility Center is a convenient location where you 6. To specify the action to take when you press the Start menu can quickly access your Joybook's settings, such as brightness, power button, click On battery or Plugged in, and then select volume, battery status, and wireless network, etc.

  • Page 24: Using Your Joybook

    Using your Joybook Using the touchpad Component Function Touchpad Moves the pointer, selects or activates items on the screen. Left touchpad Equivalent to the left button of button an optional external mouse. Right touchpad Equivalent to the right button button of an optional external mouse.

  • Page 25: Using The Wireless Button

    Using the Wireless button Function Left Right Touchpad The Wireless button allows you to turn on or turn off the touchpad touchpad wireless radio. By default, the button is "OFF" when your button button Joybook starts up. Select Click once. Tap once.

  • Page 26: Using The Keyboard

    Using the keyboard Function hotkeys You can use the function hotkeys to access commonly used functions or make quick settings. To use the hotkeys, press and hold the <Fn> (Function) key at the lower left corner of the keyboard, and then press the desired hotkey. The appearance of the keyboard legend may vary depending on the country/region of your purchase.
  • Page 27 Function hotkey Description Function hotkey Description <Fn> + <F1> Opens function hotkeys online help. <Fn> + <F8> Decreases volume. <Fn> + <F2> Puts your Joybook into sleep mode. <Fn> + <F9> Increases volume. <Fn> + <F3> Switches display between the screen <Fn>...

  • Page 28: Windows Keys And Lock Keys

    Windows keys and lock keys Using your Joybook...
  • Page 29 Function hotkey Description Function hotkey Description Windows key Activates the Run dialog box. Functionally equivalent to clicking the Start button on the Windows desktop. Press and hold the Windows key, and Num Lk Activates or deactivates the numeric + Tab then press Tab to switch between keypad integrated in the keyboard windows.

  • Page 30: Using Built-In Wireless Connectivity (Available On Selected Models)

    Using built-in wireless connectivity (available on selected models) With the built-in wireless connectivity of your Joybook, you can 2. Press the Wireless button on your Joybook to enable access other wireless network enabled devices (such as Access the WLAN. Point network stations, Notebook computers, Personal Digital Assistants, or digital projectors) wirelessly without the constraints of network cables.
  • Page 31 There are other ways for the Joybook to connect with a network. 6. Click Wireless in the Show list. A list of available wireless "LAN (Local Area Network) port (RJ-45 connector)" networks will be displayed. "Modem port (RJ-11 connector)". 7. Click a network and then click Connect. If security authentication is not required by the network you are using, there will be a successful message showing that you have connected to the network.

  • Page 32: Using Bluetooth (Available On Selected Models)

    Using Bluetooth (available on selected models) • The maximum effective range of connection between your The Bluetooth function allows you to get connected to various Joybook and the Bluetooth device is 10 meters. devices and services that support Bluetooth transmission. You can connect wirelessly without the need for data cables when 4.
  • Page 33 5. If your Bluetooth device is already turned on and 6. Please wait while Windows is searching for available discoverable, place a check mark in the My device is set up Bluetooth devices. and ready to be found checkbox, and then click Next. Using your Joybook...
  • Page 34 7. Select the Bluetooth device that you want to add, and then 8. Refer to the documentation that came with your Bluetooth click Next. device to determine if there is a pre-defined passkey. If not, you can select Choose a passkey for me. Using your Joybook...
  • Page 35 9. Windows will generate a passkey. When you are prompted to 10.The Bluetooth device is now connected to your Joybook. enter a passkey on your Bluetooth device, follow the on- Click Finish to complete. screen instructions to enter the passkey. Using your Joybook...

  • Page 36: Sending A File To A Bluetooth Device

    Sending a file to a Bluetooth device 2. Click Browse to select the location to which you want to send the file, and then click Next to continue. If your Bluetooth device is capable of sending and receiving data, such as a mobile handset, you can use the Bluetooth connectivity to transfer data wirelessly between your Bluetooth device and Joybook.
  • Page 37 3. The file will be sent to the location you specified. 4. Click Finish to complete. The example shown above is specifically for connecting to a mobile handset. To connect to other types of Bluetooth devices, refer to the online Help for details. Using your Joybook...

  • Page 38: Using Qmedia Bar

    Using QMedia Bar Introduction to QMedia Bar QMedia Bar integrates a number of software applications to enhance the multimedia experience on your Joybook. Click on the small triangle button and a rotating button bar will display. Setting up QMedia Bar Right-click on QMedia Bar and a menu will display on it.

  • Page 39: Using Qeye

    Using QEye Main screen Your Joybook comes with a 1.3 megapixel built-in camera (QEye) on the inside top of the lid, above the screen. With QEye, The Main screen in any module contains the following icons you can capture images, record videos, and also hold a video and menus.

  • Page 40: Capturing Images Or Recording Videos

    Capturing images or recording videos Settings Adjusts the capture 1. Launch 'WebCam Companion' by following one of the ways settings, such as file described below. format, resolution, • Click Start, All Programs, the WebCam Companion audio devices, video folder, and then click WebCam Companion. devices, etc.

  • Page 41: Monitoring

    Monitoring You can also click the Start Face Tracking icon in 'Magic-i' The Monitor modules detects any movement that is visible to to keep your face tracked and in the center of the video frame. QEye and records it automatically. An e-mail or text message Using QShot alert will be sent at the same time.

  • Page 42: Capturing Desktop Images

    Using BenQ Surround Capturing desktop images 1. Place your cursor on the desktop. BenQ Surround is a quick access button on your Joybook 2. Press the QShot button. that allows you to turn on or turn off SRS TruSurround XT in 3.

  • Page 43: Using Bios Setup

    To run BIOS setup, press the <F2> key immediately when the features. BenQ logo appears on the screen during system startup. The logo shows up on the screen for only a few seconds, so you must BIOS settings are specific to your Joybook hardware. Do NOT press the <F2>...

  • Page 44: Main Menu

    Left and right Selects a menu title. are 3 items included as follows. arrow keys (, a. Quiet Boot: This item controls the display of BenQ logo during system boot. Up and down Selects an item or option. arrow keys ( , ) •...

  • Page 45: Security Menu

    • To select a boot device manually, press the <F9> key when the The Security menu contains the security settings, which BenQ logo appears on the screen during system startup. The safeguard your system against unauthorized use. Boot Menu will appear. Use the up and down arrow keys ( , ) to select a boot device, and then press <Enter>...

  • Page 46: Exit Menu

    Exit menu The Exit menu displays ways of exiting BIOS setup. After finished with your settings, you must save and exit so that the new settings can take effect. • Exit Saving Changes: saves the changes you have made and exits BIOS setup.

  • Page 47: Recovering Your System

    Recovering your system Backing up your files: System recovery is a data destructive process. You should backup all data and applications prior to restoring. Please make • Make sure your system is connected to AC Power before sure your system is connected to AC Power before continuing. performing the task.

  • Page 48: Recovering Your Backup Files

    Follow the on-screen instructions to complete the task. settings: The backup creates a "BenQ user" folder on the D: drive, which can be burnt to disk and archived independently of QDataTrove. This process will ERASE ALL data on your system drive C: and Recovering your backup files: restore the system to default factory configuration.

  • Page 49: Recovering Your System Using The Supplied Discs

    The availability of the supplied discs may vary depending on your purchased model. 1. Turn on your Joybook. 2. Press the <F9> key when the BenQ logo appears on the screen during system startup. A Boot Menu screen appears. 3. Insert the supplied "Operating System Disc" into your optical drive.

  • Page 50: Step 2: Reinstalling Drivers And Applications

    Protecting your Joybook from Step 2: Reinstalling drivers and applications viruses and other security 1. Insert the "Drivers and Applications" disc into your optical threats drive. The main screen will be displayed automatically. Your Joybook comes with an Anti-Virus CD, so please be sure to If the AutoPlay feature of your optical drive is disabled in your install the anti-virus software from the disc supplied.

  • Page 51: Connecting To External Display Devices

    Connecting to external display devices Connecting to a VGA display device You can output your Joybook's video signal to an external display device, such as a projector or monitor. Once the VGA cable is connected properly, simultaneous display will be available on your Joybook and the external display device automatically. Pressing the <Fn>...

  • Page 52: S-Video Output

    S-Video output The S-Video Out socket on your Joybook allows you to output display signals to S-Video capable devices, such as a television set or VCR for viewing or recording. When you output display signals on your Joybook to an S-Video capable device, such as a TV set, the resolution on your Joybook will be adjusted automatically.

  • Page 53: Adjusting Video Standards Manually

    Adjusting video standards manually 2. Click Display Settings, and then select the Television tab. The graphics card determines the signal format from the Regional and Language Options selections in Control Panel. However, when you travel to another country/region, you might need to re-adjust TV format selections manually.
  • Page 54 3. Select the appropriate standard from the drop-down list next to Video Standard. The required settings of Video Standard may vary by country/ region. For details about which standard is used in your country/region, check with your local authorities. Connecting to external display devices...

  • Page 55: Installing Additional Memory

    Before you upgrade or replace memory, please adapter and turn over your Joybook. check on the BenQ web site to determine the module which can be used, or contact BenQ distributor or customer service center. It is recommended that you take your Joybook to the BenQ distributor or customer service center for the upgrade or memory replacement.
  • Page 56 5. Open the cover. 3. Slide the battery retainer B to the unlock position (1) and, while still holding the retainer, pull the battery away from its compartment (2). • Ground yourself to your Joybook with professional grounding equipment like an anti-static wristband, or touch the metal surface on the inside of your Joybook to discharge any static Battery retainer B electricity.
  • Page 57 7. Gently push the free edge downwards until the module locks 9. Use a screwdriver to secure it with the screws. into place. 10.Place the battery on its original position (1) and then slide If the memory module is not installed properly, your Joybook may not boot properly.

  • Page 58: Faq And Troubleshooting

    Joybook, along with basic troubleshooting steps. If IEEE 802.11a/b/g is a technical specification issued by the you are not able to resolve the issue, contact a nearest BenQ Institute of Electrical and Electronics Engineers (IEEE) that service center for assistance immediately.
  • Page 59 Joybook, or • It is possible that certain operating system files are the AC power cord may be defective. Consult your BenQ dealer damaged or missing. If so, you may need to back up all for help and maintenance.

  • Page 60: Connection

    Why does the battery on my Joybook seem to last shorter and 4. Select the appropriate mode according to the settings of your shorter? LAN service from the Value drop-down menu on the right, and then click OK. It is normal for Lithium-ion (Li-ion) batteries to decline in •...

  • Page 61: System

    • Remove programs from the Startup folder. Removing How do I update the driver? programs from the Startup folder also helps prevent programs Please visit BenQ Online Service and Support from running when Windows starts up. To do so, follow the (http://Support.BenQ.com) to search for driver updates.
  • Page 62 6. Close the open windows to return to the desktop. 6. Restart your Joybook. It may take a long time to complete. 7. Open the folder created in Step 1. To run Disk Defragmentation in Windows Vista: 8. Select the Edit and Paste commands in the folder window. 1.
  • Page 63 Why does the keyboard and/or palm rest get warm? • An earphone or external speakers may have been connected to the audio output socket, turning off the Joybook's built-in Typically, the Joybook tends to be warm slightly. The location of speakers automatically.
  • Page 64 Why is the hard disk capacity displayed by the OS different from I hear noise when connecting an earphone to the Joybook. its nominated capacity? Verify the following: You may have discovered that the capacity of a 10GB hard disk •...

  • Page 65: Display

    Why does my Joybook seem to turn off itself after a certain • The screen's brightness may have been set too low. Use period of inactivity? the <Fn> + <F5> hotkey combination to increase the brightness. This is the default setting of the Joybook to conserve battery •...
  • Page 66 I do if this happens? If your Joybook cannot display images at the default resolution, please visit the BenQ web site to download and update the latest Joybook display drivers. Contact your BenQ dealer if you encounter the following situations: •...

  • Page 67: Cleaning And Battery Maintenance

    Cleaning and battery maintenance Battery maintenance 1. Fully charge/discharge battery up to 4 cycles before achieving 11.Use of improper batteries, or attempting to disassemble a full capacity of a new battery. battery, may result in explosions. Follow vendor 2. Fully discharge and then fully charge the battery every two to recommendations in using batteries of the identical or three weeks for battery conditions.

  • Page 68: Service And Support

    • Knowledge Base: Contains answers to frequently asked questions about the Joybook as well as additional tips. • Contact Us: Here you can directly contact BenQ Customer Service for answers and advice to your questions. You can also obtain the information about the BenQ service stations in your country.

  • Page 69: Appendix

    1. Keep this manual in a safe place for easy reference when attempt to repair it yourself. Should it become damaged, needed. please contact an authorized BenQ distributor or service 2. Make sure you follow all instructions and warnings related to center.

  • Page 70: Safety Information About The Power Adapter

    Safety information about the Disposal of Waste Electrical power adapter and Electronic Equipment by users in private households in • Use only the power adapter supplied with your Joybook. Use of another type of power adapter will result in malfunction and/ the European Union.

  • Page 71: Declaration Of Conformity

    IEC 60950-1 and/or EN60950-1, First Edition BenQ EN 301489-1 V1.4.1:2002 Model designation(s)/Model no(s): EN 301489-17 V1.2.1:2002 Joybook S32 Series; DHT300 ETSI EN 300328 (V1.5.1:2004-03) ETSI EN 301893 (V1.2.3:2003-08) Company name, address, telephone & fax no. Name: BenQ Europe B.V. Ekkersrijt 4130, 5692 DC Son Address:...

  • Page 72: Safety Instructions For Poland, Romania, Slovenia, Bulgaria, Latvia, And Croatia

    Safety instructions for Poland, Romania, Slovenia, Bulgaria, Latvia, and Croatia Polski România 1. Należy upewnić się, że zastosowano się do wszystkich 1. Asiguraţi-vă că respectaţi toate instrucţiunile şi instrukcji i ostrzeżeń dotyczących systemu. avertismentele privitoare la sistem. 2. Nie należy umieszczać komputera w miejscach 2.
  • Page 73 Български Slovensko 1. Следвайте всички инструкции и предупреждения 1. Glede sistema sledite navodilom in opozorilom. относно системата. 2. Raèunalnika ne postavljajte na mesta z moènim magnetnim 2. Не слагайте компютъра на място със силно магнитно poljem. поле. 3. V primeru nepravilne namestitve akumulatorja obstaja 3.
  • Page 74 Latviski Hrvatski 1. Sekojiet visām sistēmai atbilstošajām norādēm un 1. Pridržavajte se svih uputa i upozorenja u vezi sa sustavom. brīdinājumiem. 2. Ne postavljajte računalo u područje jakih magnetskih polja. 2. Nenovietojiet datoru tuvu spēcīgiem magnētiskajiem 3. Nepravilna zamjena baterije izazvat će opasnost od laukiem.
