RLH Industries RLH 16 T1 User Manual

USER GUIDE
RLH 16 T1 Over Gigabit Ethernet
Fiber Optic Multiplexer System
IP transport of 16 T1/E1, 5 GE and 1 SFP GE optical
over a single fiber

Introduction

As a cost effective solution for the traditional telecom services
migrating to IP packet networking technology, the 16 Channel
T1 over Ethernet (T1 over IP) adopts the innovative TDM over IP
technology, with IP circuit emulation that supports transporting
up to 16 T1/E1s, 5 GE electrical ports and 1 SFP GE optical
port. The GE uplink ports and user data ports are IEEE 802.3
compliant, 10/100/1000M auto-sensing Ethernet ports. This is
ideal for transporting T1/E1 over GE copper or fiber.
State-of-the-art design provides accurate timing signals and
data bit stream reconstruction. Predefined system parameter
profiles may be applied according to different application
requirements. This system is also suitable for connecting to
wireless equipment for rapid deployment of T1/E1 services.

Key Features

• 16 channels of E1/T1 over 1 Ethernet
• 5 GE TP ports and 1 GE optical port, all 6 GE ports may serve
as network uplinks or users ports
• I IEEE 8802.3, 802.1Q, 802.1P compliant
• Supports SNMP V1/V2 network management
• Supports Ethernet spanning tree protocol which enables protec-
tion in ring and mesh topology with fast recovery
• Supports cascade concatenation for more than 16 T1 ports
• Supports VLAN on Ethernet and T1 ports
• Dual redundant power supplies
• EIA 1RU 19" rack mount or shelf mountable
• Covered by our Exclusive Unconditional Lifetime Warranty
RLH Industries, Inc.
RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 •
RLH-TG- 2C-1 T1 over Gigabit Ethernet
T1/E1
Contents
Introduction ____________________________
General Safety Practices ___________________
Special Handling Requirements
Acronyms ______________________________
Applications ____________________________
Installation _____________________________
LED Indicators __________________________
DIP Switches ___________________________
T1 Connections __________________________
Ordering Information _____________________
Troubleshooting __________________________
Specifications ___________________________
Warranty _____________________________
Technical Support _______________________
Specifications subject to change without notice.
www.fiberopticlink.com
The leader in The leader in
rugged fiber optic
rugged fiber optic
technology.
technology.
 Unconditional
 Unconditional
Lifetime Warranty Lifetime Warranty
2010D-1001
1
2
______________ 2
3
4
5
6
7
7
8
9
10
11
11
Page 1
