RLH Industries RLH-PM-3 Series User Manual

USER GUIDE
RLH Analog Phone & Data
Mux Over Fiber System
16 CHANNEL VOICE WITH DATA
OVER FIBER OPTICS
Introduction
The RLH 16 channel RLH Analog Phone & Data Mux Over Fiber
System provides a comprehensive method of multiplexing
analog phone (POTS) channels over a single pair of multimode
or single mode fibers in dual fiber models, or a single fiber in bi-
directional fiber models.
system solves the problem of adding POTS lines when available
fiber is limited, reduces equipment space, and lowers overall
equipment costs.
The system also includes four 10/100M Ethernet ports for LAN
interconnection, and two channels of RS-232 or RS-422/485
data ports. 2/4-wire E&M/Analog Data/Audio ports are available
options. All ports operate simultaneously over the fiber optic
cable, and may be used with leased lines to build up private
networks and private telephone networks.
Key Features
• Exclusive Unconditional Lifetime Warranty.
• Low cost solution for delivering analog POTS lines over fiber
• Four integrated 10/100 Base-T Ethernet ports for LAN, VOIP,
video over IP or other applications.
• 16 FXO/CO ports for connection to PABX or PSTN
• 16 FXS/Sub ports for connection of individual analog
phones or faxes.
• Ethernet switch is full/duplex, auto negotiation
• Each voice channel is connected to a single RJ-45, using pins 4
& 5, and RJ-11 adapter cables are provided.
• Supports call forwarding.
• Available with ST, SC or FC connectors.
• Optional ring down circuit over analog phone is available.
• Includes one RS-232 or RS-422/485 port.
• Available in Single or Multi-mode fiber, up to 120km fiber range.
• EIA 19" 1RU rack mountable.
• Convenient front panel LED's monitor activity of analog phone
and E&M channels.
• Ethernet interface is AUTO-MDIX (auto crossover adapting)
• Redundant power supply may be 12, 24 or 48VDC and/or
115/240VAC local power
• 0˚C ~ 50˚C (0˚F ~ 122˚F) operating temperature rated.
RLH Industries, Inc.
This compact single rack unit (1RU)
(adapters included).
RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com
Contents
Introduction _________________________
General Safety Practices _________________
Acronyms ____________________________
Front Panel __________________________
Back Panel __________________________
Installation ___________________________
Application Diagram ____________________
Ordering Information ___________________
Specifications ________________________
Technical Support ____________________
Warranty __________________________
Compliance Information
The RLH POTS Fiber Mux System is compliant with the
following industry standards:
• IEEE-80, IEEE-367
• IEEE-1590, IEEE-1615
• Motorola R56
• BR 876-310-100 BT (Telcordia)
• Bellcore SR-3966
• IEEE 802.3, IEEE 802.1Q (VLAN)
• ITU-T V.24
Specifications subject to change without notice.
The leader in
rugged fiber optic
technology.
 Unconditional
Lifetime Warranty
2012A-0504
1
2
3
3
4
7
7
9
10
11
11
Page 1
